QUICK REFERENCE CHART FX35/FX45
REAR WHEEL ALIGNMENT (Unladen*)
ELS0003Y
* : Fuel, engine coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
BRAKEELS0003Z
* : Under force of 490 N (50 kg, 110 lb) with engine running.
REFILL CAPACITIESELS00040
Camber
Degree minute (Decimal degree)Minimum –1° 18′ (–1.30°)
Nominal –0° 48′ (–0.80°)
Maximum – 0° 18′ (– 0.30°)
Total toe-inDistance Minimum 2.4 mm (0.09 in)
Nominal 4.7 mm (0.19 in)
Maximum 7.0 mm (0.28 in)
Angle (left wheel or right wheel)
Degree minute (Decimal degree)Minimum 0° 05′ (0.08°)
Nominal 0° 10′ (0.17°)
Maximum 0° 15′ (0.25°)
Front brake Pad wear limit 2.0 mm (0.079 in)
Rotor repair limit 32.0 mm (1.260 in)
Rear brake Pad wear limit 2.0 mm (0.079 in)
Rotor repair limit 14.0 mm (0.551 in)
Pedal free height 161.5 - 171.5 mm (6.358 - 6.752 in)
Pedal depressed height* More than 95 mm (3.74 in)
UNITLiter US measure
Fuel tank90 23 - 3/4 gal
Coolant (With reservoir tank)VQ35DE 8.6 9 - 1/8 qt
VK45DE 10.0 10 - 5/8 qt
Engine(VQ35DE)Drain and refill
With oil filter change 4.7 5 qt
Without oil filter change 4.4 4 - 5/8 qt
Dry engine (Overhaul) 5.4 5 - 3/4 qt
Engine(VK45DE)Drain and refill
With oil filter change 5.8 6 - 1/8 qt
Without oil filter change 5.2 5 - 1/2 qt
Dry engine (Overhaul) 7.0 7 - 3/8 qt
Transmission A/T 10.3 10 - 7/8 qt
Transfer1.25 2 - 5/8 pt
Differential carrierFront 0.65 1 - 3/8 pt
Rear 1.4 3 pt
Power steering system 1.0 1 - 1/8 qt
Air conditioning systemCompressor oil 0.18 6.0 fl oz
Refrigerant 0.55 kg 1.21 lb
2007
Page 17 of 4366
![INFINITI FX35 2007 Service Manual DESCRIPTION ACS-9
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
Components DescriptionNKS003EL
CAN CommunicationNKS003EM
CAN (Controller Area Network) is a serial c](/img/42/57018/w960_57018-16.png "INFINITI FX35 2007 Service Manual DESCRIPTION ACS-9
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
Components DescriptionNKS003EL
CAN CommunicationNKS003EM
CAN (Controller Area Network) is a serial c")
DESCRIPTION ACS-9
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
Components DescriptionNKS003EL
CAN CommunicationNKS003EM
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tric control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Refer to LAN-49, "CAN System Specification Chart" .
Component Vehicle-to-
vehicle
distance
control mode Conventional
(fixed speed) cruise
control mode Brake assist
(with pre-
view func- tion) Description
ICC unit ××× Operates electric throttle control actuator and brake
booster based on that sensor signals and CAN commu-
nication data, then controls vehicle distance.
ICC sensor ×× Irradiates laser beam, and receives reflected laser
beam to measure distance from preceding vehicle.
ECM ××× Transmits throttle position signal and ICC steering
switch signal to ICC unit through CAN communication.
ABS actuator and electric
unit (control unit) ×××
Transmits wheel speed sensor signal to ICC unit
through CAN communication.
Brake pressure sensor ×× Detects fluid pressure in master cylinder.
Brake booster ×× Adjusts brake fluid pressure, based on command from
ICC unit.
BCM × Transmit front wiper request signal to ICC unit through
CAN communication.
TCM ×× Transmits gear position signal and output shaft revolu-
tion signal to ICC unit through CAN communication.
Unified meter and A/C amp. ××× Receives ICC system display signal, ICC warning lamp
signal and buzzer output signal from ICC unit through
CAN communication.
ICC brake switch, stop
lamp switch ××× Transmit operating signal to ICC unit when touching
brake pedal. ICC unit cancels cruise system at driver's
brake operation.
ICC brake hold relay × Receives stop lamp driving signal from ICC unit, and
turns stop lamp ON.
Parking brake switch ×× The cruise system is cancelled when applied.
Page 85 of 4366
AT-1
AUTOMATIC TRANSMISSION
C TRANSMISSION/TRANSAXLE
CONTENTS
D E
F
G H
I
J
K L
M
SECTION
A
B
AT
Revision: 2006 July 2007 FX35/FX45
AUTOMATIC TRANSMISSION
INDEX FOR DTC ........................................................ 5
Alphabetical Index ............................................... ..... 5
DTC No. Index .................................................... ..... 6
PRECAUTIONS ..................................................... ..... 7
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 7
Precautions for On Board Diagnostic (OBD) System
of A/T and Engine ............................................... ..... 7
Precautions ......................................................... ..... 8
Service Notice or Precautions ............................. ..... 9
PREPARATION ...................................................... ... 10
Special Service Tools .......................................... ... 10
Commercial Service Tools ................................... .... 11
A/T FLUID .............................................................. ... 12
Changing A/T Fluid ............................................. ... 12
Checking A/T Fluid .............................................. ... 13
A/T Fluid Cooler Cleaning ................................... ... 15
A/T CONTROL SYSTEM ....................................... ... 18
Cross-sectional View (2WD Models) ................... ... 18
Cross-sectional View (VQ35DE Models for AWD) ... 19
Cross-sectional View (VK45DE Models for AWD) ... 20
Shift Mechanism .................................................. ... 21
TCM Function ...................................................... ... 32
CAN Communication ........................................... ... 33
Input/Output Signal of TCM ................................. ... 33
Line Pressure Control ......................................... ... 34
Shift Control ........................................................ ... 35
Lock-up Control ................................................... ... 37
Engine Brake Control .......................................... ... 38
Control Valve ....................................................... ... 38
ON BOARD DIAGNOSTIC (OBD) SYSTEM ......... ... 40
Introduction ......................................................... ... 40
OBD-II Function for A/T System .......................... ... 40
One or Two Trip Detection Logic of OBD-II ......... ... 40
OBD-II Diagnostic Trouble Code (DTC) .............. ... 40
Malfunction Indicator Lamp (MIL) ........................ ... 43
TROUBLE DIAGNOSIS ......................................... ... 44
DTC Inspection Priority Chart ............................. ... 44
Fail-safe .............................................................. ... 44 How to Perform Trouble Diagnosis for Quick and
Accurate Repair ................................................... ... 46
A/T Electrical Parts Location ............................... ... 51
Circuit Diagram .................................................... ... 52
Inspections Before Trouble Diagnosis ................. ... 53
Check Before Engine Is Started .......................... ... 57
Check at Idle ........................................................ ... 57
Cruise Test - Part 1 .............................................. ... 58
Cruise Test - Part 2 .............................................. ... 60
Cruise Test - Part 3 .............................................. ... 61
Vehicle Speed at Which Gear Shifting Occurs .... ... 62
Vehicle Speed at Which Lock-up Occurs/Releases ... 63
Symptom Chart .................................................... ... 64
TCM Input/Output Signal Reference Values ........ ... 89
CONSULT-II Function (A/T) ................................. ... 90
Diagnostic Procedure without CONSULT-II ......... .102
DTC U1000 CAN COMMUNICATION LINE ........... .104
Description ........................................................... .104
On Board Diagnosis Logic ................................... .104
Possible Cause .................................................... .104
DTC Confirmation Procedure .............................. .104
Wiring Diagram — AT — CAN ............................. .105
Diagnostic Procedure .......................................... .106
DTC P0615 START SIGNAL CIRCUIT .................. .107
Description ........................................................... .107
CONSULT-II Reference Value ............................. .107
On Board Diagnosis Logic ................................... .107
Possible Cause .................................................... .107
DTC Confirmation Procedure .............................. .107
Wiring Diagram — AT — STSIG ......................... .108
Diagnostic Procedure .......................................... .109
DTC P0700 TCM .................................................... .. 111
Description ........................................................... ..111
On Board Diagnosis Logic ................................... ..111
Possible Cause .................................................... ..111
DTC Confirmation Procedure .............................. ..111
Diagnostic Procedure .......................................... ..111
DTC P0705 PARK/NEUTRAL POSITION SWITCH .112
Description ........................................................... .112
CONSULT-II Reference Value ............................. .112
Page 88 of 4366
AT-4Revision: 2006 July 2007 FX35/FX45
A/T Does Not Shift: 5th Gear
→ 4th Gear ........... .219
A/T Does Not Shift: 4th Gear → 3rd Gear ........... .221
A/T Does Not Shift: 3rd Gear → 2nd Gear .......... .223
A/T Does Not Shift: 2nd Gear → 1st Gear ........... .225
Vehicle Does Not Decelerate by Engine Brake ... .227
SHIFT CONTROL SYSTEM ................................... .229
Control Device Removal and Installation ............. .229
Control Rod Removal and Installation ................. .230
Adjustment of A/T Position .................................. .231
Checking of A/T Position ..................................... .231
A/T SHIFT LOCK SYSTEM .................................... .232
Description ........................................................... .232
Shift Lock System Electrical Parts Location ........ .232
Wiring Diagram — AT — SHIFT .......................... .233
Diagnostic Procedure .......................................... .234
KEY INTERLOCK CABLE ..................................... .236
Components ........................................................ .236
Removal and Installation ..................................... .237
ON-VEHICLE SERVICE ......................................... .239
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 .............................................................. .239
Parking Components (2WD Models Only) ........... .250
Rear Oil Seal ....................................................... .258
Revolution Sensor Components (2WD Models
Only) .................................................................... .259
AIR BREATHER HOSE .......................................... .264
Removal and Installation ..................................... .264
TRANSMISSION ASSEMBLY ............................... .266
Removal and Installation (2WD Models) ............. .266
Removal and Installation (AWD Models) ............. .269 OVERHAUL ............................................................
.274
Components ......................................................... .274
Oil Channel .......................................................... .288
Locations of Adjusting Shims, Needle Bearings,
Thrust Washers and Snap Rings ......................... .291
DISASSEMBLY ...................................................... .294
Disassembly ......................................................... .294
REPAIR FOR COMPONENT PARTS ..................... .312
Oil Pump .............................................................. .312
Front Sun Gear, 3rd One-way Clutch ................... .315
Front Carrier, Input Clutch, Rear Internal Gear .... .317
Mid Sun Gear, Rear Sun Gear, High and Low
Reverse Clutch Hub ............................................. .323
High and Low Reverse Clutch ............................. .329
Direct Clutch ........................................................ .332
ASSEMBLY ............................................................ .335
Assembly (1) ........................................................ .335
Adjustment ........................................................... .349
Assembly (2) ........................................................ .352
SERVICE DATA AND SPECIFICATIONS (SDS) ... .359
General Specifications ......................................... .359
Vehicle Speed at Which Gear Shifting Occurs ..... .359
Vehicle Speed at Which Lock-up Occurs/Releases .360
Stall Speed ........................................................... .360
Line Pressure ....................................................... .360
A/T Fluid Temperature Sensor ............................. .360
Turbine Revolution Sensor ................................... .361
Vehicle Speed Sensor A/T (Revolution Sensor) .. .361
Reverse Brake ..................................................... .361
Total End Play ...................................................... .361
Page 92 of 4366
AT-8
PRECAUTIONS
Revision: 2006 July 2007 FX35/FX45
Precautions NCS001AP
Before connecting or disconnecting the A/T assembly har-
ness connector, turn ignition switch OFF and disconnect
the battery cable from the negative terminal. Because bat-
tery voltage is applied to TCM even if ignition switch is
turned OFF.
After performing each TROUBLE DIAGNOSIS, perform
“DTC (Diagnostic Trouble Code) Confirmation Procedure”.
If the repair is completed the DTC should not be displayed
in the “DTC Confirmation Procedure”.
Always use the specified brand of ATF. Refer to MA-12, "Fluids and Lubricants" .
Use lint-free paper not cloth rags during work.
After replacing the ATF, dispose of the waste oil using the methods prescribed by law, ordinance, etc.
Before proceeding with disassembly, thoroughly clean the outside of the transmission. It is important to
prevent the internal parts from becoming contaminated by dirt or other foreign matter.
Disassembly should be done in a clean work area.
Use lint-free paper or towels for wiping parts clean. Common shop rags can leave fibers that could inter-
fere with the operation of the transmission.
Place disassembled parts in order for easier and proper assembly.
All parts should be carefully cleansed with a general purpose, non-flammable solvent before inspection or
reassembly.
Gaskets, seals and O-rings should be replaced any time the transmission is disassembled.
It is very important to perform functional tests whenever they are indicated.
The valve body contains precision parts and requires extreme care when parts are removed and serviced.
Place disassembled valve body parts in order for easier and proper assembly. Care will also prevent
springs and small parts from becoming scattered or lost.
Properly installed valves, sleeves, plugs, etc. will slide along bores in valve body under their own weight.
Before assembly, apply a coat of recommended ATF to all parts. Apply petroleum jelly to protect O-rings
and seals, or hold bearings and washers in place during assembly. Do not use grease.
Extreme care should be taken to avoid damage to O-rings, seals and gaskets when assembling.
After overhaul, refill the transmission with new ATF.
When the A/T drain plug is removed, only some of the ATF is drained. Old ATF will remain in torque con-
verter and ATF cooling system.
Always follow the procedures under “Changing A/T Fluid” in the AT section when changing A/T fluid. Refer
to AT- 1 2 , "
Changing A/T Fluid" , AT- 1 3 , "Checking A/T Fluid" .
SEF289H
SEF217U
Page 99 of 4366
A/T FLUID AT-15
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
A/T Fluid Cooler CleaningNCS001AV
Whenever an A/T is replaced, the A/T fluid cooler mounted in the radiator must be inspected and cleaned.
Metal debris and friction material, if present, can become trapped in the A/T fluid cooler. This debris can con-
taminate the newly serviced A/T or, in severe cases, can block or restrict the flow of ATF. In either case, mal-
function of the newly serviced A/T may result.
Debris, if present, may build up as ATF enters the cooler inlet. It will be necessary to back flush the cooler
through the cooler outlet in order to flush out any built up debris.
A/T FLUID COOLER CLEANING PROCEDURE
1. Position an oil pan under the A/T's inlet and outlet cooler hoses.
2. Identify the inlet and outlet A/T fluid cooler hoses.
3. Disconnect the A/T fluid cooler inlet and outlet rubber hoses from the steel cooler tubes or bypass valve.
NOTE:
Replace the cooler hoses if rubber material from the hose
remains on the tube fitting.
4. Allow any ATF that remains in the cooler hoses to drain into the oil pan.
5. Insert the extension adapter hose of a can of Transmission Cooler Cleaner (Nissan P/N 999MP-AM006) into the cooler out-
let hose.
CAUTION:
Wear safety glasses and rubber gloves when spraying
the Transmission Cooler Cleaner.
Spray Transmission Cooler Cleaner only with adequate
ventilation.
Avoid contact with eyes and skin.
Do not breath vapors or spray mist.
6. Hold the hose and can as high as possible and spray Transmis- sion Cooler Cleaner in a continuous stream into the cooler outlet hose until ATF flows out of the cooler
inlet hose for 5 seconds.
7. Insert the tip of an air gun into the end of the cooler outlet hose.
8. Wrap a shop rag around the air gun tip and of the cooler outlet hose.
9. Blow compressed air regulated to 5 to 9 kg/cm
2 (70 to 130 psi)
through the cooler outlet hose for 10 seconds to force out any
remaining ATF.
10. Repeat steps 5 through 9 three additional times.
11. Position an oil pan under the banjo bolts that connect the A/T fluid cooler steel lines to the A/T.
12. Remove the banjo bolts.
13. Flush each steel line from the cooler side back toward the A/T by spraying Transmission Cooler Cleaner in a continuous stream for 5 seconds.
14. Blow compressed air regulated to 5 to 9 kg/cm
2 (70 to 130 psi) through each steel line from the cooler
side back toward the transmission for 10 seconds to force out any remaining ATF.
15. Ensure all debris is removed from the steel cooler lines.
16. Ensure all debris is removed from the banjo bolts and fittings.
17. Perform AT- 1 6 , "
A/T FLUID COOLER DIAGNOSIS PROCEDURE" .
SCIA3830E
SCIA3831E
SCIA3832E
Page 100 of 4366
AT-16
A/T FLUID
Revision: 2006 July 2007 FX35/FX45
A/T FLUID COOLER DIAGNOSIS PROCEDURE
NOTE:
Insufficient cleaning of the cooler inlet hose exterior may lead to inaccurate debris identification.
1. Position an oil pan under the A/T's inlet and outlet cooler hoses.
2. Clean the exterior and tip of the cooler inlet hose.
3. Insert the extension adapter hose of a can of Transmission Cooler Cleaner (Nissan P/N 999MP-AM006) into the cooler out-
let hose.
CAUTION:
Wear safety glasses and rubber gloves when spraying
the Transmission Cooler Cleaner.
Spray Transmission Cooler Cleaner only with adequate
ventilation.
Avoid contact with eyes and skin.
Do not breath vapors or spray mist.
4. Hold the hose and can as high as possible and spray Transmis- sion Cooler Cleaner in a continuous stream into the cooler outlet hose until ATF flows out of the cooler
inlet hose for 5 seconds.
5. Tie a common white, basket-type coffee filter to the end of the cooler inlet hose.
6. Insert the tip of an air gun into the end of the cooler outlet hose.
7. Wrap a shop rag around the air gun tip and end of cooler outlet hose.
8. Blow compressed air regulated to 5 to 9 kg/cm
2 (70 to 130 psi)
through the cooler outlet hose to force any remaining ATF into
the coffee filter.
9. Remove the coffee filter from the end of the cooler inlet hose.
10. Perform AT- 1 7 , "
A/T FLUID COOLER INSPECTION PROCE-
DURE" .
SCIA3831E
SCIA3833E
SCIA3834E
Page 105 of 4366
A/T CONTROL SYSTEM AT-21
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
Shift MechanismNCS001AY
The A/T uses compact triple planetary gear systems to improve power transmission efficiency, simplify con-
struction and reduce weight.
It also employs an optimum shift control and super wide gear ratios. They improve starting performance and
acceleration during medium and high-speed operation.
CONSTRUCTION
FUNCTION OF CLUTCH AND BRAKE
1. Front brake 2. Input clutch 3. Direct clutch
4. High and low reverse clutch 5. Reverse brake 6. Forward brake
7. Low coast brake 8. 1st one-way clutch 9. Forward one-way clutch
10. 3rd one-way clutch 11. Front sun gear 12. Input shaft
13. Mid internal gear 14. Front internal gear 15. Rear carrier
16. Rear sun gear 17. Mid sun gear 18. Front carrier
19. Mid carrier 20. Rear internal gear 21. Output shaft
22. Parking gear 23. Parking pawl
PCIA0002J
Name of the Part Abbreviation Function
Front brake (1) FR/B Fastens the front sun gear (11).
Input clutch (2) I/C Connects the input shaft (12), the front internal gear (14) and the mid internal
gear (13).
Direct clutch (3) D/C Connects the rear carrier (15) and the rear sun gear (16).
High and low reverse clutch (4) HLR/C Connects the mid sun gear (17) and the rear sun gear (16).
Reverse brake (5) R/B Fastens the rear carrier (15).
Forward brake (6) Fwd/B Fastens the mid sun gear (17).
Low coast brake (7) LC/B Fastens the mid sun gear (17).
1st one-way clutch (8) 1st OWC Allows the rear sun gear (16) to turn freely forward relative to the mid sun gear
(17) but fastens it for reverse rotation.
Forward one-way clutch (9) Fwd OWC Allows the mid sun gear (17) to turn freely in the forward direction but fastens it
for reverse rotation.
3rd one-way clutch (10) 3rd OWC Allows the front sun gear (11) to turn freely in the forward direction but fastens
it for reverse rotation.
Page 107 of 4366
A/T CONTROL SYSTEM AT-23
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
POWER TRANSMISSION
“N” Position
Since both the forward brake and the reverse brake are released, torque from the input shaft drive is not trans-
mitted to the output shaft.
“P” Position
The same as for the “N” position, both the forward brake and the reverse brake are released, so torque
from the input shaft drive is not transmitted to the output shaft.
The parking pawl linked with the selector lever meshes with the parking gear and fastens the output shaft
mechanically.
1. Front brake 2. Input clutch 3. Direct clutch
4. High and low reverse clutch 5. Reverse brake 6. Forward brake
7. Low coast brake 8. 1st one-way clutch 9. Forward one-way clutch
10. 3rd one-way clutch 11. Front sun gear 12. Input shaft
13. Mid internal gear 14. Front internal gear 15. Rear carrier
16. Rear sun gear 17. Mid sun gear 18. Front carrier
19. Mid carrier 20. Rear internal gear 21. Output shaft
22. Parking gear 23. Parking pawl
PCIA0003J
