![INFINITI FX35 2006 Service Manual EC-1362
[VK45DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 December 2006 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Fuel PressureNBS004I1
Idle Speed and Ignition TimingNBS004I](/img/42/57019/w960_57019-2745.png "INFINITI FX35 2006 Service Manual EC-1362
[VK45DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 December 2006 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Fuel PressureNBS004I1
Idle Speed and Ignition TimingNBS004I")
EC-1362
[VK45DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 December 2006 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Fuel PressureNBS004I1
Idle Speed and Ignition TimingNBS004I2
*: Under the following conditions:
Air conditioner switch: OFF
Electric load: OFF (Lights, heater fan & rear window defogger)
Steering wheel: Kept in straight-ahead position
Calculated Load ValueNBS004I3
Mass Air Flow SensorNBS004I4
*: Engine is warmed up to normal operating temperature and running under no load.
Intake Air Temperature SensorNBS004I5
Engine Coolant Temperature SensorNBS004I6
Fuel Tank Temperature SensorNBS004I7
Crankshaft Position Sensor (POS)NBS004I8
Refer to EC-1036, "Component Inspection" .
Camshaft Position Sensor (PHASE)NBS004I9
Refer to EC-1043, "Component Inspection" .
A/F Sensor 1 HeaterNBS004LW
Fuel pressure at idling kPa (kg/cm2 , psi) Approximately 350 (3.57, 51)
Target idle speed No load* (in P or N position) 650
±50 rpm
Air conditioner: ON In P or N position 700 rpm or more
Ignition timing In P or N position 12 ° ± 5 ° BTDC
Condition Calculated load value% (Using CONSULT-II or GST)
At idle 14.0 - 33.0
At 2,500 rpm 12.0 - 25.0
Supply voltageBattery voltage (11 - 14V)
Output voltage at idle 1.0 - 1.3V*
Mass air flow (Using CONSULT-II or GST) 2.0 - 6.0 g·m/sec at idle*
7.0 - 20.0 g·m/sec at 2,500 rpm*
Temperature °C ( °F) Resistance k Ω
25 (77) 1.800 - 2.200
Temperature °C ( °F) Resistance k Ω
20 (68) 2.1 - 2.9
50 (122) 0.68 - 1.00
90 (194) 0.236 - 0.260
Temperature °C ( °F) Resistance k Ω
20 (68) 2.3 - 2.7
50 (122) 0.79 - 0.90
Resistance [at 25°C (77 °F)] 2.3 - 4.3 Ω
Page 3027 of 4462
![INFINITI FX35 2006 Service Manual CYLINDER HEAD EM-233
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
If the engine speed is out of specified range, check battery liquid for proper gravity. Che](/img/42/57019/w960_57019-3026.png "INFINITI FX35 2006 Service Manual CYLINDER HEAD EM-233
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
If the engine speed is out of specified range, check battery liquid for proper gravity. Che")
CYLINDER HEAD EM-233
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 December 2006 FX35/FX45
If the engine speed is out of specified range, check battery liquid for proper gravity. Check engine
speed again with normal battery gravity.
If compression pressure is below minimum value, check valve clearances and parts associated with
combustion chamber (valve, valve seat, piston, piston ring, cylinder bore, cylinder head, cylinder head
gasket). After the checking, measure compression pressure again.
If some cylinders have low compression pressure, pour small amount of engine oil into the spark plug
hole of the cylinder to re-check it for compression.
–If the added engine oil improves the compression, piston rings may be worn out or damaged. Check the
piston rings and replace if necessary.
–If the compression pressure remains at low level despite the addition of engine oil, valves may be mal-
functioning. Check valves for damage. Replace valve or valve seat accordingly.
If two adjacent cylinders have respectively low compression pressure and their compression remains
low even after the addition of engine oil, cylinder head gaskets are leaking. In such a case, replace cyl-
inder head gaskets.
8. After inspection is completed, install removed parts in the reverse order of removal.
9. Start engine, and make sure that engine runs smoothly.
10. Perform trouble diagnosis. If DTC appears, erase it. Refer to EC-748, "
TROUBLE DIAGNOSIS" .
ComponentsNBS003IK
Removal and InstallationNBS003IL
REMOVAL
1. Remove engine assembly from vehicle. Refer to EM-243, "ENGINE ASSEMBLY" .
2. Remove exhaust manifold. Refer to EM-183, "
EXHAUST MANIFOLD AND THREE WAY CATALYST" .
3. Remove camshaft. Refer to EM-215, "
CAMSHAFT" .
1. Engine coolant temperature sensor 2. Washer 3. Cylinder head gasket (left bank)
4. Harness bracket 5. Cylinder head (right bank) 6. Cylinder head bolt
7. Cylinder head gasket (right bank) 8. Cylinder head bolt 9. Cylinder head (left bank)
PBIC2756E
Page 3236 of 4462
GI-52
TERMINOLOGY
Revision: 2006 December 2006 FX35/FX45
TERMINOLOGYPFP:00011
SAE J1930 Terminology List NAS00070
All emission related terms used in this publication in accordance with SAE J1930 are listed. Accordingly, new
terms, new acronyms/abbreviations and old terms are listed in the following chart.
NEW TERM NEW ACRONYM /
ABBREVIATION OLD TERM
Air cleaner ACL Air cleaner
Barometric pressure BARO ***
Barometric pressure sensor-BCDD BAROS-BCDD BCDD
Camshaft position CMP ***
Camshaft position sensor CMPS Crank angle sensor
Canister *** Canister
Carburetor CARB Carburetor
Charge air cooler CAC Intercooler
Closed loop CL Closed loop
Closed throttle position switch CTP switch Idle switch
Clutch pedal position switch CPP switch Clutch switch
Continuous fuel injection system CFI system ***
Continuous trap oxidizer system CTOX system ***
Crankshaft position CKP ***
Crankshaft position sensor CKPS ***
Data link connector DLC ***
Data link connector for CONSULT-II DLC for CONSULT-II Diagnostic connector for CONSULT-II
Diagnostic test mode DTM Diagnostic mode
Diagnostic test mode selector DTM selector Diagnostic mode selector
Diagnostic test mode I DTM I Mode I
Diagnostic test mode II DTM II Mode II
Diagnostic trouble code DTC Malfunction code
Direct fuel injection system DFI system ***
Distributor ignition system DI system Ignition timing control
Early fuel evaporation-mixture heater EFE-mixture heater Mixture heater
Early fuel evaporation system EFE system Mixture heater control
Electrically erasable programmable read
only memory EEPROM ***
Electronic ignition system EI system Ignition timing control
Engine control EC ***
Engine control module ECM ECCS control unit
Engine coolant temperature ECT Engine temperature
Engine coolant temperature sensor ECTS Engine temperature sensor
Engine modification EM ***
Engine speed RPM Engine speed
Erasable programmable read only memory EPROM ***
Evaporative emission canister EVAP canister Canister
Evaporative emission system EVAP system Canister control solenoid valve
Exhaust gas recirculation valve EGR valve EGR valve
Page 3237 of 4462
TERMINOLOGY GI-53
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2006 December 2006 FX35/FX45
Exhaust gas recirculation control-BPT
valve EGRC-BPT valve BPT valve
Exhaust gas recirculation control-solenoid
valve EGRC-solenoid valve EGR control solenoid valve
Exhaust gas recirculation temperature sen-
sor EGRT sensor Exhaust gas temperature sensor
EGR temperature sensor
Flash electrically erasable programmable
read only memory FEEPROM ***
Flash erasable programmable read only
memory FEPROM ***
Flexible fuel sensor FFS ***
Flexible fuel system FF system ***
Fuel pressure regulator *** Pressure regulator
Fuel pressure regulator control solenoid
valve *** PRVR control solenoid valve
Fuel trim FT ***
Heated Oxygen sensor HO2S Exhaust gas sensor
Idle air control system IAC system Idle speed control
Idle air control valve-air regulator IACV-air regulator Air regulator
Idle air control valve-auxiliary air control
valve IACV-AAC valve Auxiliary air control (AAC) valve
Idle air control valve-FICD solenoid valve IACV-FICD solenoid valve FICD solenoid valve
Idle air control valve-idle up control sole-
noid valve IACV-idle up control solenoid valve Idle up control solenoid valve
Idle speed control-FI pot ISC-FI pot FI pot
Idle speed control system ISC system ***
Ignition control IC ***
Ignition control module ICM ***
Indirect fuel injection system IFI system ***
Intake air IA Air
Intake air temperature sensor IAT sensor Air temperature sensor
Knock *** Detonation
Knock sensor KS Detonation sensor
Malfunction indicator lamp MIL Check engine light
Manifold absolute pressure MAP ***
Manifold absolute pressure sensor MAPS ***
Manifold differential pressure MDP ***
Manifold differential pressure sensor MDPS ***
Manifold surface temperature MST ***
Manifold surface temperature sensor MSTS ***
Manifold vacuum zone MVZ ***
Manifold vacuum zone sensor MVZS ***
Mass air flow sensor MAFS Air flow meter
Mixture control solenoid valve MC solenoid valve Air-fuel ratio control solenoid valve
Multiport fuel injection System MFI system Fuel injection control NEW TERM
NEW ACRONYM /
ABBREVIATION OLD TERM
Page 3239 of 4462
TERMINOLOGY GI-55
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2006 December 2006 FX35/FX45
***: Not applicable Transmission control module TCM A/T control unit
Turbocharger TC Turbocharger
Vehicle speed sensor VSS Vehicle speed sensor
Volume air flow sensor VAFS Air flow meter
Warm up oxidation catalyst WU-OC Catalyst
Warm up oxidation catalytic converter sys-
tem WU-OC system ***
Warm up three way catalyst WU-TWC Catalyst
Warm up three way catalytic converter sys-
tem WU-TWC system ***
Wide open throttle position switch WOTP switch Full switch NEW TERM
NEW ACRONYM /
ABBREVIATION OLD TERM
Page 3336 of 4462
IDX-2
ALPHABETICAL INDEX
A
A/C air flow ...................................................... ATC-37
A/C component layout ..................................... ATC-26
A/C compressor clutch removal and installation ...........
ATC-142
A/C compressor mounting ........... ATC-140, ATC-142,
ATC-146
, ATC-147, ATC-148, ATC-149, ATC-150,
ATC-152
, ATC-153, ATC-154, ATC-155
A/C compressor precaution ............................. ATC-13
A/C compressor special service tool ................ ATC-17
A/C control operation (auto A/C) ...................... ATC-34
A/C diagnostic work flow (auto A/C) .............. ATC-101
A/C evaporator ............................................... ATC-154
A/C HFC134a (R134a) system precaution ........ ATC-6
A/C HFC134a (R134a) system service procedure .......
ATC-137
A/C HFC134a (R134a) system service tools ... ATC-18
A/C HFC134a system service equipment precaution ...
ATC-13
A/C lubricant (R134a) ...................................... ATC-27
A/C lubrication oil ........................................... ATC-160
A/C operational check ...................................... ATC-60
A/C self-diagnoses (auto A/C) ........ ATC-52, ATC-101
A/C service data specification ........................ ATC-160
A/C system description (auto A/C) ................... ATC-30
A/C trouble diagnoses (auto A/C) .................... ATC-40
A/C, A - Wiring diagram ................................... ATC-45
A/T fluid checking ...................... AT-13, AT-53, MA-29
A/T fluid cooler cleaning .................................... AT-15
A/T fluid replacement ............................. AT-12, MA-31
A/T fluid temperature sensor ........................... AT-134
A/T IND - Wiring diagram .................................... DI-53
A/T self-diagnoses ........................................... AT-102
A/T shift lock system ........................................ AT-232
A/T shift lock system - Wiring diagram ............ AT-233
A/T trouble diagnoses ........................................ AT-44
Accelerator pedal position (APP) sensor ........ EC-575,
EC-582
, EC-596, EC-1254, EC-1261, EC-1275
Accelerator pedal released position learning .... EC-84,
EC-743
AF1B1-Wiring diagram ...... EC-233, EC-242, EC-251,
EC-261
, EC-606, EC-903, EC-912, EC-921, EC-931,
EC-1285
AF1B2-Wiring diagram ...... EC-235, EC-244, EC-253,
EC-263
, EC-608, EC-905, EC-914, EC-923, EC-933,
EC-1287
AF1HB1-Wiring diagram .................... EC-167, EC-837
AF1HB2-Wiring diagram .................... EC-169, EC-839
Air bag .............................................................. SRS-3
Air bag precautions ........................................... SRS-3
Air cleaner and air duct(VK45DE) ................... EM-177
Air cleaner and air duct(VQ35DE) .................... EM-17
Air cleaner filter replacement ............................ MA-25
Air cleaner filter replacement(VQ35DE) ........... MA-18
Air cleaner filter(VQ35DE) ................................ EM-18
Air conditioner cut control .................... EC-35, EC-695
Air flow meter - See Mass air flow sensor ...... EC-188,
EC-197
, EC-858, EC-867
Air fuel ratio sensor 1 ......... EC-230, EC-240, EC-249,
EC-258
, EC-604, EC-900, EC-910, EC-919, EC-928,
EC-1283
Air fuel ratio sensor 1 heater ............. EC-165, EC-836
Air mix. door motor ......................... ATC-71, ATC-131
Ambient sensor ............................. ATC-103, ATC-116
Angular tightening application ............................. EM-6
Angular tightening application(VK45DE) ........ EM-165
APPS1 - Wiring diagram ................. EC-577, EC-1256
APPS2 - Wiring diagram ................. EC-584, EC-1263
APPS3 - Wiring diagram ................. EC-598, EC-1277
ASC/BS - Wiring diagram ............... EC-540, EC-1213
ASC/SW - Wiring diagram .............. EC-523, EC-1196
ASCBOF - Wiring diagram .............. EC-617, EC-1296
ASCD .................................................. EC-36, EC-696
ASCD (automatic speed control device) ........... ACS-3
ASCD brake switch .......................................... EC-538
ASCD indicator lamp ....................................... EC-623
ASCD steering switch ...................................... EC-521
ASCIND - Wiring diagram ............... EC-624, EC-1303
AT indicator lamp ................................................ DI-52
Auto air conditioner - Wiring diagram ............. ATC-45
Auto amp ...................................................... ATC-115
Auto anti-dazzling inside mirror ....................... GW-65
Automatic amplifier ........... ATC-50, ATC-62, ATC-115
Automatic transmission fluid replacement ........ MA-32
AV communication line ........................ AV-64, AV-108
AWD - Wiring diagram ....................................... TF-17
Axle ................................................................... MA-37
Axle housing (rear) ........................................... RAX-7
B
Back Door ........................................................ BL-158
Back door ......................................................... BL-158
Back door opener - See Back door .................. BL-162
Basic inspection .................................. EC-77, EC-737
Battery ................................................................. SC-4
Battery/Starting/Charging System Tester SC-7, SC-11,
SC-23
BCM (Body control module) .............................. BCS-3
Block heater(VK45DE) .................................... EM-248
Block heater(VQ35DE) ................................... EM-123
Blower motor ................................... ATC-77, ATC-122
Blower unit .................................................... ATC-120
Brake booster .................................................... BR-15
Brake fluid level ................................................ MA-35
Brake hydraulic line ........................................... BR-11
Brake inspection ............................................... MA-36
Brake lines and cables inspection .................... MA-35
Brake master cylinder ........................................ BR-13
Brake switch ................................... EC-551, EC-1229
BRK/SW - Wiring diagram .............. EC-552, EC-1230
Bulb specifications ........................................... LT-204
Bumper, front ...................................................... EI-14
Bumper, rear ....................................................... EI-17
Page 3338 of 4462
IDX-4
ALPHABETICAL INDEX
Electrical load signal circuit .............. EC-626, EC-1305
Electrical unit ..................................................... PG-75
Electrical units location ...................................... PG-68
Electronic ignition (EI) system ............. EC-33, EC-693
Engine control circuit diagram ......................... EC-108
Engine control component parts location ......... EC-101
Engine control module (ECM) .......... EC-481, EC-1146
Engine control system diagram ........... EC-30, EC-690
Engine coolant temperature sensor (ECTS) ... EC-210,
EC-222
, EC-879, EC-892
Engine coolant(VK45DE) .................................. CO-38
Engine coolant(VQ35DE) ................................. CO-11
Engine fail-safe system ...................................... EC-96
Engine oil filter replacement ............................. MA-26
Engine oil filter replacement(VQ35DE) ............. MA-19
Engine oil precautions .......................................... GI-8
Engine oil replacement(VQ35DE) ..................... MA-18
Engine oil(VK45DE) ........................................... LU-25
Engine oil(VQ35DE) ............................................ LU-7
Engine removal(VK45DE) ............................... EM-243
Engine removal(VQ35DE) .............................. EM-113
Engine room cover(VK45DE) ......................... EM-173
ETC1 - Wiring diagram .................... EC-563, EC-1241
ETC2 - Wiring diagram .................... EC-558, EC-1236
ETC3 - Wiring diagram .................... EC-569, EC-1248
EVAP canister ...................................... EC-42, EC-702
EVAP canister purge volume control solenoid valve ....
EC-397
, EC-405, EC-1063, EC-1071
EVAP canister vent control valve ...... EC-412, EC-419,
EC-1078
, EC-1085
EVAP control system (small leak) diagnosis .. EC-388,
EC-450
, EC-1054, EC-1116
EVAP control system pressure sensor ........... EC-425,
EC-428
, EC-434, EC-1091, EC-1094, EC-1100
EVAP control system purge flow monitoring diagnosis
EC-383
, EC-1049
EVAP vapor lines inspection ................. MA-21, MA-28
Evaporative emission (EVAP) system . EC-39, EC-699
Evaporator ..................................................... ATC-154
Exhaust manifold(VK45DE) ............................ EM-183
Exhaust manifold(VQ35DE) .............................. EM-26
Exhaust system ................................................... EX-3
Exhaust system inspection ..................... EX-3, MA-29
Expansion valve ............................................. ATC-155
F
F/PUMP - Wiring diagram ................ EC-636
, EC-1315
Final drive pre-inspection .................. FFD-20, RFD-19
Final drive removal and installation .. FFD-13, FFD-15,
RFD-16
Floor trim ............................................................. EI-40
Flow charts ......................................................... GI-28
Fluid temperature sensor (A/T) ........................ AT-134
Fluorescent leak detector .............................. ATC-156
Freeze frame data ............................... EC-59, EC-720
Front axle ................................ FAX-4, FAX-10, RAX-5
Front brake solenoid valve ................. AT-150, AT-152
Front bumper ...................................................... EI-14
Front door ............................. BL-148, BL-152, GW-58
Front passenger air bag .................................. SRS-42
Front seat belt ...................................................... SB-4
Front seat belt pre-tensioner ..... SB-2, SRS-3, SRS-48
Front suspension .............................................. FSU-6
FTS - Wiring diagram ....................................... AT-135
FTTS - Wiring diagram ...... EC-330, EC-335, EC-999,
EC-1004
Fuel cut control (at no load high engine speed) EC-34,
EC-694
Fuel filter replacement ......................................... FL-4
Fuel gauge ............................................................ DI-5
Fuel injection system (Bank 1) ......... EC-305, EC-317,
EC-975
, EC-986
Fuel injection system (Bank 2) ......... EC-305, EC-317,
EC-975
, EC-986
Fuel injector ..................................................... EC-628
Fuel injector and fuel tube(VK45DE) .............. EM-194
Fuel injector and fuel tube(VQ35DE) ................ EM-45
Fuel level sensor EC-460, EC-462, EC-464, EC-1125,
EC-1127
, EC-1129
Fuel line inspection .................................. FL-3, MA-25
Fuel line inspection(VQ35DE) .......................... MA-17
Fuel precautions .......................................... GI-6, GI-7
Fuel pressure check ........................... EC-86, EC-746
Fuel pressure release ......................... EC-86, EC-746
Fuel pump ....................................... EC-635, EC-1314
Fuel pump and gauge .......................................... FL-4
Fuel system ......................................................... FL-3
Fuel tank ............................................................ FL-10
Fuel tank temperature sensor .......... EC-328, EC-334,
EC-997
, EC-1003
Fuel tank vacuum relief valve ............. EC-42, EC-702
FUELB1 - Wiring diagram .. EC-307, EC-319, EC-977,
EC-988
FUELB2 - Wiring diagram .. EC-309, EC-321, EC-979,
EC-990
Fuse .................................................................. PG-16
Fuse and fusible link box .................................. PG-82
Fusible link ........................................................ PG-16
G
Gauges ................................................................. DI-5
Generic scan tool (GST) .................................. EC-130
Glass ...................................... GW-11, GW-58, GW-62
Grille - See Exterior ............................................ EI-22
Ground distribution ........................................... PG-29
H
Harness connector ............................................ PG-72
Harness layout .................................................. PG-44
Headlining - See Roof trim .................................. EI-42
Heated oxygen sensor 2 (bank 1) .... EC-270, EC-281,
EC-294
, EC-940, EC-951, EC-964
Heated oxygen sensor 2 (bank 2) .... EC-270, EC-281,
EC-294
, EC-940, EC-951, EC-964
Heated oxygen sensor 2 heater (bank 1) ....... EC-173,
Page 3339 of 4462
IDX-5
A
C
D E
F
G H
I
J
K L
B
IDX
ALPHABETICAL INDEX
EC-843
Heated oxygen sensor 2 heater (bank 2) .......
EC-173,
EC-843
Heated seat ....................................................... SE-94
Heater and cooling unit (Heater core) ........... ATC-125
HFC134a (R134a) system precaution ............... ATC-6
HFC134a (R134a) system service procedure ATC-137
HFC134a (R134a) system service tools .......... ATC-18
HFC134a system service equipment precaution ..........
ATC-13
High and low reverse clutch solenoid valve .... AT-158,
AT-160
Hood ................................................................... BL-13
How to erase DTC for OBD system ..... EC-59, EC-727
HSEAT - Wiring diagram ................................... SE-95
I
IATS - Wiring diagram ....................... EC-207
, EC-876
ICC - Wiring diagram ....................................... ACS-21
ICC/BS - Wiring diagram ................. EC-531, EC-1204
ICC/SW - Wiring diagram ................ EC-516, EC-1189
ICCBOF - Wiring diagram ................ EC-642, EC-1321
Idle air volume learning ....................... EC-84, EC-744
Idle speed .............................. EC-82, EC-737, EC-742
Idle speed control (ISC) .... EC-468, EC-470, EC-1133,
EC-1135
Ignition coil ....................................... EC-649, EC-1328
Ignition coil(VK45DE) ...................................... EM-191
Ignition coil(VQ35DE) ........................................ EM-42
Ignition control system ..................... EC-649, EC-1328
Ignition timing ........................ EC-82, EC-737, EC-742
IGNSYS - Wiring diagram ................ EC-650, EC-1329
In vehicle sensor ........................... ATC-106, ATC-117
INF/D - Wring diagram ....................................... AV-57
INJECT - Wiring diagram ................. EC-629, EC-1308
Injector ........................................................... EC-1307
Input clutch solenoid valve ................. AT-146, AT-148
Instrument panel .................................................. IP-10
Intake air temperature sensor ........... EC-205, EC-225,
EC-874
, EC-895
Intake door control linkage adjustment ............ ATC-76
Intake door motor ........................... ATC-74, ATC-123
Intake manifold collector(VQ35DE) ................... EM-19
Intake manifold(VK45DE) ................................ EM-179
Intake manifold(VQ35DE) .................................. EM-24
Intake sensor ................................ ATC-112, ATC-119
Intake valve timing control (Bank 1) .. EC-161, EC-824
Intake valve timing control (Bank 2) .. EC-161, EC-824
Intake valve timing control position sensor (Bank 1) ....
EC-1159
Intake valve timing control position sensor (Bank 2) ....
EC-1159
Intake valve timing control solenoid valve (Bank 1) ......
EC-181
, EC-851
Intake valve timing control solenoid valve (Bank 2) ......
EC-181
, EC-851
Integrated homelink transmitter ........................ BL-227
Intelligent cruise control (ICC) system ............... ACS-6
Interior ................................................................. EI-37
IPDM (Intelligent power distribution module engine
room) ................................................................. PG-17
IVCB1 - Wiring diagram ..................... EC-182, EC-852
IVCB2 - Wiring diagram ..................... EC-184, EC-854
IVCSB1 - Wiring diagram ............................... EC-1161
IVCSB2 - Wiring diagram ............................... EC-1163
IVTB1 - Wiring diagram ................................... EC-827
IVTB2 - Wiring diagram ................................... EC-829
K
Knock sensor (KS) ........................... EC-356
, EC-1025
KS - Wiring diagram ......................... EC-357, EC-1026
L
LAN system circuit ........................................... ATC-64
Lane Departure Warning System ....................... DI-80
Laser beam aiming adjustment ....................... ACS-14
Latch (lower anchors and tether for children) system ...
SB-10
LDW .................................................................... DI-80
LDW - Wiring Diagram ........................................ DI-92
Line pressure solenoid valve ........................... AT-129
Line pressure test (A/T) ..................................... AT-54
Liquid gasket application ......................... EM-6, LU-21
Liquid gasket application(VQ35DE) ........... LU-3, CO-3
Location of electrical units ................................. PG-68
Low coast brake solenoid valve ......... AT-162, AT-164
Low tire pressure warning system .................... WT-10
Lubricant (R134a) A/C ..................................... ATC-27
Lubrication circuit (engine)(VK45DE) ................ LU-23
Lubrication circuit (engine)(VQ35DE) .................. LU-5
Lubrication oil A/C .......................................... ATC-160
M
M/ANT - Wiring diagram .................................... AV-49
MAFS - Wiring diagram ..... EC-191, EC-199, EC-861,
EC-869
Magnet clutch ................................. ATC-82, ATC-142
MAIN - Wiring diagram ........ EC-149, EC-812, AT-179
Maintenance (engine)(VQ35DE) ...................... MA-14
Major overhaul (Final drive) .............. FFD-17, RFD-18
Major overhaul (Transfer) .................................. TF-45
Malfunction indicator lamp (MIL) .......... EC-68, EC-729
Mass air flow sensor (MAFS) ............ EC-188, EC-197,
EC-858
, EC-867
Meter ..................................................................... DI-5
METER - Wiring diagram .................................... DI-12
MIL data link connectors circuit ....... EC-672, EC-1360
MIL/DL - Wiring diagram .................. EC-672, EC-1360
Mirror, door ....................................................... GW-92
Mirror, out side .................................................. GW-92
Misfire .............................................. EC-346, EC-1015
MMSW - Wiring diagram .................................. AT-167
Mode door control linkage adjustment ............. ATC-70
Mode door motor ............................ ATC-68, ATC-130
Page 3341 of 4462
IDX-7
A
C
D E
F
G H
I
J
K L
B
IDX
ALPHABETICAL INDEX
Removal and installation (A/T) ...........
AT-266, AT-269
Removal and installation (Transfer) .................... TF-44
Revolution sensor (A/T) ...................... AT-118, AT-259
Rocker cover(VK45DE) ................................... EM-200
Rocker cover(VQ35DE) ..................................... EM-51
RP/SEN - Wiring diagram ................ EC-663, EC-1342
S
SAE J1979 - Service $01 - 09 ........... EC-130
, EC-714
Seal - See Exterior .............................................. EI-27
Seat belt inspection ............................................. SB-7
Seat belt, front ..................................................... SB-4
Seat, rear ......................................................... SE-105
Self-diagnosis (Transfer) .................................... TF-22
Self-diagnostic results ....................................... EC-71
SEN/PW - Wiring diagram ............... EC-485, EC-1150
SHIFT - Wiring diagram ................................... AT-233
Shift lock system .............................................. AT-232
Shift schedule .................................................. AT-359
Shock absorber (rear) ....................................... RSU-9
Side air bag (satellite) sensor .......................... SRS-47
Side curtain air bag .......................................... SRS-44
Side trim .............................................................. EI-37
SMJ (super multiple junction) ............................ PG-77
SNOW MODE SW ........................... EC-667, EC-1346
SNOWSW - Wiring diagram ............ EC-668, EC-1347
Spark plug replacement ..................................... MA-27
Spark plug replacement(VQ35DE) .................... MA-20
Spark plug(VK45DE) ....................................... EM-192
Spark plug(VQ35DE) ......................................... EM-43
Specification value ............................. EC-138, EC-801
Speedometer ........................................................ DI-5
Spiral cable ...................................................... SRS-40
SROOF - Wiring diagram ..................... BL-166, RF-13
SRS - See Supplemental Restraint System ...... SRS-5
SRS - Wiring diagram ...................................... SRS-12
SRS Trouble diagnoses ..................................... SRS-8
Stabilizer bar (rear) ......................................... RSU-16
Stall test (A/T) .................................................... AT-53
Standardized relay ............................................. PG-79
START - Wiring diagram ..................................... SC-9
Starter .................................................................. SC-8
Starting system .................................................... SC-8
Steering gear and linkage inspection ................ MA-36
Steering linkage ................................................. PS-17
Steering wheel and column ................... PS-10, PS-12
Steering wheel turning force .............................. PS-10
Stop lamp switch ............................. EC-551, EC-1229
STSIG - Wiring diagram .................................. AT-108
Sun roof, electric ................................................ RF-10
Sunload sensor ............................. ATC-109, ATC-118
Sunroof .................................................. RF-10, RF-23
Supplemental Restraint System ........................ SRS-5
Supplemental restraint system - Wiring diagram ..........
SRS-12
Suspension ........................................................ MA-37
Symbols and abbreviations ..................... GI-11, GI-24
Symptom matrix chart ........................................ EC-97
System readiness test (SRT) code ...... EC-60, EC-720
T
Tachometer ........................................................... DI-5
TCM circuit diagram ........................................... AT-52
TCM inspection table ......................................... AT-89
Thermostat(VK45DE) ....................................... CO-53
Thermostat(VQ35DE) ....................................... CO-27
Three way catalyst function (Bank 1) EC-377, EC-1044
Three way catalyst function (Bank 2) EC-377, EC-1044
Three way catalyst precautions ............................ GI-5
Three way catalyst(VK45DE) .......................... EM-183
Three way catalyst(VQ35DE) ........................... EM-26
Throttle control motor ....................... EC-568, EC-1247
Throttle control motor relay .............. EC-556, EC-1234
Throttle position sensor (TPS) .......... EC-215, EC-339,
EC-510
, EC-512, EC-589, EC-885, EC-1008, EC-1183,
EC-1185
, EC-1268
Throttle valve closed position learning . EC-84, EC-744
Tie-rod ............................................................... PS-17
Timing chain(VK45DE) ................................... EM-203
Timing chain(VQ35DE) ..................................... EM-64
Tire rotation ............................................. WT-9, MA-35
Top tether strap child restraint ........................... SB-11
Torque converter installation AT-267, AT-268, AT-272
Torque convertor clutch solenoid valve AT-125, AT-127
TPS1 - Wiring diagram .................... EC-341, EC-1010
TPS2 - Wiring diagram ...................... EC-217, EC-887
TPS3 - Wiring diagram .................... EC-591, EC-1270
Traction control system circuit (engine) .......... EC-495,
EC-496
Transfer control unit inspection table ................. TF-20
Transverse link (front) ...................................... FSU-14
TRNSCV - Wiring diagram ............................... BL-227
Trouble diagnoses .............................................. GI-12
Two trip detection logic ........................ EC-54, EC-714
Tyre pressure monitoring system - trouble diagnoses ..
WT-13
Tyre pressure monitoring system - wiring diagram .......
WT-14
U
Unified meter and A/C amp. ............................... DI-28
V
Vacuum hose (brake system) ............................ BR-17
Vacuum hose drawing (Engine control) ........... EC-107
Valve clearance(VK45DE) .............................. EM-222
Valve clearance(VQ35DE) ................................ EM-93
Valve guide ..................................................... EM-108
Valve guide(VK45DE) ..................................... EM-239
Valve lifter ......................................................... EM-87
Valve seat(VK45DE) ....................................... EM-241
Valve seat(VQ35DE) ...................................... EM-110
Valve spring(VK45DE) .................................... EM-242
Valve spring(VQ35DE) ................................... EM-111
Page 3342 of 4462
IDX-8
ALPHABETICAL INDEX
Variable induction air control system (VIAS) EC-1224,
EC-1351
VDC -Wiring diagram ...................................... BRC-16
Vehicle security (theft warning) system ........... BL-180
Vehicle speed sensor (VSS) ........... EC-466, EC-1131,
EC-1223
VEHSEC - Wiring diagram ............................... BL-186
VENT/V - Wiring diagram EC-414, EC-421, EC-1080,
EC-1087
VIAS - Wiring diagram ................................... EC-1353
VIAS/V - Wiring diagram ................................ EC-1225
VIN registration .................................... EC-83, EC-743
VSS A/T - Wiring diagram ................................ AT-120
W
WARN - Wiring diagram ..................................... DI-40
Warning chime .................................................... DI-56
Warning lamps .................................................... DI-38
Water control valve(VK45DE) ........................... CO-53
Water pump(VK45DE) ...................................... CO-51
Water pump(VQ35DE) ...................................... CO-22
Water temperature gauge ..................................... DI-5
Wheel alignment (front) ..................................... FSU-6
Wheel alignment (rear) ..................................... RSU-5
Wheel balance ........................................ WT-8, MA-33
Wheel bearing (front) .............. FAX-4, FAX-10, RAX-5
Wheel hub (front) .................... FAX-4, FAX-10, RAX-5
Wheel sensor (VDC) ....................................... BRC-55
WINDOW - Wiring diagram ............................... GW-22
Window, door ...................................... GW-58, GW-62
Windshield ........................................................ GW-11
Wiring Diagram (Cell code) list .......................... PG-65
Wiring diagrams .................................................. GI-16
WT-T/WARN - Wiring diagram ......................... WT-14
