TPMS HYUNDAI I10 2022 Owners Manual

Modification to the original vehicle specification may invalidate the man-
ufacturers warranty and may adversely affect the safety and durability of
the vehicle.
Components which are subject to modification or are added to the origi-
nal vehicle specification without the express approval of the manufac-
turer and result in consequential loss or damage are not covered by the
vehicle manufacturers warranty.
Particular attention is drawn to the fitment of replacement road wheels
having a different specification to those installed in production. The elec-
tric power assisted steering system is specifically programmed to oper-
ate only with the road wheels fitted during production. The installation of
alternative specification road wheels may result in the replacement road
wheels fouling the vehicle body resulting in tyre damage and compro-
mised safety. The installation of after market wheels on vehicles
equipped with TPMS may result in wheel balancing difficulties or mal-
function of the TPMS system.
We recommend that you contact a HYUNDAI authorised repairer before
non original specification road wheels are installed.
CAUTION: MODIFICATIONS TO ORIGINAL VEHICLE
SPECIFICATION
This vehicle is fitted with electronically controlled fuel injection or other
micro processor controlled equipment.
It is possible for incorrectly installed two way radio equipment including
mobile telephones to adversely affect these systems.
Before radio equipment of this kind is installed, we recommend that you
contact your HYUNDAI authorised repairer for recommendation regard-
ing the suitability of the particular radio equipment concerned and the
recommended method of installation and equipment location. Incorrectly
installed or unsuitable equipment which gives rise to incorrect function-
ing of or damage to electronic vehicle components will not fall within the
scope of the vehicle manufacturers warranty.
TWO WAY RADIO INSTALLATION

2-4
Vehicle information
INTERIOR OVERVIEW
The actual shape may differ from the illustration.
OAC3019003R
1. Door handle .......................................................................................................... 5-15
2. Outside rearview mirror control switch . ............................................................... 5-25
3. Power window switches ...................................................................................... 5-26
4. Power window lock switch.................................................................................... 5-30
5. Lane Keeping Assist system button* .................................................................... 6-62
6. Tyre Pressure Monitoring System (TPMS) button* ............................................. 7-10
7. Electronic Stability Control (ESC) ........................................................................ 6-37
8. Headlight levelling device ..................................................................................... 5-43
9. Fuse box............................................................................................................... 8-52
10. Key ignition switch ................................................................................................ 6-7
Engine Start/Stop button* ................................................................................... 6-10
11. Steering wheel .................................................................................................... 5-20
12. Bonnet release lever .......................................................................................... 5-30
)XHO

4-14
Instrument cluster
NOTICE
If the light comes on continuously
after adding the engine oil and
travelling approximately 50~100
km after the engine warms up, we
recommend that the system be
checked by a HYUNDAI authorised
repairer.
Even if this light doesn't come on
after the engine has started, the
engine oil should be checked and
supplied periodically.
Low Fuel Level
Warning Light
7his warning light illuminates
‡When the fuel tank is nearly empty.
Add fuel as soon as possible.
NOTICE
Driving with the Low Fuel Level
warning light on or with the fuel
level below “0” can cause the
engine to misfire and damage the
catalytic converter (if equipped).
Master Warning Light
7his indicator light illuminates
‡When there is a malfunction in
operation in any of the following
systems:
- Forward Collision-Avoidance
Assist system malfunction (if
equipped)
- Forward Collision-Avoidance
Assist radar blocked (if equipped)
- Lamp malfunction (if equipped)
- High Beam Assist malfunction (if
equipped)
- Tire Pressure Monitoring System
(TPMS) malfunction (if equipped)
To identify the details of the warning,
look at the LCD display.

4-15
04
Low Tire Pressure
Warning Light
(if equipped)
7his warning light illuminates
‡When you set the ignition switch or
Engine Start/Stop button to the ON
position.
- It illuminates for approximately 3
seconds and then goes off.
‡When one or more of your tyres are
significantly underinflated (The
location of the underinflated tyres
are displayed on the LCD display).
For more details, refer to “Tyre
Pressure Monitoring System
(TPMS)” in chapter 7.
7his warning light remains on after
blinking for appro[imately 6 sec-
onds or repeatedly blinks on and off
at appro[imately 3 second intervals
‡When there is a malfunction with
the TPMS.
In this case, we recommend that
you have the vehicle inspected by a
HYUNDAI authorised repairer as
soon as possible.
For more details, refer to “Tyre
Pressure Monitoring System
(TPMS)” in chapter 7.
WARNING
Safe Stopping
‡The TPMS cannot alert you to
severe and sudden tyre damage
caused by external factors.
‡If you notice any vehicle instabil-
ity, immediately take your foot
off the accelerator pedal, apply
the brakes gradually with light
force, and slowly move to a safe
position off the road.
Exhaust System (GPF)
Warning Light
(Petrol Engine,
if equipped)
7his warning light illuminates

4-23
04
Low Tyre Pressure (if equipped)
OAC3079037R
This warning message is displayed if
the tyre pressure is low. The corre-
sponding tyre on the vehicle will be
illuminated.
For more details, refer to “Tyre
Pressure Monitoring System
(TPMS)” in chapter 7.
Heated Steering Wheel turned
off (if equipped)
This message illuminates if the heat-
ed steering wheel will turn off auto-
matically approximately 30 minutes
after the heated steering wheel is
turned on.
For more details, refer to “Heated
Steering Wheel” in chapter 5.
Low fuel
This warning message is displayed if
the fuel tank is almost out of fuel.
When this message is displayed, the
low fuel level warning light in the clus-
ter will come on.
It is recommended to look for the
nearest fueling station and refuel as
soon as possible.

4-28
Instrument cluster
Trip computer mode
OAC3069039R
The trip computer mode displays
information related to vehicle driving
parameters including fuel economy,
tripmeter information and vehicle
speed.
For more details, refer to "Trip
Computer" in this chapter.
Driving Assist mode
OAC3069013TU
L.A/'AW/ISLW
This mode displays the state of the
Lane Keeping Assist, Driver Attention
Warning and Intelligent Speed Limit
Warning.
For more details, refer to each sys-
tem information in chapter 6.
Master warning mode
OAC3069028TU
This warning light informs the driver
the following situations.
- Forward Collision-Avoidance Assist
system malfunction (if equipped)
- Forward Collision-Avoidance Assist
radar blocked (if equipped)
- Lamp malfunction (if equipped)
- High Beam Assist malfunction (if
equipped)
- Tyre Pressure Monitoring System
(TPMS) malfunction (if equipped)
The Master Warning Light illuminates
if one or more of the above warning
situations occur.
At this time, a Master Warning icon (
)
will appear beside the User Settings
icon (
), on the LCD display.
If the warning situation is solved, the
master warning light will be turned off
and the Master Warning icon will dis-
appear.

Hazard warning flasher ...................................................................................... 7-3
In case of an emergency whilst driving ............................................................ 7-3
If the engine stalls whilst driving .................................................................... 7-3
If the engine stalls at a crossroad or crossing ............................................... 7-3
If you have a flat tyre whilst driving ............................................................... 7-4
If the engine will not start .................................................................................. 7-5
If the engine doesn’t turn over or turns over slowly ..................................... 7-5
If the engine turns over normally but doesn’t start ...................................... 7-5
Jump starting ...................................................................................................... 7-6
If the engine overheats ...................................................................................... 7-9
Tyre Pressure Monitoring System (TPMS) ........................................................7-10
TPMS reset procedure .....................................................................................7-11
Tyre pressure monitoring system .................................................................. 7-12
Low tyre pressure telltale ............................................................................... 7-14
Low tyre pressure position telltale and tyre pressure telltale ..................... 7-14
TPMS (Tyre Pressure Monitoring System) malfunction indicator ............... 7-15
Changing a tyre with TPMS ...........................................................................7-16
If you have a flat tyre (with spare tyre) .............................................................7-18
Jack and tools ................................................................................................7-18
Changing tyres................................................................................................7-19
Jack label ....................................................................................................... 7-23
EC Declaration of conformity for Jack......................................................... 7-24
If you have a flat tyre (with tyre mobility kit) .................................................. 7-25
Introduction ................................................................................................... 7-25
Notes on the safe use of the tyre Mobility Kit ............................................. 7-26
Components of the Tyre Mobility Kit ............................................................7-27
Using the Tyre Mobility Kit ............................................................................ 7-28
Distributing the sealant ................................................................................. 7-30
Checking the tyre inflation pressure ............................................................ 7-30
7. Emergency situations
7

7-11
07
The TPMS on this vehicle monitors
and compares the rolling radius and
rotational characteristics of each
wheel and tyre whilst you are driving.
And it checks whether any tyre is sig-
nificantly under-inflated. You should
reset the system by pushing the
TPMS SET button according the
accurate procedure and store the
current tyre pressure.
After that, if one or more tyres are sig-
nificantly under-inflated, the low tyre
pressure indicator illuminates and a
message is shown on the cluster.(if
equipped) Also, if there is a malfunc-
tion with the TPMS, the TPMS mal-
function indicator will illuminate.
7306UHVHWSURFHGXUH
You should reset TPMS in below situ-
ations.

7-12
Emergency situations
Ú If the low tyre pressure indicator
turns on repeat step 3.
When resetting TPMS, the current
tyre pressure is stored as a stan-
dard tyre pressure.
CAUTION

7-13
07
Please note that the TPMS is not a
substitute for proper tyre mainte-
nance, and it is the driver’s responsi-
bility to maintain correct tyre pres-
sure, even if under-inflation has not
reached the level to trigger illumina-
tion of the TPMS low tyre pressure
telltale.
Your vehicle has also been equipped
with a TPMS malfunction indicator to
indicate when the system is not oper-
ating properly. The TPMS malfunc-
tion indicator is combined with the
low tyre pressure telltale. When the
system detects a malfunction, the
telltale will flash for approximately
one minute and then remain continu-
ously illuminated. This sequence will
continue upon subsequent vehicle
start-ups as long as the malfunction
exists.
When the malfunction indicator is illu-
minated, the system may not be able
to detect or signal low tyre pressure
as intended. TPMS malfunctions may
occur for a variety of reasons, includ-
ing the installation of replacement or
alternate tyres or wheels on the vehi-
cle that prevent the TPMS from func-
tioning properly.
Always check the TPMS malfunction
telltale after replacing one or more
tyres or wheels on your vehicle to
ensure that the replacement or alter-
nate tyres and wheels allow the
TPMS to continue to function proper-
ly.NOTICE
,I DQ\ RI WKH EHORZ KDSSHQV KDYH
WKHV\VWHPFKHFNHGE\D+<81'$,
DXWKRULVHGUHSDLUHU
7KH /RZ 7\UH 3UHVVXUH 7HOOWDOH
7306 0DOIXQFWLRQ ,QGLFDWRU
GRHV QRW LOOXPLQDWH IRU  VHF-
RQGVZKHQWKHLJQLWLRQVZLWFKLV
SODFHG WR WKH 21 SRVLWLRQ RU
HQJLQHLVUXQQLQJ
7KH73060DOIXQFWLRQ,QGLFDWRU
UHPDLQV LOOXPLQDWHG DIWHU EOLQN-
LQJIRUDSSUR[LPDWHO\PLQXWH
7KH/RZ7\UH3UHVVXUH3RVLWLRQ
7HOOWDOHUHPDLQVLOOXPLQDWHG
