INFINITI G35 2006 Owners Manual

ENGINE OIL AND OIL FILTER
RECOMMENDATION
Selecting the correct oil It is essential to choose the correct grade,
quality and viscosity engine oil to ensure
satisfactory engine life and performance.
See ªCapacities and recommended
fuel/lubricantsº earlier in this section.
INFINITI recommends the use of an energy
conserving oil in order to improve fuel
economy.
Select only engine oils that meet the
American Petroleum Institute (API) certifi- cation or International Lubricant Stan-
dardization and Approval Committee
(ILSAC) certification and SAE viscosity
standard. These oils have the API certifi-
cation mark on the front of the container.
Oils which do not have the specified
quality label should not be used as they
could cause engine damage. Oil additives INFINITI does not recommend the use of
oil additives. The use of an oil additive is
not necessary when the proper oil type is
used and maintenance intervals are fol-
lowed.
Oil which may contain foreign matter or
has been previously used should not be
used.
Oil viscosity The engine oil viscosity or thickness
changes with temperature. Because of
this, it is important that the engine oil vis-
cosity be selected based on the tempera-
tures at which the vehicle will be oper-
ated before the next oil change. The rec-
ommended SAE viscosity number chart
shows the recommended oil viscosities
for the expected ambient temperatures.
Choosing an oil viscosity other than that
recommended could cause serious engine
damage. STI0367
Technical and consumer information
9-5
w 06.1.5/V35-D/V5.0
X

Selecting the correct oil filter Your new vehicle is equipped with a high-
quality genuine NISSAN oil filter. When re-
placing, use the genuine oil filter or its
equivalent for the reason described in
change intervals.
Change intervals The oil and oil filter change intervals for
your engine are based on the use of the
specified quality oils and filters. Oil and
filter other than the specified quality, or
oil and filter change intervals longer than
recommended could reduce engine life.
Damage to engines caused by improper
maintenance or use of incorrect oil and
filter quality and/or viscosity is not cov-
ered by the new INFINITI vehicle limited
warranties.
Your engine was filled with a high quality
engine oil when it was built. You do not
have to change the oil before the first rec-
ommended change interval. Oil and filter
change intervals depend upon how you
use your vehicle. Operation under the fol-
lowing conditions may require more fre-
quent oil and filter changes.
O repeated short distance driving at cold
outside temperatures O driving in dusty conditions
O extensive idling
O towing a trailer
O stop and go commuting
Refer to the ªINFINITI Service and Mainte-
nance Guideº for the maintenance sched-
ule.
RECOMMENDED SAE VISCOSITY
NUMBER
SAE 5W-30 viscosity oil is preferred for all
ambient temperatures. SAE 10W-30,
10W-40 viscosity oil may be used if the am-
bient temperature is above 0ÉF (þ18ÉC). TI1028-C
9-6 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

AIR CONDITIONING SYSTEM
REFRIGERANT AND LUBRICANT
RECOMMENDATIONS The air conditioning system in this INFINITI
vehicle must be charged with the refrig-
erant HFC-134a (R-134a) and the lubricant,
Nissan A/C System Oil Type S or the exact
equivalents.
CAUTIONThe use of any other refrigerant or lubricant
will cause severe damage to the air condi-
tioning system and will require the replace-
ment of all air conditioner system compo-
nents.
The refrigerant HFC-134a (R-134a) in your
INFINITI vehicle will not harm the earth's
ozone layer. Although this refrigerant
does not affect the earth's atmosphere,
certain governmental regulations require
the recovery and recycling of any refriger-
ant during automotive air conditioning
system service. An INFINITI dealer has the
trained technicians and equipment
needed to recover and recycle your air
conditioning system refrigerant. Contact an INFINITI dealer when servicing
your air conditioning system.
Technical and consumer information
9-7
w 06.1.4/V35-D/V5.0
X

ENGINE Model VQ35DE
Type Gasoline, 4-cycle
Cylinder arrangement 6-cylinder, V-slanted at 60É
Bore x Stroke in (mm) 3.760 x 3.205 (95.5 x 81.4)
Displacement cu in (cm 3
) 213.45 (3,498)
Firing order 1-2-3-4-5-6*
Idle speed rpm
See the emission control label on
the underside of the hood.Ignition timing (B.T.D.C.) degree/rpm
CO percentage at idle speed [No air] %
Spark plug Standard PLFR5A-11
Service option PLFR4A-11, PLFR6A-11
Spark plug gap (Normal) in (mm) 0.043 (1.1)
Camshaft operation Timing chain The spark ignition system of this vehicle
meets all requirements of the Canadian
Interference-Causing Equipment Regula-
tions. TI0001-A
SPECIFICATIONS
9-8 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

WHEELS AND TIRES
Road wheel Type Position Size Offset in (mm)
Sedan Aluminum Ð 17 x 7JJ 1.77 (45)
Ð 18 x 7-1/2JJ 1.77 (45)
Coupe Aluminum Front 17 x 7-1/2JJ 1.18 (30)
Rear 17 x 8JJ 1.30 (33)
Front 18 x 8JJ 1.18 (30)
Rear 18 x 8JJ 1.18 (30)
Front 19 x 8JJ 1.18 (30)
Rear 19 x 8-1/2JJ 1.30 (33)
Tire Type Position Size Pressure (Cold)
Sedan Conventional Ð P215/55R17 93V 210 kPa (30 psi)
Ð 235/45R18 94W 230 kPa (33 psi)
Spare Ð T145/80D17 420 kPa (60 psi)
P215/55R17 93V*1 210 kPa (30 psi)
Coupe Conventional Front P225/50R17 93V 210 kPa (30 psi)
Rear P235/50R17 95V 210 kPa (30 psi)
Front 225/45R18 91W 240 kPa (35 psi)
Rear 245/45R18 96W 240 kPa (35 psi)
Front 225/40R19 89Y 240 kPa (35 psi)
Rear 245/40R19 94Y 240 kPa (35 psi)
Spare Ð T145/80D17 420 kPa (60 psi)
*1: Option for USA, conventional for Canada (for models with tire size P215/55R17
93V) DIMENSIONS AND WEIGHTS Sedan Coupe
Overall length in (mm) 186.9 (4,747) 182.2 (4,628)
Overall width in (mm) 69.0 (1,753) 71.5 (1,815)
Overall height in (mm) 57.7 (1,467)*1
58.4 (1,484)*2 54.8 (1,393)
55.1 (1,399)*3
Front tread in (mm) 59.1 (1,500)*1
59.3 (1,505)*2 60.4 (1,535)
Rear tread in (mm) 59.3 (1,505) 60.6 (1,540)*4
60.8 (1,545)*5
Wheelbase in (mm) 112.2 (2,850) 112.2 (2,850)
Gross vehicle weight rating lb (kg)
See the F.M.V.S.S./C.M.V.S.S.
certification label on the driver's
side lock pillar.Gross axle weight rating
Front lb (kg)
Rear lb (kg)
*1: For 2WD models
*2: For AWD models
*3: For 18 in and 19 in road wheel models
*4: For models with road wheel size Ð 17 x 8JJ and 19 x 8-1/2JJ [offset 1.30 in (33
mm)]
*5: For models with road wheel size Ð 18 x 8JJ [offset 1.18 in (30 mm)]
Technical and consumer information
9-9
w 06.1.4/V35-D/V5.0
X

When planning to travel in another
country, you should first find out if the
fuel available is suitable for your vehicle's
engine.
Using fuel with too low an octane rating
may cause engine damage. All gasoline
vehicles must be operated with unleaded
engine gasoline. Therefore, avoid taking
your vehicle to areas where appropriate
fuel is not available.
When transferring the registration of your
vehicle to another country, state, province
or district, it may be necessary to modify
the vehicle to meet local laws and regula-
tions.
The laws and regulations for motor ve-
hicle emission control and safety stan-
dards vary according to the country,
state, province or district; therefore, ve-
hicle specifications may differ.
When any vehicle is to be taken into an-
other country, state, province or district
and registered, its modifications, trans-
portation, and registration are the respon-
sibility of the user. INFINITI is not respon-
sible for any inconvenience that may re-
sult. VEHICLE IDENTIFICATION NUMBER
(VIN) PLATE The vehicle identification number plate is
attached as shown. This number is the
identification for your vehicle and is used
in the vehicle registration.
VEHICLE IDENTIFICATION NUMBER
(Chassis number) The number is stamped as shown. STI0038 STI0302
WHEN TRAVELING OR REGISTERING YOUR
VEHICLE IN ANOTHER COUNTRY VEHICLE IDENTIFICATION
9-10 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

ENGINE SERIAL NUMBER The number is stamped on the engine as
shown.
F.M.V.S.S./C.M.V.S.S.
CERTIFICATION LABEL The Federal Motor Vehicle Safety Stan-
dards (F.M.V.S.S.) or Canadian Motor Ve-
hicle Safety Standards (C.M.V.S.S.) certifi-
cation label is affixed as shown. This
label contains valuable vehicle informa-
tion, such as: Gross Vehicle Weight Rat-
ings (GVWR), Gross Axle Weight Rating
(GAWR), month and year of manufacture,
Vehicle Identification Number (VIN), etc.
Review it carefully. STI0303C STI0186B
Sedan STI0330A
Coupe
Technical and consumer information
9-11
w 06.1.4/V35-D/V5.0
X

EMISSION CONTROL INFORMATION
LABEL The emission control information label is
attached as shown.
TIRE AND LOADING INFORMATION
LABEL The cold tire pressures are shown on the
Tire and Loading Information label affixed
to the driver side center pillar. STI0317 STI0368A
Sedan STI0331A
Coupe
9-12 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

AIR CONDITIONER SPECIFICATION
LABEL The air conditioner specification label is
affixed inside of the hood as shown. STI0306
STI0332INSTALLING FRONT LICENSE PLATE
Technical and consumer information
9-13
w 06.1.4/V35-D/V5.0
X

Use the following steps to mount the li-
cense plate:
Before mounting the license plate, con-
firm that the following parts are enclosed
in the vinyl bag.
O License plate bracket
O J-nut x 2
O Screw x 2
O Screw grommet x 2
1. Temporarily place the license plate
bracket and mark the pilot hole points
q A
using holes
q B
while aligning the
towing hook hole of the front bumper
fascia.
2. Remove the license plate bracket.
3. Carefully drill two pilot holes
q A
using
a 0.39 in (10 mm) drill bit at the
marked locations. (Be sure that the
drill only goes through the fascia, or
damage to the nut may occur.)
4. Insert grommets into the hole on the
fascia.
5. Insert a flat-blade screwdriver into the
grommet hole to turn part
q C
90 de-
grees. 6. Insert a J-nut into the license plate
bracket before placing the license
plate bracket on the fascia.
7. Install the license plate bracket with
screws.
8. Install the license plate with bolts that
are no longer than 0.55 in (14 mm).
WARNING O It is extremely dangerous to ride in
a cargo area inside of a vehicle. In
a collision, people riding in these
areas are more likely to be seri-
ously injured or killed.
O Do not allow people to ride in any
area of your vehicle that is not
equipped with seats and seat
belts.
O Be sure everyone in your vehicle is
in a seat and using a seat belt
properly.
TERMS It is important to familiarize yourself
with the following terms before loading
your vehicle:
O Curb Weight (actual weight of your
vehicle) - vehicle weight including:
standard and optional equipment,
fluids, emergency tools, and spare VEHICLE LOADING INFORMATION
