FEATURES OF YOUR HYUNDAI 1- 23
WARNING:
o The side impact airbag is supplemental to
the driver's and the passenger's seat beltsystems and is not a substitute for them.Therefore your seat belts must be worn atall times while the vehicle is in motion. Theairbags deploy only in certain side impactconditions severe enough to cause sig-nificant injury to the vehicle occupants.
o For best protection from the side impact airbag system and to avoid being injuredby the deploying side impact airbag, bothfront seat occupants should sit in an up-right position with the seat belt properlyfastened. The driver's hands should beplaced on the steering wheel at the 9:00and 3:00 o'clock positions. Thepassenger's arms and hands should beplaced on their laps.
o Do not use any accessory seat covers.
o Use of seat covers could prevent or re- duce the effectiveness of the system.
o Do not install any accessories on the side or near the side impact airbag.
o Do not use excessive force on the side of the seat.
o Do not place any objects over the airbag or between the airbag and yourself.
o Do not place any objects (an umbrella, bag, etc.) between the front door and thefront seat. Such objects may become dan-gerous projectiles and cause injury if thesupplemental side impact airbag inflates.
Your Hyundai is equipped with a side impactairbag in each front seat. The purpose of theairbag is to provide the vehicle's driver and/or thefront passenger with additional protection thanthat offered by the seat belt alone. The sideimpact airbags are designed to deploy only dur-ing certain side-impact collisions, depending onthe crash severity, angle, speed and point ofimpact. The side impact airbags are not de-signed to deploy in all side impact situations.
B990B04Y-AAT Side Impact Airbag
B990B02Y
o To prevent unexpected deployment of the
side impact airbag that may result in per- sonal injury,avoid impact to the side airbagsensor when the ignition key is on.
B240C02Y-GAT SRS Care The SRS is virtually maintenance-free and there are no parts you can safely service by yourself.The entire SRS system must be inspected by anauthorized Hyundai dealer 10 years after thedate that the vehicle was manufactured. Any work on the SRS system, such as removing, installing, repairing, or any work on the steeringwheel must be performed by a qualified Hyundaitechnician. Improper handling of the SRS sys-tem may result in serious personal injury.
YT10355A

FEATURES OF YOUR HYUNDAI
1- 42 B520A01A-AAT DAY/NIGHT INSIDE REARVIEW MIR- ROR
B520A01GK
Your Hyundai is equipped with a day/night inside rearview mirror. The "night" position is selectedby flipping the tab at the bottom of the mirrortoward you. In the "night" position, the glare ofheadlights of cars behind you is reduced. B520B01O-GAT DAY/NIGHT REAR VIEW MIRROR (Electric type) (If installed)
The electric type day/night inside rearview mirror automatically controls the glare of headlights ofthe car behind you. Adjust the rearview mirror tothe desired position.
B520B01GK
WARNING: Do not adjust or fold the outside rearviewmirrors while the vehicle is moving.This could result in loss of control, and anaccident which could cause death, seriousinjury or property damage.
Sensor
The outside rearview mirror heater is actuated in connection with the rear window defroster. Toheat the outside rearview mirror glass, push inthe switch for the rear window defroster. Therearview mirror glass will be heated for defrostingor defogging and will give you improved rearvision in inclement weather conditions. Push theswitch again to turn the heater off. The outsiderearview mirror heater automatically turns itselfoff after 15 minutes.
B510C01A-AAT FOLDING THE OUTSIDE REARVIEW MIRRORS
B510C01GK
To fold the outside rearview mirrors, push them towards the rear.The outside rearview mirrors can be folded rear-ward for parking in narrow areas.

FEATURES OF YOUR HYUNDAI
1- 58
B970C02E-GAT Automatic Operation
HGK020
The FATC (Full Automatic Temperature Control) system automatically controls heating and cool-ing as follows:
1. Push the "AUTO" switch. The indicator light will illuminate confirming that the Face, Floor and/or Bi-Level modes as well as the blowerspeed and, air conditioner will be controlledautomatically. 2. Push the "TEMP" button to set the desired
temperature.The temperature will increase to the maxi-mum 32°C(90°F) by pushing on the button.Each push of the button will cause the tem-perature to increase by 0.5°C(1°F).The temperature will decrease to the mini-mum 17°C(62°F) by pushing on the button.Each push of the button will cause the tem-perature to decrease by 0.5°C(1°F).
G280A01GK
Photo sensor
HGK014
NOTE: Never place anything over the sensor whichis located on the instrument panel to ensurebetter control of the heating and coolingsystem.
NOTE: If the battery has been discharged or discon-nected, the temperature mode will reset tocentigrade degrees.This is a normal condition and you can changethe temperature mode from centigrade tofarenheit as follows;Press the TEMP button down 3 seconds ormore with the button held down. Thedisplay shows that the unit of temperature isadjusted to centigrade or fahrenheit.(°C °F or °F °C)
OUTSIDETEMP

DO-IT-YOURSELF MAINTENANCE 6-23
G200C01GK-GAT
FUSE PANEL DESCRIPTION Engine Compartment
HGK205-EPROTECTED COMPONENTS
Generator Generator Condenser Fan Radiator FanEngine Control, ECM. ATM ControlIgnition, Start RelayABSABS Blower InjectorO 2 Sensor, ECM
DRL
Front Fog Light TCM, ECM
Horn. A/ConditionerHead Light (High)Head Light (LOW)
FUSE RATING
120A50A30A 30A 30A30A30A30A30A 15A 10A15A15A10A15A 15A 15A
DESCRIPTION
BATTBATT
COND RADECU
IGN
ABS 1ABS 2
BLOWER INJ
SNSR DRL
F/FOG ECU
HORN,A/CON H/LP (H1)
H/LP (LO)
NOTE:
Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse
box on your vehicle, refer to the fuse box label.
If installed

DO-IT-YOURSELF MAINTENANCE
6-24 DESCRIPTION
IG COIL
AMP
B/UP LAMP
A/BAG IND
A/BAG
HTD MIR HAZARD
R/WIPER TAIL-RH
F/WIPER
A/C SW
RR DEFOG STOP
TAIL-LH
A/CON ECU
CLUSTER
ROOM LP
P/WINDOW T/GATE
IGN
RR FOG C/LIGHT
S/ROOF S/HTR ABS
AUDIO
G200D01GK-GAT
Inner Panel
HGK204-E
PROTECTED COMPONENTS
Ignition Coil, ECM
AMP. Multi Gauge Unit B/Up LampAir Bag Indicator Air Bag Outside Mirror DefrosterHazard Warning Light Rear Window Wiper
Tail LightFront Window Wiper A/Conditioner Rear Window DefrosterStop Light
Tail Light A/Conditioner ECM, Multi Gauge Unit, TCMCluster Map Light, Clock, Audio Power WindowTail Gate Open A/Con, A.Q.S Sensor Rear FogC/Lighter, Outside Mirror Sunroof Seat WarmerABS. TCS Audio, Clock
FUSERATING
20A20A 10A10A 15A 10A10A 15A 10A20A 10A 30A15A 10A 10A10A 10A 10A30A 15A 10A10A 15A 15A20A 10A 10A

CONTROLS AND EQUIPMENT1- 43
SB380A1-E PARKING BRAKE The parking brake must always be set when the vehicle is to be left unattended. When the parking brake is applied, and the ignition key is at the "ON" position, the parking brake warning lampwill be illuminated. Before driving the vehicle, theparking brake must be fully released and thewarning lamp extinguished.
o To set the parking brake, apply the foot brake
and pull the parking brake lever up with the button depressed. Release the button whenthe brake is fully applied.
o To release the parking brake, apply the foot brake and pull up the parking brake leverslightly. Depress the button and lower thelever.
SB370A1-E INTERIOR REAR VIEW MIRROR The interior mirror is of the day/night type to enable the glare of headlamps from followingvehicles to be eliminated during night time driv-ing.The tab located at the bottom of the mirror shouldbe set to the position nearest the windscreen fornormal day time driving, and flipped towards therear of the vehicle to eliminate glare during nighttime driving. To adjust the field of vision, themirror may be moved by hand upon the mount-ing. NOTE: The mirror should always be adjusted prior tosetting the vehicle in motion.
B520A01GK
B520B01O-GAT DAY/NIGHT REAR VIEW MIRROR (Electric type) (Not all models) The electric type day/night inside rearview mirror automatically controls the glare of headlights ofthe car behind you. Adjust the rearview mirror tothe desired position.
B520B01GK
Sensor
HGK178

CONTROLS AND EQUIPMENT
1- 58 B970C02E-AAT Automatic Operation
HGK020
The FATC (Full Automatic Temperature Control) system automatically controls heating and cool-ing as follows:
1. Push the "AUTO" switch. The indicator light will come on confirming that the Face, Floor and/or Bi-Level modes as well as the blowerspeed and, air conditioner will be controlledautomatically. 2. Push the "TEMP" button to set the desired
temperature.The temperature will increase to the maxi-mum 90°F(32°C) by pushing on the button.Each push of the button will cause the tem-perature to increase by 1°F(0.5°C).The temperature will decrease to the mini-mum 62°F(17°C) by pushing on the button.Each push of the button will cause the tem-perature to decrease by 1°F(0.5°C).
G280A01GK-D
Photo sensor
HGK014
NOTE: Never place anything over the sensor whichis located on the instrument panel to ensurebetter control of the heating and coolingsystem.
NOTE:If the battery has been discharged or discon-nected, the temperature mode will reset ascentigrade degrees.This is a normal condition and you can changethe temperature mode from centigrade tofarenheit as follows;Press the TEMP button down 3 seconds ormore with the button held down. Thedisplay shows that the unit of temperature isadjusted to contigrade or fahrenheit.(°C °F or °F °C)
OUTSIDE
TEMP

OWNER MAINTENANCE 6-9
SG070A1-E AIR CLEANER ELEMENT REPLACE- MENT
Prior to installing a sparking plug, the gap be- tween the centre and outer electrodes must bechecked and adjusted as necessary.Adjustment is facilitated by bending the outerelectrode towards or away from the centre elec-trode. Under no circumstances should attemptsbe made to adjust the position of the centreelectrode.
4. Insert the sparking plug into the cylinder head and using a suitable plug socket, slowly ratate the sparking plug, until the plug contacts theseating area. Tighten the plug with the plugsocket by a further 1/2 to 3/4 of a turn only. 5. Replace the plug lead ensuring that the cap is
pushed firmly into place. Confirm that the capis correctly seated by lightly pulling upon it.
Recommended Spark Plugs To replace the air cleaner element, remove theair intake ducting from the air flow sensor bodyand unfasten the spring clips holding the air flowsensor top to the body. Lift out the air flow sensorfollowed by the air cleaner element. Replace-ment of the element is the reverse of the above. CAUTION:
o The air flow sensor is a precision engi-
neered electronic measuring device andtherefore care should be exercised that theair flow sensor is not damaged duringreplacement of the element.
o When removing the air cleaner element, be careful that dust or dirt does not enter theair intake. These may result in damage tothe air cleaner element.
NOTE: When replacing the spark plugs, genuine Hyundai replacement parts are recom-mended.
RC10YC4(CHAMPION) BKR5ES-11(NGK) RC10PYPB4(CHAMPION) PFR5N-11(NGK)1.6/2.0L
2.7L*
* Platinum coated.
HGK213
HGK258HGK257

OWNER MAINTENANCE
6-22
G200C01GK-GAT FUSE PANEL DESCRIPTION Engine Compartment HGK205-EPROTECTED COMPONENTS
GeneratorGeneratorCondenser FanRadiator FanEngine Control, ECM. ATM ControlIgnition, Start Relay ABS ABS Blower InjectorO 2 Sensor, ECM
DRLFront fog LightTCM, ECM Horn. A/conditioner Head Light (High)Head Light (LOW)
FUSE RATING
120A50A 30A30A30A30A 30A 30A30A 15A 10A15A 15A 10A15A 15A 15A
DESCRIPTION
BATT BATT
COND RADECUIGN
ABS 1 ABS 2
BLOWER INJ
SNSR DRL
F/FOG
ECU
HORN,A/CON H/LP (H1)
H/LP (LO)
NOTE:
Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box
on your vehicle, refer to the fuse box label.
Not all models

OWNER MAINTENANCE 6-23
DESCRIPTION
IG COIL
AMP
B/UP LAMP
A/BAG IND A/BAG
HTD MIR
HAZARD
R/WIPER
TAIL-RH
F/WIPER A/C SW
RR DEFOG STOP
TAIL-LH
A/CON ECU
CLUSTER
ROOM LP
P/WINDOW T/GATE IGN
RR FOG
C/LIGHT S/ROOF
S/HTR ABS
AUDIO
G200D01GK-GAT Inner Panel
HGK204-E
PROTECTED COMPONENTS
Ignition Coil, ECM
AMP. Multi Gauge Unit B/Up Lamp Air Bag Indicator Air Bag Outside Mirror Defroster Hazard Warning LightRear Window WiperTaillightFront Window WiperA/ConditionerRear Window Defroster Stop Light Tail lightA/ConditionerECM, Multi Gauge Unit, TCMClusterMap Light, Clock, Audio Power Window Hatchback door OpenA/Con, A.Q.S Sensor Rear Fog C/Lighter, Outside MirrorSunroof Seat Warmer ABS. TCS Audio, Clock
FUSERATING
20A20A 10A 10A 15A10A 10A 15A10A20A10A30A15A 10A 10A10A10A 10A 30A 15A10A 10A 15A15A20A 10A 10A
