HUMMER H2 2008 Owners Manual

Notice:The wrong wheel can also cause problems
with bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper height,
vehicle ground clearance, and tire or tire chain
clearance to the body and chassis.
SeeChanging a Flat Tire on page 5-78for more
information.
Used Replacement Wheels
{CAUTION:
Putting a used wheel on your vehicle is
dangerous. You cannot know how it has been
used or how far it has been driven. It could fail
suddenly and cause a crash. If you have to
replace a wheel, use a new GM original
equipment wheel.
Tire Chains
Notice:Use tire chains only where legal and only
when you must. Use only SAE Class U-type
chains that are the proper size for your tires. Install
them on the rear axle tires and tighten them as
tightly as possible with the ends securely fastened.
Drive slowly and follow the chain manufacturer’s
instructions. If you can hear the chains contacting
your vehicle, stop and retighten them. If the contact
continues, slow down until it stops. Driving too
fast or spinning the wheels with chains on will
damage your vehicle.
5-75

Accessory Inator
Your vehicle may have an accessory inator system.
You can inate things like basketballs and bicycle tires.
You can also use it to bring your tire pressure up to
the proper pressure. The engine must be running and
the gearshift lever must be in PARK (P) for the inator
to operate.
The accessory inator is
located in the rear
compartment on the
passenger’s side of
the vehicle.The accessory inator kit
includes a hose and three
nozzle adapters.
To use the accessory inator, do the following:
1. Attach the appropriate nozzle adapter to the end of
the hose.
2. Attach that end of the hose to the object you wish
to inate.
5-76

3. Remove the dust cover and attach the hose to
the outlet.
The accessory inator hose also has a built-in air
pressure gage. As soon as you start to inate
an object it will automatically read the current
pressure.
4. Press and release the switch to turn the accessory
inator on. The indicator light will remain on while
the inator is running.When you are nished using the inator, press and
release the switch to turn it off. Place the inator kit tools
and the hose back in the pouch.
If your vehicle is equipped with the air suspension
system, load leveling will not function with the inator
hose attached to the inator outlet.
{CAUTION:
Inating something too much can make it
explode, and you or others could be injured.
Be sure to read the inator instructions, and
inate any object only to its recommended
pressure.
5-77

If a Tire Goes Flat
It is unusual for a tire to blowout while you are driving,
especially if you maintain your vehicle’s tires properly.
If air goes out of a tire, it is much more likely to leak out
slowly. But if you should ever have a blowout, here
are a few tips about what to expect and what to do:
If a front tire fails, the at tire creates a drag that pulls
the vehicle toward that side. Take your foot off the
accelerator pedal and grip the steering wheel rmly.
Steer to maintain lane position, and then gently brake to
a stop well out of the traffic lane.
A rear blowout, particularly on a curve, acts much like a
skid and may require the same correction you would
use in a skid. In any rear blowout remove your foot from
the accelerator pedal. Get the vehicle under control
by steering the way you want the vehicle to go. It may
be very bumpy and noisy, but you can still steer.
Gently brake to a stop, well off the road if possible.{CAUTION:
Lifting a vehicle and getting under it to do
maintenance or repairs is dangerous without
the appropriate safety equipment and training.
The jack provided with your vehicle is
designed only for changing a at tire. If it is
used for anything else, you or others could be
badly injured or killed if the vehicle slips off
the jack. Use the jack provided with your
vehicle only for changing a at tire.
If a tire goes at, the next part shows how to use the
jacking equipment to change a at tire safely.
Changing a Flat Tire
If a tire goes at, avoid further tire and wheel damage
by driving slowly to a level place. Turn on your
hazard warning ashers.
5-78

{CAUTION:
Changing a tire can be dangerous. The vehicle
can slip off the jack and roll over or fall on you
or other people. You and they could be badly
injured or even killed. Find a level place to
change your tire. To help prevent the vehicle
from moving:
1. Set the parking brake rmly.
2. Put the shift lever in PARK (P).
3. Be sure the transfer case is in a drive
gear—not in NEUTRAL.
4. Turn off the engine and do not restart
while the vehicle is raised.
5. Do not allow passengers to remain in the
vehicle.
To be even more certain the vehicle will not
move, you can put blocks at the front and rear
of the tire farthest away from the one being
changed. That would be the tire on the other
side, at the opposite end of the vehicle.When you have a at tire, use the following example as a
guide to assist you in the placement of wheel blocks.
The following steps will tell you next how to use the
jack and change a tire.
5-79

Removing the Spare Tire and
Tools (SUT)
The jack is stored in the rear cargo compartment on
the passenger side of the vehicle. The tools for the
jack are stored under the rear passenger’s seat.
To remove the tools:
1. Locate the tools by lifting the driver’s side
second row seat up to expose the oor.
SeeSplit Folding Rear Seat on page 1-8for
more information.
2. Remove the strap from the seat rail. Then carefully
slide the tool bag out from under the seat rail as
shown.
Take care to not pinch the seat cables or electrical
harnesses.
3. Open the tool bag. You will nd the following tools
needed to remove the spare tire and at tire:
5-80

A. Jack Handle
B. Jack Handle
Extensions (2)
C. Wheel WrenchD. Wheel Wrench
Extension
E. Wheel BlocksTo access the jack, remove the cover, unlock it and
then pull the cover off.
5-81

Release the jack by inserting the wheel wrench (A) into
the hole (B) and turn counterclockwise.Before proceeding, be sure to set the wheel blocks at
the appropriate tire as previously shown.
Remove the wheel blocks
from the tool bag. Then lift
the wheel block as
shown to lock it into place.
5-82

Removing the Spare Tire (SUT)
The spare tire is attached to the tire carrier. To remove
the spare tire:
In order to remove the spare tire, you may need
someone to assist you.
1. Open the tire carrier. SeeTailgate/Spare Tire
Carrier on page 2-16for tire carrier operation.
2. Unscrew the wing nut on the back of the tire carrier.3. Pull off the license plate holder from the spare tire.
4. Attach the wheel wrench to the wheel wrench
extender to remove the wheel nuts.
5. Turn the wheel wrench with the wheel wrench
extender counterclockwise to loosen the wheel nuts.
5-83

6. Remove the three wheel nuts holding the spare tire
onto the tire carrier.
7. Pull off the spare tire and gently lower to the
ground. Set it next to the at tire.
Removing the Spare Tire and
Tools (SUV)
Removing the Tools (SUV)
The equipment you need is located under the driver’s
side second row seat. To remove the equipment:
1. Locate the tools by lifting the driver’s side second
row seat up to expose the oor. SeeSplit Folding
Rear Seat on page 1-8for more information.
2. Remove the strap from the seat rail. Then carefully
slide the tool bag out from under the seat rail as
shown.
Take care not to pinch the seat cables or electrical
harness.
5-84
