Page 561 of 4462
AUTO AMP ATC-115
C
D E
F
G H
I
K L
M A
B
AT C
Revision: 2006 December 2006 FX35/FX45
AUTO AMPPFP:27760
Removal and Installation of Unified Meter and A/C Amp.NJS000EK
REMOVAL
1. Remove audio unit. Refer to AV- 4 3 , "Removal and Installation of Audio Unit" .
2. Remove mounting screws, and then remove unified meter and A/C amp.
INSTALLATION
Installation is basically the reverse order of removal.
SJIA1603E
Page 562 of 4462
ATC-116
AMBIENT SENSOR
Revision: 2006 December 2006 FX35/FX45
AMBIENT SENSORPFP:27722
Removal and InstallationNJS000EL
REMOVAL
1. Remove front grille. Refer to EI-22, "FRONT GRILLE" .
2. Disconnect ambient sensor connector, and then remove ambi- ent sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2016E
Page 563 of 4462
IN-VEHICLE SENSOR ATC-117
C
D E
F
G H
I
K L
M A
B
AT C
Revision: 2006 December 2006 FX35/FX45
IN-VEHICLE SENSORPFP:27720
Removal and InstallationNJS000EM
REMOVAL
1. Remove instrument driver lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove mounting screw, and then remove in-vehicle sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2036E
Page 564 of 4462
ATC-118
SUNLOAD SENSOR
Revision: 2006 December 2006 FX35/FX45
SUNLOAD SENSORPFP:27721
Removal and InstallationNJS000EN
REMOVAL
1. Remove front defroster grille (RH). Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect sunload sensor connector, and then remove the sunload sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2026E
Page 565 of 4462

INTAKE SENSOR ATC-119
C
D E
F
G H
I
K L
M A
B
AT C
Revision: 2006 December 2006 FX35/FX45
INTAKE SENSORPFP:27723
Removal and InstallationNJS000EO
REMOVAL
1. Remove low-pressure pipe 2 and high-pressure pipe 3. Refer to ATC-150, "Removal and Installation of
Low-pressure Pipe 2 and High-pressure Pipe 3" .
CAUTION:
Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
2. Slide evaporator to passenger side, and then remove intake sensor.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings of A/C piping with new ones, and then apply compressor oil to it when installing
it.
Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sen-
sor can be located in the same position.
Female-side piping connection is thin and easy to deform. slowly insert the male-side piping
straight in axial direction.
Insert piping securely until a click is heard.
After piping connection is completed, pull male-side piping by hand to make sure that connection
does not come loose.
When recharging refrigerant, check for leaks.
RJIA0928E
Page 566 of 4462
ATC-120
BLOWER UNIT
Revision: 2006 December 2006 FX35/FX45
BLOWER UNITPFP:27200
Removal and InstallationNJS000EP
REMOVAL
1. Remove instrument passenger lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove mounting nut, and then remove ECM with bracket attached.
3. Disconnect intake door motor connector and blower fan motor connector.
4. Remove harness clip from blower unit.
5. Remove mounting bolt and screws from blower unit.
CAUTION:
Move blower unit rightward, and remove locating pin (1
part) and joint. Then remove blower unit downward.
6. Remove blower unit.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Make sure locating pin (1 part) and joint are securely inserted.
RJIA2039E
RJIA0943E
Page 567 of 4462
BLOWER UNIT ATC-121
C
D E
F
G H
I
K L
M A
B
AT C
Revision: 2006 December 2006 FX35/FX45
Disassembly and AssemblyNJS000EQ
1. Adapter 2. Intake upper case 3. Filter cover
4. In-cabin microfilter 5. Intake lower case 6. Blower motor assembly
7. Motor cover 8. Intake door lever 2 9. Intake door motor
10. Intake door link 11. Intake door lever 3 12. Intake door 2
13. Intake door lever 1 14. Intake door 1 15. Intake bell mouth
SJIA0420E
Page 568 of 4462
ATC-122
BLOWER MOTOR
Revision: 2006 December 2006 FX35/FX45
BLOWER MOTORPFP:27226
Removal and InstallationNJS000ER
REMOVAL
1. Remove instrument lower cover. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect blower motor connector.
3. Remove mounting screws, and then remove blower motor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2239E
Page 569 of 4462
INTAKE DOOR MOTOR ATC-123
C
D E
F
G H
I
K L
M A
B
AT C
Revision: 2006 December 2006 FX35/FX45
INTAKE DOOR MOTORPFP:27730
Removal and InstallationNJS000ES
REMOVAL
1. Remove blower unit. Refer to ATC-120, "BLOWER UNIT" .
2. Remove mounting screws, and then remove intake door motor from blower unit.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA0947E
Page 570 of 4462
ATC-124
IN-CABIN MICROFILTER
Revision: 2006 December 2006 FX35/FX45
IN-CABIN MICROFILTERPFP:27277
Removal and InstallationNJS000ET
FUNCTION
Air inside passenger compartment is kept clean at either recircula-
tion or fresh mode by installing in-cabin microfilter into blower unit.
REPLACEMENT TIMING
Replace in-cabin microfilter.
Refer to MA-9, "
CHASSIS AND BODY MAINTENANCE" in Schedule 1 and MA-11, "CHASSIS AND BODY
MAINTENANCE" in Schedule 2.
Caution label is fixed inside glove box.
REPLACEMENT PROCEDURES
1. Remove instrument passenger lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove filter cover, and then remove in-cabin microfilter.
3. Take out in-cabin microfilter from blower unit.
4. Replace with new one and reinstall on blower unit.
5. Reinstall instrument passenger lower panel.
RJIA1331E
RJIA2040E
