FEATURES OF YOUR HYUNDAI 1- 59
The trip computer is the microcom- puter-controlled driver informationgauge that displays information re- lated to driving, such as outside tem- perature distance to empty, drive dis-tance and average consumption on the LCD.
B400B01TB
B400B03TB-GAT TRIP COMPUTER (If Installed)
TRIP A:
Distance you have traveled
from your origination point to a first destination.TRIP B: Distance from the first destina-
tion to the final destination. To shift from TRIP A to TRIP B, press the trip switch. When pressed for 1 second, it will reset to 0.
OUTSIDE TEMPERATUREDISTANCE TO EMPTY
AVERAGE CONSUMPTION DRIVE DISTANCE
Trip Computer Switch
o The trip computer switch is used tozero the multi-functional display mode.
o Pushing in the trip computer switch changes the display as follows;
B400B06TB
B400B03TB
1. Outside temperature This mode indicates the outside tem- perature between -40 C (-40 F) and
75 C (167 F) .
2. Distance to empty
B400B02TB

1- 60 FEATURES OF YOUR HYUNDAI
B400B04TB
4. Drive Distance
o This mode indicates the drive dis-
tance travelled since the last drive time reset.
o Pressing the trip computer switch for more than 1 second, when the drivedistance is being displayed, clearsthe drive distance to zero.
Total Fuel Consumption(L) x 100 Total Cruise Distance (km)B400B05TB
MPG =
L/100km = Total Cruise Distance(Miles) Total Fuel Consumption (G)
o This mode indicates the estimated
distance to empty from the current fuel in the fuel tank and distance toempty symbol.
o When refueling with more than 6
liters, the trip computer will recog-nize refueling.
o When the battery has been rein-
stalled after being discharged ordisconnected, drive more than 64km for an accurate distance to empty.
NOTE:
o When the distance to empty is less than 50 km, the symbol will al- ways come on and the distance toempty digits will indicate "---" with flash until more fuel is added.
o The distance to empty can differ
from the actual tripmeter accord-ing to driving conditions.
o The distance to empty can vary
according to the driving condi-tions, driving pattern or vehicle speed. 3. Average Consumption
o This mode indicates the average
consumption since the data reset.
o It displays per 10 seconds after you
drive over 50m and 10 seconds.
o Calculation Method

FEATURES OF YOUR HYUNDAI 1- 61
B340A01A-AAT COMBINATION TURN SIGNAL, HEADLIGHT AND HIGH-BEAMSWITCHTurn Signal Operation Pulling down on the lever causes the turn signals on the left side of the car to blink. Pushing upwards on the lever causes the turn signals on the rightside of the car to blink. As the turn is completed, the lever will automatically return to the center position and turnoff the turn signals at the same time. If either turn signal indicator light blinks more rapidly than usual, goes on butdoes not blink, or does not go on at all, there is a malfunction in the system. Check for a burned-out fuse or bulb orsee your Hyundai dealer.
OMC049600
B340B01A-AAT Lane Change Signal
To indicate a lane change, move the lever up or down to a point where it begins flashing.The lever will automatically return to the center position when released.OMC049601
B340C04FC-GAT Headlight Switch To operate the headlights, turn the bar- rel on the end of the multi-function switch. The first position turns on theparking lights, sidelights, tail lights and instrument panel lights. The second position turns on the headlights. NOTE: The ignition must be in the "ON" position to turn on the headlights.

1- 62 FEATURES OF YOUR HYUNDAI
B340D01A-AAT High-beam Switch
B340F01A-GATDaytime Running Lights (If Installed) Your Hyundai is equipped with day- time running lights. The daytime run- ning lights are used to improve visibil-ity for oncoming traffic. Your vehicle daytime running lights are designed to remain on continuously when the en-gine is operating even though the head- light switch is in the "OFF" position. However, the daytime running lightswill be off while the parking brake is applied.
Parking light auto cut (If installed)
o The purpose of this feature is to
prevent the battery from being dis- charged. The system automatically turns off the small light when the driver re-moves the ignition key and opens the driver- side door.
o With this feature, the parklight will be turned off automatically if the driverparks on the side of road at night.
If necessary, to keep the lights on whenthe ignition key is removed, perform the following :
1) Open the driver-side door.
2) Turn the parklights OFF and ON again using the light switch on the steering column. To turn on the headlight high beams, push the lever forward (away from you). The high beam indicator light willcome on at the same time. For low beams, pull the lever back toward you.
OSA049093

FEATURES OF YOUR HYUNDAI 1- 63
A : Wiper speed control
·
– Single wipe
· 0 – Off · --- – Intermittent wipe · 1 – Low wiper speed· 2 – High wiper speed
B : Intermittent wipe time adjustment
C : Wash with brief wipes
D : Rear wiper/washer control ·
- Wash with brief wipes
·
- Continuous wipe
· O - Off
OSA049094
B340E01A-AAT Headlight Flasher To flash the headlights, pull the switch lever toward you, then release it. The headlights can be flashed even thoughthe headlight switch is in the "OFF" position.
OMC048901/OSA049904L
Rear window wiper/washer (if installed)
Windshield wiper/washer
B350A01TB-GAT WINDSHIELD WIPER AND WASHER SWITCH

1- 64 FEATURES OF YOUR HYUNDAI
NOTE:
o Do not operate the washer more
than 15 seconds at a time or when the fluid reservoir is empty.
o In icy or freezing weather, be sure the wiper blades are not frozen tothe glass prior to operating thewipers.
o In areas where water freezes in
winter, use windshield washerantifreeze.
The windshield wiper switch has threepositions:
1. Intermittent wiper operation
2. Low-speed operation
3. High-speed operation To use the windshield washer, pull the wiper/washer lever toward the steer- ing wheel. When the washer lever is operated, the wipers automaticallymake two passes across the wind- shield. The washer continues to oper- ate until the lever is released.
B350B01O-GAT Windshield Washer Operation
NOTE: To prevent damage to the wiper system, do not attempt to wipe away heavy accumulations of snow orice. Accumulated snow and ice should be removed manually. If there is only a light layer of snow orice, operate the heater in the defrost mode to melt the snow or ice before using the wiper.
OMC048902OMC048903
B350A01A-AAT Windshield wiper

FEATURES OF YOUR HYUNDAI 1- 65
Mist Wiper Operation
If a single wipe is desired in mist, push the windshield wiper and washer con- trol lever upwards.
OMC048904 B350C01FC-GAT Adjustable Intermittent Wiper Operation (If Installed) To use the intermittent wiper feature, place the wiper switch in the "---" position.With the switch in this position, the interval between wipes can be varied from approximately 1 to 18 seconds byturning the interval adjuster barrel (1).
OMC048905B350A01TB-AAT Tail Gate Wiper And Washer Switch (If installed) 1.
: The washer fluid will be sprayed
onto the rear window and the wiper operates while the rear win- dow wiper barrel is placed in thisposition.
2.
: When the point indicates "ON", the rear window wiper op- erates continuously.
3. O
OSA049905L

1- 66 FEATURES OF YOUR HYUNDAI
CAUTION:
Do not clean the inner side of the rear window glass with an abrasive type of glass cleaner or use a scraper to remove foreign deposits fromthe inner surface of the glass as this may cause damage to the de- froster elements. NOTE: The engine must be running for the rear window defroster to operate.!
B380A01HP-AAT REAR WINDOW DEFROSTER SWITCH The rear window defroster is turned on by pushing in on the switch. To turn thedefroster off, push in on the switch a second time. The rear window de- froster automatically turns itself off af-ter about 20 minutes. To restart the defroster cycle, push in on the switch again after it has turned itself off. HTB039B370A01A-AAT HAZARD WARNING SYSTEM The hazard warning system should be used whenever you find it necessary to stop the car in a hazardous location.When you must make such an emer- gency stop, always pull off the road as far as possible.The hazard warning lights are turned on by pushing in on the hazard switch. This causes all turn signal lights toblink. The hazard warning lights will operate even though the key is not in the ignition.To turn the hazard warning lights off, push in on the switch a second time.
HTB2031

FEATURES OF YOUR HYUNDAI 1- 67
HTB2030
B360B01FC-GAT FRONT FOG LIGHT SWITCH (If Installed)
To turn on the front fog lights, push the switch in the "ON" position. They will come on when the headlight switch isin the first or second position.
B360A01Y-GAT REAR FOG LIGHT SWITCH (If Installed)
To turn on the rear fog lights, push the switch. They will come on when the headlight switch is in the second posi-tion and the key is in the "ON" position. B360A01TBB400A01A-AAT DIGITAL CLOCK
HTB2033
There are three control buttons for the digital clock. Their functions are: HOUR -Push "H" to advance the hour
indicated.
MIN -Push "M" to advance the
minute indicated.
RESET - Push "R" to reset minutes to
":00" to facilitate resetting the clock to the correct time. When this is done:
Pressing "R" between 10 : 30 and 11 :29 changes the readout to 11 : 00. Pressing "R" between 11 : 30 and 12 :29 changes the readout to 12 : 00.

1- 68 FEATURES OF YOUR HYUNDAI
B500D01TG-GAT POWER OUTLET (If installed)
OHTB029040L
These supply 12V electric power to operate electric accessories or equip- ment only when the key is in the "ON" or "ACC" position.
CAUTION:
Do not use electric accessories or equipment other than the Hyundai genuine parts in the socket.
!
B420A02A-AAT CIGARETTE LIGHTER (If Installed) For the cigarette lighter to work, the key must be in the "ACC" position or the"ON" position. To use the cigarette lighter, push it all the way into its socket. When the ele-ment has heated, the lighter will pop out to the "ready" position. Do not hold the cigarette lighter pressedin. This can damage the heating ele- ment and create a fire hazard. If it is necessary to replace the ciga-rette lighter, use only a genuine Hyundai replacement or its approved equivalent. HHR2098A
