height adjustment INFINITI FX35 2007 Service Manual

ACS-1
AUTO CRUISE CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION
A
B
ACS
Revision: 2006 July 2007 FX35/FX45
AUTO CRUISE CONTROL SYSTEM
ASCD
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ..... 3
Description .......................................................... ..... 3
ICC
PRECAUTIONS ..................................................... ..... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 4
Precautions for ICC System Service ................... ..... 4
PREPARATION ...................................................... ..... 5
Special Service Tools .......................................... ..... 5
DESCRIPTION ....................................................... ..... 6
Outline ................................................................. ..... 6
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE .............................................................. ..... 6
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................ ..... 6
BRAKE ASSIST (WITH PREVIEW FUNCTION) ..... 6
Functional Diagram ............................................. ..... 7
Components Description ..................................... ..... 9
CAN Communication ........................................... ..... 9
CAN COMMUNICATION UNIT ........................ ..... 9
Switch Operation ................................................. ... 10
ICC System Display ............................................ ... 10
ACTION TEST ....................................................... ....11
ICC System Running Test ................................... .... 11
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE .............................................................. .... 11
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................ ... 12
LASER BEAM AIMING ADJUSTMENT ................ ... 14
Outline ................................................................. ... 14
Preparation .......................................................... ... 14
Outline of Adjustment Procedure ........................ ... 14
Setting the ICC Target Board .............................. ... 14
ADJUSTING HEIGHT OF THE TARGET ......... ... 14
ADJUSTING THE RIGHT-LEFT POSITION OF
THE TARGET ................................................... ... 15 SETTING THE TARGET ..................................
... 15
Aiming Adjustment ............................................... ... 17
CHECK AFTER THE ADJUSTMENT ............... ... 18
ELECTRICAL UNITS LOCATION ......................... ... 19
Component Parts and Harness Connector Location ... 19
WIRING DIAGRAM ................................................ ... 20
Schematic ............................................................ ... 20
Wiring Diagram — ICC — ................................... ... 21
TERMINALS AND REFERENCE VALUE .............. ... 28
Terminals and Reference Value for ICC Unit ....... ... 28
Terminals and Reference Value for ICC Sensor .. ... 29
TROUBLE DIAGNOSIS — GENERAL DESCRIP-
TION ....................................................................... ... 30
Work Flow ............................................................ ... 30
CONSULT-II Function (ICC) ................................ ... 31
DESCRIPTION ................................................. ... 31
CONSULT-II BASIC OPERATION .................... ... 31
WORK SUPPORT ............................................ ... 32
SELF-DIAGNOSTIC RESULTS ........................ ... 32
DATA MONITOR .............................................. ... 33
ACTIVE TEST .................................................. ... 35
Self-Diagnostic Function ...................................... ... 37
WITH CONSULT-II ........................................... ... 37
WITHOUT CONSULT-II .................................... ... 37
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY
WILL NOT RUN ................................................ ... 39
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ..................................................................... ... 42
Diagnostic Trouble Code (DTC) Chart ................ ... 42
DTC 11 CONTROL UNIT .................................... ... 44
DTC 20 CAN COMM CIRCUIT ............................ ... 44
DTC 31 POWER SUPPLY CIR, DTC 34 POWER
SUPPLY CIR 2 .................................................... ... 44
DTC 41 VHCL SPEED SE CIRC ......................... ... 45
DTC 43 ABS/TCS/VDC CIRC ............................. ... 46
DTC 45 BRAKE SW/STOP L SW ........................ ... 46
DTC 46 OPERATION SW CIRC .......................... ... 48
DTC 61 PRESS SEN CIRCUIT ........................... ... 50
DTC 62 BOOSTER SOL/V CIRCUIT .................. ... 51
DTC 63 RELEASE SW CIRCUIT ........................ ... 52

ACS-14
[ICC]
LASER BEAM AIMING ADJUSTMENT
Revision: 2006 July 2007 FX35/FX45
LASER BEAM AIMING ADJUSTMENTPFP:00026
OutlineNKS003EQ
Adjust the laser beam aiming every time the ICC sensor is removed or installed.
CAUTION:

Adjust laser beam aiming at a horizontal place as far as 12 m (39 ft) forward the vehicle can be
seen.

Adjust laser beam aiming 5 seconds after starting engine.

Never view ICC sensor integrated unit body window directly during laser beam aiming adjustment.

Follow the CONSULT-ll when adjusting the laser beam aiming (laser beam aiming adjustment can-
not be operated without CONSULT-ll).

Never ride on vehicle during laser beam aiming adjustment.

Idle and turn headlamps OFF during laser beam aiming adjustment.
PreparationNKS003ER

Adjust the tire pressure to the specified value.

See that there is no load in the vehicle.

Coolant, engine oil filled up to correct level and full fuel tank.

Shift the gear into “P” position and release the parking brake.

Clean the ICC sensor with a soft cloth.
Outline of Adjustment ProcedureNKS003ES
1. Set up the ICC target board [KV99110100 (J-45718)].
2. Adjust the sensor following the procedure on CONSULT-II. (Turn manually the screw for up-down position adjustment. ICC sensor automatically adjust the right-left position.)
Setting the ICC Target BoardNKS003ET
Accurate ICC target board setting is required for the laser beam aiming adjustment.
CAUTION:
ICC system does not function normally if laser beam aiming is not accurate.
ADJUSTING HEIGHT OF THE TARGET
1. Attach a triangle scale at the center.
SKIA6179E
SKIA5974E

LASER BEAM AIMING ADJUSTMENT ACS-15
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
2. Adjust the height of the target board stand so that the point of
the triangle aims the center of the ICC sensor.
ADJUSTING THE RIGHT-LEFT POSITION OF THE TARGET
1. Attach a scale [at least 350 mm (14 in) or longer] or stick asshown in the figure.
2. Suspend a thread with weight on the tip of the thread to 310 mm (12.2 in) left side of the target board from the center of the tar-
get board on top.
SETTING THE TARGET
1. Suspend a thread with weight on tip to splice the center of the front and rear bumpers. Then, mark the
center point on the ground as each weight points.
2. Link the front and rear bumpers center points marked on the ground, and mark a point 5 m (16.4 ft) ahead of the sensor, on the extended line of the previous link line of the bumper center points. Then, adjust the
position of the target board so that the weight come on the top of the marked point [5 m (16.4 ft) ahead of
the sensor] and face to the vehicle.
3. Adjust the position of the target board so that the extended line that links the center of the rear window glass (the center of the
rear window defogger pattern) and the center of the windshield
(the setting part of the room mirror) align with the weight sus-
pended from the board.
4. Remove the thread suspended to the left side of board and sus- pend a thread with weight on tip on the center of the target
board. Then mark the point of weight on the ground.
SKIA6180E
SKIA1211E
SKIA5975E
SKIA1213E

BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D E
F
G H
J
K L
M
SECTION
A
B
BL
Revision: 2006 July 2007 FX35/FX45
BODY, LOCK & SECURITY SYSTEM
PRECAUTIONS .......................................................... 5
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 5
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect ..................................... ..... 5
OPERATION PROCEDURE ............................ ..... 5
Precautions for Work ........................................... ..... 5
PREPARATION ...................................................... ..... 6
Special Service Tools .......................................... ..... 6
Commercial Service Tools ................................... ..... 6
SQUEAK AND RATTLE TROUBLE DIAGNOSIS . ..... 7
Work Flow ........................................................... ..... 7
CUSTOMER INTERVIEW ................................ ..... 7
DUPLICATE THE NOISE AND TEST DRIVE .. ..... 8
CHECK RELATED SERVICE BULLETINS ...... ..... 8
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ................................................. ..... 8
REPAIR THE CAUSE ...................................... ..... 8
CONFIRM THE REPAIR .................................. ..... 9
Generic Squeak and Rattle Troubleshooting ...... ..... 9
INSTRUMENT PANEL ..................................... ..... 9
CENTER CONSOLE ........................................ ..... 9
DOORS ............................................................ ..... 9
TRUNK ............................................................. ... 10
SUNROOF/HEADLINING ................................ ... 10
SEATS .............................................................. ... 10
UNDERHOOD .................................................. ... 10
Diagnostic Worksheet ......................................... .... 11
HOOD .................................................................... ... 13
Fitting Adjustment ............................................... ... 13
LONGITUDINAL AND LATERAL CLEARANCE
ADJUSTMENT ................................................. ... 13
FRONT END HEIGHT ADJUSTMENT ............ ... 13
SURFACE HEIGHT ADJUSTMENT ................ ... 13
Removal and Installation of Hood Assembly ....... ... 14
REMOVAL ........................................................ ... 15
INSTALLATION ................................................ ... 15
Removal and Installation of Hood Lock Control .. ... 15
REMOVAL ........................................................ ... 15 INSTALLATION ................................................
... 16
Hood Lock Control Inspection ............................. ... 16
RADIATOR CORE SUPPORT ............................... ... 18
Removal and Installation ..................................... ... 18
REMOVAL ........................................................ ... 18
INSTALLATION ................................................ ... 19
FRONT FENDER ................................................... ... 20
Removal and Installation ..................................... ... 20
REMOVAL ........................................................ ... 20
INSTALLATION ................................................ ... 20
POWER DOOR LOCK SYSTEM ........................... ... 21
Component Parts and Harness Connector Location ... 21
System Description .............................................. ... 22
OUTLINE .......................................................... ... 23
CAN Communication System Description ........... ... 24
CAN Communication Unit .................................... ... 24
Schematic/With Intelligent Key ............................ ... 25
Wiring Diagram — D/LOCK —/With Intelligent Key ... 26
Schematic/Without Intelligent Key ....................... ... 31
Wiring Diagram — D/LOCK —/Without Intelligent
Key ...................................................................... ... 32
Terminals and Reference Value for BCM ............ ... 36
Terminals and Reference Value for Intelligent Key
Unit (With Intelligent Key System) ....................... ... 36
Work Flow ............................................................ ... 37
CONSULT-II Function (BCM) .............................. ... 37
CONSULT-II START PROCEDURE ................. ... 37
CONSULT-II APPLICATION ITEMS ................. ... 37
Trouble Diagnosis Chart by Symptom ................. ... 38
Check BCM Power Supply and Ground Circuit ... ... 39
Check Door Switch .............................................. ... 40
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) .......................................................... ... 40
CHECK BACK DOOR SWITCH ....................... ... 42
Check Key Switch ................................................ ... 44
Check Door Lock and Unlock Switch .................. ... 46
Check Door Lock Actuator (Driver Side) ............. ... 48
Check Door Lock Actuator (Passenger Side and
Rear LH/RH) ........................................................ ... 49
Check Fuel Lid Lock Actuator .............................. ... 50

HOOD BL-13
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2006 July 2007 FX35/FX45
HOODPFP:F5100
Fitting AdjustmentNIS001LN
LONGITUDINAL AND LATERAL CLEARANCE ADJUSTMENT
1. Remove hood lock assembly, loosen the hood hinge nuts and close the hood.
2. Adjust the lateral and longitudinal clearance, and open the hood to tighten the hood hinge mounting bolts to the specified torque.
3. Install the hood lock temporarily, and align the hood striker and lock so that the centers of striker and lock become vertical viewed from the front, by moving the hood lock laterally.
4. Tighten hood lock mounting bolts to the specified torque.
CAUTION:
Adjust right/left clearance between hood and headlamp to the following specification.
FRONT END HEIGHT ADJUSTMENT
1. Remove the hood lock and adjust the height by rotating the bumper rubber until the hood becomes 1 to1.5
mm (0.04 to 0.059 in) lower than the fender.
2. Temporarily tighten the hood lock, and position it by engaging it with the hood striker. Check the lock and striker for looseness, and tighten the hood lock mounting bolts to the specified torque.
SURFACE HEIGHT ADJUSTMENT
1. Remove hood lock, and adjust the surface height difference of hood, fender and headlamp according to the fitting standard dimension, by rotating RH and LH bumper rubbers.
2. Install hood lock temporarily, and move hood lock laterally until the centers of striker and lock become ver- tical when viewed from the front.
1. Hood hinge 2. Nut 3. Hood stay
4. Hood lock 5. Bolt 6. Bumper rubber
PIIB1212E
Hood and headlamp (C–C) : Less than 2.0 mm (0.08 in)

BL-14
HOOD
Revision: 2006 July 2007 FX35/FX45
3. Make sure that the hood lock secondary latch is properly
engaged with the secondary striker with hood's own weight.
4. Make sure that the hood lock primary latch is securely engaged with the hood striker with hood's own weight by dropping hood
from approx. 200 mm (7.87 in) height.
CAUTION:
Do not drop hood from a height of 300 mm (11.81 in) or
more.
5. Move hood lockup and down until striker smoothly engages the lock when the hood is closed.
6. When pulling the hood opener lever gently, make sure that front end of the hood rises by approximately 20 mm (0.79 in) and that hood striker and hood lock primary latch
is disengaged. Also make sure that hood opener returns to the original position.
7. After adjustment, tighten lock bolts to the specified torque.
CAUTION:
Adjust evenness between hood and each part to the following specification.
Removal and Installation of Hood AssemblyNIS001LO
Hood and head lamp (C–C) : 0.9 ± 1.5 mm (0.035 ± 0.059 in)
Hood and fender (D–D) : 0.1 ± 1.0 mm (0.004 ± 0.04 in)
PIIB1082E
1. Hood assembly 2. Hood front sealing rubber 3. Hood insulator
4. Hood hinge 5. Hood stay 6. Hood lock
7. Bolt 8. Nut
PIIA6016E

BL-16
HOOD
Revision: 2006 July 2007 FX35/FX45
4. Remove instrument driver lower panel. Refer to IP-11, "Removal and Installation" .
5. After the bolt of the case with the air cleaner is disconnected, and it is moved, the cable is pulled.
6. Remove the grommet on the dashboard, and pull the hood lock cable toward the passenger room. CAUTION:
While pulling, be careful not to damage (peeling) the outside of the hood lock cable.
INSTALLATION
1. Pull the hood lock cable through the panel hole to the engine room.
Be careful not to bend the cable too much, keeping the radius
100 mm (3.94 in) or more.
2. Make sure the cable is not offset from the positioning grommet, and push the grommet into the panel hole securely.
3. Apply the sealant to the grommet (at * mark) properly.
4. Install the cable securely to the lock.
5. After installing, check the hood lock adjustment and hood opener operation.
Hood Lock Control InspectionNIS001LQ
CAUTION:
If the hood lock cable is bent or deformed, replace it.
1. Make sure that the hood lock secondary latch is properly engaged with the secondary striker with hood's own weight.
2. Make sure that the hood lock primary latch is securely engaged with the hood striker with hood's own weight by dropping it from
approx. 200 mm (7.87 in) height.
CAUTION:
Do not drop hood from a height of 300 mm (11.81 in) or
more.
3. When pulling hood opener lever gently, make sure that front end of the hood rises by approximately 20 mm (0.79 in) and that hood striker and hood lock primary latch are disengaged. Also make sure that hood
opener returns to the original position.
PIIA0173E
PIIA3552E
PIIB1082E

BL-148
DOOR
Revision: 2006 July 2007 FX35/FX45
DOORPFP:80100
Fitting AdjustmentNIS001O6
FRONT DOOR
Longitudinal Clearance and Surface Height Adjustment at Front End
Loosen the hinge mounting bolts. Raise the front door at rear end to adjust.
REAR DOOR
Longitudinal Clearance and Surface Height Adjustment at Front End
1. Remove the center pillar upper garnish and center pillar lower garnish. Refer to EI-38, "Removal and
Installation" .
2. Accessing from inside the vehicle, loosen the mounting nuts. Open the rear door, and raise the rear door at rear end to adjust.
1. Front fender 2. Front door outer 3. Rear door outer
4. Bolt 5. Nut
PIIA6059E

BL-158
BACK DOOR
Revision: 2006 July 2007 FX35/FX45
BACK DOORPFP:90100
Fitting AdjustmentNIS001OD
VERTICAL/LATERAL CLEARANCE ADJUSTMENT
1. With the striker released, loosen the bumper rubber lock nuts.
2. Close the back door lightly and adjust the surface height by rotating the bumper rubber and, then open the back door to finally tighten the back door lock mounting bolts and bumper rubber lock nuts to the specified
torque.
Back Door AssemblyNIS001OE
REMOVAL
1. Remove roof rear garnish assembly. Refer to EI-45, "Removal and Installation" .
2. Disconnect the back door harness connector and AV antenna feeder.
3. Washer hose is separated in the connection part.
4. Support the back door lock with a proper material to prevent it from falling.
WARNING:
Body injury may occur if no supporting rod is holding the
back door open when removing the damper stay.
1. Bumper rubber 2. Back door striker 3. Screw
PIIB0208E
PIIA6028E
PIIA6061E

BR-6
BRAKE PEDAL
Revision: 2006 July 2007 FX35/FX45
BRAKE PEDALPFP:46501
Inspection and AdjustmentNFS000LS
Play and clearance between brake pedal and floor panel with pedal depressed
1. Check brake pedal height from dash lower panel.
2. Adjust height referring to the following specifications.
ADJUSTMENT
1. Loosen stop lamp switch and ASCD cancel switch (or brake switch) by rotating it counterclockwise by 45 °.
2. Loosen lock nut (A) on input rod, then rotate input rod to set pedal to the specified height, and tighten lock nut (A). Refer to
BR-15, "
Components" .
CAUTION:
Make sure the threaded end of input rod stays inside clevis.
3. With pedal pulled and held by hand, press stop lamp switch and ASCD cancel switch (or brake switch) until its threaded end con-
tacts stopper rubber.
4. With the threaded end of stop lamp switch and ASCD cancel switch (or brake switch) contacting stopper rubber, rotate switch
clockwise by 45 ° to secure.
CAUTION:
Make sure that the clearance “C” between stopper rubber
and threaded end of stop lamp switch and ASCD cancel
switch (or brake switch) is within the standard.
5. Check pedal play. CAUTION:
Make sure that stop lamps go off when pedal is released.
6. Start engine to check brake pedal depressed height.
H Brake pedal height (from dash
lower panel top surface) 161.5
− 171.5 mm (6.358 − 6.752 in)
D Depressed pedal height [under a
force of 490 N (50 kg, 110 lb) with
engine running] More than 95 mm (3.74 in)
C Clearance between stopper rubber
and the threaded end of stop lamp
switch and ASCD cancel switch (or
brake switch) 0.74
− 1.96 mm (0.0291 −0.0772 in)
A Pedal play 3 − 11 mm (0.12 − 0.43 in)
SFIA2380E
PFIA0819E
