DRIVING YOUR HYUNDAI
2- 6 C090B01A-AAT The function of each position is as follows: o P (Park): Use to hold the vehicle in place when parked orwhile starting the engine. Whenever parking thecar, apply the parking brake and shift the selectorlever to the "P" (Park) position. CAUTION: Never place the selector lever in the "P"(Park) position unless the vehicle is fullystopped. Failure to observe this caution willcause severe damage to the transaxle. C090C01A-AAT o R(Reverse): Use for backing up the vehicle. Bring the car to a complete stop before shifting the selector lever to"R" position. C090D02O-AAT o N (Neutral): In the "N" position, the transaxle is in neutral, which means that no gears are engaged. Theengine can be started with the shift lever in "N"position, although this is not recommended ex-cept if the engine stalls while the car is moving.
HGK174
C090A04Y-GAT AUTOMATIC TRANSAXLE The highly efficient Hyundai automatic transaxle has four forward speeds and one reverse speed.The individual speeds are selected automatical-ly, depending on the position of the speed selec-tor lever. The selector lever has 2 gates; the maingate and the manual gate. NOTE: For information on manual gate operation,refer to "Sports Mode". In the main gate, the selector lever has 4 posi- tions, and is equipped with a button to avoidinadvertent wrong selection. NOTE:
Depress the brake pedal and push the button when shifting.Push the button when shifting.The selector lever can be shifted freely.
The first few shifts on a new vehicle, or if the battery has been disconnected, may be some-what abrupt. This is a normal condition, andthe shifting sequence will adjust after shiftsare cycled a few times by the T.C.M (Trans-mission Control Module). CAUTION: Never shift into "R" or "P" position while thevehicle is moving.
The indicator lights in the instrument cluster indicate the selector lever position when theignition is switched "ON". During "D" or sportsmode operation, the gear currently in use dis-plays in the numeral indicator.
C090A02L

DRIVING YOUR HYUNDAI 2- 7
C090F02GK-GAT Sports Mode
HGK175
Whether the vehicle is stationary or in motion, sports mode is selected by pushing the selectorlever from the "D" position into the manual gate.To return to "D" range operation, push the selec-tor lever back into the main gate.In sports mode, moving the selector lever back-wards and forwards can make rapid gearshiftssimple. In contrast to a manual transaxle, thesports mode allows gearshifts with the accelera-tor pedal depressed.UP (+) : Push the lever forward once to shift up
one gear.DOWN (-) : Pull the lever backwards once to shift
down one gear.
C090E01O-AAT
o D(Drive):Use for normal driving. The transaxle will auto- matically shift through a four gear sequence.
CAUTION:
o In sports mode, the driver must execute
shifts in accordance with prevailing roadconditions, taking care to keep the enginespeed below the red zone.
o For engine protection, upward shifts are made automatically when the engine rpmreaches the red zone.
o By rapidly moving the selector lever back- wards (-) twice it is possible to skip onegear by using the sports mode. Sincesudden engine braking and/or rapid ac-celeration can cause a loss of traction,however, downshifts must be made care-fully in accordance with the vehicle'sspeed.
NOTE:
o In sports mode, only the four forward gears can be selected. To reverse or parkthe vehicle, move the selector lever to the"R" or "P" position as required.
o In sports mode, downward shifts are made automatically when the vehicle slowsdown. When the vehicle stops, 1st gear isautomatically selected.
o To maintain the required levels of vehicle performance and safety, the system maynot execute certain gearshifts when theselector lever is operated.
C090H01L-GAT NOTE:
o For smooth and safe operation, depressthe brake pedal when shifting from "Neu- tral" position or "Park" position to a for-ward or reverse gear.
o The ignition key must be in the "ON" position and the brake pedal fully de-pressed in order to move the shift leverfrom the "P" (Park) position to any of theother positions.
o It is always possible to shift from "R", "N", "D" position to "P" position. The vehiclemust be fully stopped to avoid transaxledamage.
o Before driving away from a stop on a
slippery road, push the selector lever for-ward into the +(UP) position. This causesthe transaxle to shift into 2nd gear whichis better for smooth driving away on aslippery road. Push the selector lever tothe -(DOWN) side to shift back to 1st gear.

DRIVING YOUR HYUNDAI
2- 8 C130A01A-AAT GOOD BRAKING PRACTICES WARNING: Nothing should be carried on top of the shelfpanel behind the rear seat. If there were anaccident or a sudden stop, such objects couldmove forward and cause damage to the ve-hicle or injure the occupants.
o After being parked, check to be sure the
parking brake is not engaged and that the parking brake indicator light is out beforedriving away.
o Driving through water may get the brakes wet. They can also get wet when the car iswashed. Wet brakes can be dangerous! Yourcar will not stop as quickly if the brakes arewet. Wet brakes cause the car to pull to one
side. To dry the brakes, apply the brakeslightly until the braking action returns to nor-mal, taking care to keep the car under controlat all times. If the braking action does notreturn to normal, stop as soon as it is safe todo so and call your Hyundai dealer for assis-tance.
o Don't coast down hills with the car out of gear. This is extremely hazardous. Keep the car ingear at all times, use the brakes to slow down,then shift to a lower gear so that enginebraking will help you maintain a safe speed.
o Don't "ride" the brake pedal. Resting your foot on the brake pedal while driving can be dan-gerous because it can result in the brakes
overheating and losing their effectiveness. It
C090I01L-GAT CAUTION:
o Shift into "R" and "P" position only when
the vehicle has completely stopped.
o Do not accelerate the engine in reverse or any of the forward positions with the brakes applied.
o Always apply the footbrake when shifting from "P" or "N", to "R", "D"position.
o Do not use the "P" (Park) position in place of the parking brake. Always set the park-ing brake, shift the transaxle into "P" (Park)position and turn off the ignition whenyou leave the vehicle, even momentarily.Never leave the vehicle unattended whilethe engine is running.
o Check the automatic transaxle fluid level regularly, and add fluid as necessary.
C090N02O-AAT Good Driving Practices
o Never move the gear selector lever from "P" or "N" to any other position with the acceler- ator pedal depressed.
o Never move the gear selector lever into "P" when the vehicle is in motion.
o Be sure the car is completely stopped before you attempt to shift into "R".
o Never take the car out of gear and coast down a hill. This may be extremely hazardous.Always leave the car in gear when moving.
o Do not "ride" the brakes. This can cause them to overheat and malfunction. Instead, whenyou are driving down a long hill, slow down and shift to a lower gear. When you do this,engine braking will help slow the car.
o Slow down before shifting to a lower gear. Otherwise, the lower gear may not be en-gaged.
o Always use the parking brake. Do not depend on placing the transaxle in "P" to keep the carfrom moving.
o Exercise extreme caution when driving on a slippery surface. Be especially careful whenbraking, accelerating or shifting gears. On aslippery surface, an abrupt change in vehiclespeed can cause the drive wheels to losetraction and the vehicle to go out of control.
WARNING:
o Avoid high cornering speeds.
o Do not make quick steering wheel move- ments, such as sharp lane changes orfast, sharp turns.
o Always wear your seat belts. In a collision crash, un unbelted person issignificantly more likely to die than a per-son wearing a seatbelt.
o The risk of rollover is greatly increased if you lose control of your vehicle at high-way speeds.
o Loss of control often occurs if two or more wheels drop off the roadway and the driveroversteers to reenter the roadway.
o In the event your vehicle leaves the road- way, do not steer sharply. Instead, slowdown before pulling back into the travellanes.
o Never exceed posted speed limits.

DRIVING YOUR HYUNDAI 2- 9
also increases the wear of the brake compo- nents.
o If a tire goes flat while you are driving, apply the brakes gently and keep the car pointedstraight ahead while you slow down. When
you are moving slowly enough for it to be safeto do so, pull off the road and stop in a safeplace.
o If your car is equipped with an automatic transaxle, don't let your car creep forward. Toavoid creeping forward, keep your foot on thebrake pedal when the car is stopped.
o Use caution when parking on a hill. Engage the parking brake and place the gear selectorlever in "P" (automatic transaxle) or in first or
reverse gear (manual transaxle). If your car isfacing downhill, turn the front wheels into thecurb to help keep the car from rolling. If yourcar is facing uphill, turn the front wheels awayfrom the curb to help keep the car from rolling.If there is no curb or if it is required by otherconditions to keep the car from rolling, blockthe wheels.
o Under some conditions your parking brake can freeze in the engaged position. This ismost likely to happen when there is an accu-mulation of snow or ice around or near therear brakes or if the brakes are wet. If there isa risk that the parking brake may freeze,apply it only temporarily while you put thegear selector lever in "P" (automatic) or in firstor reverse gear (manual transaxle) and blockthe rear wheels so the car cannot roll. Thenrelease the parking brake. o Do not hold the vehicle on the upgrade with
the accelerator pedal. This can cause thetransmission to overheat. Always use thebrake pedal or parking brake.
C120A02A-AAT ANTI-LOCK BRAKE SYSTEM (If Installed) The Anti-Lock Brake System (ABS) is designed to prevent wheel lock-up during sudden brakingor on hazardous road surfaces. The ABS controlmodule monitors the wheel speed and controlsthe pressure applied to each brake. Thus, inemergency situations or on slick roads, ABS willincrease vehicle control during braking. NOTE: During ABS operation, a slight pulsation maybe felt in the brake pedal when the brakes areapplied. Also, a noise may be heard in theengine compartment while braking. Theseconditions are normal and indicate that theanti-lock brake system is functioning proper-ly. WARNING:Your ABS will not prevent accidents due toimproper or dangerous driving maneuvers.Even though vehicle control is improved dur-ing emergency braking, always maintain asafe distance between you and objects ahead.Vehicle speeds should always be reducedduring extreme road conditions.The braking distance for cars equipped withan anti-lock braking system may be longerthan for those without it in the following roadconditions.During these conditions the vehicle shouldbe driven at reduced speeds.
o Driving on rough, gravel or snow-covered
roads.
o Driving on with tire chains installed.
o Driving on roads where the road surface is pitted or has different surface height.
The safety features of an ABS equipped ve-hicle should not be tested by high speeddriving or cornering. This could endanger thesafety of yourself or others.

DRIVING YOUR HYUNDAI
2- 10 2) When the traction control system is oper-
ating properly, you can feel a slight pulsa- tion in the vehicle. This is only the effect ofbrake control and indicates nothing un-usual.
3) When the engine starts, a click is heard from the engine compartment; however,this is only the sound of traction controlbeing checked.
4) When moving out of the mud or fresh snow, pressing the accelerator pedal maynot cause the engine speed to increasedue to TCS operation.
C310D01O-AAT Indicators and Warning The indicators should illuminate when the igni- tion key is turned to ON or START but should goout after three seconds.If the indicators do not illuminate, or the TCS orTCS-OFF indicator does not go out after 3 sec-onds, have it checked by an authorized dealer. Should there be any unusual conditions in the device while driving, TCS-OFF indicator illumi-nates as a warning.If TCS-OFF indicator illuminates, pull your car toa safe place and stop the engine.Then, start the engine again to check if the TCS-OFF indicator goes out.
C300A03Y-GAT TRACTION CONTROL SYSTEM (TCS) (If installed)
HGK156A
CAUTION: When the TCS indicator blinks, SLIP controlhas been activated. It also means that theroad is slippery or your car is acceleratingexcessively. In this situation, gently releasefoot pressure from the accelerator pedal andmaintain moderate speed. WARNING: Traction control is only a driving aid; allnormal precautions for driving in inclementweather and on slippery road surfaces shouldbe observed.
On slippery road surfaces, the traction controlsystem (TCS) limits the drive wheels from spin-ning excessively, thus helping the car to acceler-ate. It also provides sufficient driving force andsteering performance as the car turns at acceler-ated speeds. SLIP Control Limits the drive wheels from spinning exces- sively during starting or while making accelerat-ed turns on slippery roads to avoid losing thedriving force of the front wheels. Driving hints TCS does not actively apply brakes. Be sure to decelerate the car sufficiently before enteringcurves. C310B01O-AAT TCS ON/OFF Mode When the TCS is running, the TCS indicator light in the instrument cluster will blink.If you turn the system off by pressing the TCSswitch, the TCS-OFF indicator light will come onand stay on. In the TCS-OFF mode, the SLIPcontrol will be deactivated. Adjust you drivingaccordingly. To turn the system back on, pressthe switch again. The TCS-OFF indicator lightshould go off. NOTE:
1) The TCS mode will automatically be turned
ON after the engine is turned off and re-started.

DRIVING YOUR HYUNDAI 2- 11
off your engine and restart only when you're ready to go.
o Remember, your Hyundai does not require extended warm-up. As soon as the engine isrunning smoothly, you can drive away. Invery cold weather, however, give your enginea slightly longer warm-up period.
o Don't "lug" or "over-rev" the engine. Lugging is driving too slowly in too high a gear result-ing in the engine bucking. If this happens, shiftto a lower gear. Over-revving is racing theengine beyond its safe limit. This can beavoided by shifting at the recommendedspeeds.
o Use your air conditioning sparingly. The air conditioning system is operated by enginepower so your fuel economy is reduced whenyou use it.
crease wear on these components. In addi-tion, driving with your foot resting on the brakepedal may cause the brakes to overheat,which reduces their effectiveness and maylead to more serious consequences.
o Take care of your tires. Keep them inflated to the recommended pressure. Incorrect infla-tion, either too much or too little, results inunnecessary tire wear. Check the tire pres-sures at least once a month.
o Be sure that the wheels are aligned correctly. Improper alignment can result from hittingcurbs or driving too fast over irregular surfac-es. Poor alignment causes faster tire wearand may also result in other problems as wellas greater fuel consumption.
o Keep your car in good condition. For better fuel economy and reduced maintenancecosts, maintain your car in accordance withthe maintenance schedule in Section 5. If youdrive your car in severe conditions, morefrequent maintenance is required (see Sec-tion 5 for details).
o Keep your car clean. For maximum service, your Hyundai should be kept clean and free ofcorrosive materials. It is especially importantthat mud, dirt, ice, etc. not be allowed toaccumulate on the underside of the car. Thisextra weight can result in increased fuel con-sumption and also contribute to corrosion.
o Travel lightly. Don't carry unnecessary weight in your car. Weight reduces fuel economy.
o Don't let the engine idle longer than neces- sary. If you are waiting (and not in traffic), turn C150A01A-AAT
SMOOTH CORNERING
Avoid braking or gear changing in corners, espe-cially when roads are wet. Ideally, corners shouldalways be taken under gentle acceleration. If youfollow these suggestions, tire wear will be held toa minimum. C160A01A-AAT WINTER DRIVING The more severe weather conditions of winter result in greater wear and other problems. Tominimize the problems of winter driving, youshould follow these suggestions:
If the indicator remains lit even after the enginehas been started, have your car checked by anauthorized Hyundai dealer. NOTE:
1) When the TCS-OFF indicator illuminates,
traction control is automatically deacti-vated for safety.
2) This warning function is not provided when the driver selects the TCS-OFF mode.
C140A01A-GAT DRIVING FOR ECONOMY You can save fuel and get more kilometers from your car if you follow these suggestions:
o Drive smoothly. Accelerate at a moderate rate. Don't make "jack-rabbit" starts or full- throttle shifts and maintain a steady cruisingspeed. Don't race between stoplights. Try toadjust your speed to that of the other traffic soyou don't have to change speeds unneces-sarily. Avoid heavy traffic whenever possible.Always maintain a safe distance from othervehicles so you can avoid unnecessary brak-ing. This also reduces brake wear.
o Drive at a moderate speed. The faster you drive, the more fuel your car uses. Driving ata moderate speed, especially on the high-way, is one of the most effective ways toreduce fuel consumption.
o Don't "ride" the brake or clutch pedal. This can increase fuel consumption and also in-

DRIVING YOUR HYUNDAI
2- 12 C160G01A-GAT To Keep Locks from FreezingTo keep the locks from freezing, squirt an ap- proved de-icer fluid or glycerine into the keyopening. If a lock is covered with ice, squirt it withan approved de-icing fluid to remove the ice. Ifthe lock is frozen internally, you may be able tothaw it out by using a heated key. Handle theheated key with care to avoid injury. NOTE: The proper temperature for using the immo-bilizer key is from -40°C to 80°C. If you heatthe immobilizer key over 80°C to open thefrozen lock, it may cause damage to thetransponder in its head. C160H01A-AAT Use Approved Anti-Freeze in Window Washer System To keep the water in the window washer system from freezing, add an approved anti-freeze solu-tion in accordance with instructions on the con-tainer. Window washer anti-freeze is availablefrom Hyundai dealers and most auto parts out-lets. Do not use engine coolant or other types ofanti-freeze as these may damage the finish.
C160B01A-GAT Snowy or Icy ConditionsTo drive your vehicle in deep snow, it may be necessary to use snow tires or to install tirechains on your tires. If snow tires are needed, itis necessary to select tires equivalent in size andtype to the original equipment tires. Failure to doso may adversely affect the safety and handlingof your car. Speeding, rapid acceleration, sud-den brake applications, and sharp turns arepotentially very hazardous practices. Duringdeceleration, use engine braking to the fullestextent. Sudden brake applications on snowy oricy roads may cause skids to occur. You need tokeep sufficient distance between the vehicle infront and your vehicle. Also, apply the brakegently. It should be noted that installing tire chainson the tire will provide a greater driving force, butwill not prevent side skids. NOTE: Tire chains are not legal in all provinces.Check province laws before fitting tire chains. C160C01A-AAT Use High Quality Ethylene Glycol Coolant Your Hyundai is delivered with high quality ethyl- ene glycol coolant in the cooling system. It is theonly type of coolant that should be used becauseit helps prevent corrosion in the cooling system,lubricates the water pump and prevents freezing.Be sure to replace or replenish your coolant in
C160D01F-AAT Check Battery and Cables Winter puts additional burdens on the battery system. Visually inspect the battery and cablesas described in Section 6 (See page 6-18). Thelevel of charge in your battery can be checkedby your Hyundai dealer or a service station. C160E01A-AAT Change to "Winter Weight" Oil if Necessary In some climates it is recommended that a lower viscosity "winter weight" oil be used during coldweather. See Section 9 for recommendations. Ifyou aren't sure what weight oil you should use,consult your Hyundai dealer. C160F01F-GAT Check Spark Plugs and Ignition Sys- tem Inspect your spark plugs as described in Section 6 (See page 6-8) and replace them if necessary.Also check all ignition wiring and components tobe sure they are not cracked, worn or damagedin any way.
accordance with the maintenance schedule inSection 5. Before winter, have your coolant test-ed to assure that its freezing point is sufficient forthe temperatures anticipated during the winter.

DRIVING YOUR HYUNDAI 2- 13
C170A01A-AAT HIGHER SPEED MOTORING Pre-Trip Inspections 1. Tires: Adjust the tire inflation pressures to specifica-tion. Low tire inflation pressures will result inoverheating and possible failure of the tires.Avoid using worn or damaged tires which mayresult in reduced traction or tire failure. NOTE: Never exceed the maximum tire inflation pres-sure shown on the tires. 2. Fuel, engine coolant and engine oil: High speed travel consumes more fuel thanurban motoring. Do not forget to check bothengine coolant and engine oil. 3. Drive belt: A loose or damaged drive belt may result inoverheating of the engine. C180A01A-AAT USE OF LIGHTS Check your lights regularly for correct operation and always keep them clean. When driving dur-ing the day in conditions of poor visibility, it ishelpful to drive with headlights on low beam. Thisenables you to be seen as well as to see.
C160I01A-AAT Don't Let Your Parking Brake FreezeUnder some conditions your parking brake can freeze in the engaged position. This is most likelyto happen when there is an accumulation of snowor ice around or near the rear brakes or if thebrakes are wet. If there is a risk the parking brakemay freeze, apply it only temporarily while youput the gear selector lever in "P" (automatic) or infirst or reverse gear (manual transaxle) andblock the rear wheels so the car cannot roll. Thenrelease the parking brake. C160K01A-AAT Carry Emergency Equipment Depending on the severity of the weather where you drive your car, you should carry appropriateemergency equipment. Some of the items youmay want to carry include tire chains, tow strapsor chains, flashlight, emergency flares, sand, ashovel, jumper cables, a window scraper, gloves,ground cloth, coveralls, a blanket, etc.
C160J01A-AAT Don't Let Ice and Snow Accumulate Underneath Under some conditions, snow and ice can build up under the fenders and interfere with the steer-ing. When driving in severe winter conditionswhere this may happen, you should periodicallycheck underneath the car to be sure the move-ment of the front wheels and the steering compo-nents is not obstructed.
C190B01S-AAT Trailer Hitches Select the proper hitch and ball combination, making sure that it's location is compatible withthat of the trailer or vehicle being towed.Use a quality non-equalizing hitch which distrib-utes the tongue load uniformly throughout thechassis. The hitch should be bolted securely to the car and installed by a qualified technician. DO NOTUSE A HITCH DESIGNED FOR TEMPORARYINSTALLATION AND NEVER USE ONE THATATTACHES ONLY TO THE BUMPER.
C190A01A-GAT TRAILER OR VEHICLE TOWINGIf you are considering towing with your car, you should first check with your Province Depart-ment of Motor Vehicles to determine their legalrequirements.Since laws vary from province to province, therequirements for towing trailers, cars, other typesof vehicles, or apparatus may differ. Ask yourHyundai dealer for further details before towing. CAUTION Do not do any towing with your car during itsfirst 2,000 km (1,200 miles) in order to allowthe engine to properly break in. Failure toheed this caution may result in serious en-gine or transaxle damage.

DRIVING YOUR HYUNDAI
2- 14 2. The total gross vehicle weight with trailer
must not exceed the Gross Vehicle Weight Rating (GVWR) shown on the vehicle iden-tification plate (see page 8-1). The totalgross vehicle weight is the combinedweight of the vehicle, driver, all passen-
gers and their luggage, cargo, hitch, trailertongue load and other optional equip-ment.
3. The front or rear axle weight must not exceed the Gross Axle Weight Rating(GAWR) shown on the vehicle identifica-tion plate (see page 8-1). It is possible thatyour towing package does not exceed theGVWR but exceeds the GAWR. Improper
trailer loading and/or too much luggage inthe trunk can overload the rear axle. Re-distribute the load and check the axleweight again.
SSA2200DGross Axle Weight Gross Vehicle Weight
C190C02Y-GAT Trailer BrakesIf your trailer is equipped with a braking system, make sure it conforms to federal and/or localregulations and that it is properly installed andoperating correctly. NOTE: If you tow a trailer or vehicle, your car willrequire more frequent maintenance due tothe additional load. See "Maintenance UnderSevere Usage Conditions" on page 5-4. CAUTION:
o Never connect a trailer brake system di-
rectly to the vehicle brake system.
o When towing a trailer on steep grades (in excess of 12%) pay close attention to theengine coolant temperature gauge to en-
sure the engine does not overheat. If theneedle of the coolant temperature gauge
moves across the dial towards "H" (HOT),pull over and stop as soon as it is safe todo so, and allow the engine to idle until itcools down. You may proceed once theengine has cooled sufficiently.
C190D01A-GAT Safety Chains Should the hitch connection between your car and the trailer or vehicle you are towing fail, thetrailer or vehicle could wander dangerously acrossother lanes of traffic and ultimately collide with another vehicle. To eliminate this potentially dan-gerous situation, safety chains, attached be-tween your car and the trailer or towed vehicle,are required in most provinces. C190E01GK-GAT Trailer Weight Limit
Tongue load Total trailer weightSSA2200B
Tongue loads can be increased or decreased by redistributing the load in the trailer. This can be
verified by checking the total weight of the loadedtrailer and then checking the load on the tongue. NOTE:
1. Never load the trailer with more weight in the back than in the front. About 60% ofthe trailer load should be in the front halfon the trailer and the remaining 40% in therear.

DRIVING YOUR HYUNDAI 2- 15
Maximum
Towable Weight Trailer550
1,200 1,400
CAUTION: The following specifications are recom-
mended when towing a trailer. The loadedtrailer weight cannot safely exceed the val-ues in the following chart.
kg
With Brake Type1.6 L
2.0/2.7 L
4. The maximum permissible static vertical
load on the coupling device:
WARNING: Improperly loading your car and trailer can
seriously affect its steering and braking per-formance causing a crash which you may be
serious injury or death.Without Brake Type
Coupling point
HGK260
1.6 L
2.0/2.7 L 50 kg 60 kg
View from below the vehicle
5. The maximum permissible overhang of
the coupling point : 990 mm.
C190F01A-GAT Trailer or Vehicle Towing Tips
1. Before towing, check hitch and safety chainconnections as well as proper operation of the trailer running lights, brake lights, and turnsignals.
2. Always drive your vehicle at a moderate speed (Less than 100 km/H).
3. Trailer towing requires more fuel than normal conditions.
4. To maintain engine braking efficiency and electrical charging performance, do not usefifth gear (manual transaxle) or overdrive(automatic transaxle).
5. Always secure items in the trailer to prevent load shift while driving.
6. Check the condition and air pressure of all tires on the trailer and your car. Low tirepressure can seriously affect the handling.Also check the spare tire.
7. The vehicle/trailer combination is more af- fected by crosswind and buffeting.When being passed by a large vehicle, keepa constant speed and steer straight ahead. Ifthere is too much wind buffeting, slow down toget out of the other vehicle's air turbulence.
8. When parking your car and trailer, especially on a hill, be sure to follow all the normalprecautions. Turn your front wheel into thecurb, set the parking brake firmly, and put thetransmission in 1st or Reverse (manual) orPark (automatic). In addition, place wheelchocks at each of the trailer's tires.
