Hyundai Accent 2011 - RHD (UK. Australia) User Guide

F11
AUSTRALIAN DESIGN RULES
The compliance plate located on the left wheel housing of the luggage compartment shows that your vehicle has been tested and found to comply with all relevant Australian Design Rules (ADR's) applicable at its date of manufacture.Any part, that is subject to these ADR's, must not be removed or altered and is to be maintained in good order at all times for the vehicle to be roadworthy and re- registerable by all registerable authorities. Consult an Authorised Hyundai Motor Dealer before conducting any repairs that may affect these areas or if requiring further classification on design rules or safetyfeatures. Failure to observe the above warning may render the vehicle compliance invalid and result in personal injury which may have otherwise been avoided.
A100A01MC-DAT

FEATURES OF YOUR HYUNDAI
1
1
Fuel Recommendations ................................................ 1-2
Running in Your New Hyundai ..................................... 1-3
Immobiliser System ...................................................... 1-3
Door Locks ................................................................... 1-5
Theft-Alarm System ...................................................... 1-8Window Glass............................................................. 1-11
Seats ........................................................................... 1-13
Seat Belts .................................................................... 1-22
Child Restraint System ................................................ 1-28
Supplemental Restraint (AIRBAG) System .................1-37
Instrument Cluster and Indicator Lights .......................1-46
Warning and Indicator Lights....................................... 1-50
Trip Computer .............................................................. 1-58
Multi-Function Light Sw itch .......................................... 1-61
Windshield Wiper/Washer Switch ................................1-63
Sunroof ........................................................................ 1-70
Mirror ........................................................................... 1-75
Bonnet Release ........................................................... 1-79
Heating and Cooling Control .......... ..............................1-89
Stereo Sound System ................................................. 1-99
Antenna ..................................................................... 1-103
Audio System ............................................................ 1-104

1FEATURES OF YOUR HYUNDAI
2FUEL RECOMMENDATIONS
B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to:
o Observe all regulations regardingregistration and insurance.
o Determine that acceptable fuel is available.
Unleaded petrol with a Pump Octane Rating of 87 (Research Octane Num- ber 91) or higher must be used inyour Hyundai. If leaded petrol is used, it will cause the catalytic converter to become ineffec- tive and the emission control system to malfunction. This can also result inincreased maintenance expense. To avoid accidental use of leaded fuel, the larger nozzle used with leaded petrolat service stations cannot be inserted into the fuel tank opening of your Hyundai.
B010A01A-DAT Use Unleaded Petrol
B010E01A-DATPetrol for Cleaner Air To help contribute to cleaner air, Hyundai recommends that you usepetrol treated with detergent additives, which help prevent deposit formation in the engine. This petrol will help theengine run cleaner and enhance per- formance of the Emission Control Sys- tem.
B010D01A-DAT Do not Use Methanol Fuels containing methanol (wood al- cohol) should not be used in your Hyundai. This type of fuel can reducevehicle performance and damage com- ponents of the fuel system.
! CAUTION:
Hyundai Warranty Policy will not cover the damage of the fuel sys- tem and performance problems that are caused by the use of methanolor fuels containing methanol.
B010B01A-AAT What About Gasohol [E-10]? Gasohol (a mixture of 90% unleaded gasoline and 10% ethanol or grainalcohol) may be used in your Hyundai. However, if your engine develops drive ability problems, the use of 100% un-leaded gasoline is recommended. Fu- els with unspecified quantities of alco- hol, or alcohols other than ethanol,should not be used.
B010A01MC-A
UNLEADED
FUEL ONLY

1
FEATURES OF YOUR HYUNDAI
3IMMOBILISER SYSTEMRUNNING IN YOUR NEW HYUNDAI
B020A01S-DAT During the First 2,000 km No formal running in period is required with your new Hyundai. However, youcan contribute to the economical op- eration and durability of your Hyundai by observing the following recommen-dations during the first 2,000 km.
o Don't drive faster than 88 km/h.
o While driving, keep your engine
speed or revolutions per minutebetween 2,000 and 4,000 rpm.
o Use moderate acceleration. Don't use full-throttle starts.
o For the first 300 km, try to avoid hard stops.
o Don't labour the engine (in other
words, don't drive so slowly in toohigh a gear that the engine hesi- tates : shift to a lower gear).
o Whether going fast or slow, vary your speed from time to time.
o Don't let the engine idle longer than
3 minutes.
o Do not tow a trailer during the first 2,000 km of operation.
!
B880A01A-DAT The immobiliser system is an anti-theft device, designed to deter automobile theft. B880B03MC-DAT Keys All of the locks fitted to the vehicle are operated by the same key. However,since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the keydoes not become locked inside the vehicle by mistake. NOTE: If you make your own duplicate key, you will not be able to cancel the immobiliser system or start the en-gine. CAUTION:
o When starting the engine, do not use the key with other immobiliser keys around. Otherwise the en- gine may not start or may stopsoon after it starts. Keep each keys separately not to have any malfunction after youreceive your new vehicle.
o Do not install the metal accesso-
ries near the key or ignition switch.The engine may not start for the metal accessories may interrupt the transponder signal from nor-mally transmitting.
!WARNING:
In order to prevent theft of your ve- hicle, do not leave spare keys any-where in your vehicle.

1FEATURES OF YOUR HYUNDAI
4
B880D01CM-DAT Limp Home Procedures
In case the immobiliser warning indica- tor blinks for five seconds when the ignition key is turned to "ON" position,this indicates that the immobiliser sys- tem is out of order. Should the immobiliser system be out of order,your vehicle will need to be towed to a Hyundai dealer for rectification.
In the interest of security, the metal tag attached to the keys which bears thekey number should be removed from the key ring after you receive your new vehicle. In addition, key numbers can-not be provided by Hyundai for security reasons. If you need additional keys or if youshould lose your keys, your authorised Hyundai dealer can make new keys if you can supply the key number.
B880C01MC-DAT Key Numbers
The vehicle key number is recorded upon a metal tag attached to the keys when the vehicle is first delivered toyou. The key number should be recorded and kept in a safe place in case theneed to order further keys arises. New keys are available from any Hyundai dealer by quoting the relevant keynumber.
OMC027002HNF2011

1
FEATURES OF YOUR HYUNDAI
5
!
DOOR LOCKS
B040A02Y-DAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (espe- cially if there are children in the car), be sure that all the doors are securely closed and locked so that the doors cannot be inadvert- ently opened from the inside. This helps ensure that the doors will not be opened accidentally. Also, when combined with the proper use of seat belts, locking the doors helps keep occupants from being ejected from the car in case of an accident.
o Before opening the door, always
look for and avoid oncoming traffic.
o In case of an accident, all doors
will unlock automatically (If In- stalled).
OMC025005R B040C01MC-GAT Locking From the Outside The doors can be locked without a key. To lock the doors, first push the inside lock switch to the "LOCK" position sothat the red mark on the switch is not visible, then close the door.
B040B01A-AAT Locking and Unlocking Front Doors with a Key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key toward the rear.
UNLOCKLOCK
B040C04MCR

1FEATURES OF YOUR HYUNDAI
6
!
OMC025006R
B040D01MC-DAT Locking From the Inside
To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position. NOTE:
o When the door is locked, the red mark on the switch is not visible.
o The driver's door can be opened by pulling the inside door handle even if the lock switch is de- pressed. B040E04A-DAT CHILD-PROTECTOR REAR DOOR LOCK (4 Door) Your Hyundai is equipped with a "child- protector" rear door lock assembly.
NOTE:
o If your vehicle is equipped with
central door locking system, the door will not lock if the key is leftin the ignition switch when the front doors are closed.
o When locking the door this way, be careful not to lock the door withthe ignition key left in the vehicle.
o To protect against theft, always remove the ignition key, close allwindows, and lock all doors and the boot lid(4 Door)/tail gate(3 Door)when leaving your vehicle unat- tended.
LOCK
UNLOCK
B040E01MC
WARNING:
Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can beopened and you may be ejected from the vehicle and can be injured or killed.

1
FEATURES OF YOUR HYUNDAI
7
!
B040G01MC-DAT Central Door Lock (If Installed) The central door locking switch is lo- cated on the driver's arm rest. It is operated by depressing the door lockswitch. NOTE:
o When pushing the front portion of
the driver's door lock switch, all vehicle doors will lock. If any door is open when the switch is depressed, the door will remainlocked when closed.
OMC029047R o When pushing the rear portion of
the switch, all vehicle doors will unlock.
o The central door locking is oper-
ated by turning the key in thedriver's door lock toward the front or rear of the vehicle.
o The driver's door can be opened by pulling the inside door handleeven if the lock switch is de- pressed.
o If the door is locked/unlocked mul- tiple times in rapid succession with either the vehicle key or doorlock switch, the system may stop operating temporarily in order to protect the circuit and prevent damage to system components.
LOCK
UNLOCK
When the lock mechanism is engaged, the rear door cannot be opened from inside. Its use is recommended when-ever there are small children in the rear seat. To engage the child-protector feature so the door cannot be opened from the inside, move the child-protector leverto the "
" position and close the door.
Move the lever to the "
" position
when normal door operation is desired. The outside door handle will function normally, regardless of the position of the child protector door lock.
WARNING:
Be careful not to pull the inside doorhandle while driving. If you pull theinside door handle, the door can be opened and you may be ejected from the vehicle and can be injured orkilled.

1FEATURES OF YOUR HYUNDAI
8THEFT-ALARM SYSTEM
Park the car and stop the engine. Arm the system as described in the follow- ing paragraph.
1) Remove the ignition key from theignition switch.
2) Make sure that all doors, boot lid (4 Door) / tail gate (3 Door) and engine bonnet are closed and latched.
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal lights will blink once to indicate that the system is armed.
! CAUTION:
Do not arm the system until all pas- sengers have left the car. If the sys- tem is armed while a passenger(s) remains in the car, the alarm may beactivated when the remaining passenger(s) leave the car.
B070A01A-DAT (If Installed) This system is designed to provide protection from unauthorised entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal lights.
B070B02MC-DAT Armed StageB070B01MCRNOTE:
1) If any door, boot lid (4 Door)/ tail
gate (3 Door) or engine bonnet remains open, the system will notbe armed. If this happens, rearm the system as previously described.
2) Once the system is armed, only the boot lid (4 Door) may be un-locked using the ignition key with-out disarming the system.

1
FEATURES OF YOUR HYUNDAI
9
B070D03MC-DAT Disarmed Stage
B070C02MC-DATAlarm Stage The alarm will be activated if any of the following occurs while the car is parked and the system is armed.
1) Any door, tail gate (3 Door) included,
is opened without using the trans- mitter.
2) The boot lid (4 Door) is opened with-
out using the ignition key.
3) The engine bonnet is opened. The alarming horn will sound and the turn signal lights will blink continuouslyfor 27 seconds. To turn off the system, unlock the door with the transmitter. The system will be disarmed when the driver's or passenger's door is un- locked by depressing the button on thetransmitter after the system was armed. After completion of the step above, the turn signal lights will blink twice to indicate that the system is disarmed. If any door, boot lid(4 Door)/tail gate (3 Door) included, is not opened within 30 seconds, the system will be re-armed. NOTE: When the system is disarmed with the interior light switched to "DOOR",the interior light will illuminate for 30 seconds.
B070D02AMCCAUTION:
Only the transmitter can disarm the armed stage. If the transmitter doesnot disarm the system, it is neces- sary to take the following steps; 1. Unlock and open the door with the key, which will cause the alarm to be activated.
2. Insert the key in the ignition key cylinder and turn the ignition keyto "START" position.
After completing the steps above,the system will be disarmed.
!
CAUTION:
Do not change, alter or adjust the theft-alarm system because it couldcause the theft-alarm system to mal- function and should only be ser- viced by an authorised Hyundaidealer. Malfunctions caused by improper alterations, adjustments or modifi-cations to the theft-alarm system are not covered by your vehicle manu- facturer warranty.
!
