8CONSUMER INFORMATION
6
I090A01MC-GAT WHEN TO REPLACE TIRES
The original tires on your car have tread wear indicators. The location of tread wear indicators is shown by the "TWI"or " " marks, etc., The tread wear indicators appear when the tread depth is 1.6 mm (0.06 in.). The tire should be replaced when these appear as a solid bar across two or more grooves of thetread. Always replace your tires with those of the recommended size. If you change wheels, the new wheel's rimwidth and offset must meet Hyundai specification.
!WARNING:
o Driving on worn-out tires is dan- gerous! Worn-out tires can cause
loss of braking effectiveness, steering control and traction. When replacing tires, never mixradial and bias-ply tires on the same car. If you replace radial tires with bias-ply tires, they mustbe installed in sets of four.
o Using tires and wheels of other
than the recommended sizes maycause unusual handling charac- teristics that may cause death, serious injury or property dam-age.
OMC055017
Wear indicator
I070A01A-AAT TIRE BALANCING A tire that is out of balance may affect handling and tire wear. The tires onyour Hyundai were balanced before the car was delivered but may need balancing again during the years youown the car. Whenever a tire is dismounted for repair, it should be rebalanced beforebeing reinstalled on the car. I080A01A-AAT TIRE TRACTION Tire traction can be reduced if you drive on worn tires, tires that are im- properly inflated or on slippery road surfaces. Tires should be replacedwhen tread wear indicators appear. To reduce the possibility of losing control, slow down whenever there is rain,snow or ice on the road.

9 VEHICLE SPECIFICATIONS
2
Type Wheel free playRack stroke Oil pump type 4 Door
4280 (168.5)
1695 (66.7)1470 (57.9) 2500 (98.4) 1470 (57.9)1460 (57.5)
ItemOverall length Overall width Overall heightWheel base Wheel tread J030A01MC-GAT TIRE
GASOLINE
MF45AH, MF55AH 90A (13.5V)
0.9 KW
Dual hydraulic with brake booster Ventilated disc Drum (without ABS)Disc (with ABS) Cable operated on rear wheel
J010A01MC-GAT MEASUREMENT
J060A01A-GAT FUEL SYSTEM
Rack and pinion 0 ~ 30 mm (0 ~ 1.18 in.) 142 mm (5.59 in.) 138 mm (5.43 in.)Vane type
175/70 R14, 185/65 R14, 195/55 R15 175/70 R14, 185/65 R14, 205/45 R16 Full size
4 Door3 Door Spare
Front Rear
mm (in.)
J020A01MC-GAT POWER STEERING Fuel tank Capacity Liter
45 Imp.gal
9.9
J040A01MC-GAT ELECTRICAL
Item Battery Alternator Starter
J050A01MC-GAT BRAKE Type Front brake type Rear brake typeParking brake
3 Door
4045 (159.3)
DIESEL
MF68AH
120A(12V) 1.7 KW
175 Tire only Except 175 Tire
