EC-94
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS

If DTC U1000 or U1001 is displayed with other DT C, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-146
.
 If DTC U1010 is displayed with other DTC, fi rst perform the trouble diagnosis for DTC U1010.
Refer to EC-148
.
*: Models with ICC.Priority Detected items (DTC)
1  U1000 U1001 CAN communication line  U1010 CAN communication
 P0101 P0102 P0103 Mass air flow sensor
 P0112 P0113 P0127 Intake air temperature sensor
 P0117 P0118 P0125 Engine coolant temperature sensor
 P0128 Thermostat function
 P0122 P0123 P0222 P0223 P1225 P1226 P2135 Throttle position sensor
 P0181 P0182 P0183 Fuel tank temperature sensor
 P0327 P0328 Knock sensor
 P0335 Crankshaft position sensor (POS)
 P0340 P0345 Camshaft position sensor (PHASE)
 P0460 P0461 P0462 P0463 Fuel level sensor
 P0500 Vehicle speed sensor
 P0605 ECM
 P0643 Sensor power supply
 P0700 TCM
 P0705 Park/neutral position (PNP) switch
 P0850 Park/neutral position (PNP) switch
 P1610 - P1615 NATS
 P2122 P2123 P2127 P2128 P2138 Accelerator pedal position sensor
2  P0031 P0032 P0051 P0052 Air fuel ratio (A/F) sensor 1 heater  P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater
 P0075 P0081 Intake valve timing control solenoid valve
 P0130 P0131 P0132 P0133 P0150 P0151 P0152 P0153 P2A00 P2A03 Air fuel ratio (A/F) sensor 1
 P0137 P0138 P0139 P0157 P0158 P0159 Heated oxygen sensor 2
 P0441 EVAP control system purge flow monitoring
 P0443 P0444 P0445 EVAP canister purge volume control solenoid valve
 P0447 P0448 EVAP canister vent control valve
 P0451 P0452 P0453 EVAP control system pressure sensor
 P0550 Power steering pressure sensor
 P0603 ECM power supply
 P0710 P0717 P0720 P0731 P0732 P0733 P0734 P0735 P0740 P0744 P0745 P1730 P1752 P1757 P1762 P1767
P1772 P1774 A/T related sensors, solenoid valves and switches
 P1217 Engine over temperature (OVERHEAT)
 P1805 Brake switch
 P2100 P2103 P2118 Electric throttle control actuator
 P2101 Electric throttle control function
3  P0011 P0021 Intake valve timing control  P0171 P0172 P0174 P0175 Fuel injection system function
 P0300 - P0306 Misfire
 P0420 P0430 Three way catalyst function
 P0442 EVAP control system (SMALL LEAK)
 P0455 EVAP control system (GROSS LEAK)
 P0456 EVAP control sys tem (VERY SMALL LEAK)
 P0506 P0507 Idle speed control system
 P1148 P1168 Closed loop control
 P1211 TCS control unit
 P1212 TCS communication line
 P1421 COLD START CONTROL
 P1564 ICC steering switch/ASCD steering switch
 P1568 ICC command valve*
 P1572 ICC brake switch/ASCD brake switch
 P1574 ICC vehicle speed sensor/ASCD vehicle speed sensor
 P1715 Turbine revolution sensor
 P2119 Electric throttle control actuator
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-116
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
99 G/YICC steering switch
(models with ICC system) [Ignition switch: ON]
 ICC steering switch: OFF
Approximately 4.3V
[Ignition switch: ON]
 MAIN switch: Pressed Approximately 0V
[Ignition switch: ON]
 CANCEL switch: Pressed Approximately 1.3V
[Ignition switch: ON]
 RESUME/ACCELERATE switch: Pressed Approximately 3.7V
[Ignition switch: ON]
 SET/COAST switch: Pressed Approximately 3.0V
[Ignition switch: ON]
 DISTANCE switch: Pressed Approximately 2.2V
99 G/Y ASCD steering switch
(models with ASCD system) [Ignition switch: ON]
 ASCD steering switch: OFF
Approximately 4.0V
[Ignition switch: ON]
 MAIN switch: Pressed Approximately 0V
[Ignition switch: ON]
 CANCEL switch: Pressed Approximately 1.0V
[Ignition switch: ON]
 RESUME/ACCELERATE switch: Pressed Approximately 3.0V
[Ignition switch: ON]
 SET/COAST switch: Pressed Approximately 2.0V
101 P/L Stop lamp switch [Ignition switch: OFF]
 Brake pedal: Fully released
Approximately 0V
[Ignition switch: OFF]
 Brake pedal: Slightly depressed BATTERY VOLTAGE
(11 - 14V)
102 LG/B PNP switch [Ignition switch: ON]
 Selector lever: P or N
Approximately 0V
[Ignition switch: ON]
 Except above position BATTERY VOLTAGE
(11 - 14V)
104 L/OR Throttle co ntrol motor relay[Ignition switch: OFF]
BATTERY VOLTAGE
(11 - 14V)
[Ignition switch: ON] 0 - 1.0V
106 OR Accelerator pedal position
sensor 1 [Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully released
0.5 - 1.0V
[Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully depressed 3.9 - 4.7V
107 PU/W Fuel tank temperature sen-
sor [Engine is running] Approximately 0 - 4.8V
Output voltage varies with fuel
tank temperature.
108 SB ICC brake switch
(models with ICC system)
ASCD brake switch
(models with ASCD system) [Ignition switch: ON]
 Brake pedal: Slightly depressed
Approximately 0V
[Ignition switch: ON]
 Brake pedal: Fully released BATTERY VOLTAGE
(11 - 14V)
109 W/L Ignition switch [Ignition switch: OFF]
0V
[Ignition switch: ON] BATTERY VOLTAGE
(11 - 14V)
TER-
MI-
NAL NO. WIRE
COLOR
ITEM CONDITION DATA (DC Voltage)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-118
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
ItemDIAGNOSTIC TEST MODE
WORK SUP-
PORT SELF-DIAGNOSTIC
RESULTS DATA
MONI-
TOR ACTIVE
TEST DTC & SRT
CONFIRMATION
DTC*
1FREEZE FRAME
DATA*
1
SRT
STATUS DTC
WORK
SUP-
PORT
ENGINE CONTROL COMPONENT PARTS
INPUT
Crankshaft position sensor (POS) ×××
Camshaft position sensor (PHASE) ×××
Mass air flow sensor ××
Engine coolant temperature sensor ××××
Air fuel ratio (A/F) sensor 1 ××××
Heated oxygen sensor 2 ××××
Vehicle speed sensor ×××
Accelerator pedal position sensor ××
Throttle position sensor ×××
Fuel tank temperature sensor ×××
EVAP control system pressure sen-
sor ××
Intake air temperature sensor ×××
Knock sensor ×
Refrigerant pressure sensor ×
Closed throttle position switch (ac-
celerator pedal position sensor sig-
nal) ×
Air conditioner switch ×
Park/neutral position (PNP) switch ××
Stop lamp switch ××
Power steering pressure sensor ××
Battery voltage ×
Load signal ×
Fuel level sensor ××
ICC steering switch ××
ASCD steering switch ××
ICC brake switch ××
ASCD brake switch ××
Snow mode switch ×
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-122
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
EVAP SYS PRES V The signal voltage of EVAP control system pres-
sure sensor is displayed.
FUEL LEVEL SE V  The signal voltage of the fuel level sensor is dis-
played.
START SIGNAL × Indicates start signal status [ON/OFF] computed by
the ECM according to the signals of engine speed
and battery voltage.  After starting the engine, [OFF] is dis-
played regardless of the starter signal.
CLSD THL POS × Indicates idle position [ON/OFF] computed by ECM
according to the accelerator pedal position sensor
signal.
AIR COND SIG × Indicates [ON/OFF] condition of the air conditioner
switch as determined by the air conditioner signal.
P/N POSI SW × Indicates [ON/OFF] condition from the park/neutral
position (PNP) switch signal.
PW/ST SIGNAL × [ON/OFF] condition of the power steering system
(determined by the signal voltage of the power
steering pressure sensor) is indicated.
LOAD SIGNAL × Indicates [ON/OFF] condition from the electrical
load signal.
ON: Rear window defogger switch is ON and/or
lighting switch is in 2nd position.
OFF: Both rear window defogger switch and light-
ing switch are OFF.
IGNITION SW × Indicates [ON/OFF] condition from ignition switch
signal.
HEATER FAN SW × Indicates [ON/OFF] condition from the heater fan
switch signal.
BRAKE SW × Indicates [ON/OFF] condition from the stop lamp
switch signal.
INJ PULSE-B1 ×
 Indicates the actual fuel injection pulse width com-
pensated by ECM according to the input signals.  When the engine is stopped, a certain
computed value is indicated.
INJ PULSE-B2 ×
IGN TIMING × Indicates the ignition timing computed by ECM ac-
cording to the input signals.  When the engine is stopped, a certain
value is indicated.
CAL/LD VALUE %  Calculated load value indicates the value of the cur-
rent air flow divided by peak air flow.
MASS AIRFLOW g·m/s  Indicates the mass air flow computed by ECM ac-
cording to the signal voltage of the mass air flow
sensor.
PURG VOL C/V %  Indicates the EVAP canister purge volume control
solenoid valve control value computed by the ECM
according to the input signals.
 The opening becomes larger as the value increas- es.
INT/V TIM(B1) °CA
 Indicates [ °CA] of intake camshaft advanced angle.
INT/V TIM(B2) °CA
INT/V SOL(B1) %  The control condition of the intake valve timing con- trol solenoid valve (determined by ECM according
to the input signals) is indicated.
 The advance angle becomes larger as the value in-
creases.
INT/V SOL(B2) %
AIR COND RLY
× The air conditioner relay control condition (deter-
mined by ECM according to the input signals) is in-
dicated.
FUEL PUMP RLY × Indicates the fuel pump relay control condition de-
termined by ECM according to the input signals.
Monitored item Unit Description Remarks
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-123
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
VENT CONT/V
× The control condition of the EVAP canister vent
control valve (determined by ECM according to the
input signals) is indicated.
ON: Closed
OFF: Open
THRTL RELAY × Indicates the throttle co
ntrol motor relay control
condition determined by the ECM according to the
input signals.
COOLING FAN HI/MID/
LOW/
OFF  The control condition of the cooling fan (determined
by ECM according to the input signals) is indicated.
HI: High speed operation
MID: Middle speed operation
LOW: Low speed operation
OFF: Stop
HO2S2 HTR (B1) × Indicates [ON/OFF] condition of heated oxygen
sensor 2 heater determined by ECM according to
the input signals.
HO2S2 HTR (B2)
×
I/P PULLY SPD rpm  Indicates the engine speed computed from the tur-
bine revolution sensor signal.
VEHICLE SPEED km/h or
mph  Indicates the vehicle speed computed from the rev-
olution sensor signal.
IDL A/V LEARN YET/
CMPLT  Display the condition of idle air volume learning
YET: Idle Air Volume Learning has not been per-
formed yet.
CMPLT: Idle Air Volume Learning has already been
performed successfully.
TRVL AFTER MIL km or
mile  Distance traveled while MIL is activated.
SNOW MODE SW ON/OFF  Indicates [ON/OFF] condition from the snow mode
switch signal.
A/F S1 HTR(B1) %  Air fuel ratio (A/F) sensor 1 heater control value computed by ECM according to the input signals.
 The current flow to the heater becomes larger as the value increases.
A/F S1 HTR(B2) %
AC PRESS SEN V
 The signal voltage from the refrigerant pressure
sensor is displayed.
VHCL SPEED SE km/h or
mph  The vehicle speed computed from the vehicle
speed signal sent from TCM is displayed.
SET VHCL SPD km/h or
mph  The preset vehicle speed is displayed.
MAIN SW ON/OFF  Indicates [ON/OFF] condition from MAIN switch
signal.
CANCEL SW ON/OFF  Indicates [ON/OFF] condition from CANCEL switch
signal.
RESUME/ACC SW ON/OFF  Indicates [ON/OFF] condition from RESUME/AC-
CELERATE switch signal.
SET SW ON/OFF  Indicates [ON/OFF] condition from SET/COAST
switch signal.
BRAKE SW1 ON/OFF  Indicates [ON/OFF] condition from ASCD brake
switch signal.
BRAKE SW2 ON/OFF  Indicates [ON/OFF] condition of stop lamp switch
signal.
Monitored item Unit Description Remarks
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-130
< SERVICE INFORMATION >[VQ35DE]
TROUBLE DIAGNOSIS
*: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally. Thus, they
differ from
ECM terminals voltage signal. CANCEL SW  Ignition switch: ON
CANCEL switch: Pressed ON
CANCEL switch: Released OFF
RESUME/ACC SW  Ignition switch: ON RESUME/ACCELERATE switch:
Pressed
ON
RESUME/ACCELERATE switch: Re-
leased OFF
SET SW  Ignition switch: ON SET/COAST switch: Pressed ON
SET/COAST switch: Released OFF
BRAKE SW1  Ignition switch: ON Brake pedal: Fully released ON
Brake pedal: Slightly depressed OFF
BRAKE SW2  Ignition switch: ON Brake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
DIST SW  Ignition switch: ON DISTANCE switch: Depressed ON
DISTANCE switch: Released OFF
CRUISE LAMP  Ignition switch: ON MAIN switch: pressed at the 1st time
→
at the 2nd time ON
→ OFF
SET LAMP  MAIN switch: ON
 When vehicle speed is between
40km/h (25MPH) and 144km/h
(89MPH) ASCD: Operating ON
ASCD: Not operating OFF
MONITOR ITEM CONDITION SPECIFICATION
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DTC P0130, P0150 A/F SENSOR 1
EC-213
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
1. Start engine and warm it up to normal operating temperature.
2. Let engine idle for 2 minutes.
3. Check 1st trip DTC.
4. If 1st trip DTC is detected, go to
EC-217, "
Diagnosis Procedure".
PROCEDURE FOR MALFUNCTION B
CAUTION:
Always drive vehicle at a safe speed.
With CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Select “A/F SEN1 (B1)” or “A/F SEN1 (B2) ” in “DATA MONITOR” mode with CONSULT-III.
3. Check “A/F SEN1 (B1)” or “A/F SEN1 (B2)” indication. If the indication is constantly approx . 1.5V and does not fluctuates, go to EC-217, "
Diagnosis Procedure".
If the indication fluctuates around 1.5V, go to next step.
4. Select “A/F SEN1 (B1) P1276” (for DTC P0130) or “A/F SEN1 (B2) P1286” (for DTC P0150) of “A/F
SEN1” in “DTC WORK SUPPORT” mode with CONSULT-III.
5. Touch “START”.
6. When the following conditions are met, “TESTIN G” will be displayed on the CONSULT-III screen.
If “TESTING” is not displayed after 20 seconds, retry from step 2.
7. Release accelerator pedal fully. NOTE:
Never apply brake during releasing the accelerator pedal.
8. Make sure that “TESTING” changes to “COMPLETED”. If “TESTING” changed to “OUT OF CONDITION”, retry from step 6.
9. Make sure that “OK” is display ed after touching “SELF-DIAG RESULT”.
If “NG” is displayed, go to EC-217, "
Diagnosis Procedure".
Overall Function CheckINFOID:0000000001326049
PROCEDURE FOR MALFUNCTION B
Use this procedure to check the overall function of the A/F sensor 1 circuit. During this check, a 1st trip DTC
might not be confirmed.
With GST
1. Start engine and warm it up to normal operating temperature.
2. Drive the vehicle at a speed of 80 km/h (50 MPH) for a few minutes in the suitable gear position.
3. Set D position, then release the accelerator pedal fu lly until the vehicle speed decreases to 50 km/h (30
MPH).
NOTE:
Never apply brake during releasing the accelerator pedal.
4. Repeat steps 2 to 3 for five times.
5. Stop the vehicle and turn ignition switch OFF.
6. Wait at least 10 seconds and restart engine.
7. Repeat steps 2 to 3 for five times.
8. Stop the vehicle and connect GST to the vehicle.
9. Make sure that no 1st trip DTC is displayed. If 1st trip DTC is displayed, go to EC-217, "
Diagnosis Procedure".
ENG SPEED 1,100 - 3,200 rpm
VHCL SPEED SE More than 64 km/h (40 MPH)
B/FUEL SCHDL 1.0 - 8.0 msec
Shift lever D position
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

INDEX FOR DTCEC-597
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OP0453 0453 EVAP SYS PRES SEN
EC-966
P0455 0455 EVAP GROSS LEAKEC-973
P0456 0456 EVAP VERY SML LEAKEC-979
P0460 0460 FUEL LEV SEN SLOSHEC-986
P0461 0461 FUEL LEVEL SENSOREC-988
P0462 0462 FUEL LEVL SEN/CIRCEC-990
P0463 0463 FUEL LEVL SEN/CIRCEC-990
P0500 0500
VEH SPEED SEN/CIRC*5EC-992
P0506 0506 ISC SYSTEM EC-994
P0507 0507 ISC SYSTEMEC-996
P0550 0550 PW ST P SEN/CIRCEC-998
P0603 0603 ECM BACK UP/CIRCUITEC-1003
P0605 0605 ECMEC-1007
P0643 0643 SENSOR POWER/CIRCEC-1009
P0700 0700 TCM AT- 1 0 1
P0705 0705 PNP SW/CIRCAT- 1 0 2
P0710 0710 ATF TEMP SEN/CIRCAT- 1 3 2
P0717 0717 TURBINE SENSORAT- 1 0 6
P0720 0720
VEH SPD SEN/CIR AT*5AT- 1 0 8
P0731 0731 A/T 1ST GR FNCTN AT- 11 4
P0732 0732 A/T 2ND GR FNCTNAT- 11 6
P0733 0733 A/T 3RD GR FNCTNAT- 11 8
P0734 0734 A/T 4TH GR FNCTNAT- 1 2 0
P0735 0735 A/T 5TH GR FNCTNAT- 1 2 2
P0740 0740 TCC SOLENOID/CIRCAT- 1 2 4
P0744 0744 A/T TCC S/V FNCTNAT- 1 2 6
P0745 0745 L/PRESS SOL/CIRCAT- 1 2 8
P0850 0850 P-N POS SW/CIRCUITEC-1014
P1140 1140 INTK TIM S/CIRC-B1EC-1019
P1145 1145 INTK TIM S/CIRC-B2EC-1019
P1148 1148 CLOSED LOOP-B1EC-1027
P1168 1168 CLOSED LOOP-B2EC-1027
P1211 1211 TCS C/U FUNCTNEC-1028
P1212 1212 TCS/CIRC EC-1029
P1217 1217 ENG OVER TEMPEC-1030
P1225 1225 CTP LEARNING-B1EC-1041
P1226 1226 CTP LEARNING-B1EC-1043
P1421 1421 COLD START CONTROLEC-1045
P1564 1564 ASCD SWEC-1047 (Models with ICC)
EC-1053
(Models with ASCD)
P1568 1568 ICC COMMAND VALUE*
6EC-1059
P1572 1572 ASCD BRAKE SW EC-1060 (Models with ICC)
EC-1068
(Models with ASCD)
DTC*
1
Items
(CONSULT-III screen terms) Reference page
CONSULT-III
GST*
2ECM*3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-598
< SERVICE INFORMATION >[VK45DE]
INDEX FOR DTC
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: Models with ICC.
Alphabetical IndexINFOID:0000000001326484
P1574 1574 ASCD VHL SPD SEN EC-1075 (Models with ICC)
EC-1077
(Models with ASCD)
P1610 1610 LOCK MODE BL-4
P1611 1611 ID DISCARD, IMM-ECMBL-4
P1612 1612 CHAIN OF ECM-IMMU BL-4
P1614 1614 CHAIN OF IMMU-KEYBL-4
P1615 1615 DIFFERENCE OF KEYBL-4
P1715 1715 IN PULY SPEEDEC-1079
P1730 1730 A/T INTERLOCK AT- 1 3 9
P1752 1752 I/C SOLENOID/CIRCAT- 1 4 3
P1757 1757 FR/B SOLENOID/CIRCAT- 1 4 5
P1762 1762 D/C SOLENOID/CIRCAT- 1 4 7
P1767 1767 HLR/C SOL/CIRCAT- 1 4 9
P1772 1772 LC/B SOLENOID/CIRCAT- 1 5 1
P1774 1774 LC/B SOLENOID FNCTAT- 1 5 3
P1800 1800 VIAS S/V-1EC-1080
P1805 1805 BRAKE SW/CIRCUITEC-1084
P2100 2100 ETC MOT PWR-B1EC-1088
P2101 2101 ETC FNCTN/CIRC-B1EC-1092
P2103 2103 ETC MOT PWREC-1088
P2118 2118 ETC MOT-B1EC-1098
P2119 2119 ETC ACTR-B1 EC-1102
P2122 2122 APP SEN 1/CIRC EC-1104
P2123 2123 APP SEN 1/CIRCEC-1104
P2127 2127 APP SEN 2/CIRC E C - 111 0
P2128 2128 APP SEN 2/CIRCE C - 111 0
P2135 2135 TP SENSOR-B1E C - 111 6
P2138 2138 APP SENSOREC-1122
P2A00 2A00 A/F SENSOR1 (B1) EC-1129
P2A03 2A03 A/F SENSOR1 (B2)EC-1129
DTC*1
Items
(CONSULT-III screen terms) Reference page
CONSULT-III
GST*
2ECM*3
Items
(CONSULT-III screen terms) DTC*
1
Reference page
CONSULT-III
GST*
2ECM*3
A/F SEN1 HTR (B1) P0031 0031 EC-739
A/F SEN1 HTR (B1) P0032 0032EC-739
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

INDEX FOR DTCEC-599
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OA/F SEN1 HTR (B2) P0051 0051
EC-739
A/F SEN1 HTR (B2) P0052 0052EC-739
A/F SENSOR1 (B1) P0130 0130EC-798
A/F SENSOR1 (B1) P0131 0131EC-806
A/F SENSOR1 (B1) P0132 0132EC-814
A/F SENSOR1 (B1) P0133 0133EC-822
A/F SENSOR1 (B1) P2A00 2A00EC-1129
A/F SENSOR1 (B2) P0150 0150 EC-798
A/F SENSOR1 (B2) P0151 0151EC-806
A/F SENSOR1 (B2) P0152 0152EC-814
A/F SENSOR1 (B2) P0153 0153EC-822
A/F SENSOR1 (B2) P2A03 2A03EC-1129
A/T 1ST GR FNCTN P0731 0731 AT- 11 4
A/T 2ND GR FNCTN P0732 0732AT- 11 6
A/T 3RD GR FNCTN P0733 0733AT- 11 8
A/T 4THT GR FNCTN P0734 0734AT- 1 2 0
A/T 5TH GR FNCTN P0735 0735AT- 1 2 2
A/T INTERLOCK P1730 1730AT- 1 3 9
A/T TCC S/V FNCTN P0744 0744AT- 1 2 6
APP SEN 1/CIRC P2122 2122EC-1104
APP SEN 1/CIRC P2123 2123EC-1104
APP SEN 2/CIRC P2127 2127 E C - 111 0
APP SEN 2/CIRC P2128 2128E C - 111 0
APP SENSOR P2138 2138EC-1122
ASCD BRAKE SW P1572 1572EC-1060 (Models with ICC)
EC-1068
(Models with ASCD)
ASCD SW P1564 1564 EC-1047
(Models with ICC)
EC-1053
(Models with ASCD)
ASCD VHL SPD SEN P1574 1574 EC-1075
(Models with ICC)
EC-1077
(Models with ASCD)
ATF TEMP SEN/CIRC P0710 0710 AT- 1 3 2
BRAKE SW/CIRCUIT P1805 1805EC-1084
CAN COMM CIRCUIT U1000
1000*4EC-724
CAN COMM CIRCUIT U10011001*4EC-724
CHAIN OF ECM-IMMU P1612 1612 BL-4
CHAIN OF IMMU-KEY P1614 1614BL-4
CKP SEN/CIRCUIT P0335 0335EC-906
CLOSED LOOP-B1 P1148 1148EC-1027
CLOSED LOOP-B2 P1168 1168EC-1027
CMP SEN/CIRC-B1 P0340 0340 EC-911
COLD START CONTROL P1421 1421EC-1045
CONTROL UNIT(CAN) U1010 1010 EC-726
CTP LEARNING-B1 P1225 1225EC-1041
Items
(CONSULT-III screen terms) DTC*
1
Reference page
CONSULT-III
GST*
2ECM*3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
