WARNINGDo not pump the brake pedal. Doing so may
result in increased stopping distances.
Normal operation The ABS will not operate at speeds below
3 to 6 MPH (5 to 10 km/h) to stop the ve-
hicle. (The speeds will vary according to
road conditions.) When the anti-lock
system senses that one or more wheels
are close to locking up, the actuator
(under the hood) rapidly applies and re-
leases hydraulic pressure (like pumping
the brakes very quickly). While the actua-
tor is working, you may feel a pulsation in
the brake pedal and hear a noise or vibra-
tion from the actuator under the hood.
This is normal and indicates that the ABS
is working properly. However, the ABS op-
eration may indicate that road conditions
are hazardous and extra care is required
while driving.
Self-test feature The anti-lock brake system consists of
electronic sensors, electric pumps, and
hydraulic solenoids controlled by a com- puter. The computer has a built-in diag-
nostic feature that tests the system each
time you start the engine and move the
vehicle at a low speed in forward or re-
verse. When the self-test occurs, you may
hear a clunk noise and/or feel a pulsation
in the brake pedal. This is normal and is
not an indication of any malfunction. If
the computer senses any malfunction, it
switches the ABS off and turns on the
ABS warning light in the instrument
panel. The brake system operates nor-
mally, but without anti-lock assistance.
If the light comes on during the self-test
or while driving, take the vehicle to an
INFINITI dealer for repair.
WARNING The anti-lock brake system is a sophisticated
device, but it cannot prevent accidents re-
sulting from careless or dangerous driving
techniques. It can help maintain vehicle con-
trol during braking on slippery surfaces, but
remember that the stopping distance on slip-
pery surfaces will be longer than on normal
surfaces even with the anti-lock brake system. Stopping distances may also be
longer on rough, gravel or snow covered
roads, or if you are using tire chains. Always
maintain a safe distance from the vehicle in
front of you. Ultimately, the responsibility
for safety of self and others rests in the
hands of the driver.
Tire type and condition of tires may also af-
fect braking effectiveness.
O When replacing tires, install the speci-
fied size of tires to the front and rear.
O When installing a spare tire, make sure it
is the proper size and type as specified
on the Tire and Loading Information
label. See ªVehicle identificationº in the
ª9. Technical and consumer informa-
tionº section for the Tire and Loading In-
formation label location.
Starting and driving
5-27
w 06.1.4/V35-D/V5.0
X

O If brake related parts such as brake
pads, rotors and calipers are not stan-
dard equipment or are extremely dete-
riorated, the ªVDC OFFº indicator or
ªSLIPº indicator or both indicator lights
may illuminate.
O When driving on extremely inclined sur-
faces such as higher banked corners, the
Vehicle Dynamic Control system may not
operate properly and the ªVDC OFFº indi-
cator or ªSLIPº indicator or both indi-
cator lights may illuminate. Do not drive
on these types of roads.
O When driving on an unstable surface
such as a turntable, ferry, elevator or
ramp, the ªVDC OFFº indicator or ªSLIPº
indicator or both indicator lights may il-
luminate. This is not a malfunction. Re-
start the engine after driving onto a
stable surface.
O If wheels or tires other than those rec-
ommended are used, the VDC system
may not operate properly and the ªVDC
OFFº indicator or ªSLIPº indicator or
both indicator lights may illuminate. O The VDC system is not a substitute for
winter tires or tire chains on a snow cov-
ered road. The Rear Active Steer (RAS) system is an
electronically controlled four-wheel
steering system.
The angle of the rear wheels are adjusted
by the RAS system, depending on the ve-
hicle speed and steering angle. The rear
wheels are designed to turn momentarily
in the opposite direction and then change
to the same direction as the front wheels.
At low speeds, the rear wheels will not
turn and the system functions as a two-
wheel steering system.
If a malfunction occurs in the system, the
RAS function will stop but the ordinary
two-wheel steering system will operate
normally. The ªRASº warning light will il-
luminate.
If the light illuminates while you are driv-
ing, contact an INFINITI dealer for repair.REAR ACTIVE STEER (RAS) SYSTEM (if so
equipped)
Starting and driving
5-29
w 06.1.4/V35-D/V5.0
X

WARNINGThe RAS system, although a sophisticated
device, cannot prevent accidents resulting
from careless or dangerous driving tech-
niques. Ultimately the responsibility for
safety of self and others rests in the hands of
the driver. Therefore only through attentive
and careful driving methods can the RAS
system be fully appreciated and safety as-
sured. FREEING A FROZEN DOOR LOCK To prevent a door lock from freezing, apply
de-icer or glycerin to it through the key
hole. If the lock becomes frozen, heat the
key before inserting it into the key hole.
ANTI-FREEZE In the winter when it is anticipated that the
temperature will drop below 32ÉF (0ÉC),
check antifreeze to assure proper winter
protection. For additional information, see
ªEngine cooling systemº in the ª8. Mainte-
nance and do-it-yourselfº section.
BATTERY If the battery is not fully charged during
extremely cold weather conditions, the
battery fluid may freeze and damage the
battery. To maintain maximum efficiency,
the battery should be checked regularly.
For additional information, see ªBatteryº
in the ª8. Maintenance and do-it-yourselfº
section.
DRAINING OF COOLANT WATER If the vehicle is to be left outside without
antifreeze, drain the cooling system by
opening the drain plug located under the
radiator. Refill before operating the ve-
hicle. See ªEngine cooling systemº in the ª8. Maintenance and do-it-yourselfº sec-
tion for changing engine coolant.
TIRE EQUIPMENT 1. SUMMER tires are of a tread design to
provide superior performance on dry
pavement. However, the performance
of these tires will be substantially re-
duced in snowy and icy conditions. If
you operate your vehicle on snowy or
icy roads, INFINITI recommends the
use of MUD & SNOW or ALL SEASON
tires on all four wheels. Please consult
an INFINITI dealer for the tire type,
size, speed rating and availability in-
formation.
2. For additional traction on icy roads,
studded tires may be used. However,
some provinces and states prohibit
their use. Check local, state and pro-
vincial laws before installing studded
tires.
Skid and traction capabilities of
studded snow tires, on wet or dry sur-
faces, may be poorer than that of non-
studded snow tires.
3. Tire chains may be used if desired.
Make sure they are of proper size for
the tires on your vehicle and are in-COLD WEATHER DRIVING
5-30 Starting and driving
w 06.1.4/V35-D/V5.0
X

stalled according to the chain manu-
facturer's suggestions. However, some
provinces and states prohibit their
use. Check local state and provincial
laws before installing tire chains. Use
only SAE Class S chains. Class ªSº
chains are used on vehicles with re-
stricted tire to vehicle clearance. Ve-
hicles that can use Class ªSº chains
are designed to meet the SAE stan-
dard minimum clearances between the
tire and the closest vehicle suspen-
sion or body component required to
accommodate the use of a winter trac-
tion device (tire chains or cables). The
minimum clearances are determined
using the factory equipped tire size.
Other types may damage your vehicle.
Use chain tensioners when recom-
mended by the tire chain manufac-
turer to ensure a tight fit. Loose end
links of the tire chain must be secured
or removed to prevent the possibility
of damage to the fenders or under-
body. If possible, avoid fully loading
your vehicle when using tire chains. In
addition, drive at a reduced speed.
Otherwise, your vehicle may be dam-
aged and/or vehicle handling and per-
formance may be adversely affected. O Never install the tire chains on TEMPO-
RARY USE ONLY spare tires.
O Do not use the tire chains on dry roads.
O The tire chains must be installed only
on the rear wheels and not on the front
wheels.
Do not drive with tire chains on paved
roads which are clear of snow. Driving
with chains in such conditions can
cause damage to the various mecha-
nisms of the vehicle due to some over-
stress.
4. For all-wheel drive (AWD):
If you install snow tires, they must
also be the same size, brand, con-
struction and tread pattern on all four
wheels.
SPECIAL WINTER EQUIPMENT It is recommended that the following items
be carried in the vehicle during winter:
O a scraper and stiff-bristled brush to re-
move ice and snow from the windows
and wiper blades.
O a sturdy, flat board to be placed under
the jack to give it firm support. O a shovel to dig the vehicle out of
snow-drifts.
O extra window washer fluid to refill the
reservoir tank.
DRIVING ON SNOW OR ICE
WARNING O Wet ice (32ÉF, 0ÉC and freezing rain),
very cold snow or ice can be slick and
very hard to drive on. The vehicle will
have much less traction or ªgripº under
these conditions. Try to avoid driving on
wet ice until the road is salted or sanded.
O Whatever the condition, drive with cau-
tion. Accelerate and slow down with
care. If accelerating or downshifting too
fast, the drive wheels will lose even
more traction.
O Allow more stopping distance under
these conditions. Braking should be
started sooner than on dry pavement.
Starting and driving
5-31
w 06.1.4/V35-D/V5.0
X

VEHICLE RECOVERY (Freeing a
stuck vehicle) After removing the front license plate (or
the bumper cover), securely install the re-
covery hook
q 1
. (Located with jacking
tools.)
Reinstall the license plate on the lower fit-
ting point. WARNING O Stand clear of a stuck vehicle.
O Do not spin your tires at high speed. This
could cause them to explode and result
in serious injury. Parts of your vehicle
could also overheat and be damaged.
CAUTION O Tow chains or cables must be attached
only to the vehicle recovery hooks or
main structural members of the vehicle.
Otherwise, the vehicle body will be dam-
aged.
O Do not use the vehicle tie downs to free a
vehicle stuck in sand, snow, mud, etc.
Never tow a vehicle using the vehicle tie
downs or recovery hooks.
O Always pull the cable straight out from
the front of the vehicle. Never pull the ve-
hicle at an angle. O Pulling devices should be routed so they
do not touch any part of the suspension,
steering, brake or cooling systems.
O Pulling devices such as ropes or canvas
straps are not recommended for use in
vehicle towing or recovery.
If your vehicle is stuck in sand, snow,
mud, etc., use the following procedure:
1. Turn off the Vehicle Dynamic Control
(VDC) system.
2. Make sure the area in front and be-
hind the vehicle is clear of obstruc-
tions.
3. Turn the steering wheel right and left
to clear an area around the front tires.
4. Slowly rock the vehicle forward and
backward.
O Shift back and forth between R (re-
verse) and D (drive) (automatic trans-
mission models) or 1st (low) and R (re-
verse) (manual transmission models).
O Apply the accelerator as little as pos-
sible to maintain the rocking motion.SCE0524
In case of emergency
6-15
w 06.1.4/V35-D/V5.0
X

mends the use of SNOW or ALL SEASON
tires on all four wheels.
Snow tires If snow tires are needed, it is necessary
to select tires equivalent in size and load
rating to the original equipment tires. If
you do not, it can adversely affect the
safety and handling of your vehicle.
Generally, snow tires will have lower
speed ratings than factory equipped tires
and may not match the potential
maximum vehicle speed. Never exceed
the maximum speed rating of the tire.
If you operate your vehicle in snowy or icy
conditions, INFINITI recommends the use
of snow or all season tires on all four
wheels.
For additional traction on icy roads, stud-
ded tires may be used. However, some
provinces and states prohibit their use.
Check local, state and provincial laws be-
fore installing studded tires. Skid and
traction capabilities of studded snow
tires, on wet or dry surfaces, may be
poorer than that of non-studded snow
tires. All-wheel drive (AWD) models
CAUTION O Always use tires of the same type, size,
brand, construction (bias, bias-belted or
radial), and tread pattern on all four
wheels. Failure to do so may result in a
circumference difference between tires
on the front and rear axles which will
cause excessive tire wear and may
damage the transmission, transfer case
and differential gears.
O ONLY use spare tires specified for the
AWD model.
If excessive tire wear is found, it is recom-
mended that all four tires be replaced
with tires of the same size, brand, con-
struction and tread pattern. The tire pres-
sure and wheel alignment should also be
checked and corrected as necessary. Con-
tact an INFINITI dealer.
Tire chains must be installed only on the
rear wheels and not on the front wheels.
Do not drive with tire chains on paved
roads which are clear of snow. Driving with chains in such conditions can cause
damage to the various mechanisms of the
vehicle due to some overstress.
TIRE CHAINS Use of tire chains may be prohibited ac-
cording to location. Check the local laws
before installing tire chains. When install-
ing tire chains, make sure they are the
proper size for the tires on your vehicle
and are installed according to the chain
manufacturer's suggestions. Use only SAE
class ªSº chains. Class ªSº chains are
used on vehicles with restricted tire to ve-
hicle clearance. Vehicles that can use
Class ªSº chains are designed to meet
the minimum clearances between the tire
and the closest vehicle suspension or
body component required to accommo-
date the use of a winter traction device
(tire chains or cables). The minimum
clearances are determined using the fac-
tory equipped tires. Other types may
damage your vehicle. Use chain ten-
sioners when recommended by the tire
chain manufacturer to ensure a tight fit.
Loose end links of the tire chain must be
secured or removed to prevent the possi-
bility of whipping action damage to the
fenders or underbody. If possible, avoid
fully loading your vehicle when using tire
chains. In addition, drive at a reduced
8-44 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

O Do not use abrasive cleaners when
washing the wheels.
O Inspect wheel rims regularly for dents or
corrosion. Such damage may cause loss
of pressure or poor seal at the tire bead.
O INFINITI recommends that the road
wheels be waxed to protect against
road salt in areas where it is used
during winter.
Spare tire (TEMPORARY USE ONLY
spare tire (T-type)) Observe the following precautions if the
T-type spare tire must be used, otherwise
your vehicle could be damaged or in-
volved in an accident.
CAUTIONO The T-type spare tire should be used only
for an emergency. It should be replaced by
a standard tire at the first opportunity.
O Drive carefully while the T-type spare tire
is installed.
Avoid sharp turns and abrupt braking
while driving. O Periodically check the T-type spare tire
inflation pressure, and always keep it at
60 psi (420 kPa, 4.2 bar).
O With the T-type spare tire installed, do
not drive your vehicle at speeds faster
than 50 MPH (80 km/h).
O When driving on roads covered with
snow or ice, the T-type spare tire should
be used on the front wheel and the origi-
nal tire used on the rear wheels (drive
wheels). Use tire chains only on the rear
two original tires (Sedan).
O
Tire tread of the T-type spare tire will wear
at a faster rate than the original tire. Re-
place the T-type spare tire as soon as the
tread wear indicators appear.
O Do not use the T-type spare tire on other
vehicles.
O Do not use more than one T-type spare
tire at the same time.
O Do not tow a trailer while the T-type
spare tire is installed. CAUTION O Do not use tire chains on a T-type spare
tire. Tire chains will not fit properly on
the T-type spare tire and may cause
damage to the vehicle.
O Because the T-type spare tire is smaller
than the original tire, ground clearance
is reduced. To avoid damage to the ve-
hicle do not drive over obstacles. Also do
not drive the vehicle through an auto-
matic car wash since it may get caught.
8-48 Maintenance and do-it-yourself
w 06.1.5/V35-D/V5.0
X

Shifting
Automatic transmission ...................... 5-6, 5-12
Manual transmission .......................... 5-7, 5-16
Shoulder belt guide .......................................... 1-17
Shoulder belt height adjustment ...................... 1-16
Side air bag system (See supplemental side
air bag and curtain side-impact air bag
systems) .......................................................... 1-48
SNOW mode switch ......................................... 2-27
Spark plugs ..................................................... 8-19
Speedometer ..................................................... 2-3
Starting
Before starting the engine ......................... 5-10
Jump starting .............................................. 6-8
Precautions when starting and driving ........ 5-2
Push starting............................................. 6-10
Starting the engine .................................... 5-11
Status light, Front passenger air bag ............... 1-44
Steering
Power steering fluid .................................. 8-13
Power steering system .............................. 5-25
Rear active steer (RAS) system .................. 5-29
Steering wheel switch for audio
controls .................................................... 4-28
Tilting steering wheel................................ 3-30
Storage ............................................................ 2-31
Stowing golf bags............................................ 2-39
Sun shade ....................................................... 2-42
Sun visors ....................................................... 3-32
Sunglasses holder ........................................... 2-32
Sunroof ........................................................... 2-42
Automatic sunroof..................................... 2-42
Supplemental air bag warning labels ................ 1-51
Supplemental air bag warning light.......... 1-51, 2-14 Supplemental restraint system ......................... 1-36
Precautions on supplemental restraint
system ...................................................... 1-36
Supplemental side and curtain side-impact
air bag systems ............................................... 1-48
Switch
Autolight switch ........................................ 2-22
Fog light switch......................................... 2-25
Hazard warning flasher switch .................. 2-25
Headlight switch........................................ 2-21
Ignition switch (except Intelligent Key
system) ....................................................... 5-6
Ignition switch automatic transmission
models ............................................... 5-6, 5-12
Ignition switch manual transmission
models ............................................... 5-7, 5-16
Power door lock switch ............................... 3-4
Rear window and outside mirror defroster
switch ....................................................... 2-20
Steering wheel switch for audio control .... 4-28
Turn signal switch..................................... 2-24
Vehicle Dynamic Control (VDC) off
switch ....................................................... 2-28
T
Tachometer........................................................ 2-4
Temperature gauge, Engine coolant
temperature gauge ............................................ 2-4
Theft (INFINITI Vehicle Immobilizer System),
Engine start ..................................................... 2-18
Three way catalyst ............................................. 5-3
Tilting steering wheel ...................................... 3-30 Tire
Flat tire ....................................................... 6-2
Pressure, Low tire pressure warning
light .......................................................... 2-12
Tire pressure monitoring system (TPMS) ..... 5-3
Uniform tire quality grading ...................... 9-23
Tires
Spare tire ................................................. 8-48
Tire and Loading Information label ............ 9-12
Tire chains ................................................ 8-44
Tire dressing ............................................... 7-3
Tire pressure............................................. 8-37
Tire pressure monitoring system
(TPMS) ................................................. 5-3, 6-2
Tire rotation .............................................. 8-45
Types of tires ............................................ 8-43
Wheel/tire size ........................................... 9-9
Wheels and tires ....................................... 8-37
Top tether strap child restraints ....................... 1-26
Towing
Flat towing ................................................ 9-22
Tow truck towing ....................................... 6-12
Towing a trailer ......................................... 9-18
Towing load/specification chart................. 9-18
Towing safety ............................................ 9-19
TPMS, Tire pressure monitoring system ............. 5-3
Trailer towing ................................................... 9-18
Transceiver, HomeLink Universal
Transceiver ...................................................... 2-46
Transmission
Automatic transmission fluid (ATF)............. 8-13
Driving with automatic transmission ... 5-6, 5-12
Driving with manual transmission ....... 5-7, 5-16
Transmission selector lever lock release .... 5-15
10-6
w 06.1.4/V35-D/V5.0
X
