Scheduled Maintenance Normal Usage Severe Usage*Engine Oil And Filter* Replace 7,500 or 12 mos. Replace 3,750 or 6 mos.
Fuel Additives Add 7,500 or 12 mos.
Tire Rotation Perform 7,500 Perform 7,500
Air Cleaner FilterInspect
Replace7,500
30,000Inspect
ReplaceSame As Normal
More Frequently
Battery Condition Inspect 7,500 Inspect Same As Normal
Vacuum Hose Inspect 7,500 Inspect Same As Normal
Climate Control Air Filter
(For Evaporator And Blower Unit)Replace 15,000 Replace More Frequently
Air Conditioning Refrigerant Inspect 15,000 Inspect Same As Normal
Brake Hoses & Lines Inspect 15,000 Inspect Same As Normal
Drive Shafts & Boots Inspect 15,000 Inspect 7,500 or 6 mos.
Exhaust Pipe & Muffler Inspect 15,000 Inspect Same As Normal
Front Disc Brake/Pads Inspect 15,000 Inspect More Frequently
Rear Brake Disc/Pads Inspect 15,000 Inspect More Frequently
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball JointInspect 15,000 Inspect More Frequently
Suspension Mounting Bolts Inspect 15,000 Inspect Same As Normal
Brake Fluid Inspect 30,000 Inspect Same As Normal
Fuel Filter Inspect 30,000 Inspect Same As Normal
Fuel Lines, Fuel Hoses and Connections Inspect 30,000 Inspect Same As Normal
Fuel Tank Air Filter Inspect 30,000 Inspect Same As Normal
Parking Brake Inspect 30,000 Inspect More Frequently
Vapor Hose & Fuel Filler Cap Inspect 30,000 Inspect Same As Normal
Valve Clearance Inspect 60,000 Inspect Same As Normal
Drive Belt (Alt, A/C)1st Inspect 60,000 or 72 mos.
Add. Inspect 15,000 or 24 mos.Inspect Same As Normal
Spark Plugs (Iridium Coated) Replace 105,000 or 10 yrs. Replace More Frequently
Coolant1st Replace 120,000 or 10 yrs.
Add Replace 30,000 or 24 mos.Replace Same As Normal
Automatic Transaxle Fluid No check, No service required Replace 60,000
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*See Owner’s Manual for details.Looking for more detailed information? This Quick Reference Guide does not replace your vehicle’s Owner’s
Manual, If you require additional information or are unsure of a specific issue, you should always refer to the vehicle’s
Owner’s Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing, however, specifications
and equipment can change without notice. No warranty or guarantee is being extended in this Quick Reference
Guide, and Hyundai reserves the right to change product specifications and equipment at any time without incurring
obligations. Some vehicles are shown with optional equipment. Specifications apply to U.S. vehicles only. Please
contact your Hyundai dealer for current vehicle specifications.MAINTENANCE
NP150-M2015
(Rev 09/30/15)
Printing 10/03/15
www.hyundai.com
HYUNDAI
AZERAQuick Reference Guide
Roadside Assistance:
1-800-243-7766
Consumer Affairs:
1-800-633-5151
Sirius
XM®Radio:
1-800-967-2346
Blue Link:
1-855-2BLUELINK
(1-855-225-8354)
☐ TIRE PRESSURE MONITORING SYSTEM
(TPMS) – page 29
Explain TPMS function to customer.
- When illuminated, one or more
tires are under-inflated.
- Blinks for approximately one minute
then remains illuminated when there
is a malfunction with the TPMS.☐ CLOCK ADJUSTMENT – page 27
- Demonstrate how to adjust the clock.☐ VEHICLE SETTINGS – pages 12-13 & 24-26
- Demonstrate vehicle settings
in instrument cluster
- Demonstrate navigation use,
enter dealer address
- Show radio presets☐ BLUETOOTH – pages 18
- Demonstrate phone pairing
Refer to www.hyundaiusa.com/bluetooth
- Demonstrate QR code☐
BLUE LINK – pages 21-23
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
- Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES☐ DEFROST - page 15
1 Press the front defrost button.
2 Set to warmest temperature setting.
3 Set to highest fan speed.
Page 2 of 18
Table of contentsGETTING STARTED
Engine start/stop button 03
Front seat adjustment 04Fuel door 06Headrest adjustment 05Rear seat folding 06Remote keyless entry 02
Seat belt adjustments 05
Smart trunk 04
Trunk opening 03
FEATURES AND CONTROLSActive ECO system 31
Automatic transmission 28
Auto hold 31
Blind spot detection system (BSC) 30
Central door lock switch 07
Child-protector rear door lock 33
Climate control 14-15
Clock adjustment 27
Cruise control/
Advance Smart Cruise Control system 16
Driver’s main controls 07
Electric Parking Brake [EPB] 31
Electronic Stability Control (ESC) 32
Head lights and fog lights 08
Homelink wireless control system 11
Instrument cluster 12-13
Instrument panel illumination 13
Interior lights 11
Lane departure waning system (LDWS) 29
Rearview camera 33
Rear parking assist System 30Steering wheel adjustments 06
Steering wheel controls 16-17
Sunroof 10
Tire Pressure Monitoring System (TPMS) 29
Trip computer 13
Wiper and washer 09
MULTIMEDIAAUX, USB, and iPod
® Port 27
Blue Link Telematics system 21-23
Bluetooth operation tips 19-20
Bluetooth phone pairing 19
Navigation 24-26
Voice recognition tips 20
Steering
Wheel
AdjustmentsPage 06Head lights
and fog lightsPage 08
Instrument
clusterPages 12-13
NavigationPages 24-26
Wiper and
washerPage 09
Climate
controlPages 14-15
Use this Quick Reference Guide to learn
about the features that will enhance your
enjoyment of your Hyundai. More detailed
information about these features are
available in your Owner’s Manual.
* Some vehicles may not be equipped with all
the listed features.
How to:1. Pair phone to your vehicle. Refer to page 18.
2. Get started with Blue Link. Refer to page 21-23.
Cruise control/
Advance
Smart Cruise
Control
SystemPage 16Trip
computerPage 13
WARNING!
To reduce the risk of serious injury to yourself and others,
read and understand the important SAFETY INFORMATION
in your Owner’s Manual.Automatic
transmissionPage 28
Engine start/
stop buttonPage 03
Page 3 of 18
GETTING STARTED
AZERA
03 02
HYUNDAI
REMOTE KEYLESS ENTRY
LockUnlockTrunk openAlarm
Driver’s door Lock / Unlock
Smart key must be within range.Press: Once – Unlock driver door
Twice – Unlock all doors
Third – Lock all doorsRemove mechanical keyPress and hold the release
A button and
remove the key.
Reinstall mechanical key Put the key into the key slot and push it until
a click sound is heard.
A
ENGINE START / STOP BUTTONWith the ignition
OFF, press the engine start / stop button:
t 0 O D F G P S " $ $ " D D F T T P S Z
N P E F
t 5 X J D F G P S 0 / N P E F
t 5 I S F F U J N F T G P S 0 ' ' To start the engine, press the start/stop button while: t % F Q S F T T J O H U I F C S B L F Q F E B M To shut engine OFF, shift to: t 1 1 B S L
B O E Q S F T T U I F F O H J O F T U B S U T U P Q C V U U P O Emergency situations t Shut off engine while driving:
Press engine start/stop button for more than 2 seconds or
press it 3 times consecutively within 3 seconds.
t Restart engine while driving:
Press engine start/stop button with shift lever in N (Neutral).
NOTE: You can activate or deactivate the Two
Turn Unlock features in the vehicle. Refer to
i - $ % E J T Q M B Z w J O U I F 0 X O F S T . B O V B M T F D U J P O
TRUNK OPENING
Press to open.
Smart key needs
to be within range.Press and hold to
open.
Insert key and turn. Pull the release button
in the vehicle.
Download QR Code ReaderYou can download a QR reader app to your smart phone to take advantage
of the QR codes throughout this Quick Reference Guide.
iPhone
® - Apple
® App Store
Android
® - Google Play
BlackBerry® - BlackBerry
® App World
Page 4 of 18
GETTING STARTED
AZERA
05
HYUNDAI
FRONT SEAT ADJUSTMENT
HEADREST ADJUSTMENT
Forward or backward adjustmentTo Adjust Headrest Forward:
Pull forward to 1 to 3 positions.
To Adjust Backward :
Pull all the way forward then release.
Seatback
angleForward and backwardSeat cushion height $ V T I J P O F Y U F O T J P O B E K V T U N F O U
(for driver’s seat)
To Raise Headrest:
Pull headrest up.
To Lower Headrest:
Press lock knob while pressing down
on headrest.Height adjustment
PRESS
SEAT BELT ADJUSTMENT (Front seat)
Pull up to raise.Press button and
push down to lower.
SMART TRUNK
Smart TrunkTrunk will open automatically when
detecting smart key within range near
the trunk for more than 3 seconds.To enable Smart Trunk function:Vehicle must be in P (Park) to adjust
settings in the User Setting mode.
4 F M F D U % P P S 5 S V O L J O U I F 6 T F S
Settings in the instrument cluster.
$ I F D L 4 N B S U 5 S V O L
NOTE:
Function is active after 15 seconds when all doors are closed and locked. The
vehicle will also provide an audible and visual alarm while activating. For more
details, refer to Owner's Manual.
Page 5 of 18
AZERA
07
GETTING STARTED
06
HYUNDAI
Outside Rearview MirrorsMove the selecting switch
A to the
right or left.
Press the appropriate direction
(
) on the switch.
If L or R button is still selected, both
mirrors will tilt downward when reversing.
% F T F M F D U - P S 3 X J M M E J T B C M F U I F B V U P U J M U
down.Middle positionLock the control.
DRIVER’S MAIN CONTROLS
Window Auto down/up Press past detent to fully
open/close window.Power Window Lock Switch % J T B C M F T U I F Q P X F S X J O E P X T X J U D I F T
on the passenger doors.Power Folding MirrorsLeft - The mirror will unfold
$ F O U F S 5 I F N J S S P S X J M M G P M E P S V O G P M E
automatically when door is locked or
unlocked by the smart key or the button
on the outside of door handle
Right - The mirror will fold
A
STEERING WHEEL ADJUSTMENTS
NOTE: % P O P U B E K V T U X I J M F E S J W J O H
Use the switch
A to set the tilt
angle
B and telescopic distance
C.
A
B
C
Tilt Telescopic
CENTRAL DOOR LOCK SWITCH
All doors will lock.
All doors will unlock.
REAR SEAT FOLDING
1
2
NOTE: After adding fuel, always
reinstall the fuel cap onto the filler neck
by rotating it clockwise until it clicks
once.
Failure to do this may result in the
$ I F D L & O H J O F - J H I U
) illuminating.
FUEL DOOR
$ I F D L U I F F O H J O F P J M S F H V M B S M Z C F U X F F O
recommended oil changes.
FEATURES AND CONTROLS
Page 6 of 18
FEATURES AND CONTROLS
AZERA
09 08
HYUNDAI
HEAD LIGHTS AND FOG LIGHTS
Parking lightOFFHead lightAuto light
Escort Function ) F B E M J H I U T X J M M T U B Z P O G P S B Q Q S P Y J N B U F M Z T F D P O E T B G U F S F Y J U J O H B O E
locking vehicle. Press the remote lock button twice to turn the head
light off. See the Owner’s Manual for more detail.
WIPER AND WASHER
MIST -
Single wipe
OFF -
Off
INT -
Intermittent wipe
LO -
Normal wiper speed
HI
- Fast wiper speed
Front Intermittent wipe time
adjustment
Fast wiper speed
Slow wiper speed
Front Wiper and Washer Smart High Beam
Pull to spray and wipe
Wash with brief wipes
High beam
Fog light Turn signals and lane change signals Flashing head lights
PUSHPULL
Smart High Beam Function1. Select auto position on stalk.
2. Push lever forward to engage Auto
High beam.
3. Push lever forward again to
disengage.
See Owner's Manual for more details.
Page 7 of 18
FEATURES AND CONTROLS
AZERA
11 10
HYUNDAI
SUNROOFSliding the sunroof
To Open
Press switch rearward.
Press switch rearward past
the detent to open completely.To ClosePress switch forward past the detent
to close completely.
1 S F T T U I F T V O T I B E F $ - 0 4 & C V U U P O
The sunroof glass will close then
the sunshade will close. To stop
the sunroof movement at any point,
press the sunshade control switch
momentarily.To TiltPress the switch up.To closePush the switch forward or pull the
switch down.
Tilting the sunroof
Closing the Sunshade
INTERIOR LIGHTSAA
AA
BB
CC
HOMELINK WIRELESS CONTROL SYSTEM
r ) P N F - J O L
Programming Rolling Code Garage Press and hold your selected HomeLink button for 20 seconds. Release
when light flashes rapidly.
1 S F T T B O E S F M F B T F U I F i M F B S O w P S i T N B S U w C V U U P O P O U I F H B S B H F E P P S
opener motor-head unit.
NOTE: T F D P O E X J O E P X U P J O J U J B U F O F Y U T U F Q
Press and hold the desired HomeLink button for 2 seconds and release.
Repeat this sequence up to 3 times. If programming is successful, the
garage door should open or close during this step.
' P S E F U B J M J O T U S V D U J P O T J O D M V E J O H i 4 U B O E B S E U Z Q F w H B S B H F E P P S
S F G F S U P
your Owner’s Manual or visit www.homelink.com Type AType B
Front Map Lamp Push the switch to turn the map
lamp on or off.
A
Front Room Lamp ( )
(Type B)
Push the switch to turn the room
lamp (overhead lamp) on or off.
B
Front Room Lamp ( )
(Type A)
Push the switch to turn the room
lamp (overhead lamp) on or off.
B
Front Door Lamp ( ) Lights will turn on when any door
is open.
C
Page 8 of 18
FEATURES AND CONTROLS
AZERA
13 12
HYUNDAI
WARNINGS AND INDICATORSSeat belt
warning lightAir bag warning light
Low Tire Pressure Indicator / TPMS
(Tire Pressure
Monitoring System) malfunction indicator
ABS warning light
Front fog light indicator
Light on indicatorTrunk open
warning lightElectronic Power Steering
system warning lightHigh beam indicator
Cruise indicatorParking brake & Brake
fluid warning lightEngine oil pressure
warning lightCharging system
warning light
Malfunction
indicator light
ESC
(Electronic Stability
Control) indicator
Low fuel level
warning light
ESC (Electronic Stability
Control) OFF indicator
Cruise SET indicator
Shift pattern indicatorDoor open
warning
light
Engine coolant
temperature warning light
Turn signal indicatorActive ECO indicator
Immobilizer indicator
Low beam indicator
INSTRUMENT PANEL ILLUMINATION
Push the control
switch up or down
to adjust the
brightness
TRIP COMPUTER
Smart High beam
indicator
Tachometer Speedometer
Fuel gauge Warning and
Indicator lights Turn signal indicators
$ P M P S - $ % E J T Q M B Z
Engine coolant
temperature gauge
1 . 0 % & C V U U P O G P S D I B O H J O H
modes2 : MOVE switch for changing
items3 4 & - & $ 5 3 & 4 & 5 C V U U P O G P S
setting or resetting the
selected item
Page 9 of 18
FEATURES AND CONTROLS
AZERA
15
HYUNDAI
1. Press the front
windshield defrost
control.3. Set the fan speed
to the highest
setting. 2. Set the temperature
control to the
warmest setting.
NOTE
To reduce the tendency of the glass fogging and improve visibility,
keep the interior surface of the windshield clean by wiping it with a
clean cloth and glass cleaner. In addition, select air intake control to
the outside (fresh) air position whenever possible while operating the
vehicle.DEFROSTING / DEFOGGING
Press to activate /
deactivate the rear defroster.REAR WINDOW DEFROSTER
1 S F T T U I F 4 : / $
button to operate
the driver and
passenger side
temperature
individually.Press the
$ - * . " 5 &
information screen
selection button to
display climate
information on the
screen.
SYNC BUTTON CLIMATE BUTTON AIR INTAKE CONTROL
Outside (fresh) air positionRecirculated air position
This is used to select outside
(fresh) air position or recirculated
air position.
MODE SELECTION
Face LevelBi LevelFloor Level ' M P P S % F G S P T U - F W F M
AUTOMATIC HEATING
AND COOLING
1. Press the AUTO
button.
2. Press the temperature
button to the desired
setting.
The modes, fan speeds, air intake
and air-conditioning will be
controlled automatically according to
the temperature setting.
Front windshield defroster buttonFan speed control knob OFF button
Rear window
defroster button
Passenger’s temperature
control switch
$ M J N B U F * O G P S N B U J P O T D S F F O
selection button Sync button " 6 5 0 " V U P N B U J D $ M J N B U F $ P O U S P M
button
Air conditioning button
% S J W F S T U F N Q F S B U V S F
control switch
Mode selection switch
Air intake control button
Page 10 of 18
FEATURES AND CONTROLS
AZERA
17 16
HYUNDAI
* G F Y Q F S J F O D J O H E J G m D V M U Z V T J O H 7 P J D F 3 F D P H O J U J P O U P Q M B D F B D B M M
C F T V S F
you are using the actual full contact name as entered in your phone
book, not a casual or nick-name (e.g., if name was entered as “Robert
<0034004e004a005500490077000d000100540042005a0001006900240042004d004d000100330050004300460053005500010034004e004a005500490077000d0001004f005000550001006900240042004d004d000100230050004300010034004e004a00
5500490077000a000f>Bluetooth controlA TALK Activate voice recognition.B CALL Place and transfer call.C END End call or cancel function.A VOLUME Raise or lower speaker volume.B SEEK / PRESET Press to change presets.
Press and hold to seek stations.
C MODE $ I B O H F U I F B V E J P T P V S D F
Hold to turn Audio power ON/OFF.D MUTE Mute the sound.
Audio control Cruise control system/Advance Smart Cruise Control system
A
C
B
D
ABC
STEERING WHEEL CONTROLS
A
C
D
B
1
2
Setting Vehicle Distance
(Advanced Smart Cruise
Control only)
The vehicle to vehicle distance
1 will automatically activate when you
set the cruise speed
2.This system assist you in setting the
distance from the vehicle ahead and
will maintain the selected distance
without you depressing the
accelerator or the brake pedal.
* G Z P V S W F I J D M F J T F R V J Q Q F E X J U I " E W B O D F E 4 N B S U $ S V J T F $ P O U S P M B O E
you wish to eliminate the vehicle distance function, you can change
cruise control setting to a standard setting.
1 S F T T U I F $ S V J T F $ P O U S P M C V U U P O P O U I F
T U F F S J O H X I F F M U P U V S O P O $ S V J T F $ P O U S P M
Then press and hold the vehicle distance
button for more than 2 seconds to toggle
C F U X F F O 4 N B S U $ S V J T F $ P O U S P M 4 $ $
B O E
$ S V J T F $ P O U S P M $ $
N P E F
Please refer to your Owner's Manual for
more information. Each time the vehicle distance set button is pressed, the vehicle to
vehicle distance changes as follows: 5 I F $ S V J T F $ P O U S P M
system allows you to
program the vehicle to
maintain a constant
speed without holding
the accelerator pedal.
% J T U B O D F
% J T U B O D F
% J T U B O D F
% J T U B O D F
A 5 V S O 0 O 0 G G U I F $ S V J T F $ P O U S P M B Resume or Increase
U I F $ S V J T F $ P O U S P M T Q F F E C 4 F U P S % F D S F B T F
U I F $ S V J T F $ P O U S P M T Q F F E D $ B O D F M U I F $ S V J T F $ P O U S P M
