display INFINITI FX35 2004 Service Manual

NAVIGATION SYSTEM
AV-125
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
41 –Shield
ground–– – – –
42 (B/Y) GroundAudio TX
communica-
tion signalOutput ONOperate audio
volume.Audio dose not
operate properly.
43 (G/B) 41RGB syn-
chronizing
signalInput ONPress the “MAP”
button.NAVI screen is
rolling.
44 (R/W) 45RGB signal
(R: red)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks bluish.
45 –Shield
ground–– – – –
46 (R/L) 45RGB signal
(G: green)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks reddish.
47 –Shield
ground–– – – –
48 (B) 45RGB signal
(B: blue)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks yellowish.
49 –Shield
ground–– – – –
50 (L/R) 47RGB signal
(R: red)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.RGB screen
looks bluish. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Igni-
tion
switchOperation
SKIA4402E
SKIA0164E
SKIA4977E
SKIA4978E
SKIA4979E
SKIA4980E

AV-126
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
51 (B) 49RGB area
(YS) signalOutput ONPress the“TRIP”
button.RGB screen is
not shown.
52 (L/W) 47RGB signal
(G: green)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.RGB screen
looks reddish.
53 (W) 49Vertical syn-
chronizing
(VP) signalInput ONSelector lever in
R position.Audio and A/C
does not operate
properly.
54 (L) 47RGB signal
(B: blue)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.RGB screen
looks yellowish.
55 (R) 49Horizontal
synchroniz-
ing (HP) sig-
nalInput ON –Audio and A/C
does not operate
properly.
56 (G) 49RGB syn-
chronizing
signalOutput ONPress the “TRIP”
button.NAVI screen is
rolling. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Igni-
tion
switchOperation
SKIA0162E
SKIA4981E
SKIA0161E
SKIA4982E
SKIA4983E
SKIA0164E

NAVIGATION SYSTEM
AV-127
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for DisplayAKS00BN0
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Ignition
switchOperation
1 (B) Ground Ground – ON – Approx. 0V –
2 (W/G) GroundPower supply
(Inverter) Input ON – Approx. 9VScreen is not
shown
3 (BR/W) GroundPower supply
(Signal) Input ON – Approx. 9VScreen is not
shown
6 (L/W) 7RGB signal (G:
green)Input ONSelect “Display
Diagnosis (DCU)”
of CONFIRMA-
TION/ADJUST-
MENT function.RGB screen
looks reddish.
7 – Shield ground – – – – –
8 (R) 21Horizontal syn-
chronizing (HP)
signalOutput ON –RGB screen
is not shown.
9 (B) 21RGB area (YS)
signalInput ONPress the “TRIP”
button.Rear view is
not displayed.
11 ( P U ) 2 3Display communi-
cation signal
(DCU-DSP)Input ON –Though a
screen is dis-
played, it is
impossible to
adjust bright-
ness.
13 (P) Ground(Inverter)
Ground – ON – Approx. 0V –
14 (P/L) Ground(Signal)
Ground – ON – Approx. 0V –
17 (L/R) 7RGB signal (R:
red)Input ONSelect “Display
Diagnosis (DCU)”
of CONFIRMA-
TION/ADJUST-
MENT function.RGB screen
looks bluish.
SKIA4981E
SKIA4983E
SKIA0162E
SKIA4364E
SKIA4980E

AV-128
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
18 (L) 7RGB signal (B:
blue)Input ONSelect “Display
Diagnosis (DCU)”
of CONFIRMA-
TION/ADJUST-
MENT function.RGB screen
looks yellow-
ish.
19 (G) 21RGB synchroniz-
ing signalInput ONPress the “TRIP”
button.NAVI screen
is rolling.
20 (W) 21Vertical synchro-
nizing (VP) signalOutput ONSelector lever in
R position.Rear view
monitor
screen is roll-
ing.
21 – Shield ground – – – – –
22 (LG) 23Display communi-
cation signal
(DSP-DCU)Output ON –Though a
screen is dis-
played, it is
impossible to
adjust bright-
ness.
23 – Shield ground – – – – –Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Ignition
switchOperation
SKIA4982E
SKIA0164E
SKIA0161E
SKIA4363E

AV-130
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
On Board Self-Diagnosis FunctionAKS00BN2
DESCRIPTION

Diagnosis function consists of the self-diagnosis mode performed automatically and the CONFIRMATION/
ADJUSTMENT mode operated manually.

Self-diagnosis mode checks for connections between the units constituting this system, analyzes each
individual unit at the same time, and displays the results on the LCD screen.

CONFIRMATION/ADJUSTMENT mode is used to perform trouble diagnosis that require operation and
judgment by an operator (malfunction that cannot be automatically judged by the system), to check/
change the set value, and to display the History of Errors of the navigation system.
DIAGNOSIS ITEM
NOTE:
Make the status that is set by D/N function be shown.
Mode Description
Self-diagnosis (DCU) Display control unit diagnosis
Self-diagnosis (NAVI)

NAVI Control unit diagnosis (DVD-ROM drive will not be diagnosed
when no map DVD-ROM is in it)

Analyzes connection between the NAVI control unit and the GPS
antenna connection between the NAVI control unit and each unit, and
operation of each unit.
Confirmation/
AdjustmentDisplay diagnosisOn display control unit mode, color tone and shading of the screen can be
checked by the display of a color bar and a gray scale.
Vehicle signalsOn display control unit mode, analyzes the following vehicle signals: Vehi-
cle speed signal, light signal
NOTE , ignition switch signal, and reverse sig-
nal.
Auto Climate Control A/C self-diagnosis of A/C system.
NavigationDisplay diagnosisOn NAVI C/U mode, color tone and shading of the screen can be checked
by the display of a color bar and a gray scale.
Vehicle signalsOn NAVI C/U mode, analyzes the following vehicle signals: Vehicle speed
signal, light signal, ignition switch signal, and reverse signal.
History of ErrorsDiagnosis results previously stored in the memory (before turning ignition
switch ON) are displayed in this mode. Time and location when/where the
errors occurred are also displayed.
Naviga-
tionDisplay Lon-
gitude & Lat-
itudeDisplay the map. Use the joystick to adjust position. Longitude and latitude
will be displayed.
Speed Cali-
brationUnder ordinary conditions, the navigation system distance measuring
function will automatically compensate for minute decreases in wheel and
tire diameter caused by tire wear or low -pressure. Speed calibration
immediately restores system accuracy in cases such as when distance
calibration is needed because of the use of tire chains in inclement
weather.
Angle
adjustmentCorrects difference between actual turning angle of a vehicle and turning
angle of the car mark on the display.
Initialize
LocationThis mode is for initializing the current location. Use when the vehicle is
transported a long distance on a trailer, etc.
CAN DIAG SUPPOPT MONITOR Display status of CAN communication.

NAVIGATION SYSTEM
AV-133
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
SELF–DIAGNOSIS RESULT
Quick reference table
1. Select a malfunctioning diagnosis No. in the diagnosis result quick reference table.
2. Find estimated malfunctioning system in the diagnosis No. table and perform check by referring to AV-
11 6 , "Wiring Diagram — COMM —" .
3. Turn the ignition switch OFF and perform self-diagnosis again.
*: DCU = Display control unit
CAUTION:

When A/C and AV switch has a malfunction, you cannot start. Refer to AV- 1 7 1 , "Unable to Oper-
ate All of A/C and AV switch (Unable to start Self-Diagnosis)" .

When display has a malfunction, you cannot start. Refer to AV- 1 6 7 , "Screen is Not Shown" .
Self-Diagnosis Codes
Self-Diagnosis Mode (NAVI)AKS00BN4
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system off.
3. While pressing the “MUTE/II ” button, turn the volume control
dial clockwise or counterclockwise for 30 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)

Shifting from current screen to previous screen is performed
by pressing “PREV” button.
4. The initial trouble diagnosis screen will be shown, and items
“Self-Diagnosis (DCU)”, “Self-Diagnosis (NAVI)”, “Confirmation/
Adjustment” and “CAN DIAG SUPPORT MONITOR” will
become selective.
Screen switch
Diagnosis
No.
Switch color DCU* Display Audio unit NavigationGPS
antenna
Red×1
Gray××2
××3
×××4
Diagnosis
No.Possible causeReference
page
1 Display control unit malfunctionAV-183
2 Display communication line between display control unit and display. AV-156
3Audio unit power supply and ground circuit.
Audio communication line between display control unit and audio unit.AV-154
4NAVI control unit power supply and ground circuit.
AV communication line between and display control unit and NAVI control unit.AV-153
SKIA4971E
SKIA4207E

NAVIGATION SYSTEM
AV-135
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
SELF–DIAGNOSIS RESULT
Quick Reference Table
1. Select an malfunctioning diagnosis number. in the diagnosis result quick reference table.
2. Find estimated malfunctioning system in the diagnosis number. table and perform check by referring to
AV- 11 6 , "
Wiring Diagram — COMM —" .
3. Turn the ignition switch OFF and perform self-diagnosis again.
*: Navigation = NAVI control unit
CAUTION:

When A/C and AV switch has a malfunction, you cannot start. Refer to AV- 1 7 1 , "Unable to Operate
All of A/C and AV switch (Unable to start Self-Diagnosis)" .

When display has a malfunction, you cannot start. Refer to AV- 1 6 7 , "Screen is Not Shown" .
Self-diagnosis Codes
Screen switch
Diagnosis No.
Switch color Navigation* GPS antenna
Red×1
Gray×2
Yellow×3
×4
××5
Diagnosis
No.Possible causeReference
page
1 NAVI control unit malfunctionRefer to
AV-182
2 No map DVD-ROM is inserted in the NAVI control unit.Refer to
AV-158
3When “DVD-ROM error. Please check disc.” is shown.
1. Eject map DVD-ROM and check if it is compatible with the system.
2. Check ejected DVD-ROM for dirt, damage, and warpage.
3. If no error is found, insert a known good map DVD-ROM of the same type and perform self-diagno-
sis again. If same result is shown, the NAVI control unit is malfunctioning. If result is normal, the map
DVD-ROM is malfunctioning.Refer to
AV-158
4If “Error found in DVD-ROM or DVD-ROM driver in control unit. Please perform diagnosis in accor-
dance with service manual” is shown, carry out same inspection as diagnosis No. 3.Refer to
AV-158
5GPS antenna system
1. Visually check for a broken wire in the GPS antenna coaxial cable.
2. Disconnect GPS antenna connector, and make sure approximately 5V is supplied from the NAVI
control unit. If not, the NAVI control unit is malfunctioning. If 5V is supplied, replace the GPS
antenna. If the connection is still malfunction after the replacement of the GPS antenna, the NAVI
control unit is malfunctioning.Refer to
AV-159

AV-136
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
Confirmation/Adjustment ModeAKS00BN5
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system off.
3. While pressing the “MUTE/II ” button, turn the volume control
dial clockwise or counterclockwise for 30 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)

Shifting from current screen to previous screen is performed
by pressing “PREV” button.
4. The initial trouble diagnosis screen will be shown, and items
“Self-Diagnosis (DCU)”, “Self-Diagnosis (NAVI)”,“Confirmation/
Adjustment” and “CAN DIAG SUPPORT MONITOR” will
become selective.
5. When “Confirmation/Adjustment” is selected on the initial trouble
diagnosis screen, the operation will enter the CONFIRMATION/
ADJUSTMENT mode. In this mode, check and adjustment of
each item will become possible.
6. The initial trouble diagnosis screen will be shown, and items
“Display Diagnosis”, “Vehicle Signals”, “Auto Climate Control”
and “Navigation” will become selective.
7. Select each switch on “CONFIRMATION/ADJUSTMENT”
screen to display the relevant diagnosis screen.
DISPLAY DIAGNOSIS
SKIA4971E
SKIA4207E
SKIA4220E
SKIA4602E

NAVIGATION SYSTEM
AV-137
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45

When RGB signal error occurred in the RGB system, tone of the color bar will change as follows.

When the color of the screen looks unusual, refer to AV- 1 6 2 , "Color of RGB Image is Not Proper (All
screens Looks Bluish)" ,AV- 1 6 3 , "Color of RGB Image is Not Proper (All Screens Looks Reddish)" and
AV- 1 6 4 , "
Color of RGB Image is Not Proper (All Screens Looks Yellowish)" .
VEHICLE SIGNALS

A comparison check can be made of each actual vehicle signal
and the signals recognized by the system.
CAUTION:
In case of confirming light signal, set D/N mode to ON/OFF
of lighting switch (normal setting).

OFF: D (Day mode)

ON: N (Night mode)
Unless above setting, light signal (ON/OFF) may not be
accurately displayed.

If vehicle speed is NG, refer to AV- 1 5 0 , "Vehicle Speed Signal Check for Display Control Unit" .

If light is NG, refer to AV- 1 5 2 , "Illumination Signal Check for Display Control Unit" .

If IGN is NG, refer to AV- 1 5 2 , "Ignition Signal Check for Display Control Unit" .

If reverse is NG, refer to AV- 1 5 3 , "Reverse Signal Check for Display Control Unit" .
AUTO CLIMATE CONTROL

Refer to ATC Automatic Air Conditioner AT C - 5 3 , "Self-diagnosis Function" for details. R (red) signal error : Screen looks bluish
G (green) signal error : Screen looks reddish
B (blue) signal error : Screen looks yellowish
SKIA5628E
Diagnosis item Display Condition Remarks
Vehicle speedON Vehicle speed > 0 MPH (0 km/h)
Changes in indication may be delayed by
approx. 1.5 seconds. This is normal. OFF Vehicle speed = 0 MPH (0 km/h)
– Ignition switch in ACC position
IGNON Ignition switch ON
–
OFF Ignition switch ACC
ReverseON Selector lever in R position
Changes in indication may be delayed by
approx. 1.5 seconds. This is normal. OFF Selector lever except R position
– Ignition switch in ACC position
LightON Lighting switch ON
–
OFF Lighting switch OFF

AV-138
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
NAVIGATION
1. The initial trouble diagnosis screen will be shown, and items
“Display Diagnosis”, “Vehicle Signals”, “History of Errors” and
“Navigation” will become selective.
2. Select each switch on “CONFIRMATION/ADJUSTMENT”
screen to display the relevant diagnosis screen.
DISPLAY DIAGNOSIS

When RGB signal error occurred in the RGB system, tone of the color bar will change as follows.

When the color of the screen looks unusual, refer to AV- 1 5 9 , "Color of RGB Image is Not Proper (NAVI
Screen Looks Bluish)" ,AV- 1 6 0 , "Color of RGB Image is Not Proper (NAVI Screen Looks Reddish)" and
AV- 1 6 1 , "
Color of RGB Image is Not Proper (NAVI Screen Looks Yellowish)" .
SKIA4226E
SKIA0362E
R (red) signal error : Screen looks bluish
G (green) signal error : Screen looks reddish
B (blue) signal error : Screen looks yellowish
