Self-Diagnosis Mode (DCU)INFOID:0000000001328723
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pressing the “4” button, turn the volume control dial clock- wise or counterclockwise for 30 clicks or more. (When the self-
diagnosis mode is started, a short beep will be heard.)
 Shifting from current screen to previous screen is performedby pressing “BACK” button.
4. The initial trouble diagnosis screen will be shown, and items “Self Diagnosis (DCU)”, “Confirmation/Adjustment” and “CAN
DIAG SUPPORT MONITOR” will become selective.
5. Perform self-diagnosis by selecting the “Self Diagnosis (DCU)”.  Self-diagnosis screen is displayed, and then self-diagnosisstarts.
 The bar graph visible below self-diagnosis screen displays progress of the diagnosis.
Mode Description
Self Diagnosis (DCU)  Display control unit diagnosis
 Analyzes connection between the display control unit and each unit, and
operation of each unit.
Confirmation/
Adjustment Display Diagnosis
Color tone and shading of the display control unit-generated image can be
checked by the display of a color bar and a gray scale.
Vehicle Signals Diagnosis of signals that are input to display control unit can be performed
for Vehicle Speed, IGN, Reverse and Light.
Auto Climate Control Refer to AT C - 4 3 , "
Self-Diagnosis Function".
CAN DIAG SUPPOPT MONITOR The transmitting/receiving of CAN communication can be monitored.
SKIB8743E
SKIB7871E
SKIA4208E
