TROUBLE DIAGNOSIS FOR SYMPTOMS
AT-191
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2004 November 2004 FX35/FX45
TCM terminals and data are reference value. Measured between each terminal and ground.
A/T CHECK Indicator Lamp Does Not Come OnACS007GD
SYMPTOM:
A/T CHECK indicator lamp does not come on for about 2 seconds when turning ignition switch to
“ON”.
DIAGNOSTIC PROCEDURE
1. CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to AT- 9 4 , "
SELF-DIAGNOSTIC RESULT MODE" , AT- 1 0 3 , "TCM SELF-DIAG-
NOSTIC PROCEDURE (NO TOOLS)" .
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to AT- 1 0 5 , "DTC U1000 CAN COMMUNICATION LINE" .
NO >> GO TO 2.
2. CHECK TCM POWER SOURCE
1. Disconnect A/T assembly harness connector.
2. Turn ignition switch ON. (Do not start engine.)
3. Check voltage between A/T assembly harness connector termi-
nals and ground. Refer to AT-130, "
Wiring Diagram — AT —
POWER" .
4. Turn ignition switch OFF.
5. Check voltage between A/T assembly harness connector termi-
nals and ground. Refer to AT-130, "
Wiring Diagram — AT —
POWER" .
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
TerminalWire
colorItem Condition Data (Approx.)
3 L CAN-H – –
4PUK-line (CONSULT-
II signal)The terminal is connected to the data link connector for CONSULT-II. –
7ORBack-up lamp
relaySelector lever in “R” position. 0V
Selector lever in other positions. Battery voltage
8 R CAN-L – –
Item ConnectorTerminal
(Wire color)Voltag e
TCM F441 (LG) - Ground
Battery voltage 2 (LG) - Ground
6 (Y) - Ground
SCIA2105E
Item ConnectorTerminal
(Wire color)Voltag e
TCM F441 (LG) - Ground
Battery voltage
2 (LG) - Ground
6 (Y) - Ground 0V
SCIA2104E

REFRIGERATION SYSTEM
ATC-21
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2004 November 2004 FX35/FX45
REFRIGERATION SYSTEMPFP:KA990
Refrigerant CycleAJS00146
REFRIGERANT FLOW
The refrigerant flows in the standard pattern, that is, through the compressor, the condenser with liquid tank,
through the evaporator, and back to the compressor. The refrigerant evaporation through the evaporator coil is
controlled by an externally equalized expansion valve, located inside the evaporator case.
FREEZE PROTECTION
Under usual operating conditions, when the A/C is switched on, the compressor runs continuously, and the
evaporator pressure, and therefore, temperature is controlled by the compressor to prevent freeze up.
Refrigerant System ProtectionAJS00147
REFRIGERANT PRESSURE SENSOR
The refrigerant system is protected against excessively high- or low-pressure by the refrigerant pressure sen-
sor, located on the condenser. If the system pressure rises above, or falls below the specifications, the refrig-
erant pressure sensor detects the pressure inside the refrigerant line and sends the voltage signal to the ECM.
ECM makes the A/C relay go OFF and stops the compressor when pressure on the high-pressure side
detected by refrigerant pressure sensor is over about 2,746 kPa (28 kg/cm
2 , 398 psi), or below about 134 kPa
(1.4 kg/cm
2 , 20 psi).
PRESSURE RELIEF VALVE
The refrigerant system is also protected by a pressure relief valve, located in the rear head of the compressor.
When the pressure of refrigerant in the system increases to an unusual level [more than 3,727 kPa (38 kg/cm
2
, 540 psi)], the release port on the pressure relief valve automatically opens and releases refrigerant into the
atmosphere.
RJIA0849E

AIR CONDITIONER CONTROL
ATC-33
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2004 November 2004 FX35/FX45
MAGNET CLUTCH CONTROL
When A/C switch or DEF switch is pressed, unified meter and A/C amp. inputs compressor ON signal to BCM.
BCM sends compressor ON signal to ECM, via CAN communication line.
ECM judges whether compressor can be turned ON, based on each sensor status (refrigerant-pressure sen-
sor signal, throttle angle, etc.). If it judges compressor can be turned ON, it sends compressor ON signal to
IPDM E/R, via CAN communication line.
Upon receipt of compressor ON signal from ECM, IPDM E/R turns air conditioner relay ON to operate com-
pressor.
When sending compressor ON signal to IPDM E/R via CAN communication line, ECM simultaneously sends
compressor feedback signal to unified meter and A/C amp. via CAN communication line.
Unified meter and A/C amp, then, uses input compressor feedback signal to control air inlet.
SELF-DIAGNOSTIC SYSTEM
The self-diagnostic system is built into the unified meter and A/C amp. to quickly locate the cause of symp-
toms.
RJIA1957E

AV-38
AUDIO
Revision: 2004 November 2004 FX35/FX45
Noise InspectionAKS00BMR
The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunction.
Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and opera-
tion of each piece of electrical equipment, and determine the cause.
NOTE:
The source of the noise can be found easily by listening to the noise while removing the fuses of electrical
components, one by one.
TYPE OF NOISE AND POSSIBLE CAUSE
Occurrence condition Possible cause
Occurs only when engine is
ON.A continuous growling noise occurs. The speed
of the noise varies with changes in the engine
speed.

Ignition condenser
A whistling noise occurs while the engine speed
is high. A booming noise occurs while the engine
is running and the lighting switch is ON.

Alternator
The occurrence of the noise is linked with the operation of the fuel pump.

Fuel pump condenser
Noise only occurs when various
electrical components are oper-
ating.A cracking or snapping sound occurs with the
operation of various switches.

Relay malfunction, radio malfunction
The noise occurs when various motors are oper-
ating.

Motor case ground

Motor
The noise occurs constantly, not just under certain conditions.

Rear window defogger coil malfunction

Open circuit in printed heater

Poor ground of antenna amplifier or
antenna feeder line

Mirror type film is attached on the rear win-
dow glass

After-market TV antenna and/or electrical
accessories such as radio are attached on
the rear window glass.
A cracking or snapping sound occurs while the vehicle is being driven, especially
when it is vibrating excessively.

Ground wire of body parts.

Ground due to incorrectinstallation of
parts.

Wiring connections or ashort circuit.

BL-2Revision: 2004 November 2004 FX35/FX45Trouble Diagnosis Chart by Symptom .................... 41
Check Door Switch ................................................. 42
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) ............................................................. 42
CHECK BACK DOOR SWITCH .......................... 44
Check Key Switch ................................................... 46
Check Door Lock and Unlock Switch ..................... 48
Check Door Lock Actuator (Driver side) ................. 50
Check Door Lock Actuator (Passenger Side and
Rear LH/RH) ........................................................... 51
Check Fuel Lid Opener Actuator ............................ 52
Check Front Door Key Cylinder Switch (Lock) ....... 53
Check Front Door Key Cylinder Switch (Unlock) .... 54
Check Select Unlock Relay Circuit ......................... 55
REMOTE KEYLESS ENTRY SYSTEM ..................... 56
Component Parts and Harness Connector Location ... 56
System Description ................................................. 57
INPUTS ............................................................... 57
OPERATED PROCEDURE ................................. 58
CAN Communication System Description .............. 59
CAN Communication Unit ....................................... 59
Schematic ............................................................... 60
Wiring Diagram — KEYLES— ................................ 61
FIG. 1 ................................................................... 61
FIG. 2 ................................................................... 62
FIG. 3 ................................................................... 63
Terminals and Reference Value for BCM ................ 64
Terminals and Reference Value for IPDM E/R ........ 65
CONSULT-II Function ............................................. 65
CONSULT-II INSPECTION PROCEDURE .......... 65
CONSULT-II APPLICATION ITEMS .................... 66
Work Flow ............................................................... 68
Trouble Diagnosis Chart by Symptom .................... 69
Check Key Fob Battery and Function ..................... 71
Check ACC Switch ................................................. 72
Check Door Switch ................................................. 73
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) ............................................................. 73
CHECK BACK DOOR SWITCH .......................... 75
Check Key Switch ................................................... 77
Check IPDM E/R Operation .................................... 78
Check Hazard Function .......................................... 79
Check Horn Function .............................................. 79
Check Headlamp Function ..................................... 79
Check Map Lamp and Ignition Keyhole Illumination
Function .................................................................. 79
ID Code Entry Procedure ....................................... 80
KEY FOB ID SET UP WITH CONSULT-II ........... 80
KEY FOB ID SET UP WITHOUT CONSULT-II .... 82
Key Fob Battery Replacement ................................ 83
INTELLIGENT KEY SYSTEM ................................... 84
Component Parts and Harness Connector Location ... 84
System Description ................................................. 86
DOOR LOCK FUNCTION ................................... 86
REMOTE CONTROL ENTRY FUNCTIONS ........ 87
ENGINE STARTUP FUNCTION .......................... 88
WARNING AND ALARM FUNCTION .................. 89
CHANGE SETTINGS FUNCTION ....................... 92
INTELLIGENT KEY REGISTRATION .................. 92STEERING LOCK UNIT REGISTRATION ........... 92
CAN Communication System Description .............. 93
CAN Communication Unit ....................................... 93
Schematic ............................................................... 94
Wiring Diagram — I/KEY— ..................................... 96
Terminals and Reference Value for INTELLIGENT
KEY UNIT .............................................................109
Terminals and Reference Value for Steering Lock
unit ........................................................................ 111
Terminals and Reference Value for BCM .............. 111
Terminals and Reference Value for IPDM E/R ......112
Diagnosis Procedure .............................................113
WORK FLOW ....................................................113
CONSULT-II Functions .........................................114
CONSULT-II Inspection Procedure .......................114
BASIC OPERATION ..........................................114
CONSULT-II Application Items ..............................115
WORK SUPPORT .............................................115
SELF-DIAGNOSTIC RESULTS .........................115
DATA MONITOR ................................................115
ACTIVE TEST ....................................................116
List of Operation Related Parts .............................117
Trouble Diagnosis Symptom Chart .......................118
ALL FUNCTIONS OF THE INTELLIGENT KEY
ARE NOT OPERATING .....................................118
REMOTE CONTROL ENTRY FUNCTION MAL-
FUNCTION ........................................................118
DOOR LOCK FUNCTION MALFUNCTION .......119
ENGINE START FUNCTION MALFUNCTION ..120
WARNING CHIME FUNCTION MALFUNCTION .120
Check CAN Communication System Inspection ...123
Check Intelligent Key Unit Power Supply and
Ground Circuit .......................................................124
Check Key Switch (Intelligent Key Unit Input) .......124
Check Key Switch (BCM Input) .............................126
Check Ignition Knob Switch ..................................127
Check Door Switch ...............................................128
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) ............................................................128
CHECK BACK DOOR SWITCH .........................129
Check Unlock Sensor ...........................................131
Check Door Request Switch .................................132
Check Intelligent Key Warning Buzzer ..................134
Check Outside Key Antenna .................................135
Check Inside Key Antenna ....................................138
Check Steering Lock Unit ......................................139
Check Stop Lamp Switch ......................................141
Check Detention Switch ........................................142
Check Select Unlock Relay ...................................144
Check Hazard Function ........................................145
Check Horn Function ............................................145
Check Headlamp Function ....................................145
Check IPDM E/R Operation ..................................145
Removal and Installation of Intelligent Key Unit ....146
REMOVAL ..........................................................146
INSTALLATION ..................................................146
Intelligent Key Inspection ......................................147
INTELLIGENT KEY DISASSEMBLY AND

POWER DOOR LOCK SYSTEM
BL-41
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2004 November 2004 FX35/FX45
Trouble Diagnosis Chart by SymptomAIS004M0
Always check the “Work Flow” before troubleshooting. Refer to BL-37, "Work Flow" .
*1 : Lock operation
*2 : Unlock operation
*3 : Driver side
*4 : Except driver sideSymptom Diagnoses service procedureReference
page
Key reminder door system does not operate properly.1.Check key reminder door mode.*
*: Key reminder door mode can be changed.
First check key reminder door mode.BL-40
2. Preliminary CheckBL-38
3. Check key switch.BL-46
4. Check door switch. BL-42
5. Replace BCM.BCS-15
Power door lock does not operate with door lock and unlock switch.1. Preliminary checkBL-382. Check door lock and unlock switch.BL-48
3. Replace BCM.BCS-15
Power door lock does not operate with door key cylinder operation.
(Power door lock operate properly with door lock and unlock switch.)1. Check front door key cylinder switch.BL-53*1
BL-54*2
2. Replace power window main switch. –
Specific door lock actuator does not operate.1. Check door lock actuator.BL-50
*3
BL-51*4
2. Replace BCM.BCS-15
All door lock actuator (except passenger side and fuel lid) does not
operate.*
*: Only model with intelligent key system.1. Check select unlock relay circuit.BL-55
Select unlock does not operate.
(All other power door lock system is “OK”.)1. Check select unlock mode.*
*: Select unlock mode can be changed.
First check select unlock mode.BL-40
2. Replace BCM.BCS-15
Fuel lid opener actuator does not operate.
(All door lock actuators operates properly.)1.Check fuel lid opener actuator.BL-52

POWER DOOR LOCK SYSTEM
BL-55
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2004 November 2004 FX35/FX45
Check Select Unlock Relay Circuit AIS004M9
1. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect BCM, door lock actuator (driver side), and passenger side select unlock relay connector.
3. Check continuity between BCM connector M4 terminal 50 and
passenger side select unlock relay connector M30 terminal 4.
4. Check continuity between passenger side select unlock relay
connector M30 terminal 4 and ground.
5. Check continuity between passenger side select unlock relay
connector M30 terminal 3 and door lock actuator connector D10
(driver side), D52 (rear LH), D72 (rear RH) terminal 3.
6. Check continuity between passenger side unlock relay connec-
tor M30 terminal 3 and ground.
OK or NG
OK >> Check passenger side select unlock relay.
NG >> Repair or replace harness.50 (PU) – 4 (PU) : Continuity should exist.
4 (PU) – Ground : Continuity should not exist.
PIIB0403E
3 (PU) – 3 (PU) : Continuity should exist.
3 (PU) – Ground : Continuity should not exist.
PIIB0404E

REMOTE KEYLESS ENTRY SYSTEM
BL-65
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for IPDM E/RAIS004MG
* : In the state that horn reminder operates.
CONSULT-II FunctionAIS004MH
The following functions are performed by combining data received and command transmitted via the commu-
nication line from the BCM.
*:Refer to BCS-14, "CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)" .
CONSULT-II INSPECTION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Turn ignition switch “OFF”.
2. Connect “CONSULT-II” and “CONSULT-II CONVERTER” to the
data link connector.
3. Turn ignition switch “ON”.
4. Touch “START (NISSAN BASED VHCL)”.
TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
Approx.
38 B Ground — 0
48 L CAN H — —
49 R CAN L — —
51 SB Horn relayWhen door lock is operated using key
fob* (OFF → ON)Battery voltage → 0
60 B Ground — 0
BCM diagnosis
positionInspection items and diagnosis mode Description
BCM C/U*Self-diagnosis results Carries out the self-diagnosis.
DATA MONI-
TORCAN diagnosis support
monitorDisplays CAN communication system diagnosis, disabled
transmission status, and communication status of each unit
communicated with BCM.
Selection from menu Displays the input data to BCM on real-time basis.
MULTI REMOTE
ENTDATA MONITORDisplays the input remote keyless entry system data to BCM
on real–time basis.
ACTIVE TEST Gives a drive to a load to check the operation.
WORK SUPPORT Changes the setting for each function.
PBIB1503E
MBIB0233E

BL-78
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2004 November 2004 FX35/FX45
Check IPDM E/R OperationAIS004MO
1. CHECK IPDM E/R INPUT VOLTAGE
Check voltage between IPDM E/R connector E9 terminal 51 and
ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
2. CHECK IPDM E/R HARNESS
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay connector.
3. Check continuity between IPDM E/R connector E9 terminal 51
and horn relay connector E10 terminal 1.
OK or NG
OK >> Check harness connection.
NG >> Repair or replace harness.51 (SB) – Ground : Battery voltage
PIIA6403E
51 (SB) – 1 (SB) : Continuity should exist.
PIIA6404E

BL-110
INTELLIGENT KEY SYSTEM
Revision: 2004 November 2004 FX35/FX45
26 P/L Stop lamp switch —Brake pedal depressed (ON) 5
Brake pedal not depressed (OFF) 0
27 L/W Ignition knob switch —Press ignition knob. 12
Return ignition knob to LOCK position. 0
28 W/B Door unlock sensor — Door is locking → unlock 5 → 0
29 GYDoor request switch
(back door)—Back door request switch operation:
Press (ON)0
Other than the above (OFF) 5
31 Y/B Steering lock unit ground — — 0
32 R/BSteering lock unit com-
municationLOCKPress ignition knob with Intelligent Key
inside vehicle.
Other than the above 5
35 LGInside key antenna (+)
signal
(Dashboard)
LOCKAny door open → Close (Door switch:
ON → OFF)
Ignition knob switch: ON (press ignition
knob.)
36 PUInside key antenna (-)
signal
(Dashboard)
37 G Outside antenna RH (+)
LOCKPassenger door request switch opera-
tion (Switch: ON)
38PU/
WOutside antenna RH (-)
39 R/Y Detention switch LOCKA/T selector lever in “P” position. 0
A/T selector lever in other position. Battery voltage
40BR/
WDoor lock relay LOCKDoor request switch (passenger side)
pressedBattery voltage → 0 → Battery
voltage Te r -
minal
No.Wire
colorItemMeasuring condition
Standard (V)
Approx. Ignition knob
positionOperation or conditions
SIIA1911J
SIIA1910J
SIIA1910J
