Revision: 2004 November 2004 FX35/FX45Diagnostic Procedure ........................................... 232
Component Inspection ......................................... 234
Removal and Installation ...................................... 235
DTC P0138, P0158 HO2S2 .................................... 236
Component Description ........................................ 236
CONSULT-II Reference Value in Data Monitor Mode
. 236
On Board Diagnosis Logic ................................... 236
DTC Confirmation Procedure ............................... 237
Wiring Diagram .................................................... 238
Diagnostic Procedure ........................................... 241
Component Inspection ......................................... 243
Removal and Installation ...................................... 244
DTC P0139, P0159 HO2S2 .................................... 245
Component Description ........................................ 245
CONSULT-II Reference Value in Data Monitor Mode
. 245
On Board Diagnosis Logic ................................... 245
DTC Confirmation Procedure ............................... 246
Overall Function Check ........................................ 246
Wiring Diagram .................................................... 248
Diagnostic Procedure ........................................... 251
Component Inspection ......................................... 253
Removal and Installation ...................................... 255
DTC P0171, P0174 FUEL INJECTION SYSTEM
FUNCTION .............................................................. 256
On Board Diagnosis Logic ................................... 256
DTC Confirmation Procedure ............................... 256
Wiring Diagram .................................................... 258
Diagnostic Procedure ........................................... 260
DTC P0172, P0175 FUEL INJECTION SYSTEM
FUNCTION .............................................................. 265
On Board Diagnosis Logic ................................... 265
DTC Confirmation Procedure ............................... 265
Wiring Diagram .................................................... 267
Diagnostic Procedure ........................................... 269
DTC P0181 FTT SENSOR ...................................... 273
Component Description ........................................ 273
On Board Diagnosis Logic ................................... 273
DTC Confirmation Procedure ............................... 273
Wiring Diagram .................................................... 275
Diagnostic Procedure ........................................... 276
Component Inspection ......................................... 277
Removal and Installation ...................................... 278
DTC P0182, P0183 FTT SENSOR ......................... 279
Component Description ........................................ 279
On Board Diagnosis Logic ................................... 279
DTC Confirmation Procedure ............................... 279
Wiring Diagram .................................................... 280
Diagnostic Procedure ........................................... 281
Component Inspection ......................................... 282
Removal and Installation ...................................... 283
DTC P0222, P0223 TP SENSOR ........................... 284
Component Description ........................................ 284
CONSULT-II Reference Value in Data Monitor Mode
. 284
On Board Diagnosis Logic ................................... 284
DTC Confirmation Procedure ............................... 285
Wiring Diagram .................................................... 286Diagnostic Procedure ...........................................287
Component Inspection ..........................................290
Removal and Installation ......................................290
DTC P0300 - P0306 MULTIPLE CYLINDER MIS-
FIRE, NO. 1 - 6 CYLINDER MISFIRE .....................291
On Board Diagnosis Logic ....................................291
DTC Confirmation Procedure ...............................291
Diagnostic Procedure ...........................................292
DTC P0327, P0328 KS ...........................................297
Component Description ........................................297
On Board Diagnosis Logic ....................................297
DTC Confirmation Procedure ...............................297
Wiring Diagram .....................................................298
Diagnostic Procedure ...........................................299
Component Inspection ..........................................300
Removal and Installation ......................................301
DTC P0335 CKP SENSOR (POS) ..........................302
Component Description ........................................302
CONSULT-II Reference Value in Data Monitor Mode
.302
On Board Diagnosis Logic ....................................302
DTC Confirmation Procedure ...............................302
Wiring Diagram .....................................................303
Diagnostic Procedure ...........................................304
Component Inspection ..........................................307
Removal and Installation ......................................307
DTC P0340, P0345 CMP SENSOR (PHASE) ........308
Component Description ........................................308
CONSULT-II Reference Value in Data Monitor Mode
.308
On Board Diagnosis Logic ....................................308
DTC Confirmation Procedure ...............................308
Wiring Diagram .....................................................309
Diagnostic Procedure ...........................................312
Component Inspection ..........................................315
Removal and Installation ......................................315
DTC P0420, P0430 THREE WAY CATALYST FUNC-
TION ........................................................................316
On Board Diagnosis Logic ....................................316
DTC Confirmation Procedure ...............................316
Overall Function Check ........................................317
Diagnostic Procedure ...........................................318
DTC P0441 EVAP CONTROL SYSTEM .................321
System Description ...............................................321
On Board Diagnosis Logic ....................................321
DTC Confirmation Procedure ...............................321
Overall Function Check ........................................322
Diagnostic Procedure ...........................................323
DTC P0442 EVAP CONTROL SYSTEM .................326
On Board Diagnosis Logic ....................................326
DTC Confirmation Procedure ...............................327
Diagnostic Procedure ...........................................328
DTC P0444, P0445 EVAP CANISTER PURGE VOL-
UME CONTROL SOLENOID VALVE ......................335
Description ............................................................335
CONSULT-II Reference Value in Data Monitor Mode
.335
On Board Diagnosis Logic ....................................336
DTC Confirmation Procedure ...............................336

EC-10Revision: 2004 November 2004 FX35/FX45DTC Confirmation Procedure ...............................937
Wiring Diagram .....................................................938
Diagnostic Procedure ...........................................939
Component Inspection ..........................................941
Removal and Installation ......................................941
DTC P0222, P0223 TP SENSOR ............................942
Component Description ........................................942
CONSULT-II Reference Value in Data Monitor Mode
.942
On Board Diagnosis Logic ....................................942
DTC Confirmation Procedure ...............................943
Wiring Diagram .....................................................944
Diagnostic Procedure ...........................................945
Component Inspection ..........................................948
Removal and Installation ......................................948
DTC P0300 - P0308 MULTIPLE CYLINDER MIS-
FIRE, NO. 1 - 8 CYLINDER MISFIRE .....................949
On Board Diagnosis Logic ....................................949
DTC Confirmation Procedure ...............................949
Diagnostic Procedure ...........................................950
DTC P0327, P0328, P0332, P0333 KS ...................955
Component Description ........................................955
On Board Diagnosis Logic ....................................955
DTC Confirmation Procedure ...............................955
Wiring Diagram .....................................................956
Diagnostic Procedure ...........................................957
Component Inspection ..........................................959
Removal and Installation ......................................959
DTC P0335 CKP SENSOR (POS) ..........................960
Component Description ........................................960
CONSULT-II Reference Value in Data Monitor Mode
.960
On Board Diagnosis Logic ....................................960
DTC Confirmation Procedure ...............................960
Wiring Diagram .....................................................961
Diagnostic Procedure ...........................................962
Component Inspection ..........................................964
Removal and Installation ......................................965
DTC P0340 CAMSHAFT POSITION (CMP) SEN-
SOR (PHASE) .........................................................966
Component Description ........................................966
On Board Diagnosis Logic ....................................966
DTC Confirmation Procedure ...............................966
Wiring Diagram .....................................................967
Diagnostic Procedure ...........................................968
Component Inspection ..........................................970
Removal and Installation ......................................970
DTC P0420, P0430 THREE WAY CATALYST FUNC-
TION ........................................................................971
On Board Diagnosis Logic ....................................971
DTC Confirmation Procedure ...............................971
Overall Function Check ........................................972
Diagnostic Procedure ...........................................973
DTC P0441 EVAP CONTROL SYSTEM .................976
System Description ...............................................976
On Board Diagnosis Logic ....................................976
DTC Confirmation Procedure ...............................976
Overall Function Check ........................................977
Diagnostic Procedure ...........................................978DTC P0442 EVAP CONTROL SYSTEM .................981
On Board Diagnosis Logic ....................................981
DTC Confirmation Procedure ................................982
Diagnostic Procedure ............................................983
DTC P0444, P0445 EVAP CANISTER PURGE VOL-
UME CONTROL SOLENOID VALVE ......................990
Description ............................................................990
CONSULT-II Reference Value in Data Monitor Mode
.990
On Board Diagnosis Logic ....................................991
DTC Confirmation Procedure ................................991
Wiring Diagram .....................................................992
Diagnostic Procedure ............................................994
Component Inspection ..........................................995
Removal and Installation .......................................996
DTC P0447 EVAP CANISTER VENT CONTROL
VALVE ......................................................................997
Component Description ........................................997
CONSULT-II Reference Value in Data Monitor Mode
.997
On Board Diagnosis Logic ....................................997
DTC Confirmation Procedure ................................998
Wiring Diagram .....................................................999
Diagnostic Procedure ...........................................1000
Component Inspection .........................................1002
DTC P0451 EVAP CONTROL SYSTEM PRESSURE
SENSOR .................................................................1004
Component Description .......................................1004
CONSULT-II Reference Value in Data Monitor Mode
1004
On Board Diagnosis Logic ...................................1004
DTC Confirmation Procedure ...............................1005
Diagnostic Procedure ...........................................1005
Component Inspection .........................................1006
DTC P0452 EVAP CONTROL SYSTEM PRESSURE
SENSOR .................................................................1007
Component Description .......................................1007
CONSULT-II Reference Value in Data Monitor Mode
1007
On Board Diagnosis Logic ...................................1007
DTC Confirmation Procedure ...............................1008
Wiring Diagram ....................................................1009
Diagnostic Procedure ...........................................1010
Component Inspection .........................................1013
DTC P0453 EVAP CONTROL SYSTEM PRESSURE
SENSOR .................................................................1014
Component Description .......................................1014
CONSULT-II Reference Value in Data Monitor Mode
1014
On Board Diagnosis Logic ...................................1014
DTC Confirmation Procedure ...............................1015
Wiring Diagram ....................................................1016
Diagnostic Procedure ...........................................1017
Component Inspection .........................................1021
DTC P0455 EVAP CONTROL SYSTEM ................1022
On Board Diagnosis Logic ...................................1022
DTC Confirmation Procedure ...............................1023
Diagnostic Procedure ...........................................1024

EC-34
[VQ35DE]
ENGINE CONTROL SYSTEM
Revision: 2004 November 2004 FX35/FX45
FUEL INJECTION TIMING
Two types of systems are used.
Sequential Multiport Fuel Injection System
Fuel is injected into each cylinder during each engine cycle according to the firing order. This system is used
when the engine is running.
Simultaneous Multiport Fuel Injection System
Fuel is injected simultaneously into all six cylinders twice each engine cycle. In other words, pulse signals of
the same width are simultaneously transmitted from the ECM.
The six injectors will then receive the signals two times for each engine cycle.
This system is used when the engine is being started and/or if the fail-safe system (CPU) is operating.
FUEL SHUT-OFF
Fuel to each cylinder is cut off during deceleration or operation of the engine at excessively high speeds.
Electronic Ignition (EI) SystemABS006K8
INPUT/OUTPUT SIGNAL CHART
*1: This signal is sent to the ECM through CAN communication line.
*2: ECM determines the start signal status by the signals of engine speed and battery voltage.
SYSTEM DESCRIPTION
The ignition timing is controlled by the ECM to maintain the best air-
fuel ratio for every running condition of the engine. The ignition tim-
ing data is stored in the ECM. This data forms the map shown.
The ECM receives information such as the injection pulse width and
camshaft position sensor signal. Computing this information, ignition
signals are transmitted to the power transistor.
e.g., N: 1,800 rpm, Tp: 1.50 msec
A °BTDC
During the following conditions, the ignition timing is revised by the
ECM according to the other data stored in the ECM.

At starting

During warm-up
SEF179U
Sensor Input Signal to ECM ECM function Actuator
Crankshaft position sensor (POS)
Engine speed*
2
Piston position
Ignition timing
controlPower transistor Camshaft position sensor (PHASE)
Mass air flow sensor Amount of intake air
Engine coolant temperature sensor Engine coolant temperature
Throttle position sensor Throttle position
Accelerator pedal position sensor Accelerator pedal position
Knock sensor Engine knocking
Park/neutral position (PNP) switch Gear position
Battery
Battery voltage*
2
Wheel sensor*1Vehicle speed
SEF742M

EC-90
