3. Place the end of the
spanner wrench on the
nut and then turn
the wheel wrench
counterclockwise to
loosen the nut
holding the tire to
the carrier.
4. Pull off the tire retainer plate and set it aside.
Remove the spare tire from the wheel carrier.
5. Put the spare tire near the at tire.The tools you’ll be using to nish changing a at tire are
the following:
A. Jack
B. Wheel Blocks
C. Jack HandleD. Jack Handle
Extension
E. Wheel Wrench
F. Ratchet
Before proceeding, be sure to set the wheel blocks at
the appropriate tires as shown previously.
5-76

5. Turn the ratchet counterclockwise to loosen the
wheel nuts.
6. Remove the three wheel nuts holding the spare tire
onto the tire carrier.
7. Pull off and gently lower the spare tire to the
ground. Set it next to the at tire.The tools you’ll be using to nish changing a at tire
include the following:
A. Jack
B. Wheel Blocks
C. Jack HandleD. Jack Handle
Extension
E. Wheel Wrench
F. Ratchet
Before proceeding, be sure to set the wheel blocks at
the appropriate tires as shown previously.
5-78

Removing the Flat Tire and
Installing the Spare Tire
1. To remove the center
cap, place the at end
of the wheel wrench
in the slot on the wheel
and gently pry the
center cap out.
2. Slide the ratchet onto the wheel wrench with the
DOWN mark facing you.
3. Turn the ratchet counterclockwise to loosen the
wheel nuts. Don’t remove them yet.
You will now need to jack the vehicle up using the
instructions following.
5-79

5. Turn the ratchet clockwise to raise the jack head to
the lifting point.
Front Flat Tire:Position
the jack under the vehicle
on the frame behind
the at tire where the
frame sections overlap.
See the graphic following
for an approximate
measurement of the jack
location on the frame.
Front Flat Tire
X = 28.5 inches (72.0 cm)
5-81

Rear Flat Tire:Place the
jack under the curved rear
axle pad. Make sure
the jack head is positioned
so that the rear axle
pad is resting securely on
the jack head.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get
under a vehicle when it is supported only
by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
6. Turn the ratchet clockwise to raise the vehicle.
Raise the vehicle far enough off the ground so
there is enough room for the spare tire to clear
the ground. Rear Flat Tire
5-82

9. After mounting the
spare, put the wheel
nuts back on with
the rounded end of
the nuts toward
the wheel.
10. Tighten each wheel nut by hand. Then use the
ratchet/wheel wrench to tighten the nuts, with
the UP mark facing you, clockwise until the wheel is
held against the hub.
You will not be tightening the nuts fully yet.
5-84

11. Lower the vehicle by turning the ratchet
counterclockwise, with the DOWN mark facing you.
Then lower the jack completely.
{CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to come loose
and even come off. This could lead to an
accident. Be sure to use the correct wheel
nuts. If you have to replace them, be sure to
get new GM original equipment wheel nuts.
Stop somewhere as soon as you can and have
the nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-112for wheel nut
torque specication.
Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-112for the wheel nut
torque specication. Front Position
Rear Position
5-85

12. Tighten the nuts rmly
in a crisscross
sequence as shown by
turning the ratchet
clockwise, with the UP
mark facing you.
13. When you install the wheel and tire, you must
also reinstall the center cap. Place the cap on
the wheel and tap it into place until it sits ush
with the wheel.
Storing a Flat or Spare Tire
and Tools
Inside-Mounted Tire
Use the art and text following to help you store the
spare or at tire back into its proper spot when you
are done.
Store the at or spare tire back inside the vehicle on the
spare tire mount.A. Spare or Flat Tire
B. Receiver Extension
(If Equipped)C. Tire Retainer Plate
D. Nut
E. Wheel Blocks
5-86

5. Slide the license plate holder onto the spare or at
tire. Secure it from the back of the tire carrier with
the wing nut.
If you choose not to reinstall the spare or at tire on
the vehicle, you will still need to reinstall the
license plate holder on the spare tire carrier.
Storing the Tools
SUV
Follow these instructions to store the jack and tools:
1. Lower the jack completely.
2. Place the jack in the mounting bracket.
3. Tighten the wingnut (A)
until the jack is
securely fastened.
4. Place the tools in the bag.
5. Slide the securing clip over the bag and secure the
bag to the oor by tightening the wingnut (B) to the
stud coming out of the oor.
In order to reduce the potential of the jack
squeaking or rattling, you will need to preload the
jack so it ts tightly in the mounting bracket.
To do this, turn the u-hook/clevis at the top of the
jack clockwise until the jack is held tight in the
mounting bracket.
5-88

SUT
Follow these instructions to store the jack and tools:
1. Lower the jack completely.
2. Place the jack (B) in the mounting bracket in the
rear cargo compartment.3. Tighten the wingnut (C) until the jack is
securely fastened.
In order to reduce the potential of the jack
squeaking or rattling, you will need to preload the
jack so it ts tightly in the mounting bracket.
To do this, turn the u-hook/clevis at the top of the
jack clockwise until the jack is held tight in the
mounting bracket.
4. Place the wheel blocks (E) onto the mounting stud
and tighten the wingnut (D) to secure them.
5. Place the tools in the tool bag (A), roll the bag
together tightly and neatly and then close it with
the hook and loop fasteners.
If you do not roll the tool bag tightly and neatly, you
will have trouble getting it back into the storage
retention clips in the next step.
