BL-16
< SERVICE INFORMATION >
HOOD
6. Remove the grommet on the dashboard, and pull the hood lock cable toward the passenger room.CAUTION:
While pulling, be careful not to damage (p eeling) the outside of the hood lock cable.
INSTALLATION
1. Pull the hood lock cable through the panel hole to the engine room.
Be careful not to bend the cable too much, keeping the radius
100 mm (3.94 in) or more.
2. Make sure the cable is not offset from the positioning grommet, and push the grommet into the panel hole securely.
3. Apply the sealant to the grommet (at * mark) properly.
4. Install the cable securely to the lock.
5. After installing, check the hood lock adjustment and hood opener operation.
Hood Lock Control InspectionINFOID:0000000001327786
CAUTION:
If the hood lock cable is bent or deformed, replace it.
1. Make sure that the hood lock secondary latch is properlyengaged with the secondary striker with hood's own weight.
2. Make sure that the hood lock primary latch is securely engaged with the hood striker with hood's own weight by dropping it from
approx. 200 mm (7.87 in) height.
CAUTION:
Do not drop hood from a he ight of 300 mm (11.81 in) or
more.
3. When pulling hood opener lever gently, make sure that front end of the hood rises by approximately 20 mm (0.79 in) and that hood striker and hood lock primary latch are disengaged. Also make sure that hood
opener returns to the original position.
PIIA0173E
PIIA3552E
PIIB1082E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

INTELLIGENT KEY SYSTEMBL-99
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
Terminal and Reference Valu e for INTELLIGENT KEY UNITINFOID:0000000001327842
Te r -
minal Wire
color Item Signal
Input/
output Condition
Voltage (V)(Approx.)
Ignition
knob po- sition Operation or conditions
1R/W Steering lock unit power
supply
Output LOCK — 5
2 L CAN-H Input/
Output —— —
3 P CAN-L Input/
Output —— —
4LG Intelligent Key warning
buzzer Output LOCKOperate remote
controller button or door request switch. Buzzer OFF Battery voltage
Sound
buzzer
0
5W/L Door request switch
(driver side) Input —Door request switch operation:
Press (ON).
0
Other than the above (OFF) 5
6 W Ignition switch (ON) Input ON or
START — Battery voltage
7 B/W key switch Input LOCK Insert mechanical key into igni-
tion key cylinder.
Battery voltage
Remove mechanical key from ig-
nition key cylinder. 0
10 LG Ignition switch (ACC) Input ACC or
ON — Battery voltage
11 L/R Power source (Fuse) Input — — Battery voltage
12 B Ground — — — 0
13 P Inside key antenna (+)
(Luggage room) Output
LOCKAny door open
→ all doors shut
(Door switch: ON → OFF)
14 L Inside key antenna (-)
(Luggage room)
Output
15 G Inside key antenna (+)
signal
(Dashboard) Output
LOCKAny door open
→ Close (Door
switch: ON → OFF)
Ignition knob switch: ON (press
ignition knob.)
16 R Inside key
antenna (-)
signal
(Dashboard) Output
17 L Back door antenna (+) Output
LOCKBack door request switch opera-
tion (Switch: ON)
18 W/L Back door antenna (-) Output
SIIA1910J
SIIA1910J
SIIA1910J
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-100
< SERVICE INFORMATION >
INTELLIGENT KEY SYSTEM
19 SB Outside antenna LH (+) OutputLOCKDriver door request signal opera-
tion (Switch: ON)
20 G/Y Outside antenna LH (-) Output
25 W/R Door request switch
(passenger side)
Input —Door request switch operation:
Press (ON)
0
Other than the above (OFF) 5
26 P/L Stop lamp switch Input — Brake pedal depressed (ON) 5
Brake pedal not depressed
(OFF)
0
27 L/W Ignition knob switch Input — Press ignition knob. 12
Return ignition knob to LOCK po-
sition.
0
28 W/B Door unlock sensor Input — Door is locking → unlock 5 → 0
29 GY Door request switch
(back door)
Input —Back door request switch opera-
tion: Press (ON)
0
Other than the above (OFF) 5
31 Y/B Steering lock unit
ground —— — 0
32 R/B Steering lock unit com-
munication Output LOCKPress ignition knob with Intelli-
gent Key inside vehicle.
Other than the above 5
35 LG Inside key antenna (+)
signal
(Dashboard) Output
LOCKAny door open
→ Close (Door
switch: ON → OFF)
Ignition knob switch: ON (press
ignition knob.)
36 PU Inside key antenna (-)
signal
(Dashboard) Output
37 G Outside antenna RH (+) Output
LOCKPassenger door request switch
operation (Switch: ON)
38 G/W Outside antenna RH (-) Output
Te r -
minal Wire
color Item Signal
Input/
output Condition
Voltage (V)(Approx.)
Ignition
knob po-
sition Operation or conditions
SIIA1910J
SIIA1911J
SIIA1910J
SIIA1910J
