1. Firmly apply the parking brake.
2. Automatic transmission models:
Move the selector lever to the P (Park)
position.
Manual transmission models:
Place the shift lever in the R (Reverse)
position. When parking on an uphill
grade, place the shift lever in the 1
(Low gear) position.
3. To help prevent the vehicle from
rolling into the street when parked on
a sloping drive way, it is a good prac-
tice to turn the wheels as illustrated.
O HEADED DOWNHILL WITH CURB:
q 1
Turn the wheels into the curb and
move the vehicle forward until the
curb side wheel gently touches the
curb.
O HEADED UPHILL WITH CURB:
q 2
Turn the wheels away from the curb
and move the vehicle back until the
curb side wheel gently touches the
curb. O HEADED UPHILL OR DOWNHILL, NO
CURB:
q 3
Turn the wheels toward the side of the
road so the vehicle will move away
from the center of the road if it moves.
4. Turn the ignition switch to the LOCK
position and remove the key. The power assisted steering uses a hy-
draulic pump, driven by the engine, to as-
sist steering.
If the engine stops or the drive belt
breaks, you will still have control of the
vehicle. However, much greater steering
effort is needed, especially in sharp turns
or at low speeds.
WARNING If the engine is not running or is turned off
while driving, the power assist for the steer-
ing will not work. Steering will be much
harder to operate.POWER STEERING
Starting and driving
5-25
w 06.1.4/V35-D/V5.0
X

BRAKING PRECAUTIONS The brake system has two separate hy-
draulic circuits. If one circuit malfunc-
tions, you will still have braking ability at
two wheels.
Vacuum assisted brake
The brake booster aids braking by using
engine vacuum. If the engine stops, you
can stop the vehicle by depressing the
brake pedal. However, greater foot pres-
sure on the brake pedal will be required
to stop the vehicle and the stopping dis-
tance will be longer.
Wet brakes
When the vehicle is washed or driven
through water, the brakes may get wet.
As a result, your braking distance will be
longer and the vehicle may pull to one
side during braking.
To dry brakes, drive the vehicle at a safe
speed while lightly tapping the brake
pedal to heat-up the brakes. Do this until
the brakes return to normal. Avoid driving
the vehicle at high speeds until the
brakes function correctly.
Parking brake break-in
Break-in the parking brake shoes when-
ever the stopping effect of the parking brake is weakened or whenever the park-
ing brake shoes and/or drums/rotors are
replaced, in order to assure the best
braking performance.
This procedure is described in the vehicle
service manual and can be performed by
your INFINITI dealer.
Using the brakes
Avoid resting your foot on the brake pedal
while driving. This will cause overheating
of the brakes, increases wear on the
brakes and pads, and reduces gas
mileage.
To help save the brakes and to prevent
the brakes from overheating, reduce
speed and downshift to a lower gear be-
fore going down a slope or long grade.
Overheated brakes may reduce braking
performance and could result in loss of
vehicle control.
WARNING O While driving on a slippery surface, be
careful when braking, accelerating or
downshifting. Abrupt braking or accel- erating could cause the wheels to skid
and result in an accident.
O If the engine is not running or is turned
off while driving, the power assist for the
brakes will not work. Braking will be
harder.
ANTI-LOCK BRAKE SYSTEM (ABS) The anti-lock brake system (ABS) controls
the brakes so the wheels will not lock when
braking abruptly or when braking on slip-
pery surfaces. The system detects the rota-
tion speed at each wheel and varies the
brake fluid pressure to prevent each wheel
from locking and sliding. By preventing
wheel lockup, the system helps the driver
maintain steering control and helps to mini-
mize swerving and spinning on slippery sur-
faces.
Using the system Depress the brake pedal and hold it
down.BRAKE SYSTEM
5-26 Starting and driving
w 06.1.4/V35-D/V5.0
X

Stopping the vehicle 1. Safely move the vehicle off the road
away from traffic.
2. Turn on the hazard warning flashers.
3. Park on a level surface and apply the
parking brake. Shift the manual trans-
mission into the R (Reverse) position
(automatic transmission into the P
(Park) position).
4. Turn off the engine.
5. Raise the hood to warn other traffic,
and to signal professional road assis-
tance personnel that you need assis-
tance.
6. Have all passengers get out of the ve-
hicle and stand in a safe place, away
from traffic and clear of the vehicle.
WARNINGO Make sure the parking brake is securely
applied and the manual transmission is
shifted into R (Reverse), or the automatic
transmission into P (Park). O Never change tires when the vehicle is
on a slope, ice or slippery areas. This is
hazardous.
O Never change tires if oncoming traffic is
close to your vehicle. Wait for profes-
sional road assistance.
Blocking wheels Place suitable blocks
q 1
at both the front
and back of the wheel diagonally oppo-
site the flat tire to prevent the vehicle
from moving when it is jacked up.
WARNING Be sure to block the wheel as the vehicle
may move and result in personal injury. MCE0001A
In case of emergency
6-3
w 06.1.4/V35-D/V5.0
X

5. Securely store the flat tire and jacking
equipment in the vehicle.
6. Place the spare tire cover and the
trunk floor carpeting over the dam-
aged tire.
7. Close the trunk.
WARNINGO Always make sure that the spare tire and
jacking equipment are properly secured
after use. Such items can become dangerous projectiles in an accident or
sudden stop.
O The T-type spare tire and small size
spare tire are designed for emergency
use. See ªWheels and tiresº in the ª8.
Maintenance and do-it-yourselfº sec-
tion.
If needed, Roadside Assistance is avail-
able. Please see your Warranty Information
Booklet or Roadside Assistance I.D. Card
for the toll-free number to call (U.S.) or War-
ranty Information Booklet (Canada). To start your engine with a booster bat-
tery, the instructions and precautions
below must be followed.
WARNING O If done incorrectly, jump starting can
lead to a battery explosion, resulting in
severe injury or death. It could also dam-
age your vehicle.
O Explosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.
O Do not allow battery fluid to come into
contact with eyes, skin, clothing or
painted surfaces. Battery fluid is a corro-
sive sulfuric acid solution which can
cause severe burns. If the fluid should
come into contact with anything, imme-
diately flush the contacted area with wa-
ter.
O Keep battery out of the reach of children.SCE0384B
Sedan SCE0425A
Coupe JUMP STARTING
6-8 In case of emergency
w 06.1.4/V35-D/V5.0
X

O The booster battery must be rated at 12
volts. Use of an improperly rated battery
can damage your vehicle.
O Whenever working on or near a battery,
always wear suitable eye protectors (for
example, goggles or industrial safety
spectacles) and remove rings, metal
bands, or any other jewelry. Do not lean
over the battery when jump starting.
O Do not attempt to jump start a frozen
battery. It could explode and cause se-
rious injury.
If needed Roadside Assistance is available.
Please see your Warranty Information
Booklet or Roadside Assistance I.D. Card
for the toll-free number to call (U.S.) or War-
ranty Information Booklet (Canada).
WARNING Always follow the instructions below. Failure
to do so could result in damage to the charg-
ing system and cause personal injury.
1. If the booster battery is in another ve-
hicle
q B
, position the two vehicles
q A
and
q B
to bring their batteries into
close proximity to each other.
Do not allow the two vehicles to touch. 2. Apply parking brake. Move the shift
lever to the N (Neutral) position (On
automatic transmission models, move
the selector lever to the P (Park) posi-
tion). Switch off all unnecessary elec-
trical systems (light, heater, air condi-
tioner, etc.).
3. Remove vent caps on the battery (if so
equipped). Cover the battery with an
old cloth to reduce explosion hazard.
4. Connect jumper cables in the se-
quence as illustrated. SCE0539A
In case of emergency
6-9
w 06.1.4/V35-D/V5.0
X

WARNINGO Do not continue to drive if your vehicle
overheats. Doing so could cause engine
damage or a vehicle fire.
O To avoid the danger of being scalded,
never remove the radiator cap while the
engine is still hot. When the radiator cap
is removed, pressurized hot water will
spurt out, possibly causing serious in-
jury.
O Do not open the hood if steam is coming
out.
If your vehicle is overheating (indicated
by an extremely high temperature gauge
reading), or if you feel a lack of engine
power, detect abnormal noise, etc., take
the following steps:
1. Move the vehicle safely off the road,
apply the parking brake and move the
shift lever to the N (Neutral) position
(automatic transmission to the P
(Park) position).
Do not stop the engine. 2. Turn off the air conditioner. Open all
the windows, and move the tempera-
ture control to maximum hot and the
fan control to high speed.
3. If engine overheating is caused by
climbing a long hill on a hot day, run
the engine at a fast idle (approximately
1,500 rpm) until the temperature gauge
indication returns to normal.
4. Get out of the vehicle. Look and listen
for steam or coolant escaping from the
radiator before opening the hood. (If
steam or coolant is escaping, turn off
the engine.) Do not open the hood fur-
ther until no steam or coolant can be
seen.
5. Open the engine hood.
WARNING If steam or water is coming from the engine,
stand clear to prevent getting burned.
6. Visually check if the cooling fan is run-
ning. The radiator hoses and radiator
should not leak water. If coolant is
leaking or the cooling fan does not
run, stop the engine. WARNING O Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or to get caught in, the engine
belts or the engine cooling fan.
O The engine cooling fan can start at any
time when the coolant temperature is
high.
7. After the engine cools down, check
the coolant level in the reservoir tank
with the engine running. Add coolant
to the reservoir tank if necessary.
Have your vehicle repaired at an
INFINITI dealer.
If needed, Roadside Assistance is avail-
able. Please see your Warranty Information
Booklet or Roadside Assistance I.D. Card
for the toll-free number to call (U.S.) or War-
ranty Information Booklet (Canada).IF YOUR VEHICLE OVERHEATS
In case of emergency
6-11
w 06.1.4/V35-D/V5.0
X

In order to maintain the appearance of
your vehicle, it is important to care for it
properly.
To protect the paint surfaces, please
wash your vehicle as soon as you can.
O After a rainfall to prevent possible
damage from acid rain.
O After driving in coastal areas to pre-
vent possible damage from sea salt.
O When foreign objects, such as soot,
bird droppings, tree sap, metal par-
ticles, or insects get on the paint sur-
faces.
O When dust or mud builds up on the
paint surfaces.
Whenever possible, store or park your ve-
hicle inside garage or in covered area.
When it is necessary to park outside, park
in a shady area or protect the vehicle with
a body cover.
Be careful not to scratch the paint surface
when putting on or removing the body
cover.
WASHING Wash dirt off the vehicle with a wet
sponge and plenty of water. Clean the ve- hicle thoroughly using a mild soap, spe-
cial vehicle soap or general purpose dish-
washing liquid mixed with clean, luke-
warm (never hot) water.
CAUTION O Do not use strong household soap,
strong chemical detergents, gasoline or
solvents.
O Do not wash the vehicle in direct sun-
light or while the vehicle body is hot, as
the surface may become water-spotted.
O Avoid using tight-napped or rough
cloths, such as washing mitts. Care must
be taken when removing caked-on dirt or
other foreign substances so the paint
surface is not scratched or damaged.
Rinse the vehicle again with plenty of
clean water.
Inside flanges, seams and folds on the
doors, hatches and hood are particularly
vulnerable to the effects of road salt.
Therefore, these areas must be regularly
cleaned. Make sure that the drain holes
in the lower edge of the door are open. Spray water under the body and in the
wheel wells to loosen the dirt and wash
away road salt.
Avoid leaving water spots on the paint
surface by using a damp chamois to dry
the vehicle.
WAXING Regular waxing protects the paint surface
and helps retain new vehicle appearance.
Polishing is recommended to remove
built-up wax residue and to avoid a
weathered appearance before re-applying
wax.
An INFINITI dealer can assist you in
choosing the proper product.
O Wax your vehicle only after a thorough
washing. Follow the instructions sup-
plied with the wax.
O Do not use a wax containing any abra-
sives, cutting compounds or cleaners
that may damage the vehicle finish.
Machine compounding or aggressive pol-
ishing on a base coat/clear coat paint fin-
ish may dull the finish or leave swirl
marks.CLEANING EXTERIOR
7-2 Appearance and care
w 06.1.4/V35-D/V5.0
X

P
Parking
Brake check .............................................. 8-23
Parking brake check .................................. 5-19
Parking brake operation ............................ 5-19
Parking on hills ......................................... 5-19
Parking/parking on hills .................................. 5-24
Personal lights................................................. 2-45
Phone
Bluetooth Hands-Free Phone System ...... 4-30
Car phone or CB radio .............................. 4-29
Power
Front seat adjustment ................................. 1-2
Power door lock .......................................... 3-3
Power outlet ............................................. 2-29
Power steering fluid .................................. 8-13
Power steering system .............................. 5-25
Power windows ......................................... 2-39
Precautions
All-wheel drive (AWD) driving safety............ 5-6
Audio operation......................................... 4-16
Braking precautions .................................. 5-26
Child restraints .......................................... 1-18
Cruise control ........................................... 5-20
Maintenance ............................................... 8-5
Seat belt usage ........................................... 1-9
Supplemental restraint system .................. 1-36
When starting and driving ........................... 5-2
Push starting ................................................... 6-10 R
Radio
Car phone or CB radio .............................. 4-29
Steering wheel switch for audio control .... 4-28
Readiness for inspection/maintenance (I/M)
test (US only)................................................... 9-25
Rear active steer (RAS) system......................... 5-29
Rear armrest pocket......................................... 2-37
Rear door lock, Child safety rear door lock ........ 3-5
Rear power point ............................................. 2-29
Rear seat adjustment ......................................... 1-5
Rear window and outside mirror defroster
switch.............................................................. 2-20
Recorders, Event data ...................................... 9-26
Registering your vehicle in another country ..... 9-10
Remote keyless entry system
Except Intelligent Key system ...................... 3-5
For Intelligent Key system ......................... 3-20
Reporting safety defects (US only) ................... 9-24
Roadside assistance program ............................ 6-2
Rollover ............................................................. 5-5
Room light....................................................... 2-44
S
Safety
Child seat belts.......................................... 1-12
Reporting safety defects (US only) ............ 9-24
Towing safety ............................................ 9-19
Seat
Belt warning light........................................ 1-9
Belt warning light and chime..................... 2-13 Seat adjustment
Front power seat adjustment ....................... 1-2
Rear seat adjustment................................... 1-5
Seat belt(s)
Child safety................................................ 1-12
Infants ....................................................... 1-12
Injured persons .......................................... 1-13
Larger children ........................................... 1-13
Precautions on seat belt usage ................... 1-9
Pregnant women ........................................ 1-13
Pre-tensioner seat belt system .................. 1-50
Seat belt cleaning ....................................... 7-5
Seat belt extenders .................................... 1-17
Seat belt maintenance ............................... 1-17
Seat belts.................................................... 1-9
Seat belt warning light .............................. 2-13
Shoulder belt guide ................................... 1-17
Shoulder belt height adjustment................ 1-16
Small children............................................ 1-12
Three-point type with retractor ................... 1-13
Seat(s)
Driver-side memory ................................... 3-34
Heated seats............................................. 2-26
Seats........................................................... 1-2
Secondary trunk lid release ............................. 3-27
Security system, Vehicle security system ......... 2-17
Security systems (INFINITI Vehicle Immobilizer
System), Engine start ....................................... 2-18
Security systems (See vehicle security
system) ............................................................ 2-17
Selector lever, Shift lock release ...................... 5-15
Servicing air conditioner.......................... 4-10, 4-14
Shift lock release, Transmission ....................... 5-15
10-5
w 06.1.4/V35-D/V5.0
X
