INFINITI G35 2006 Owners Manual

q 5
Maximum load rating
This number indicates the maximum
load in kilograms and pounds that
can be carried by the tire. When re-
placing the tires on the vehicle, al-
ways use a tire that has the same
load rating as the factory installed
tire.
q 6
Term of ªtubelessº or ªtube typeº
Indicates whether the tire requires
an inner tube (ªtube typeº) or not
(ªtubelessº).
q 7
The word ªradialº
The word ªradialº is shown if the
tire has radial structure.
q 8
Manufacturer or brand name
Manufacturer or brand name is
shown.
Other tire-related terminology:
In addition to the many terms that are
defined throughout this section, In-
tended Outboard Sidewall is (1) the
sidewall that contains a whitewall,
bears white lettering or bears manufac- turer, brand and/or model name
molding that is higher or deeper than
the same molding on the other sidewall
of the tire, or (2) the outward facing
sidewall of an asymmetrical tire that
has a particular side that must always
face outward when mounted on a ve-
hicle.
TYPES OF TIRES
WARNING O When changing or replacing tires, be
sure all four tires are of the same type
(i.e., Summer, All Season or Snow) and
construction. An INFINITI dealer may be
able to help you with information about
tire type, size, speed rating and avail-
ability.
O Replacement tires may have a lower
speed rating than the factory equipped
tires, and may not match the potential
maximum vehicle speed. Never exceed
the maximum speed rating of the tire.
O Replacing tires with those not originally specified by INFINITI could affect the
proper operation of the tire pressure
monitoring system (TPMS).
O For additional information regarding
tires, refer to ªImportant Tire Safety In-
formationº (US) or ªTire Safety Informa-
tionº (Canada) in the Warranty Informa-
tion Booklet.
All season tires INFINITI specifies All Season tires on some
models to provide good performance for
use all year, including snowy and icy road
conditions. All Season tires are identified
by ALL SEASON and/or M&S on the tire
sidewall. Snow tires have better snow trac-
tion than All Season tires and may be
more appropriate in some areas.
Summer tires INFINITI specifies summer tires on some
models to provide superior performance
on dry roads. Summer tire performance is
substantially reduced in snow and ice.
Summer tires do not have the tire traction
rating ªM&Sº on the tire sidewall.
If you plan to operate your vehicle in
snowy or icy conditions, INFINITI recom-
Maintenance and do-it-yourself
8-43
w 06.1.5/V35-D/V5.0
X

mends the use of SNOW or ALL SEASON
tires on all four wheels.
Snow tires If snow tires are needed, it is necessary
to select tires equivalent in size and load
rating to the original equipment tires. If
you do not, it can adversely affect the
safety and handling of your vehicle.
Generally, snow tires will have lower
speed ratings than factory equipped tires
and may not match the potential
maximum vehicle speed. Never exceed
the maximum speed rating of the tire.
If you operate your vehicle in snowy or icy
conditions, INFINITI recommends the use
of snow or all season tires on all four
wheels.
For additional traction on icy roads, stud-
ded tires may be used. However, some
provinces and states prohibit their use.
Check local, state and provincial laws be-
fore installing studded tires. Skid and
traction capabilities of studded snow
tires, on wet or dry surfaces, may be
poorer than that of non-studded snow
tires. All-wheel drive (AWD) models
CAUTION O Always use tires of the same type, size,
brand, construction (bias, bias-belted or
radial), and tread pattern on all four
wheels. Failure to do so may result in a
circumference difference between tires
on the front and rear axles which will
cause excessive tire wear and may
damage the transmission, transfer case
and differential gears.
O ONLY use spare tires specified for the
AWD model.
If excessive tire wear is found, it is recom-
mended that all four tires be replaced
with tires of the same size, brand, con-
struction and tread pattern. The tire pres-
sure and wheel alignment should also be
checked and corrected as necessary. Con-
tact an INFINITI dealer.
Tire chains must be installed only on the
rear wheels and not on the front wheels.
Do not drive with tire chains on paved
roads which are clear of snow. Driving with chains in such conditions can cause
damage to the various mechanisms of the
vehicle due to some overstress.
TIRE CHAINS Use of tire chains may be prohibited ac-
cording to location. Check the local laws
before installing tire chains. When install-
ing tire chains, make sure they are the
proper size for the tires on your vehicle
and are installed according to the chain
manufacturer's suggestions. Use only SAE
class ªSº chains. Class ªSº chains are
used on vehicles with restricted tire to ve-
hicle clearance. Vehicles that can use
Class ªSº chains are designed to meet
the minimum clearances between the tire
and the closest vehicle suspension or
body component required to accommo-
date the use of a winter traction device
(tire chains or cables). The minimum
clearances are determined using the fac-
tory equipped tires. Other types may
damage your vehicle. Use chain ten-
sioners when recommended by the tire
chain manufacturer to ensure a tight fit.
Loose end links of the tire chain must be
secured or removed to prevent the possi-
bility of whipping action damage to the
fenders or underbody. If possible, avoid
fully loading your vehicle when using tire
chains. In addition, drive at a reduced
8-44 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

speed. Otherwise, your vehicle may be
damaged and/or vehicle handling and
performance may be adversely affected.
Tire chains must be installed only on the
rear wheels and not on the front wheels.
Never install tire chains on a TEMPORARY
USE ONLY spare tire.
Do not use the chains on dry roads. Driv-
ing with chains in such conditions can
cause damage to the various mechanisms
of the vehicle due to some overstress.
CHANGING WHEELS AND TIRES Tire rotation (Sedan)
INFINITI recommends rotating the tires
every 7,500 miles (12,000 km).
See ªFlat tireº in the ª6. In case of
emergencyº section for tire replacing
procedures.
As soon as possible, tighten the wheel
nuts to the specified torque with a
torque wrench.
Wheel nut tightening torque:
80 ft-lb (108 N z m) The wheel nuts must be kept tightened
to specification at all times. It is recom-
mended that wheel nuts be tightened to
specification at each tire rotation in-
terval.
WARNING O After rotating the tires, check and
adjust the tire pressure.
O Retighten the wheel nuts when the
vehicle has been driven for 600
miles (1,000 km) (also in cases of a
flat tire, etc.).
O Do not include the T-type spare
tire or any other small size spare
tire in the tire rotation.
O For additional information re-
garding tires, refer to ªImportant
Tire Safety Informationº (US) or
ªTire Safety Informationº (Canada)
in the Warranty Information
Booklet.
Tire rotation (Coupe)
Tires cannot be rotated on this vehicle,
as front tires are a different size from DI0048-D
Sedan
Maintenance and do-it-yourself
8-45
w 06.1.5/V35-D/V5.0
X

rear tires and the direction of the wheel
rotation is fixed for each tire.
A pin is on the front brake rotor to pre-
vent the rear wheels from being in-
stalled in place of the front wheels. The
spare tire can be installed in place of
the front and rear wheels. When install-
ing the spare tire in the front wheel, the
hole in the spare tire wheel must be
aligned with the pin on the brake rotor.
WARNINGO Retighten the wheel nuts when the
vehicle has been driven for 600
miles (1,000 km) (also in cases of a
flat tire, etc.).
O For additional information re-
garding tires, refer to ªImportant
Tire Safety Informationº (US) or
ªTire Safety Informationº (Canada)
in the Warranty Information
Booklet. 1. Wear indicator
2. Location mark
Tire wear and damage
WARNINGO Tires should be periodically in-
spected for wear, cracking,
bulging or objects caught in the
tread. If excessive wear, cracks,
bulging or deep cuts are found, the
tire(s) should be replaced. O The original tires have built-in
tread wear indicators. When the
wear indicators are visible, the
tire(s) should be replaced.
O Tires degrade with age and use.
Have tires, including the spare,
over 6 years old checked by a
qualified technician because some
tire damage may not be obvious.
Replace the tires as necessary to
prevent tire failure and possible
personal injury.
O Improper service of the spare tire
may result in serious personal in-
jury. If it is necessary to repair the
spare tire, contact an INFINITI
dealer.
O For additional information re-
garding tires, refer to ªImportant
Tire Safety Informationº (US) or
ªTire Safety Informationº (Canada)
in the Warranty Information
Booklet.
Replacing wheels and tires When replacing a tire, use the same size,
speed rating and load carrying capacity
as originally equipped. See ªSpecifica- MDI0004C
8-46 Maintenance and do-it-yourself
w 06.1.5/V35-D/V5.0
X

tionsº in the ª9. Technical and consumer
informationº section for recommended
types and sizes of tires and wheels.
WARNINGO The use of tires other than those recom-
mended or the mixed use of tires of dif-
ferent brands, construction (bias, bias-
belted or radial), or tread patterns can ad-
versely affect the ride, braking, handling,
ground clearance, body-to-tire clearance,
tire chain clearance, speedometer calibra-
tion, headlight aim and bumper height.
Some of these effects may lead to accidents
and could result in serious personal injury.
O If the wheels are changed for any reason,
always replace with wheels which have
the same off-set dimension. Wheels of a
different off-set could cause premature
tire wear, degrade vehicle handling char-
acteristics and/or interference with the
brake discs. Such interference can lead
to decreased braking efficiency and/or
early brake pad wear.
O When a spare tire is mounted or a wheel
is replaced, tire pressure will not be indi-
cated, the TPMS will not function and the low tire pressure warning light will flash.
Contact your INFINITI dealer as soon as
possible for tire replacement and/or sys-
tem resetting.
O Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.
O Do not install a deformed wheel or tire
even if it has been repaired. Such wheels
or tires could have structural damage
and could malfunction without warning.
O The use of retread tires is not recom-
mended.
O For additional information regarding tires,
refer to ªImportant Tire Safety Informationº
(US) or ªTire Safety Informationº (Canada)
in the Warranty Information Booklet.
CAUTION Always use tires of the same type, size,
brand, construction (bias, bias-belted or ra-
dial), and tread pattern on all four wheels.
Failure to do so may result in a circumference difference between tires on the front and
rear axles which will cause excessive tire
wear and may damage the transmission,
transfer case and differential gears (AWD
models).
Wheel balance Unbalanced wheels may affect vehicle han-
dling and tire life. Even with regular use,
wheels can get out of balance. Therefore,
they should be balanced as required.
Wheel balance service should be per-
formed with the wheels off the vehicle.
Spin balancing the wheels on the vehicle
could lead to transmission damage.
For additional information regarding tires,
refer to ªImportant Tire Safety Informa-
tionº (US) or ªTire Safety Informationº
(Canada) in the INFINITI Warranty Informa-
tion Booklet.
Care of wheels O Wash the wheels when washing the
vehicle to maintain their appearance.
O Clean the inner side of the wheels
when the wheel is changed or the un-
derside of the vehicle is washed.
Maintenance and do-it-yourself
8-47
w 06.1.5/V35-D/V5.0
X

O Do not use abrasive cleaners when
washing the wheels.
O Inspect wheel rims regularly for dents or
corrosion. Such damage may cause loss
of pressure or poor seal at the tire bead.
O INFINITI recommends that the road
wheels be waxed to protect against
road salt in areas where it is used
during winter.
Spare tire (TEMPORARY USE ONLY
spare tire (T-type)) Observe the following precautions if the
T-type spare tire must be used, otherwise
your vehicle could be damaged or in-
volved in an accident.
CAUTIONO The T-type spare tire should be used only
for an emergency. It should be replaced by
a standard tire at the first opportunity.
O Drive carefully while the T-type spare tire
is installed.
Avoid sharp turns and abrupt braking
while driving. O Periodically check the T-type spare tire
inflation pressure, and always keep it at
60 psi (420 kPa, 4.2 bar).
O With the T-type spare tire installed, do
not drive your vehicle at speeds faster
than 50 MPH (80 km/h).
O When driving on roads covered with
snow or ice, the T-type spare tire should
be used on the front wheel and the origi-
nal tire used on the rear wheels (drive
wheels). Use tire chains only on the rear
two original tires (Sedan).
O
Tire tread of the T-type spare tire will wear
at a faster rate than the original tire. Re-
place the T-type spare tire as soon as the
tread wear indicators appear.
O Do not use the T-type spare tire on other
vehicles.
O Do not use more than one T-type spare
tire at the same time.
O Do not tow a trailer while the T-type
spare tire is installed. CAUTION O Do not use tire chains on a T-type spare
tire. Tire chains will not fit properly on
the T-type spare tire and may cause
damage to the vehicle.
O Because the T-type spare tire is smaller
than the original tire, ground clearance
is reduced. To avoid damage to the ve-
hicle do not drive over obstacles. Also do
not drive the vehicle through an auto-
matic car wash since it may get caught.
8-48 Maintenance and do-it-yourself
w 06.1.5/V35-D/V5.0
X

9 Technical and consumer information Capacities and recommended fuel/lubricants ... 9-2
Fuel recommendation .................................. 9-3
Engine oil and oil filter recommendation ..... 9-5
Recommended SAE viscosity number .......... 9-6
Air conditioning system refrigerant and
lubricant recommendations ......................... 9-7
Specifications................................................... 9-8
Engine......................................................... 9-8
Wheels and tires ......................................... 9-9
Dimensions and weights ............................. 9-9
When traveling or registering your vehicle in
another country .............................................. 9-10
Vehicle identification ...................................... 9-10
Vehicle identification number (VIN) plate ... 9-10
Vehicle identification number (Chassis
number) ..................................................... 9-10
Engine serial number ................................. 9-11
F.M.V.S.S./C.M.V.S.S. certification label ..... 9-11
Emission control information label ............. 9-12
Tire and loading information label ............. 9-12
Air conditioner specification label .............. 9-13 Installing front license plate............................ 9-13
Vehicle loading information ............................ 9-14
Terms ........................................................ 9-14
Vehicle load capacity ................................. 9-15
Loading tips ............................................... 9-17
Measurements of weights .......................... 9-17
Towing a trailer ............................................... 9-18
Maximum load limits ................................. 9-18
Towing load/specification chart ................. 9-19
Towing safety ............................................ 9-19
Flat towing ................................................ 9-22
Uniform tire quality grading............................ 9-23
Emission control system warranty .................. 9-24
Reporting safety defects (US only) .................. 9-24
Readiness for inspection/maintenance (I/M)
test (US only).................................................. 9-25
Event data recorders ...................................... 9-26
Owner's Manual/Service Manual order
information ................................................... 9-26
In the event of a collision.......................... 9-27
w 06.1.4/V35-D/V5.0
X

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure in-
structed in the ª8. Maintenance and do-it-yourselfº section to determine the proper refill capacity. Capacity (Approximate)
Recommended
specificationsUS
measure Imp
measure Liter
Fuel*1 20 gal 16-5/8 gal 76
Engine oil (Drain and refill)*8
With oil filter change 5 qt 4-1/8 qt 4.7 O API Certification Mark*2, *3
O API grade SG/SH, Energy Conservin gI&IIorAPI grade SJ or SL, Energy Conserving*2, *3
O ILSAC grade GF-I, GF-II & GF-III*2, *3Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system
With reservoir 9-1/4 qt 7-5/8 qt 8.7
Genuine NISSAN Long Life Antifreeze/Coolant or equivalent
Reservoir 7/8 qt 3/5 qt 0.8
Automatic transmission fluid Ð Ð Ð Genuine NISSAN Matic J ATF*4
Manual transmission gear oil Ð Ð Ð Genuine NISSAN Manual Transmission Fluid (MTF)
HQ Multi 75W-85 or API GL-4, Viscosity SAE 75W-85 or 75W-90
Differential gear oil Ð Ð Ð API GL-5, Viscosity SAE 80W-90*5
Transfer fluid Ð Ð Ð Genuine NISSAN Matic D ATF (Continental U.S. and Alaska) or CANADA NISSAN Automatic Trans-
mission Fluid*6
Power steering fluid (PSF) Refill to the proper fluid level according to the in-
structions in the ª8. Maintenance and do-it-yourselfº
section. Genuine NISSAN PSF or equivalent*10
Brake and clutch fluid Genuine NISSAN Super Heavy Duty Brake Fluid*7 or equivalent DOT 3
Multi-purpose grease Ð Ð Ð NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant Ð Ð Ð HFC-134a (R-134a)*9
Air conditioning system lubricants Ð Ð Ð NISSAN A/C System Oil Type S or exact equivalent
Windshield washer fluid Ð Ð Ð Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1: For additional information, see ªFuel recommendationº later in this section.
*2: For additional information, see ªEngine oil and oil filter recommendationº later in this section.
*3: For additional information, see ªRecommended SAE viscosity numberº later in this section.
*4: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not
covered by the INFINITI new vehicle limited warranty.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures always above 32ÉF (0ÉC).
*6: DEXRON TM
III/MERCON TM
or equivalent may also be used. Outside the continental United States and Alaska contact an INFINITI dealer for more information regarding suitable fluids, including recommended
brand(s) of DEXRON TM
III/MERCON TM
automatic transmission fluid.
*7: Available in mainland US through an INFINITI dealer.
*8: For additional information, see ªEngine oilº in the ª8. Maintenance and do-it-yourselfº section for changing engine oil.
*9: For additional information, see ªVehicle identificationº later in this section for air conditioner specification label.
*10: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON TM
III/MERCON TM
or equivalent ATF may also be used.CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS
9-2 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

FUEL RECOMMENDATION
Sedan Ð Automatic transmission
models Use unleaded regular gasoline with an oc-
tane rating of at least 87 AKI (Anti-Knock In-
dex) number (Research octane number 91).
For improved vehicle performance,
INFINITI recommends the use of unleaded
premium gasoline with an octane rating of
at least 91 AKI number (Research octane
number 96).
Sedan Ð Manual transmission
and Coupe models Use unleaded premium gasoline with an
octane rating of at least 91 AKI (Anti-
Knock Index) number (Research octane
number 96).
If premium gasoline is not available, un-
leaded regular gasoline with an octane
rating of 87 AKI number (Research octane
number 91) may be temporarily used, but
only under the following precautions:
O Have the fuel tank filled only partially
with unleaded regular gasoline, and
fill up with unleaded premium gaso-
line as soon as possible. O Avoid full throttle driving and abrupt
acceleration.
However, for maximum vehicle perfor-
mance, the use of unleaded premium gaso-
line is recommended.
CAUTION O Using a fuel other than that specified
could adversely affect the emission con-
trol system, and may also affect the war-
ranty coverage.
O Under no circumstances should a leaded
gasoline be used, because this will dam-
age the three-way catalyst.
O Do not use E-85 fuel in your vehicle. Your
vehicle is not designed to run on E-85
fuel. Using E-85 fuel can damage the fuel
system components and is not covered
by the INFINITI vehicle limited warranty.
Gasoline specifications INFINITI recommends using gasoline that
meets the World-Wide Fuel Charter
(WWFC) specifications where it is avail- able. Many of the automobile manufactur-
ers developed this specification to im-
prove emission control system and ve-
hicle performance. Ask your service
station manager if the gasoline meets the
WWFC specifications.
Reformulated gasoline Some fuel suppliers are now producing
reformulated gasolines. These gasolines
are specially designed to reduce vehicle
emissions. INFINITI supports efforts to-
wards cleaner air and suggests that you
use reformulated gasoline when avail-
able.
Gasoline containing oxygenates Some fuel suppliers sell gasoline contain-
ing oxygenates such as ethanol, MTBE
and methanol with or without advertising
their presence. INFINITI does not recom-
mend the use of fuels of which the oxy-
genate content and the fuel compatibility
for your INFINITI cannot be readily deter-
mined. If in doubt, ask your service sta-
tion manager.
If you use oxygenate-blend gasoline,
please take the following precautions as
the usage of such fuels may cause vehicle
Technical and consumer information
9-3
w 06.1.4/V35-D/V5.0
X

performance problems and/or fuel system
damage.
O The fuel must be unleaded and have an
octane rating no lower than that recom-
mended for unleaded gasoline.
O If an oxygenate-blend, excepting a
methanol blend, is used, it should con-
tain no more than 10% oxygenate.
(MTBE may, however, be added up to
15%.)
O If a methanol blend is used, it should
contain no more than 5% methanol
(methyl alcohol, wood alcohol). It
should also contain a suitable amount
of appropriate cosolvents and corro-
sion inhibitors. If not properly formu-
lated with appropriate cosolvents and
corrosion inhibitors, such methanol
blends may cause fuel system damage
and/or vehicle performance problems.
At this time, sufficient data is not avail-
able to ensure that all methanol blends
are suitable for use in INFINITI vehicles.
If any driveability problems such as en-
gine stalling and hard hot starting are ex-
perienced after using oxygenate-blend fu-
els, immediately change to a non-
oxygenate fuel or a fuel with a low blend
of MTBE. Take care not to spill gasoline during refu-
eling. Gasoline containing oxygenates can
cause paint damage.
E-85 fuel E-85 fuel is a mixture of approximately
85% fuel ethanol and 15% unleaded gaso-
line. E-85 can only be used in a Flexible
Fuel Vehicle (FFV). Do not use E-85 fuel in
your vehicle. U.S. government regulations
require fuel ethanol dispensing pumps to
be identified by a small, square, orange
and black label with the common abbre-
viation or the appropriate percentage for
that region.
Aftermarket fuel additives INFINITI does not recommend the use of
any aftermarket fuel additives (i.e. fuel in-
jector cleaner, octane booster, intake
valve deposit removers, etc.) which are
sold commercially. Many of these addi-
tives intended for gum, varnish or deposit
removal may contain active solvent or
similar ingredients that can be harmful to
the fuel system and engine.
Octane rating tips Using unleaded gasoline with an octane
rating lower than recommended can cause persistent, heavy spark knock. (Spark
knock is a metallic rapping noise.) If se-
vere, this can lead to engine damage. If
you detect a persistent heavy spark knock
even when using gasoline of the stated oc-
tane rating, or if you hear steady spark
knock while holding a steady speed on
level roads, have your dealer correct the
condition. Failure to correct the condition
is misuse of the vehicle, for which INFINITI
is not responsible.
Incorrect ignition timing will result in
knocking, after-run or overheating. This in
turn may cause excessive fuel consump-
tion or damage to the engine. If any of the
above symptoms are encountered, have
your vehicle checked at an INFINITI dealer
or other competent service facility.
However, now and then you may notice
light spark knock for a short time while ac-
celerating or driving up hills. This is no
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.
9-4 Technical and consumer information
w 06.1.4/V35-D/V5.0
X
