SE-42
AUTOMATIC DRIVE POSITIONER
Revision: 2004 November 2004 FX35/FX45
Can Communication Inspection Using CONSULT-II (Self-diagnosis)AIS002XL
1. SELF-DIAGNOSTIC RESULT CHECK
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect to CONSULT-II, and select “AUTO DRIVE POS.” on the “SELECT DAIAG SYSTEM” screen.
2. Select “SELF-DIAG RESULTS” on “SELECT DISG MODE” screen.
3. Check display content in self-diagnostic results.
Displayed U1000?
Yes >> INSPECTION END
No >> Refer to LAN-4, "
Precautions When Using CONSULT-II" .
Symptom ChartAIS002XM
MIRROR MOTOR RHThe RH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal.
MIRROR MOTOR LHThe LH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal. Test item Description
Symptom Diagnoses / service procedureReference
page
Only setting change function cannot be set with display.Interacted display system (with out NAVI)AV- 5 5
Navigation system (with NAVI)AV- 8 8
A part of seat system does not operate (both automati-
cally and manually).1. Sliding motor circuit check SE-44
2. Reclining motor circuit check SE-45
3. Front lifter motor circuit checkSE-46
4. Rear lifter motor circuit checkSE-48
5. If the above systems are normal, replace the driver
seat control unit.SE-15
A part of steering tilt, telescopic and door mirror does not
operate (both automatically and manually).1.Tilt motor circuit checkSE-51
2. Telescopic motor circuit checkSE-49
3. Mirror motor LH circuit check SE-52
4. Mirror motor RH circuit check SE-54
5. If the above systems are normal, replace the automatic
drive positioner control unit.SE-15
A part of seat system does not operate (only automatic
operation).1. Sliding sensor circuit checkSE-56
2. Reclining sensor circuit checkSE-57
3. Front lifting sensor circuit checkSE-58
4. Rear lifting sensor circuit checkSE-59
5. If the above systems are normal, replace the driver
seat control unit.SE-15
A part of door mirror system dose not operate (only auto-
matic operation).1. Mirror sensor LH circuit checkSE-622. Mirror sensor RH circuit checkSE-63
3. If all the above systems are normal, replace the auto-
matic drive positioner control unit.SE-15
Page 4172 of 4449
AUTOMATIC DRIVE POSITIONER
SE-43
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: 2004 November 2004 FX35/FX45
All the automatic operations do not operate.1. Detention switch (P range switch) circuit checkSE-82
2. Key switch and key lock solenoid circuit check (with
intelligent key)SE-83
3. Key switch circuit inspection (without intelligent key)SE-85
4. UART communication line circuit checkSE-89
5. Tilt sensor circuit checkSE-61
6. Telescopic sensor circuit checkSE-74
7. If all the above systems are normal, replace the auto-
matic drive positioner control unit.SE-15
A part of seat system does not operate (only manual
operation).1. Sliding switch circuit checkSE-67
2. Reclining switch circuit checkSE-68
3. Front lifting switch circuit checkSE-70
4. Rear lifting switch circuit checkSE-71
5. If the above systems are normal, replace the driver
seat control unit.SE-15
A part of steering tilt, telescopic and door mirror does not
operate (only manual operation).1. Door mirror remote control (change over switch) circuit
check SE-78
2. Door mirror remote control (mirror switch) switching cir-
cuit check SE-80
3. Tilt switch checkSE-76
4. Telescopic switch checkSE-74
5. If the above systems are normal, replace the automatic
drive positioner control unit.SE-15
Only memory switch operation dose not operate.1. Seat memory switch circuit checkSE-862. If the above systems are normal, replace the driver
seat control unit.SE-15
Seat memory indicator lamps 1 and 2 do not illuminate.1. Seat memory indicator lamp circuit checkSE-882. If all the above systems are normal, replace the driver
seat control unit.SE-15
The Entry/Exiting does not operated when door is opened
and closed.
(The Entry/Exiting operates with key switch)1. Front door switch (driver side) circuit checkSE-65
2. If all the above systems are normal, replace the BCMBCS-15
Only door mirror system dose not operated (only auto-
matic operation).Steering and door mirror sensor power supply and ground
circuit checkSE-64
Only seat sliding and seat reclining operation does not
operationSliding switch and reclining switch ground circuit checkSE-72
Only sear lifting (front and rear) operation does not opera-
tionFront lifting switch and rear lifting switch ground circuit
checkSE-73
Only lumber support does not operate Lumber support circuit checkSE-91
Symptom Diagnoses / service procedureReference
page
Page 4242 of 4449
SRS-1
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
H RESTRAINTS
CONTENTS
C
D
E
F
G
I
J
K
L
M
SECTION SRS
A
B
SRS
Revision: 2004 November 2004 FX35/FX45
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for SRS “AIR BAG” and “SEAT BELT
PRE-TENSIONER” Service ..................................... 3
Wiring Diagrams and Trouble Diagnosis .................. 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) ....... 5
SRS Configuration ................................................... 5
Front Seat Belt Pre-tensioner with Load Limiter ...... 6
Front Side Air Bag .................................................... 6
Side Curtain Air Bag ................................................. 6
TROUBLE DIAGNOSIS .............................................. 7
Trouble Diagnosis Introduction ................................. 7
DIAGNOSIS FUNCTION ....................................... 7
HOW TO PERFORM TROUBLE DIAGNOSIS
FOR QUICK AND ACCURATE REPAIR ............... 7
WORK FLOW ........................................................ 8
Component Parts Location ....................................... 9
Schematic .............................................................. 10
Wiring Diagram — SRS — ...................................... 11
CONSULT-II Function ............................................ 15
DIAGNOSIS MODE FOR CONSULT-II ............... 15
HOW TO CHANGE SELF-DIAGNOSIS MODE
WITH CONSULT-II .............................................. 15
HOW TO ERASE SELF-DIAGNOSTIC
RESULTS ............................................................ 16
Self-Diagnosis Function (Without CONSULT-II) ..... 16
HOW TO CHANGE SELF-DIAGNOSIS MODE
WITHOUT CONSULT-II ...................................... 16
HOW TO ERASE SELF-DIAGNOSIS RESULTS ... 16
SRS Operation Check ............................................ 17
DIAGNOSTIC PROCEDURE 1 ........................... 17
Trouble Diagnosis with CONSULT-II ...................... 19
DIAGNOSTIC PROCEDURE 2 ........................... 19
DIAGNOSTIC PROCEDURE 3 ........................... 23
DIAGNOSTIC PROCEDURE 4 (CONTINUED FROM DIAGNOSTIC PROCEDURE 2) .............. 25
DIAGNOSTIC PROCEDURE 5 ........................... 25
Trouble Diagnosis without CONSULT-II ................. 29
DIAGNOSTIC PROCEDURE 6 ........................... 29
WARNING LAMP FLASH CODE CHART ........... 30
Trouble Diagnosis: “AIR BAG” Warning Lamp Does
Not Turn OFF ......................................................... 34
DIAGNOSTIC PROCEDURE 7 ........................... 34
Trouble Diagnosis: “AIR BAG” Warning Lamp Does
Not Turn ON ........................................................... 35
DIAGNOSTIC PROCEDURE 8 ........................... 35
DRIVER AIR BAG MODULE .................................... 36
Removal and Installation ........................................ 36
REMOVAL ........................................................... 36
INSTALLATION ................................................... 37
SPIRAL CABLE ........................................................ 38
Removal and Installation ........................................ 38
REMOVAL ........................................................... 38
INSTALLATION ................................................... 39
FRONT PASSENGER AIR BAG MODULE .............. 40
Removal and Installation ........................................ 40
REMOVAL ........................................................... 40
INSTALLATION ................................................... 40
FRONT SIDE AIR BAG MODULE ............................ 41
Removal and Installation ........................................ 41
REMOVAL ........................................................... 41
INSTALLATION ................................................... 42
SIDE CURTAIN AIR BAG MODULE ........................ 43
Removal and Installation ........................................ 43
REMOVAL ........................................................... 43
INSTALLATION ................................................... 44
CRASH ZONE SENSOR ........................................... 45
Removal and Installation ........................................ 45
REMOVAL ........................................................... 45
INSTALLATION ................................................... 45
SIDE AIR BAG (SATELLITE) SENSOR ................... 46
Removal and Installation ........................................ 46
REMOVAL ........................................................... 46
INSTALLATION ................................................... 46
Page 4244 of 4449
PRECAUTIONS
SRS-3
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
AHS000HB
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for SRS “AIR BAG” and “SEAT BELT PRE-TENSIONER” ServiceAHS000HC
Do not use electrical test equipment to check SRS circuits unless instructed to in this Service Manual.
Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 min-
utes.
For approximately 3 minutes after the cables are removed, it is still possible for the air bag and seat belt
pre-tensioner to deploy. Therefore, do not work on any SRS connectors or wires until at least 3 minutes
have passed.
Diagnosis sensor unit must always be installed with their arrow marks “⇐” pointing towards the front of the
vehicle for proper operation. Also check diagnosis sensor unit for cracks, deformities or rust before instal-
lation and replace as required.
The spiral cable must be aligned with the neutral position since its rotations are limited. Do not turn steer-
ing wheel and column after removal of steering gear.
Handle air bag module carefully. Always place driver and front passenger air bag modules with the pad
side facing upward and seat mounted front side air bag module standing with the stud bolt side facing
down.
Conduct self-diagnosis to check entire SRS for proper function after replacing any components.
After air bag inflates, the front instrument panel assembly should be replaced if damaged.
Always replace instrument panel pad following front passenger air bag deployment.
Wiring Diagrams and Trouble DiagnosisAHS000HE
When you read wiring diagrams, refer to the following:
GI-15, "How to Read Wiring Diagrams" in GI section
PG-3, "POWER SUPPLY ROUTING CIRCUIT" in PG section
When you perform trouble diagnosis, refer to the following:
GI-11, "How to Follow Trouble Diagnoses" in GI section
GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident" in GI section
Check for any service bulletins before servicing the vehicle.
Page 4245 of 4449
SRS-4
PREPARATION
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsAHS000HF
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsAHS000HG
Tool number
(Kent-Moore No.)
Tool nameDescription
KV99105300
(J41246)
Air bag module bracketAnchoring air bag module
KV99106400
(J38381)
Deployment toolDisposing of air bag module and front seat
belt pre-tensioner
KV99110200
(J38381-65)
Deployment tool adapter for front
passenger air bag moduleConnecting between the deployment tool
and front passenger air bag module
KV99110500
(J38381-80)
Deployment tool adapter for
driver air bag module (Yellow and
orange connectors)
Deployment tool adapter for front
seat belt pre-tensioner (Yellow
connector)
Deployment tool adapter for side
curtain air bag module (Yellow
connector)
Connecting between the deployment tool
and driver air bag module
Connecting between the deployment tool
and front seat belt pre-tensioner
Connecting between the deployment tool
and side curtain air bag module
KV99108300
(J38381-35)
Deployment tool adapter for front
side air bag moduleConnecting between the deployment tool
and front side air bag module
S-NT354
S-NT357
SHIA0173E
PHIA0184E
ZZA1166D
Tool name Application
Tamper resistant TORX bit Size: T30
S-NT757
Page 4290 of 4449
DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
SRS-49
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: 2004 November 2004 FX35/FX45
DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONERPFP:00014
Caution for Air Bag Module and Seat Belt Pre-tensionerAHS000I5
Before disposing of air bag module and seat belt pre-tensioner, or vehicles equipped with such systems,
deploy the systems. If such systems have already been deployed due to an accident, dispose of them as
indicated in SRS-49, "
DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER" .
When deploying the air bag module and seat belt pre-tensioner, always use the Special Service Tool;
Deployment tool [KV99106400 (J38381)].
When deploying the air bag module and seat belt pre-tensioner, stand at least 5 m (16 ft) away from the
deployment component.
When deploying air bag module and seat belt pre-tensioner, a fairly loud noise is made, followed by
smoke being released. The smoke is not poisonous, however, be careful not to inhale smoke since it irri-
tates the throat and can cause choking.
Always activate one air bag module at a time.
Due to heat, leave air bag module unattended for more than 30 minutes after deployment. Also leave seat
belt pre-tensioner unattended for more than 10 minutes after deployment.
Be sure to wear gloves when handling a deployed air bag module and seat belt pre-tensioner.
Never apply water to the deployed air bag module and seat belt pre-tensioner.
Wash your hands clean after finishing work.
Place the vehicle outdoors with an open space of at least 6 m (20 ft) on all sides when deploying air bag
module and seat belt pre-tensioner while mounted in vehicle.
Use a voltmeter to make sure the vehicle battery is fully charged.
Do not dispose of the air bag module and seat belt pre-tensioner undeployed.
CHECKING DEPLOYMENT TOOL
Connecting to Battery
CAUTION:
The battery must show voltage of 9.6 V or more.
Remove the battery from the vehicle and place it on dry wood blocks
approximately 5 m (16 ft) away from the vehicle.
Wait 3 minutes after the vehicle battery is disconnected before
proceeding.
Connect red clip of deployment tool to battery positive terminal
and black clip to negative terminal.
Make sure the polarity is correct. The right side lamp in the tool,
marked “deployment tool power”, should glow with a green
light. If the right side lamp glows red, reverse the connections
to the battery.
Deployment Tool Check
Press the deployment tool switch to the ON position. The left side
lamp in the tool, marked “air bag connector voltage” should illumi-
nate. If it does not illuminate, replace the tool.
SRS019
SBF266H
Page 4302 of 4449
TF-1
TRANSFER
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION TF
A
B
TF
Revision: 2004 November 2004 FX35/FX45
TRANSFER
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions .............................................................. 3
Service Notice .......................................................... 4
Wiring Diagrams and Trouble Diagnosis .................. 4
PREPARATION ........................................................... 5
Special Service Tools ............................................... 5
Commercial Service Tools ........................................ 6
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 7
NVH Troubleshooting Chart ..................................... 7
TRANSFER FLUID ..................................................... 8
Replacement ............................................................ 8
DRAINING ............................................................. 8
FILLING ................................................................. 8
Inspection ................................................................. 8
FLUID LEAKAGE AND FLUID LEVEL .................. 8
AWD SYSTEM ............................................................ 9
Power Transfer Diagram .......................................... 9
System Description .................................................. 9
DESCRIPTION ...................................................... 9
ELECTRIC CONTROLLED COUPLING ............. 10
AWD CONTROL UNIT ........................................ 10
AWD WARNING LAMP ........................................ 11
System Diagram ...................................................... 11
COMPONENTS FUNCTION DESCRIPTION ..... 12
CAN Communication .............................................. 12
SYSTEM DESCRIPTION .................................... 12
TROUBLE DIAGNOSIS ............................................ 13
Fail-Safe Function .................................................. 13
How to Perform Trouble Diagnosis ........................ 13
BASIC CONCEPT ............................................... 13
Location of Electrical Parts ..................................... 14
Circuit Diagram ...................................................... 15
Wiring Diagram — AWD — .................................... 16
Trouble Diagnosis Chart for Symptoms ................. 19
AWD Control Unit Input/Output Signal Reference
Values .................................................................... 19AWD CONTROL UNIT INSPECTION TABLE ..... 19
CONSULT-II Function (ALL MODE AWD/4WD) ..... 21
FUNCTION .......................................................... 21
CONSULT-II SETTING PROCEDURE ................ 21
SELF-DIAG RESULT MODE ............................... 21
DATA MONITOR MODE ...................................... 23
ACTIVE TEST MODE ......................................... 24
AWD CONTROL UNIT PART NUMBER ............. 24
TROUBLE DIAGNOSIS FOR SYSTEM .................... 25
Power Supply Circuit For AWD Control Unit ........... 25
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 25
DIAGNOSTIC PROCEDURE .............................. 25
AWD Control Unit ................................................... 26
DIAGNOSTIC PROCEDURE .............................. 26
ABS System ........................................................... 26
DIAGNOSTIC PROCEDURE .............................. 26
AWD Solenoid ........................................................ 27
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 27
DIAGNOSTIC PROCEDURE .............................. 27
COMPONENT INSPECTION .............................. 29
AWD Actuator Relay ............................................... 30
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 30
DIAGNOSTIC PROCEDURE .............................. 30
Engine Control Signal ............................................. 31
DIAGNOSTIC PROCEDURE .............................. 31
CAN Communication Line ...................................... 31
DIAGNOSTIC PROCEDURE .............................. 31
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 32
AWD Warning Lamp Does Not Turn ON When The
Ignition Switch Is Turned To ON ............................. 32
DIAGNOSTIC PROCEDURE .............................. 32
AWD Warning Lamp Does Not Turn OFF Several
Seconds After Engine Started ................................ 32
DIAGNOSTIC PROCEDURE .............................. 32
Heavy Tight-corner Braking Symptom Occurs
When The Vehicle Is Driven And The Steering
Wheel Is Turned Fully To Either Side After The
Page 4303 of 4449
TF-2Revision: 2004 November 2004 FX35/FX45Engine Is Started .................................................... 34
DIAGNOSTIC PROCEDURE .............................. 34
Vehicle Does Not Enter AWD Mode Even Though
AWD Warning Lamp Turned To OFF ...................... 35
DIAGNOSTIC PROCEDURE .............................. 35
While Driving, AWD Warning Lamp Flashes Rapidly
(When Flashing In Approx. 1 Minute And Then Turn-
ing OFF) ................................................................. 36
While Driving, AWD Warning Lamp Flashes Slowly
(When Continuing To Flash Until Turning Ignition
Switch OFF) ............................................................ 36
DIAGNOSTIC PROCEDURE .............................. 36
AWD CONTROL UNIT .............................................. 38
Removal and Installation ........................................ 38
REMOVAL ........................................................... 38
INSTALLATION .................................................... 38
FRONT OIL SEAL ..................................................... 39
Removal and Installation ........................................ 39
REMOVAL ........................................................... 39
INSTALLATION .................................................... 39REAR OIL SEAL ....................................................... 40
Removal and Installation ......................................... 40
REMOVAL ............................................................ 40
INSTALLATION .................................................... 41
AIR BREATHER HOSE ............................................. 42
Removal and Installation ......................................... 42
TRANSFER ASSEMBLY ........................................... 43
Removal and Installation ......................................... 43
REMOVAL ............................................................ 43
INSTALLATION .................................................... 43
Components ............................................................ 44
Disassembly and Assembly .................................... 45
DISASSEMBLY .................................................... 45
INSPECTION ....................................................... 49
ASSEMBLY .......................................................... 49
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 55
General Specifications ............................................ 55
Page 4304 of 4449
PRECAUTIONS
TF-3
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
ADS000RH
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
PrecautionsADS000RI
Before connecting or disconnecting the AWD control unit
harness connector, turn ignition switch “OFF” and discon-
nect negative battery cable. Because battery voltage is
applied to AWD control unit even if ignition switch is turned
“OFF”.
When connecting or disconnecting pin connectors into or
from AWD control unit, take care not to damage pin termi-
nals (bend or break).
When connecting pin connectors, make sure that there are
no bends or breaks on AWD control unit pin terminal.
Before replacing AWD control unit, perform AWD control
unit input/output signal inspection and make sure whether
AWD control unit functions properly or not. Refer to TF-19,
"AWD Control Unit Input/Output Signal Reference Values" .
SEF289H
SEF291H
SDIA1848E
Page 4305 of 4449
TF-4
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Service NoticeADS000RJ
After overhaul refill the transfer with new transfer fluid.
Check the fluid level or replace the fluid only with the vehicle parked on level ground.
During removal or installation, keep inside of transfer clear of dust or dirt.
Replace all tires at the same time. Always use tires of the proper size and the same brand and pattern.
Fitting improper size and unusual wear tires applies excessive force to vehicle mechanism and can cause
longitudinal vibration.
Disassembly should be done in a clean work area.
Before proceeding with disassembly, thoroughly clean the transfer. It is important to prevent the internal
parts from becoming contaminated by dirt or other foreign matter.
Check for the correct installation status prior to removal or disassembly. If matching marks are required,
be certain they do not interfere with the function of the parts when applied.
All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or
reassembly.
Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them
with a new ones if necessary.
Gaskets, seals and O-rings should be replaced any time when the transfer is disassembled.
In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
tightening sequence is specified, use it.
Observe the specified torque when assembling.
Clean and flush the parts sufficiently and blow-dry them.
Be careful not to damage sliding surfaces and mating surfaces.
Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere
with the operation of the transfer.
Wiring Diagrams and Trouble DiagnosisADS000RK
When you read wiring diagrams, refer to the following:
GI-15, "How to Read Wiring Diagrams".
PG-3, "POWER SUPPLY ROUTING CIRCUIT".
When you perform trouble diagnosis, refer to the following:
GI-11, "How to Follow Trouble Diagnoses".
GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident".
