PREPARATION
TF-5
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsADS000RL
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
ST27862000
(—)
Drift
a: 62.5 mm (2.461 in) dia.
b: 42 mm (1.654 in) dia.

Installing front oil seal into front case
KV38108300
(J44195)
Flange wrench

Removing and installing companion flange
lock nut
KV381054S0
(J34286)
Puller

Removing rear oil seal
ST30720000
(J25405)
Drift
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.

Installing rear oil seal
KV40104830
(—)
Drift
a: 76.3 mm (3.004 in) dia.
b: 67.9 mm (2.673 in) dia.

Installing rear oil seal
ST33061000
(J8107-2)
Drift
a: 38 mm (1.50 in) dia.
b: 28.5 mm (1.122 in) dia.

Removing front drive shaft front bearing
ST35322000
(—)
Drift
a: 39 mm (1.54 in) dia.
b: 31 mm (1.22 in) dia.

Removing front drive shaft rear bearing
ZZA0194D
NT771
ZZA0601D
ZZA0811D
ZZA1003D
ZZA0810D
ZZA1000D

TF-6
PREPARATION
Revision: 2004 November 2004 FX35/FX45
Commercial Service ToolsADS000SA
ST30022000
(—)
Drift
a: 110 mm (4.33 in) dia.
b: 56 mm (2.20 in) dia.
c: 46 mm (1.81 in) dia.
Installing front drive shaft front bearing

Installing main shaft into rear case
ST30914000
(—)
Drift
a: 98 mm (3.86 in) dia.
b: 51 mm (2.01 in) dia.
c: 40 mm (1.57 in) dia.

Installing front drive shaft rear bearing
ST30613000
(—)
Drift
a: 72 mm (2.83 in) dia.
b: 48 mm (1.89 in) dia.

Installing main shaft oil seal into front case Tool number
(Kent-Moore No.)
Tool nameDescription
ZZA0978D
ZZA0978D
ZZA1000D
Tool nameDescription
Power tool

Loosening nuts and bolts
PBIC0190E

TROUBLE DIAGNOSIS
TF-21
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
CONSULT-II Function (ALL MODE AWD/4WD)ADS000S5
FUNCTION
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II SETTING PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.

For details, refer to the separate “CONSULT-II Operations Man-
ual”.
1. Turn ignition switch “OFF”.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector on vehicle.
3. Turn ignition switch “ON”.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “ALL MODE AWD/4WD”.
If “ALL MODE AWD/4WD” is not indicated, go to GI-40, "
CON-
SULT-II Data Link Connector (DLC) Circuit" .
6. Perform each diagnostic test mode according to each service
procedure.
SELF-DIAG RESULT MODE
Operation Procedure
1. Perform “CONSULT-II SETTING PROCEDURE”. Refer to TF-21, "CONSULT-II SETTING PROCEDURE"
.
2. Start engine and drive at 30 km/h (19 MPH) or more for approx. 1 minute.
Diagnostic test mode FunctionReference
page
Self-diagnostic results

Self-diagnostic results can be read and erased quickly.TF-21
Data monitor
Input/Output data in the AWD control unit can be read.TF-23
CAN diagnostic support monitor
The results of transmit/receive diagnosis of CAN communication can be read. —
Active test

Diagnostic Test Mode in which CONSULT-II drives some actuators apart from
the AWD control unit and also shifts some parameters in a specified range.TF-24
ECU part number
AWD control unit part number can be read.TF-24
PBIB1503E
SAIA0450E
SDIA2216E

SERVICE DATA AND SPECIFICATIONS (SDS)
TF-55
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsADS000S9
Applied model VQ35DE VK45DE
Transfer model ETX13B
Fluid capacity (Approx.)
1.25 (2-5/8 US pt, 2-1/4 lmp pt)

TF-56
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2004 November 2004 FX35/FX45
