GW-20
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
POWER WINDOW SERIAL LINK
With Front Power Window Anti-pinch System
Power window main switch, front power window switch (passenger side), and BCM transmit and receive the
signal by power window serial link.
The under mentioned signal is transmitted from BCM to power window main switch and front power window
switch (passenger side)
Keyless power window down signal.
The under mentioned signal is transmitted from power window main switch to front power window switch (pas-
senger side)
Front passenger side door window operation signal.
Power window control by key cylinder switch signal.
Power window lock signal.
Retained power operation signal.
With Front and Rear Power Window Anti-pinch System
Power window main switch, front power window switch (passenger side), rear power window switches and
BCM transmit and receive the signal by power window serial link.
The under mentioned signal is transmitted from BCM to power window main switch and front power window
switch (passenger side).
Keyless power window down signal.
The under mentioned signal is transmitted from power window main switch to front power window switch (pas-
senger side)
Front passenger side door window operation signal.
Power window control by key cylinder switch signal.
Power window lock signal.
Retained power operation signal.
The under mentioned signal is transmitted from power window main switch to rear power window switch (LH
or RH)
Rear LH or RH side door window operation signal.
Power window lock signal.
Retained power operation signal.
POWER WINDOW LOCK
With Front Power Window Anti-pinch System
The power window lock is designed to lock operation of all windows except for driver side door window.
When the lock position, ground of the rear power window switches in the power window main switch is discon-
nected. The power window lock signal is transmitted to front power window switch (passenger side) by power
window serial link. This prevents the power window motors from operating.
With Front and Rear Power Window Anti-pinch System
The power window lock is designed to lock operation of all windows except for driver side door window.
When the lock position, the power window lock signal is transmitted to front power window switch (passenger
side) and rear power window switches by power window serial link. This prevents the power window motors
from operating.
Page 3180 of 4449
POWER WINDOW SYSTEM
GW-21
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
RETAINED POWER OPERATION
When the ignition switch is turned to the OFF position from ON or START position.
Power is supplied for 45 seconds / with front power window anti-pinch system
through BCM terminal 53
to power window main switch terminal 10
to rear power window switch (LH and RH) terminals 1.
Power is supplied for 45 seconds / with front and rear power window anti-pinch system
through BCM terminal 53
to power window main switch terminal 10.
When power and ground are supplied, the BCM continues to be energized, and the power window can be
operated.
The retained power operation is canceled when the driver or passenger side door is opened.
RAP signal period can be changed by CONSULT-II. Refer to GW-40, "
CONSULT-II Inspection Procedure" .
ANTI-PINCH SYSTEM
With front power window anti-pinch system
Power window main switch and front power window switch (passenger side) monitors the power window motor
operation and the power window position (full closed or other) for driver side and passenger side power win-
dow by the signals from encoder and limit switch in front power window motor (driver side and passenger
side).
When power window main switch detects interruption during the following close operation,
automatic close operation when ignition switch is in the “ON” position
automatic close operation during retained power operation
manual close operation during retained power operation
power window main switch or front power window switch (passenger side) controls each power window motor
for open and the power window will be lowered about 150 mm (5.91 in).
With front and rear power window anti-pinch system
Power window main switch and each power window switch monitors the power window motor operation and
the power window position (full closed or other) for each power window by the signals from encoder and limit
switch in power window motor.
When power window switch detects interruption during the following close operation,
automatic close operation when ignition switch is in the “ON” position
automatic close operation during retained power operation
manual close operation during retained power operation
Power window main switch or each power window switch controls each power window motor for open and the
power window will be lowered about 150 mm (5.91 in).
POWER WINDOW CONTROL BY THE KEY CYLINDER SWITCH
When ignition key switch is OFF, front power window can be opened or closed by turning the key cylinder
switch UNLOCK / LOCK position more than 1.5 second over condition.
Power window can be opened as the door key cylinder is kept fully turning to the UNLOCK position.
Power window can be closed as the door key cylinder is kept fully turning to the LOCK position.
The power window DOWN stops when the following operations are carried out.
While performing open / close the window, power window is stopped at the position as the door key cylin-
der is placed on NEUTRAL.
When the ignition switch is turned ON while the power window DOWN is operated.
Page 3188 of 4449
POWER WINDOW SYSTEM
GW-29
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Terminal and Reference Value for Power Window Main Switch / With Front
Power Window Anti-pinch System
AIS004Q3
Terminal Wire color Item ConditionVoltage [V]
(Approx.)
1YRear LH power window
UP signalWhen rear LH switch in
power window main switch is
UP at operated.Battery voltage
2 SB Limit switch and encoder ground — 0
3RRear LH power window
DOWN signalWhen rear LH switch in
power window main switch is
DOWN at operated.Battery voltage
4PDoor key cylinder switch
LOCK signalKey position
(Neutral → Locked)5 → 0
5GRear RH power window
DOWN signalWhen rear RH switch in
power window main switch is
DOWN at operated. Battery voltage
6ORDoor key cylinder switch
UNLOCK signalKey position
(Neutral → Unlocked)5 → 0
7LGRear RH power window
UP signalWhen rear RH switch in
power window main switch is
UP at operated. Battery voltage
8LFront driver side
power window motor UP signalWhen front LH switch in
power window main switch is
UP at operated Battery voltage
9 GY Limit switch signalDriver side door window is
between fully-open and just
before fully-closed position (ON)0
Driver side door window is
between just before fully-closed
position and fully-closed position
(OFF)5
10 BR Rap signalIGN SW ON Battery voltage
Within 45 second after ignition
switch is turned to OFFBattery voltage
When driver side or passenger
side door open in power window
timer is operates0
11 BFront driver side
power window motor DOWN signalWhen front LH switch in
power window main switch is
DOWN at operated Battery voltage
13 PU Encoder pulse signalWhen power window motor oper-
ates.
14 Y Power window serial linkIGN SW ON or power window
timer operating.
15 W Encoder power supplyWhen ignition switch ON or
power window timer operates10
OCC3383D
PIIA2344J
Page 3197 of 4449
GW-38
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
Terminal and Reference Value for Power Window Main Switch / With Front and
Rear Power Window Anti-pinch System
AIS004Q8
Terminal Wire color Item ConditionVoltage [V]
(Approx.)
2 SB Limit switch and encoder ground — 0
4PDoor key cylinder switch
LOCK signalKey position
(Neutral → Locked)5 → 0
6ORDoor key cylinder switch
UNLOCK signalKey position
(Neutral → Unlocked)5 → 0
8LFront driver side power window
motor UP signalWhen front LH switch in
power window main switch is
UP at operated. Battery voltage
9 GY Limit switch signalDriver side door window is between
fully-open and just before fully-
closed position (ON).0
Driver side door window is between
just before fully-closed position and
fully-closed position (OFF).5
10 BR Rap signalIGN SW ON Battery voltage
Within 45 second after ignition
switch is turned to OFFBattery voltage
When driver side or passenger side
door is open in power window timer
is operates0
11 BFront driver side power window
motor DOWN signalWhen front LH switch in
power window main switch is
DOWN at operated. Battery voltage
13 PU Encoder pulse signalWhen power window motor oper-
ates.
14 Y Power window serial linkIGN SW ON or power window timer
operating.
15 W Encoder power supplyWhen ignition switch ON or power
window timer operates.10
17 B Ground — 0
19 W Battery power supply — Battery voltage
OCC3383D
PIIA2344J
Page 3201 of 4449
GW-42
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
Trouble Diagnosis Symptom Chart / With Front Power Window Anti-pinch Sys-
tem
AIS004QC
Make sure other systems using the signal of the following systems operate normally.
Symptom Repair order Refer to page
None of the power windows can be operated using any switch.1. BCM power supply and ground circuit checkGW-44
2. Power window main switch power supply
and ground circuit checkGW-45
3. Power window serial link checkGW-71
Driver side power window alone does not operated.1. Front power window motor (driver side) cir-
cuit checkGW-48
2. Replace power window main switch —
Front passenger side power window alone does not operated.1. Front power window switch (passenger side)
power and ground circuit checkGW-46
2. Power window serial link checkGW-71
3. Front power window motor (passenger side)
circuit checkGW-49
4. Replace BCMBCS-15
Rear LH side power window alone does not operated 1. Rear power window motor (LH) circuit checkGW-50
Rear RH side power window alone does not operated 1. Rear power window motor (RH) circuit checkGW-52
Anti-pinch system does not operate normally (driver side)1. Door window sliding part malfunction
A foreign material adheres to window glass
or glass run rubber.
Glass run rubber wear or deformation.
Sash is tilted too much, or no enough.—
2. Limit switch adjustingGW-78
3. Limit switch circuit check (driver side)GW-56
4. Encoder circuit check (driver side)GW-61
Anti-pinch system does not operate normally (passenger side)1. Door window sliding part malfunction
A foreign material adheres to window glass
or glass run rubber.
Glass run rubber wear or deformation.
Sash is tilted too much, or no enough.—
2. Limit switch adjustingGW-78
3. Limit switch circuit check (passenger side)GW-57
4. Encoder circuit check (passenger side)GW-63
Power window retained power operation does not operate properly1. Check the retained power operation mode
setting.GW-412. Door switch checkGW-67
3. Replace BCM.BCS-15
Does not operate by key cylinder switch1. Door key cylinder switch checkGW-692. Replace power window main switch —
Power window lock switch does not function 1. Power window lock switch checkGW-73
Auto operation does not operate but manual operates normally
(driver side)1. Encoder circuit check (driver side)GW-61
2. Replace power window main switch. —
Auto operation does not operate but manual operates normally
(passenger side)1. Encoder circuit check (passenger side)GW-63
2. Replace front power window switch (passen-
ger side)—
Page 3203 of 4449
![INFINITI FX35 2004 Service Manual GW-44
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
BCM Power Supply and Ground Circuit CheckAIS004QE
1. CHECK FUSE
Check 15A fuse [No.1, located in fuse block (J/B)]
Check 15A fuse [No](/img/42/57021/w960_57021-3202.png "INFINITI FX35 2004 Service Manual GW-44
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
BCM Power Supply and Ground Circuit CheckAIS004QE
1. CHECK FUSE
Check 15A fuse [No.1, located in fuse block (J/B)]
Check 15A fuse [No")
GW-44
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
BCM Power Supply and Ground Circuit CheckAIS004QE
1. CHECK FUSE
Check 15A fuse [No.1, located in fuse block (J/B)]
Check 15A fuse [No.22, located in fuse block (J/B)]
Check 50A fusible link (letter M located in the fuse and fusible link box).
NOTE:
Refer to GW-15, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to
PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between BCM connector M3, M4 terminal 38, 42,
55 and ground.
OK or NG
OK >> GO TO 3.
NG >> Check BCM power supply circuit for open or short.
Power window retained power operation does not operate
properly1. Check the retained power operation mode set-
ting.GW-41
2. Door switch checkGW-67
3. Replace BCM.BCS-15
Does not operate by key cylinder switch1. Door key cylinder switch checkGW-692. Replace power window main switch —
Power window lock switch does not function 1. Power window lock switch checkGW-73
Auto operation does not operate but manual operate normally
(driver side)1. Encoder circuit check (driver side)GW-61
2. Replace power window main switch —
Auto operation does not operate but manual operate normally
(passenger side)1. Encoder circuit check (passenger side)GW-63
2. Replace front power window switch (passen-
ger side)—
Auto operation does not operate but manual operate normally
(rear LH or RH)1. Encoder circuit check (rear LH or RH)GW-65
2. Replace rear power window switch (LH or RH) — Symptom Repair order Refer to page
38 (W/L) – Ground : Battery voltage
42 (L/R) – Ground : Battery voltage
55 (G) – Ground : Battery voltage
PIIA6160E
Page 3228 of 4449
POWER WINDOW SYSTEM
GW-69
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Front Door Key Cylinder Switch Check AIS004QU
1. CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL
With CONSULT-II
Check (“KEY CYL LK-SW”, “KEY CYL UN-SW”) in “DATA MONITOR” mode for “POWER DOOR ROCK SYS-
TEM” with CONSULT-II. Refer to BL-40, "
Data Monitor"
Without CONSULT-II
Check voltage between power window main switch connector and ground.
OK or NG
OK >> Further inspection is necessary. Refer to symptom
chart.
NG >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect power window main switch and front door key lock assembly (driver side) connector.
3. Check continuity between power window main switch connector
D6 terminals 4, 6 and front door lock assembly (driver side) con-
nector D10 terminals 1, 6.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness between power window main
switch and front door key lock assembly (driver side).
Monitor item Condition
KEY CYL LK-SWLock : ON
Neutral / Unlock : OFF
KEY CYL UN-SWUnlock : ON
Neutral / Lock : OFF
PIIA6285E
ConnectorTerminals (Wire color)
Key position Voltage [V]
(Approx.)
(+) (–)
D64 (P)
GroundLock 0
Neutral / Unlock 5
6 (OR)Unlock 0
Neutral / Lock 5
PIIA4211E
4 (P) – 1 (P) : Continuity should exist.
6 (OR) – 6 (OR) : Continuity should exist.
PIIA4212E
Page 3229 of 4449
GW-70
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
3. CHECK DOOR KEY CYLINDER SWITCH GROUND
Check continuity between front door lock assembly (driver side) con-
nector D10 terminal 5 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK DOOR KEY CYLINDER SWITCH
Check continuity between door lock assembly terminals 1, 6 and 5.
OK or NG
OK >> Further inspection is necessary. Refer to symptom
chart.
NG >> Replace front door key cylinder (driver side) switch.5 (B) – Ground : Continuity should exist.
PIIA4213E
Terminals Key position Continuity
1
5Lock Yes
Neutral / Unlock No
6Unlock Yes
Neutral / Lock No
PIIA4214E
Page 3230 of 4449
POWER WINDOW SYSTEM
GW-71
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Power Window Serial Link Check (Passenger Side)AIS004QV
1. CHECK POWER WINDOW SWITCH OUTPUT SIGNAL
With CONSULT-II
Check (“CDL LOCK SW ”, “CDL UNLOCK SW”) in DATA MONITOR mode for “REMOTE KEYLESS ENTRY
SYSTEM” with CONSULT-II. Refer to BL-40, "
Data Monitor" .
Without CONSULT-II
1. Remove key from ignition switch, and the door of driver side and passenger side is closed.
2. Check signal between BCM connector and ground with oscilloscope when door lock and unlock switch
(driver side and passenger side) is turned “LOCK” or “UNLOCK”.
3. Make sure signals which are shown in the figure below can be detected during 10 second just after door
lock and unlock switch (driver side and passenger side) is turned “LOCK” or “UNLOCK”.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK BCM OUTPUT SIGNAL
Check (“POWER WINDOW DOWN”) in “ACTIVE TEST” mode for “REMOTE KEYLESS ENTRY SYSTEM”
with CONSULT-II. Refer to BL-67, "
Active Test"
OK or NG
OK >> Further inspection is necessary. Refer to symptom
chart.
NG >> Replace BCM.
Monitor item Condition
CDL LOCK SW LOCK : ON
UNLOCK : OFF
CDL UNLOCK SW LOCK : OFF
UNLOCK : ON
PIIA7068E
ConnectorTerminals (Wire color)
Signal
(Reference value)
(+) (–)
M3 22 (OR) Ground
PIIA6290EPIIA1297E
When “ACTIVE TEST” is performed, is the window of
driver side and passenger side lowered.
PIIA3080E
Page 3278 of 4449
IDX-5
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
LT-73
Headlining - See Roof trim .................................. EI-42
Heated oxygen sensor 1 (bank 1) .... EC-205, EC-214,
EC-226
, EC-433, EC-439, EC-863, EC-872, EC-884,
EC-1103
, EC-1109
Heated oxygen sensor 1 (bank 2) .... EC-205, EC-214,
EC-226
, EC-433, EC-439, EC-863, EC-872, EC-884,
EC-1103
, EC-1109
Heated oxygen sensor 1 heater (bank 1) ....... EC-149,
EC-806
Heated oxygen sensor 1 heater (bank 2) ....... EC-149,
EC-806
Heated oxygen sensor 2 (bank 1) .... EC-236, EC-245,
EC-446
, EC-457, EC-894, EC-903, EC-1116, EC-1127
Heated oxygen sensor 2 (bank 2) .... EC-236, EC-245,
EC-446
, EC-457, EC-894, EC-903, EC-1116, EC-1127
Heated oxygen sensor 2 heater (bank 1) ....... EC-157,
EC-814
Heated oxygen sensor 2 heater (bank 2) ....... EC-157,
EC-814
Heated seat ....................................................... SE-98
Heater and cooling unit (Heater core) ........... ATC-126
HFC134a (R134a) system precaution ............... ATC-5
HFC134a (R134a) system service procedure ATC-137
HFC134a (R134a) system service tools .......... ATC-18
HFC134a system service equipment precaution ..........
ATC-13
High & low reverse clutch solenoid valve ....... AT-164,
AT-166
Hood ................................................................... BL-14
Horn ................................................................. WW-56
HORN - Wiring diagram ................................... WW-56
HSEAT - Wiring diagram ................................... SE-99
I
IATS - Wiring diagram ....................... EC-182
, EC-839
ICC - Wiring diagram ....................................... ACS-20
ICC/BS - Wiring diagram ................. EC-524, EC-1191
ICC/SW - Wiring diagram ................ EC-510, EC-1176
ICCBOF - Wiring diagram ................ EC-616, EC-1294
Idle air volume learning ....................... EC-49, EC-698
Idle mixture ratio .................................. EC-38, EC-687
Idle speed ............................................ EC-38, EC-687
Idle speed control (ISC) .... EC-392, EC-394, EC-1048,
EC-1050
Ignition coil ....................................... EC-585, EC-1262
Ignition coil(VK45DE) ...................................... EM-185
Ignition coil(VQ35DE) ........................................ EM-42
Ignition control system ..................... EC-585, EC-1262
Ignition key hole illumination ............................. LT-153
Ignition timing ...................................... EC-38, EC-687
IGNSYS - Wiring diagram ................ EC-586, EC-1263
Illumination control ............................................ LT-197
In vehicle sensor ........................... ATC-107, ATC-118
INF/D - Wring diagram ....................................... AV-63
INJECT - Wiring diagram ................. EC-598, EC-1275
Injector ............................................. EC-597, EC-1274
Input clutch solenoid valve ................. AT-152, AT-154
Instrument panel ................................................. IP-10
Intake air temperature sensor ........... EC-180, EC-200,
EC-837
, EC-858
Intake door control linkage adjustment ............ ATC-78
Intake door motor ............................ ATC-76, ATC-124
Intake manifold(VK45DE) ............................... EM-174
Intake manifold(VQ35DE) ................................. EM-24
Intake sensor ................................ ATC-113, ATC-120
Intake valve timing control (Bank 1) ... EC-145, EC-795
Intake valve timing control (Bank 2) ... EC-145, EC-795
Intake valve timing control position sensor (Bank 1) ....
EC-1095
Intake valve timing control position sensor (Bank 2) ....
EC-1095
Intake valve timing control solenoid valve (Bank 1) ......
EC-408
, EC-1070
Intake valve timing control solenoid valve (Bank 2) ......
EC-408
, EC-1070
Integrated homelink transmitter ....................... BL-228
Intelligent cruise control (ICC) system .............. ACS-6
Interior ................................................................. EI-37
Interior lamp ...................................................... LT-157
IPDM (Intelligent power distribution module engine
room) ................................................................. PG-18
IVCB1 - Wiring diagram .... EC-409, EC-798, EC-1071
IVCB2 - Wiring diagram .... EC-411, EC-800, EC-1073
IVCSB1 - Wiring diagram ............................... EC-1096
IVCSB2 - Wiring diagram ............................... EC-1098
IVIS (Infiniti vehicle immobilizer system) precautions ...
GI-3
J
Joint connector (J/C) .......................................... PG-76
K
Knock sensor (KS) ............................. EC-297
, EC-955
KS - Wiring diagram ........................... EC-298, EC-956
L
LAN system circuit ........................................... ATC-66
Laser beam aiming adjustment ....................... ACS-12
Latch (lower anchors and tether for children) system ...
SB-11
Line pressure solenoid valve ........................... AT-127
Line pressure test (A/T) ..................................... AT-52
Liquid gasket application ................................... LU-21
Liquid gasket application(VQ35DE) EM-6, LU-3, CO-3
Location of electrical units ................................. PG-70
Low coast brake solenoid valve ......... AT-168, AT-170
Low tire pressure warning system ...................... WT-7
Lubricant (R134a) A/C ........................ ATC-7, ATC-27
Lubrication circuit (engine)(VK45DE) ................ LU-23
Lubrication circuit (engine)(VQ35DE) .................. LU-5
Lubrication oil A/C .......................................... ATC-161
