FEATURES OF YOUR HYUNDAI 1- 73
You should then release the button, and pro- ceed to program the next desired station. Atotal of 18 stations can be programmed byselecting one AM and two FM stations perbutton.
o When completed, any preset station may be recalled by selecting AM, FM1 or FM2 bandand the appropriate station button.
CAUTION:
o Do not place beverages close to the audio system. The audio system mechanism maybe damaged if you spill them.
o Do not impact on the audio system, or the audio system mechanism could be dam-aged.

FEATURES OF YOUR HYUNDAI
1- 74
H260B01O-AAT COMPACT DISC PLAYER OPERATION (H260) (If Installed) H260A01O
1.Playing CD
2. FF/REW Button
3. TRACK UP/DOWN
4. SCAN Button
5. REPEAT Button
6. EJECT Button

FEATURES OF YOUR HYUNDAI 1- 75
B260D02O-AAT
1. Playing CD
o Insert the CD with the label facing upward.
o Insert the CD to start CD playback, during
radio operation.
o When a disc is in the CD deck, if you press the play button, the CD player will begin playingeven if the radio is being used.
o The CD player can be used when the ignition switch is in either the "ON" or "ACC" position.
2. FF/REW ( / ) If you want to fast forward or reverse through the compact disc track, push and hold the FF ( )or REW ( ) button.When you release the button, the compact discplayer will resume playing.
3. TRACK UP/DOWN
o The desired track on the disc currently being played can be selected using the track num- ber.
o Press once to skip forward to the beginn- ing of the next track. Press once to skipback to the beginning of the track.
4. SCAN Button
o Press the SCAN button to playback the first 10 seconds of each track.
o Press the SCAN button again within 10 sec. when you have reached the desired track. 5. REPEAT Button
o To repeat the track you are currently listening
to, press the RPT button. To cancel , press again.
o If you do not release RPT operation when the track ends, it will automatically be replayed.This process will be continued until you pushthe button again.
6. EJECT Button When the EJECT button is pressed with a CD loaded, the CD will eject. NOTE:
o If the CD does not operate properly or if the ER2 fault code is displayed, use one oftwo methods to reset the CD deck func-tion.
- Remove the audio fuse for 5 minutes.Then, reinstall the audio fuse.
- Diconnect the negative terminal of the battery and wait 5 minutes. Then re-connect the negative battery terminal.
o To assure proper operation of the unit, keep the vehicle interior temperaturewithin a normal range by using thevehicle's air conditioning or heating sys-tem.
o When replacing the fuse, replace it with a fuse having the correct capacity.
o The preset station frequencies are allerased when the car battery is discon- nected. Therefore, all data will have to beset again if this should occur.
o Do not add any oil to the rotating parts. Keep magnets, screwdrivers and othermetallic objects away from the tape mecha-nism and head.
o This equipment is designed to be used only in a 12 volt DC battery system withnegative ground.
o This unit is made of precision parts. Do not attempt to disassemble or adjust anyparts.
o When driving your vehicle, be sure to keep the volume of the unit set low enough toallow you to hear sounds coming from theoutside.
o Do not expose this equipment (including the speakers) to water or excessive mois-ture.

FEATURES OF YOUR HYUNDAI
1- 76
CAUTION:
o Do not insert warped or poor quality discs
into the CD player as damage to the unitmay occur.
o Do not insert anything like coins into the player slot as damage to the unit mayoccur.
o Do not place beverages close to the audio system. The playback mechanism may bedamaged if you spill them.
o Do not impact on the audio system, or the playback mechanism could be damaged.
o Driving on the off-roads or other vibra- tions may skip your compact disc.Do not use the audio system on off-roadsas the discs could be scratched and dam-aged.
o Do not grip or pull out the disc with your hand while the disc is being pulled into theunit by the self loading mechanism. Thesecan cause poor disc scratching to occuror trouble in the compact disc player.
o Avoid using CD-Recordable or CD- Rewritable as the player could not be op-erated in recording way of the CD maker.When using the compact disc player, genu-ine CDs are recommended.

FEATURES OF YOUR HYUNDAI 1- 77
B260E01E-AAT
CD AUTO CHANGER (H260) (If Installed) H260A01O
1. CD Select Button
4. FF/REW Button
3. TRACK UP/DOWN
6. SCAN Button
5. REPEAT Button
2. DISC Select Button

FEATURES OF YOUR HYUNDAI
1- 78
B260F02GK-AAT The CD auto changer is located in the right side of the quarter trim.
o To use the CD auto changer. 1. Open the sliding lid of the CD auto chang- er.
2. To eject the compact disc magazine, press the EJECT button located inside the CD auto changer.
3. Insert the discs into the magazine.
4. Push the magazine into the CD auto chang- er and close the sliding lid.
o The CD auto changer can be used when the ignition switch is in either the "ON" or "ACC"position.
1. CD Select Button When the CD changer magazine contains discs, press the "CD" button and the CD changer canbe used even if the radio is being used. TheHyundai CD changer can hold up to eight discs.The disc number will be lit, and the track number,and elapsed time will be displayed. 2. DISC Select Button To select the CD you want, push " " to change the disc number. o This unit is made of precision parts. Do
not attempt to disassemble or adjust anyparts.
o When driving your vehicle, be sure to keep the volume of the unit set low enough toallow you to hear sounds coming from theoutside.
CAUTION:
o Do not insert warped or poor quality discs into the CD changer as damage to the unitmay occur.
o Do not insert anything like coins into the changer slot as damage to the unit mayoccur.
o Do not place beverages close to the audio system. The playback mechanism may bedamaged if you spill them.
o Do not impact on the audio system, or the playback mechanism could be damaged.
o Driving on the off-roads or other vibra- tions may skip your compact disc.Do not use the audio system on off-roadsas the discs could be scratched and dam-aged.
o Do not grip or pull out the disc with your hand while the disc is being pulled into theunit by the self loading mechanism. Thesecan cause poor disc scratching to occuror trouble in the compact disc changer.
o Avoid using CD-Recordable or CD- Rewritable as the changer could not beoperated in recording way of the CD maker.When using the compact disc changer,genuine CDs are recommended.
TUNEDISC
3. TRACK UP/DOWN
o The desired track on the disc currently being
played can be selected using the track num- ber.
o Press once to skip forward to the begin- ning of the next track. Press once to skipback to the beginning of the track.
4. FF/REW ( / ) If you want to fast forward or reverse through the compact disc track, push and hold in the FF ( )or REW ( ) button.When you release the button, the compact discplayer will resume playing. 5. REPEAT
o To repeat the track you are listening to, press the RPT button. To cancel , press again.
o If you do not release RPT operation when the track ends, it will automatically be replayed. This process will be continued until you pushthe button again.
6. SCAN Button
o Press the SCAN button to playback the first 10 seconds of each track.
o Press the SCAN button again within 10 sec. for the desired track.
NOTE:
o When replacing the fuse, replace it with a fuse having the correct capacity.
o This equipment is designed to be used only in a 12 volt DC battery system withnegative ground.

FEATURES OF YOUR HYUNDAI 1- 79
B890A01Y-AAT AUDIO FAULT CODE
If you see any error indication in the display while using the system in the CD or Tape mode, find the cause in the chart below. If you cannot clear the error indication, take the car to your Hyundai dealer.
INDICATION
CAUSE SOLUTION
Er2 Er3 Er6 Er8HHHno CD CD DECK MECHANICAL ERROR (EJECT ERROR, LOADING ERROR) FOCUS ERROR DATA READ ERROR DISC ERRORTAPE DECK ERROR TAPE EJECT ERROR TEMPERATURE IS TOO HIGH NO DISC IN MAGAZINE NO CD MAGAZINE IN THEAUTO CHANGER AFTER RESETTING THE AUDIO SYSTEM, PUSH THE EJECT BUTTON.IF DISC IS NOT EJECTED, CONSULT YOUR HYUNDAI DEALER. MAKE SURE THE DISC IS NOT SCRATCHED OR DAMAGED. PRESS THE EJECT BUTTON AND PULL OUT THE DISC. THEN INSERT ANORMAL CD DISC. CHECK IF THE DISC IS INSERTED CORRECTLY IN THE CD PLAYER. MAKE SURE THE DISC IS NOT SCRATCHED OR DAMAGED. AFTER RESETTING THE AUDIO SYSTEM, PUSH THE EJECT BUTTON. IF TAPE DOES NOT EJECT, CONSULT YOUR HYUNDAI DEALER. FAULT CODE WILL RESET AUTOMATICALLY WHEN THE TEMPERA- TURE RETURNS TO NORMAL. INSERT DISC IN MAGAZINE OR INSERT CD MAGAZINE IN THE AUTO CHANGER.

FEATURES OF YOUR HYUNDAI
1- 80
B260A01GK-GAT INFINITY SOUND SYSTEM (B260)(If installed) B260A01GK
1. On/Off Switch ( )
2. Tone Button ( )
3. Road traffic announcement button( )
4. Operating mode switching button (
Mode) 5. Function button (
Function)
6. Waveband switching button ( Band)
7. CD eject button ( )
8. Volume control 9. Multifunction buttons
10. Display
11. Right rotary control
1
2
3 4
56 7
8 9 10 11

FEATURES OF YOUR HYUNDAI 1- 81
B260B01GK
B260B01GK-GAT ANTI-THEFT DEVICE
1. Remove portable panel As an effective anti-theft device, the portable panel can be removed from unit. For this pur-pose, press and hold button. The display hasbeen folded down.After 20 seconds an audible signal indicates thatthe control component is folded down. The unit isswitched to mute.The unit switches off after a further 10 seconds. NOTE:
o For safety reasons, it is not permissible to
leave the portable panel open when driv-ing.
o Please insert the portable panel in the accompanying protective Cover after re-moval. 2. Inserting portable panel Insert the portable panel so that it engages first in the lower left catch and then in the lower right.Then press the portable panel into the uppercatches. Or position portable panel directly overall four catches and press in firmly to engage. Forproper functioning, ensure that the portable panelis firmly engaged in all four catches.
B260B02GK
B260C01GK-GAT GENERAL OPERATION
1.Switch On / Off Press the button
to switch the power on. To
switch the power off, press the button again.
2. Adjust Volume Turn volume control to right / left. The volume is increased or decreased. The current volumelevel is shown on the display.
3. Mute Function The unit can be switched to mute in each opera- tion mode by pressing the volume control. MUTEappears on the display.The mute function is cancelled by pressing thevolume control, changing the operation mode,changing the waveband or inserting a CD 4. Activate Tone menu Press
button. The tone menu is activated.
The following functions can be called up: BASS (Bass), TREB (Treble), BAL (balance), FAD(Fader), LOUD (Loudness) and STEREO (Re-ception optimization).Bass and treble setting for the AM / FMwavebands, for road traffic announcements andCD operation are stored separately (values form-7 to +7). The setting for fader balance andloudness (no loudness with AM) are stored to-gether for all operating modes (values from -7 to+7).
5. Adjust Bass Press
button and then multifunction button
(1) "-" or "+". BASS and the set value are dis- played. Set the desired bass via both buttons. Center setting: Press both buttons simulta- neously.
(1) (2) (3) (4) (5) (6)
Portable panel

FEATURES OF YOUR HYUNDAI
1- 82
6.Adjust Treble Press
button and then multifunction button
(2) "-" or "+". TREB and the set value are dis- played. Set the desired treble via both buttons. Center setting: Press both buttons simulta- neously.
7. Adjust Balance Press
button and then multifunction button (3)
" " or " ". BAL and the set value are displayed. Set the desired balance via both buttons. Center setting: Press both buttons simulta- neously.
8. Fader Press
button and then multifunction button (4)
" " or " ". FAD and the set value are displayed. Set the desired fade level via both buttons. Center setting: Press both buttons simulta- neously.
9. Loudness On / Off Press
button and then multifunction button (5)
"LD". LOUD ON or LOUD OFF are displayed. The loudness can be switched on or off alter-nately by pressing the multifunction button.
10.Linear Adjustment It controls the amplification ratio from high to low tone. Activate tone menu. Then again press andhold button
for more than 2 seconds. The
tone values for the set signal source (e.g. radio/ FM) are set to an average value FM LINEAR.Press and hold
button for more than 4 sec-
onds. All tone values for the signal sources radio and tape /CD are set to an average value ALLLINEAR. 11.Adjust Mono /Stereo Three different reception optimization setting can be set in order to suppress reception dependentinterference and reflections.Repeatedly press multifunction button (6) "ST" intone menu until the desired optimization is set. AUTO: Setting for normal operation - i.e., the unit switches from stereo to mono and back depend-ing upon reception location (provides the opti-mum setting for almost all reception areas). STEREO: Setting for unusual reception situa- tions - i.e. the unit is set permanently to stereo(e.g. for private radio stations in city areas) MONO: Setting for reception conditions in which reflections constantly occur - i.e., the unit is setconstantly to mono.The setting is effective immediately after press-ing the multifunction button "ST" and is alsoretained on switching off.
B260D01GK-GAT RADIO OPERATION
1. Select operating Mode Press
Button. The operating mode. Radio,
CD can be selected. The last selected operating mode is selectedafter the button is pressed for the first time. If theother operating modes are to be selected, pressthe
button quickly and repeatedly until the
desired operating mode is selected.
2. Select Waveband Press
button repeatedly until desired
waveband FM 1, FM 2 or AM is selected. When changing the waveband, the last selected stationis selected.
3. Switch on radio menu mode Press
button. The radio menu mode is
switched on and displayed, The unit switches back to the normal display if no buttons arepressed within the next 8 seconds.
4. Radio Operation Setting procedures for station selection. The desired broadcasting station can be se-lected via station search, manual tuning,autostore, direct frequency input and stationbuttons.
