transmission HYUNDAI I10 2023 Owners Manual

1-2
Foreword
FOREWORD
Congratulations, and thank you for choosing HYUNDAI.We are pleased to wel-
come you to the growing number of discerning people who drive HYUNDAIs.
We are very proud of the advanced engineering and high-quality construction
of each HYUNDAI we build.
Your Owner’s Manual will introduce you to the features and operation of your
new HYUNDAI. To become familiar with your new HYUNDAI, so that you can
fully enjoy it, read this Owner’s Manual carefully before driving your new vehi-
cle.
This manual contains important safety information and instructions intended to
familiarize you with your vehicle’s controls and safety features so you can safe-
ly operate your vehicle.
This manual also contains information on maintenance designed to enhance
safe operation of the vehicle. It is recommended that all service and mainte-
nance on your car be performed by a HYUNDAI authorised repairer.
HYUNDAI authorised repairers are prepared to provide high-quality service,
maintenance and any other assistance that may be required.
This Owner’s Manual should be considered a permanent part of your vehicle,
and should be kept in the vehicle so you can refer to it at any time. The manual
should stay with the vehicle if you sell it to provide the next owner with important
operating, safety and maintenance information.
HYUNDAI MOTOR COMPANY
CAUTION
Severe engine and transmission damage may result from the use of poor
quality fuels and lubricants that do not meet HYUNDAI specifications.
You must always use high quality fuels and lubricants that meet the spec-
ifications listed on Page 2-11 in the Vehicle Specifications section of the
Owner’s Manual.
Copyright 2019 HYUNDAI Motor Company. All rights reserved. No part of this
publication may be reproduced, stored in any retrieval system or transmitted in
any form or by any means without the prior written permission of HYUNDAI
Motor Company.

2-12
Vehicle information
RECOMMENDED LUBRICANTS AND CAPACITIES
To help achieve proper engine and powertrain performance and durability, use
only lubricants of the proper quality. The correct lubricants also help promote
engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
Lubricant Volume Classification
Engine oil *1 *2
(drain and refill)
1.0 MPI 3.1 l (2.73 lmp qt.)
API Latest (SN Plus)
1.2 MPI 3.4 l (2.99 lmp qt.)
Manual Transmission fluid1.3~1.4 l
(1.21~1.23 lmp qt.)API Serviced GL-4, SAE 70W, TGO-9
(HYUNDAI genuine transmission
fluid)
- HK SYN MTF 70W
- SPIRAX S6 GHME 70W MTF
- GS MTF HD 70W
Automated Manual
Transmission fluid1.3~1.4 l
(1.21~1.23 lmp qt.)API Serviced GL-4, SAE 70W, TGO-9
(HYUNDAI genuine transmission
fluid)
- HK SYN MTF 70W
- SPIRAX S6 GHME 70W MTF
- GS MTF HD 70W
Coolant1.0 MPI4.49 l
(3.95 lmp qt.)MIXTURE, Antifreeze with water
(Ethylene glycol base coolant for
aluminium radiator)
1.2 MPI4.77 l
(4.20 lmp qt.)
Brake/Clutch fluid0.7~0.8 l
(0.62~0.7 lmp qt.)FMVSS116 DOT-4
Fuel 36 l (7.92 lmp gal.) -
*1 : Refer to the recommended SAE viscosity numbers on the next page.
*
2 : Engine oils labelled Energy Conserving Oil are now available. Along with other additional benefits, they con-
tribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these
improvements are difficult to measure in everyday driving, but in a year’s time, they can offer significant cost
and energy savings.

3-12
Safety system
WARNING
Cargo
Cargo should always be secured
to prevent it from being thrown
about the vehicle in a collision and
causing injury to the vehicle occu-
pants. Do not place objects in the
rear seats, since they cannot be
properly secured and may hit the
front seat occupants in a collision.
WARNING
Cargo loading
Make sure the engine is off, the
Automated manual transmission
is in N (Neutral) or the Manual
transmission is in R (Reverse) or
1st, and the parking brake is
securely applied whenever loading
or unloading cargo. Failure to take
these steps may allow the vehicle
to move if the shift lever is inadver-
tently moved to another position.
Head restraint
The vehicle’s front and rear seats
have adjustable head restraints. The
head restraints provide comfort for
passengers, but more importantly
they are designed to help protect
passengers from whiplash and other
neck and spinal injuries during an
accident, especially in a rear impact
collision.
WARNING
To reduce the risk of serious injury
or death in an accident, take the
following precautions when adjust-
ing your head restraints:
‡Always properly adjust the head
restraints for all passengers
BEFORE starting the vehicle.

Instrument cluster .............................................................................................. 4-2
Instrument cluster control .............................................................................. 4-3
Gauges and meters ......................................................................................... 4-3
Transmission shift indicator ............................................................................ 4-7
Warning and indicator lights ......................................................................... 4-8
LCD display messages ..................................................................................4-20
LCD display........................................................................................................4-26
LCD display control .......................................................................................4-26
LCD display modes ........................................................................................ 4-27
User settings mode .......................................................................................4-29
Trip computer ................................................................................................4-34
4. Instrument cluster
4

4-7
04
Transmission shift indicator
(if equipped)
Automated manual transmission
Shift Indicator (if equipped)
OTL045132
This indicator displays which Automa-
ted Manual Transmission shift lever is
selected.

4-8
Instrument cluster
Manual Transmission Shift
Indicator (if equipped)
OPDE046142
This indicator informs which gear is
desired whilst driving to save fuel.

4-19
04
Press Brake
(for Automated Manual
Transmission)
7his indicator light illuminates

4-21
04
Press brake pedal to start
engine (for smart key system
and Automated Manual
Transmission)
This warning message is displayed if
the Engine Start/Stop button changes
to the ACC position twice by pressing
the button repeatedly without
depressing the brake pedal.
You can start the vehicle by depress-
ing the brake pedal.
Press clutch pedal to start
engine (for smart key system
and Manual transmission)
This warning message is displayed if
the Engine Start/Stop button is in the
ACC position twice by pressing the
button repeatedly without depressing
the clutch pedal.
Depress the clutch pedal to start the
engine.
Press START button again
(for smart key system)
This message is displayed if you
were unable to start the vehicle when
the Engine Start/Stop button was
pressed.
If this occurs, attempt to start the
engine by pressing the Engine Start/
Stop button again.
If the warning message appears each
time you press the Engine Start/Stop
button, we recommend that you have
your vehicle inspected by a HYUNDAI
authorised repairer.
Shift to N to start engine
(for smart key system and
Automated Manual
Transmission)
This warning message is displayed if
you try to start the engine with the
shift button not in the N (Neutral)
position.
i Information
lever in the 1 (1eutral) position.
Check BRAKE SWITCH fuse (for
smart key system and
Automated manual transmis-
sion)
This warning message is displayed if
the brake switch fuse is disconnect-
ed.
You need to replace the fuse with a
new one. If that is not possible, you
can start the engine by pressing the
Engine Start/Stop button for 10 sec-
onds in the ACC position.

4-27
04
LCD display modes
Menu
Trip Computer
Driving Assist
User Settings
Master warning
Up/DownFuel Economy Lane safetyDriver Assistance
The Master Warning
mode displays warning
messages related to the
vehicle when one or
more systems is not
operating normally. Door
Accumulated InfoDriver Attention
Warning Lights
Convenience
Drive Info
Intelligent Speed Limit
WarningService Interval
Other Features
Digital SpeedometerLanguage
Reset
Transmission
The information provided may differ depending on which functions are applicable to your vehicle.

4-37
04
i Information
7he vehicle must be driven for a mini-
mum of .1 miles (3 metres) since
the last ignition key cycle before the
average fuel economy will be recalcu-
lated.
Digital speedometer
OPDE046145R
This message shows the speed of
the vehicle (km/h, MPH).Transmission (if equipped)
OAC3069029TU
This mode displays the temperature
of Automated manual transmission.
For more details, refer to the
"Automated manual transmission
(AMT)" in chapter 6.
