LT-1
LIGHTING SYSTEM
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION LT
A
B
LT
Revision: 2006 December 2006 FX35/FX45
LIGHTING SYSTEM
PRECAUTIONS ..................................................... ..... 5
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 5
General Precautions for Service Operations ....... ..... 6
HEADLAMP - XENON TYPE - .............................. ..... 7
Component Parts and Harness Connector Location ..... 7
System Description ............................................. ..... 7
OUTLINE .......................................................... ..... 7
HEADLAMP OPERATION ............................... ..... 8
COMBINATION SWITCH READING FUNCTION ..... 9
EXTERIOR LAMP BATTERY SAVER CONTROL ..... 9
AUTO LIGHT OPERATION (IF EQUIPPED) .... ..... 9
VEHICLE SECURITY SYSTEM ....................... ..... 9
XENON HEADLAMP ........................................ ..... 9
CAN Communication System Description ........... ..... 9
CAN Communication Unit ................................... ..... 9
Schematic ........................................................... ... 10
Wiring Diagram — H/LAMP — ............................ .... 11
Terminals and Reference Values for BCM .......... ... 15
Terminals and Reference Values for IPDM E/R .. ... 16
How to Proceed With Trouble Diagnosis ............. ... 17
Preliminary Check ............................................... ... 17
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 17
CONSULT-II Functions (BCM) ............................ ... 19
CONSULT-II BASIC OPERATION .................... ... 19
WORK SUPPORT ............................................ ... 19
DATA MONITOR .............................................. ... 19
ACTIVE TEST .................................................. ... 20
CONSULT-II Functions (IPDM E/R) .................... ... 21
CONSULT-II BASIC OPERATION .................... ... 21
DATA MONITOR .............................................. ... 21
ACTIVE TEST .................................................. ... 22
Headlamp Does Not Change To High Beam (Both
Sides) .................................................................. ... 22
Headlamp Does Not Change To High Beam (One
Side) .................................................................... ... 24
Headlamp Low Beam Does Not Illuminate (Both
Sides) .................................................................. ... 25 Headlamp Low Beam Does Not Illuminate (One
Side) .................................................................... ... 28
Headlamp RH Low Beam and High Beam Does Not
Illuminate ............................................................. ... 29
Headlamp LH Low Beam and High Beam Does Not
Illuminate ............................................................. ... 30
Headlamps Do Not Turn OFF .............................. ... 31
General Information for Xenon Headlamp Trouble
Diagnosis ............................................................. ... 33
Caution: ............................................................... ... 33
Xenon Headlamp Trouble Diagnosis ................... ... 33
Aiming Adjustment ............................................... ... 34
PREPARATION BEFORE ADJUSTING ........... ... 34
LOW BEAM AND HIGH BEAM ........................ ... 34
ADJUSTMENT USING AN ADJUSTMENT
SCREEN (LIGHT/DARK BORDERLINE) ......... ... 35
Bulb Replacement ............................................... ... 35
HEADLAMP HIGH/LOW BEAM ....................... ... 35
DAYTIME/PARKING LAMP .............................. ... 36
FRONT TURN SIGNAL LAMP ......................... ... 36
FRONT SIDE MARKER LAMP ........................ ... 36
Removal and Installation ..................................... ... 36
REMOVAL ........................................................ ... 36
INSTALLATION ................................................ ... 37
Disassembly and Assembly ................................. ... 37
DISASSEMBLY ................................................ ... 37
ASSEMBLY ...................................................... ... 37
DAYTIME LIGHT SYSTEM .................................... ... 39
Component Parts and Harness Connector Location ... 39
System Description .............................................. ... 39
OUTLINE .......................................................... ... 39
DAYTIME LIGHT OPERATION ........................ ... 40
COMBINATION SWITCH READING FUNCTION ... 40
AUTO LIGHT OPERATION .............................. ... 40
CAN Communication System Description ........... ... 40
CAN Communication Unit .................................... ... 40
Schematic ............................................................ ... 41
Wiring Diagram — DTRL — ................................ ... 42
Terminals and Reference Values for BCM ........... ... 46
How to Proceed With Trouble Diagnosis ............. ... 48
Page 3564 of 4462
LT-2Revision: 2006 December 2006 FX35/FX45 Preliminary Check ...............................................
... 49
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 49
INSPECTION PARKING BRAKE SWITCH CIR-
CUIT ................................................................. ... 50
CONSULT-II Functions (BCM) ............................. ... 51
CONSULT-II BASIC OPERATION .................... ... 51
DATA MONITOR ............................................... ... 51
ACTIVE TEST .................................................. ... 52
Daytime Light Control Does Not Operate Properly ... 53
Aiming Adjustment ............................................... ... 55
Bulb Replacement ............................................... ... 55
Removal and Installation ..................................... ... 55
Disassembly and Assembly ................................. ... 55
AUTO LIGHT SYSTEM .......................................... ... 56
Component Parts and Harness Connector Location ... 56
System Description .............................................. ... 56
OUTLINE .......................................................... ... 56
COMBINATION SWITCH READING FUNCTION ... 57
DELAY TIMER FUNCTION .............................. ... 57
CAN Communication System Description ........... ... 57
CAN Communication Unit .................................... ... 57
Major Components and Functions ....................... ... 57
Schematic ............................................................ ... 58
Wiring Diagram — AUTO/L — ............................. ... 59
Terminals and Reference Values for BCM ........... ... 62
Terminals and Reference Values for IPDM E/R ... ... 63
How to Proceed With Trouble Diagnosis ............. ... 63
Preliminary Check ............................................... ... 64
SETTING CHANGE FUNCTIONS .................... ... 64
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 64
CONSULT-II Functions (BCM) ............................. ... 66
CONSULT-II BASIC OPERATION .................... ... 66
WORK SUPPORT ............................................ ... 66
DATA MONITOR ............................................... ... 66
ACTIVE TEST .................................................. ... 68
CONSULT-II Functions (IPDM E/R) ..................... ... 68
CONSULT-II BASIC OPERATION .................... ... 68
DATA MONITOR ............................................... ... 68
ACTIVE TEST .................................................. ... 69
Symptom Chart .................................................... ... 69
Lighting Switch Inspection ................................... ... 69
Optical sensor System Inspection ....................... ... 70
Removal and Installation of Optical Sensor ......... ... 72
REMOVAL ........................................................ ... 72
INSTALLATION ................................................. ... 72
HEADLAMP AIMING CONTROL ........................... ... 73
Schematic ............................................................ ... 73
Wiring Diagram — H/AIM — ................................ ... 74
Removal and Installation ..................................... ... 77
REMOVAL ........................................................ ... 77
INSTALLATION ................................................. ... 77
Switch Circuit Inspection ..................................... ... 77
FRONT FOG LAMP ............................................... ... 78
Component Parts and Harness Connector Location ... 78
System Description .............................................. ... 78
OUTLINE .......................................................... ... 78
FRONT FOG LAMP OPERATION .................... ... 79 COMBINATION SWITCH READING FUNCTION
... 79
EXTERIOR LAMP BATTERY SAVER CONTROL ... 79
CAN Communication System Description ........... ... 79
CAN Communication Unit .................................... ... 79
Wiring Diagram — F/FOG — ............................... ... 80
Terminals and Reference Values for BCM ........... ... 82
Terminals and Reference Values for IPDM E/R ... ... 82
How to Proceed With Trouble Diagnosis ............. ... 83
Preliminary Check ................................................ ... 83
CHECK POWER SUPPLY AND GROUND CIR-
CUIT .................................................................. ... 83
CONSULT-II Functions (BCM) ............................. ... 84
CONSULT-II Functions (IPDM E/R) ..................... ... 84
Front Fog Lamps Do Not Illuminate (Both Sides) ... 85
Front Fog Lamp Does Not Illuminate (One Side) . ... 87
Aiming Adjustment ............................................... ... 88
Bulb Replacement ................................................ ... 89
Removal and Installation ...................................... ... 89
REMOVAL ......................................................... ... 89
INSTALLATION ................................................. ... 89
TURN SIGNAL AND HAZARD WARNING LAMPS ... 90
Component Parts and Harness Connector Location ... 90
System Description .............................................. ... 90
TURN SIGNAL OPERATION ............................ ... 90
HAZARD LAMP OPERATION .......................... ... 91
REMOTE CONTROL ENTRY SYSTEM OPER-
ATION ............................................................... ... 92
COMBINATION SWITCH READING FUNCTION ... 93
CAN Communication System Description ........... ... 93
CAN Communication Unit .................................... ... 93
Schematic ............................................................ ... 94
Wiring Diagram — TURN — ................................ ... 95
Terminals and Reference Values for BCM ........... ... 98
Terminals and Reference Value for Rear Combina-
tion Lamp Control Unit ......................................... ... 99
How to Proceed With Trouble Diagnosis ............. .102
Preliminary Check ................................................ .102
CHECK POWER SUPPLY AND GROUND CIR-
CUIT .................................................................. .102
CONSULT-II Functions (BCM) ............................. .104
CONSULT-II BASIC OPERATION .................... .104
DATA MONITOR ............................................... .104
ACTIVE TEST ................................................... .104
Turn Signal Lamp Does Not Operate ................... .105
Rear Turn Signal Lamp Does Not Operate .......... .106
Hazard Warning Lamp Does Not Operate But Turn
Signal Lamp Operate ........................................... .108
Bulb Replacement (Front Turn Signal Lamp) ....... .110
Bulb Replacement (Rear Turn Signal Lamp) ....... .110
Removal and Installation of Front Turn Signal Lamp .110
Removal and Installation of Rear Turn Signal Lamp .110
Removal and Installation of Rear Combination
Lamp Control Unit ................................................ .110
REMOVAL ......................................................... .110
INSTALLATION ................................................. .110
LIGHTING AND TURN SIGNAL SWITCH ............. . 111
Removal and Installation ...................................... . 111
REMOVAL ......................................................... . 111
INSTALLATION ................................................. . 111
Page 3571 of 4462
HEADLAMP - XENON TYPE - LT-9
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 December 2006 FX35/FX45
Ground is supplied
to front combination lamp RH and LH terminals 7
through grounds E21, E50 and E51,
With power and ground supplied, the high beam headlamps illuminate.
If voltage is applied to a high beam solenoid, the bulb shade will move, even a xenon head lamp bulb comes
out, and a high beam and a low beam are changed.
The unified meter and A/C amp. that received the high beam request signal by BCM through the CAN commu-
nication makes a high beam indicator lamp turn on in combination meter.
COMBINATION SWITCH READING FUNCTION
Refer to BCS-3, "COMBINATION SWITCH READING FUNCTION" .
EXTERIOR LAMP BATTERY SAVER CONTROL
When the combination switch (lighting switch) is in the 2ND position (ON), and the ignition switch is turned
from ON or ACC to OFF, the battery saver control function is activated.
Under this condition, the headlamps remain illuminated for 5 minutes, then the headlamps are turned OFF.
Exterior lamp battery saver control mode can be changed by the function setting of CONSULT-II.
AUTO LIGHT OPERATION (IF EQUIPPED)
Refer to LT- 5 6 , "System Description" .
VEHICLE SECURITY SYSTEM
The vehicle security system will flash the high beams if the system is triggered. Refer to BL-180, "VEHICLE
SECURITY (THEFT WARNING) SYSTEM" .
XENON HEADLAMP
Xenon type lamps are used for to the low beam headlamps. Xenon bulbs do not use a filament. Instead, they
produce light when a high voltage current is passed between two tungsten electrodes through a mixture of
xenon (an inert gas) and certain other metal halides. In addition to strong lighting power, electronic control of
the power supply gives the headlamps stable quality and tone color.
Followings are some advantages of the xenon type headlamp.
The light produced by the headlamps is white color similar to sunlight that is easy to the eyes.
Light output is nearly double that of halogen headlamps, affording increased area of illumination.
Retroreflected luminance increases and the contrast enhances on the wet road in the rain. That makes
visibility go up more than the increase of the light volume.
Power consumption is approximately 25 percent less than halogen headlamps, reducing battery load.
CAN Communication System DescriptionNKS002V7
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitNKS002V8
Refer to LAN-32, "CAN Communication Unit" .
Page 3590 of 4462
LT-28
HEADLAMP - XENON TYPE -
Revision: 2006 December 2006 FX35/FX45
6. CHECK HEADLAMP GROUND
1. Turn ignition switch OFF.
2. Check continuity between front combination lamp RH harness connector E24 terminal 7 and ground.
3. Check continuity between front combination lamp LH harness connector E44 terminal 7 and ground.
OK or NG
OK >> Check headlamp harness and connectors, ballasts (HID control unit), and xenon bulbs. Refer to LT- 3 3 , "
Xenon Headlamp Trouble Diagnosis" .
NG >> Repair harness or connector.
Headlamp Low Beam Does Not Illuminate (One Side)NKS002VL
1. CHECK BULB
Check ballast (HID control unit) and xenon bulb of lamp which does not illuminate. Refer to LT- 3 3 , "
Xenon
Headlamp Trouble Diagnosis" .
OK or NG
OK >> GO TO 2.
NG >> Replace malfunctioning part.
2. CHECK HEADLAMP INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front combination lamp RH or LH connector.
3. Turn ignition switch ON.
4. Lighting switch is turned 2ND position.
5. Check voltage between front combination lamp RH or LH har- ness connector and ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3. 7 – Ground : Continuity should exist.
7 – Ground : Continuity should exist.
PKIA5207E
(+) (-) Voltage
Front combination
lamp connector Terminal
RH E24 6 Ground Battery voltage
LH E44 6
PKIA5208E
Page 3598 of 4462
LT-36
HEADLAMP - XENON TYPE -
Revision: 2006 December 2006 FX35/FX45
DAYTIME/PARKING LAMP
1. Turn lighting switch OFF.
2. Remove air cleaner case (when replacing LH bulb of VK45). Refer to EM-177, "
AIR CLEANER AND AIR DUCT" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
5. Installation is the reverse order of removal.
FRONT TURN SIGNAL LAMP
1. Turn lighting switch OFF.
2. Turn bulb socket counterclockwise with suitable tool and unlock it.
3. Remove bulb from its socket.
4. Installation is the reverse order of removal.
FRONT SIDE MARKER LAMP
1. Turn lighting switch OFF.
2. Remove fender protecter (front). Refer to EI-24, "
FENDER
PROTECTOR" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
5. Installation is the reverse order of removal.
CAUTION:
After installing bulb, be sure to install plastic cap and bulb socket securely to insure watertight-
ness.
Removal and InstallationNKS002VU
REMOVAL
1. Disconnect the battery cable from the negative terminal or remove power fuse.
2. Remove front bumper. Refer to EI-14, "
Removal and Installa-
tion" .
3. Remove headlamp mounting bolts and nut.
4. Remove plastics bumper bracket, then pull headlamp toward vehicle front, disconnect connector, and remove headlamp. Daytime/Parking lamp : 12 V - 21/5 W
PKIC9732E
Front turn signal lamp : 12 V - 21 W (amber)
SKIA6182E
Front side marker lamp : 12 V - 3.8 W
SKIA5552E
SKIA5553E
Page 3599 of 4462
HEADLAMP - XENON TYPE - LT-37
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 December 2006 FX35/FX45
INSTALLATION
Installation is the reverse order of removal.
NOTE:
After installation, perform aiming adjustment. Refer to LT- 3 4 , "
Aiming Adjustment" .
Disassembly and Assembly NKS002VV
DISASSEMBLY
1. Turn plastic cap counterclockwise and unlock it.
2. Turn xenon bulb socket counterclockwise, and unlock it.
3. Unlock retaining spring, and remove xenon bulb.
4. Remove HID control unit cover mounting screw.
5. Remove HID control unit cover.
6. Disconnect HID control unit connector.
7. Remove HID control unit mounting screws.
8. Remove HID control unit.
9. Turn daytime/parking lamp bulb socket counterclockwise and unlock it.
10. Remove daytime/parking lamp bulb from its socket.
11. Turn front turn signal lamp bulb socket counterclockwise and unlock it.
12. Remove front turn signal lamp bulb from its socket.
13. Turn front side marker lamp bulb socket counterclockwise and unlock it.
14. Remove front side marker lamp bulb from its socket.
ASSEMBLY
Assembly is the reverse order of disassembly. Headlamp mounting bolt : 6.1 N·m (0.62 kg-m, 54 in-lb)
1. Side marker lamp bulb 2. Side marker lamp bulb socket 3. Front turn signal lamp bulb socket
4. Front turn signal lamp bulb 5. Seal packing 6. Plastic cap
7. Xenon bulb 8. Xenon bulb socket 9. HID control unit cover mounting screw
10. HID control unit cover 11. HID control unit mounting screw 12. HID control unit
13. Seal packing 14. Daytime/Parking lamp bulb socket 15. Daytime/Parking lamp bulb
16. Headlamp housing assembly 17. Retaining spring :Alway replace after every disassembly
:N·m (kg-m, in-lb)
PKIC9685E
Page 3616 of 4462
LT-54
DAYTIME LIGHT SYSTEM
Revision: 2006 December 2006 FX35/FX45
4. CHECK GROUND
1. Check continuity between parking lamp RH harness connector E23 terminal 3 and ground.
2. Check continuity between parking lamp LH harness connector E43 terminal 3 and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK BULB
Inspect bulbs of lamp which do not illuminate.
OK or NG
OK >> GO TO 6.
NG >> Replace bulb.
6. CHECK DAYTIME RELAY CIRCUIT
1. Disconnect combination meter connector.
2. Check continuity between daytime lamp relay harness connec- tor E15 terminal 1 and combination meter harness connector
M20 terminal 10.
OK or NG
OK >> GO TO 7.
NG >> Repair harness or connector.
7. CHECK INPUT SIGNAL
1. Connect combination meter connector.
2. Start engine running.
3. Select “BCM” on CONSULT-II. With “HEAD LAMP” data monitor, make sure “ENGINE RUN” turns ON-OFF linked with operation
of engine running or stop.
4. Select “BCM” on CONSULT-II. With “HEAD LAMP” data monitor, make sure “PKB SW” turns ON-OFF linked with operation of
parking brake switch.
OK or NG
OK >> Replace BCM. Refer to BCS-15, "Removal and Installation of BCM" .
NG >> GO TO 8. 3 – Ground : Continuity should exist.
3 – Ground : Continuity should exist.
PKIC9688E
1 – 10 : Continuity should exist.
PKIA5216E
Engine running : ENGINE RUN ON
Engine stop : ENGINE RUN OFF
Parking brake ON : PKB SW ON
Parking brake OFF : PKB SW OFF
PKIA7591E
Page 3668 of 4462
LT-106
TURN SIGNAL AND HAZARD WARNING LAMPS
Revision: 2006 December 2006 FX35/FX45
4. CHECK GROUND
1. Check continuity between front combination lamp LH harness connector E44 terminal 8 and ground.
2. Check continuity between front combination lamp RH harness connector E24 terminal 8 and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK TURN SIGNAL LAMPS SHORT CIRCUIT
1. Disconnect rear combination lamp unit connector.
2. Check continuity (short circuit) between front combination lamp LH harness connector E44 terminal 4 and ground.
3. Check continuity (short circuit) between front combination lamp RH harness connector E24 terminal 4 and ground.
OK or NG
OK >> GO TO 6.
NG >> Repair harness or connector.
6. CHECK BULB
Check bulb standard of each turn signal lamp is correct.
OK or NG
OK >> Replace BCM if turn signal lamps does not work after setting the connector again. Refer to BCS-
15, "Removal and Installation of BCM" .
NG >> Replace turn signal lamp bulb.
Rear Turn Signal Lamp Does Not OperateNKS002XN
1. CHECK TAIL LAMPS AND STOP LAMPS
Make sure tail lamps and stop lamps is illuminated.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3. 8 – Ground : Continuity should exist.
8 – Ground : Continuity should exist.
PKIA5218E
4 – Ground : Continuity should not exist.
4 – Ground : Continuity should not exist.
PKIA5219E
Page 3670 of 4462
LT-108
TURN SIGNAL AND HAZARD WARNING LAMPS
Revision: 2006 December 2006 FX35/FX45
5. CHECK REAR COMBINATION LAMPS CIRCUIT
1. Disconnect rear combination lamp RH and LH connectors.
2. Check continuity between rear combination lamp control unit harness connector B65 terminal 11 and rear combination lamp
LH harness connector B57 terminal 3.
3. Check continuity between rear combination lamp control unit harness connector B65 terminal 10 and rear combination lamp
LH harness connector B57 terminal 4.
4. Check continuity between rear combination lamp control unit harness connector B65 terminal 9 and rear combination lamp RH harness connector B219 terminal 3.
5. Check continuity between rear combination lamp control unit harness connector B65 terminal 8 and rear combination lamp RH harness connector B219 terminal 4.
OK or NG
OK >> Replace rear combination lamp control unit or rear combination lamp, and then check if turn signal lamps is illuminated.
NG >> Repair harness or connector.
Hazard Warning Lamp Does Not Operate But Turn Signal Lamp OperateNKS002XO
1. CHECK BULB
Make sure bulb standard of each turn signal lamp is correct.
OK or NG
OK >> GO TO 2.
NG >> Replace bulb. 11 – 3 : Continuity should exist.
10 – 4 : Continuity should exist.
9 – 3 : Continuity should exist.
8 – 4 : Continuity should exist.
SKIA5910E
Page 3672 of 4462
LT-110
TURN SIGNAL AND HAZARD WARNING LAMPS
Revision: 2006 December 2006 FX35/FX45
5. CHECK HAZARD SWITCH
Check continuity hazard switch.
OK or NG
OK >> Replace BCM if turn signal lamps does not work after setting the connector again. Refer to BCS-15, "
Removal
and Installation of BCM" .
NG >> Replace hazard switch.
Bulb Replacement (Front Turn Signal Lamp)NKS002XQ
Refer to LT- 3 5 , "Bulb Replacement" .
Bulb Replacement (Rear Turn Signal Lamp)NKS002XR
Refer to LT- 1 5 4 , "Bulb Replacement" .
Removal and Installation of Front Turn Signal LampNKS002XS
Refer to LT- 3 6 , "Removal and Installation" .
Removal and Installation of Rear Turn Signal Lamp NKS002XT
Refer to LT- 1 5 4 , "Removal and Installation" .
Removal and Installation of Rear Combination Lamp Control UnitNKS002XU
REMOVAL
1. Remove luggage side box (LH). Refer to EI-44, "Removal and
Installation" .
2. Remove nuts (2), and remove rear combination lamp control unit.
INSTALLATION
Installation is the reverse order of removal.
Terminal Condition Continuity
Hazard switch
12 Hazard switch is ON Yes
Hazard switch is OFF No
PKIA5221E
PKIB3631E
