NOTE:
The approach warning chime may sound and the
system display may blink when the ICC sensor
detects some reflectors
 A
which are fitted on
vehicles in other lanes or on the side of the road.
This may cause the ICC system to decelerate or
accelerate the vehicle. The ICC sensor may de-
tect these reflectors when the vehicle is driven
on winding roads, hilly roads or when entering
or exiting a curve. The ICC sensor may also de-
tect reflectors on narrow roads or in road con-
struction zones. In these cases you will have to
manually control the proper distance ahead of
your vehicle. Also, the sensor sensitivity can be affected by
vehicle operation (steering maneuver or driving
position in the lane) or traffic or vehicle condi-
tion (for example, if a vehicle is being driven
with some damage).
Automatic cancellation A chime sounds under the following conditions
and the control is automatically canceled.
● When the vehicle speed falls below approxi-
mately 20 MPH (32 km/h)
● When the selector lever is not in the D
(Drive), DS (Drive Sport) or manual shift
mode
● When the windshield wipers are operated at
low speed (LO) or high speed (HI)
● When the SNOW mode switch is turned on
● When the VDC is turned off
● When the VDC operates
Warning light and display Condition A :
The chime sounds and the Intelligent Cruise
Control system is canceled automatically in the
conditions described below. Part of the system
display will come on or blink, making it impos-
sible to set.
● When the VDC is turned off
● When the ABS or VDC (including the traction
control system) operates
● When a tire slips
● When the SNOW mode switch is turned on
● When strong light (sunlight, etc.) is directly
shining on the front of the vehicleSSD0284A SSD0614
5-36 Starting and driving
 —
—
04/29/10—pattie


Sensor maintenance The sensor for the ICC system
 A
is located
below the front bumper.
To keep the ICC system operating properly, be
sure to observe the following:
● Always keep the sensor clean. Wipe with a
soft cloth carefully so as not to damage the
sensor.
● Do not strike or damage the areas around
the sensor. Do not touch or remove the
screw located on the sensor. Doing so could cause failure or malfunction. If the sensor is
damaged due to an accident, contact an
INFINITI retailer.
● Do not attach a sticker (including transpar-
ent material) or install an accessory near the
sensor. This could cause failure or malfunc-
tion.
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE This mode allows driving at a speed between 25
to 89 MPH (40 to 144 km/h) without keeping
your foot on the accelerator pedal.
WARNING● In the conventional (fixed speed) cruise con-
trol mode, a warning chime does not sound
to warn you if you are too close to the vehicle
ahead, as neither the presence of the vehicle
ahead nor the vehicle-to-vehicle distance is
detected.
● Pay special attention to the distance be-
tween your vehicle and the vehicle ahead of
you or a collision could occur.
● Always confirm the setting in the Intelligent
Cruise Control system display.Sedan SSD0926
Coupe — Type A SSD0662 Coupe — Type B SSD0663
5-38 Starting and driving
 —
—
04/29/10—pattie


● Do not use the conventional (fixed speed)
cruise control mode when driving under the
following conditions:
– when it is not possible to keep the vehicle
at a set speed
– in heavy traffic or in traffic that varies in
speed
– on winding or hilly roads
– on slippery roads (rain, snow, ice, etc.)
– in very windy areas
● Doing so could cause a loss of vehicle control
and result in an accident.
Conventional (fixed speed) cruise
control switch 1) RESUME/ACCELERATE switch:
Resumes set speed or increases speed
incrementally.
2) SET/COAST switch:
Sets the desired cruise speed, reduces
speed incrementally.
3) CANCEL switch:
Deactivates the system without erasing
the set speed.
4) MAIN switch:
Master switch to activate the system. Conventional (fixed speed) cruise
control mode display and indicators The display is located between the speedom-
eter and tachometer.
1) MAIN switch indicator:
Indicates that the MAIN switch is ON.
2) Cruise set switch indicator:
Displays while the vehicle speed is con-
trolled by the conventional (fixed speed)
cruise control mode of the ICC system.
3) Cruise system warning light:
Comes on if there is a malfunction in the
cruise control system. SSD0617 SSD0618
Starting and driving
5-39
 —
—
04/29/10—pattie


Operating conventional (fixed speed)
cruise control mode To turn on the conventional (fixed speed) cruise
control mode, push and hold the MAIN switch
 A
for longer than about 1.5 seconds.
When pushing the MAIN switch on, the Intelli-
gent Cruise Control system display and the
CRUISE indicator are displayed on the dot ma-
trix crystal display. After you hold the MAIN
switch on for longer than about 1.5 seconds, the
Intelligent Cruise Control system display goes
out. The CRUISE indicator stays lit. You can now
set your desired cruising speed. Pushing the
MAIN switch again will turn the system com-
pletely off. When the ignition switch is pushed to the OFF
position, the system is also automatically
turned off. To use the Intelligent Cruise Control
again, quickly push and release the MAIN
switch (vehicle-to-vehicle distance control
mode) or push and hold it (conventional cruise
control mode) again to turn it on.
CAUTIONTo avoid accidentally engaging cruise control,
make sure to turn the MAIN switch off when not
using the Intelligent Cruise Control system.
To set cruising speed, accelerate your vehicle to
the desired speed, push the SET/COAST switch
and release it. (The SET indicator will come on in
the display.) Take your foot off the accelerator
pedal. Your vehicle will maintain the set speed.
● To pass another vehicle, depress the accel-
erator pedal. When you release the pedal,
the vehicle will return to the previously set
speed.
● The vehicle may not maintain the set speed
when going up or down steep hills. If this
happens, manually maintain vehicle speed.
To cancel the preset speed, use any of the
following methods:
a) Push the CANCEL button. The SET indica-
tor will go out.SSD0619 SSD0620
5-40 Starting and driving
 —
—
04/29/10—pattie


WARNING● The sonar system is a convenience but it is
not a substitute for proper parking. Always
look around and check that it is safe to do so
before parking. Always move slowly.
● Read and understand the limitations of the
sonar system as contained in this section.
Inclement weather may affect the function of
the sonar system; this may include reduced
performance or a false activation.
● This system is not designed to prevent con-
tact with small or moving objects. ● The system is designed as an aid to the
driver in detecting large stationary objects
to help avoid damaging the vehicle. The sys-
tem will not detect small objects below the
bumper, and may not detect objects close to
the bumper or on the ground.
● If your vehicle sustains damage to the
bumper fascia, leaving it misaligned or bent,
the sensing zone may be altered causing
inaccurate measurement of obstacles or
false alarms. CAUTIONKeep the interior of the vehicle as quiet as pos-
sible to hear the tone clearly.
The sonar system sounds a tone to warn the
driver of obstacles near the bumper. When the
“Sonar Display” key is ON, the sonar indicator
will also appear in the center display. (See
“SONAR INDICATOR” later in this section.) The
system detects rear obstacles when the selector
lever is in the “R” (Reverse) position.
The system may not detect objects at speeds
above 6 MPH (10 km/h) and may not detect
certain angular or moving objects.
The sonar system detects obstacles up to 3.9
feet (1.2 m) from the bumper with a decreased
coverage area at the outer corners of the
bumper. Refer to the illustration for approxi-
mate zone coverage areas. As you move closer
to the obstacle, the rate of the tone increases.
When the obstacle is less than 11.8 in (30 cm)
away, the tone will sound continuously.
Keep the corner/center sonar (located on the
bumper fascia) free from snow, ice and large
accumulations of dirt (do not clean the sonar
with sharp objects). If the sonar is covered, it
will affect the accuracy of the sonar system. SSD0927
SONAR SYSTEM (if so equipped)
5-46 Starting and driving
 —
—
04/29/10—pattie


The sensitivity level of the corner/center sonar
can be adjusted (higher or lower) in the SONAR
setting display. (See “HOW TO USE SETTING
BUTTON” in the “4. Monitor, climate, audio,
phone and voice recognition systems” section
for the “Sonar” settings.)
 1
Rear view monitor display
 A
Corner sonar indicator
 B
Center sonar indicator
SONAR INDICATOR With the “Sonar Display” key ON in the “Sonar”
settings, when the corner/center sonar detects
obstacles near the bumper, a tone will sound
and the sonar indicator will appear in the center
display. When the rear view monitor is dis-
played, the sonar indicator will appear in the
upper corner of the display
 1
.
The sonar indicators
 A
and
 B
indicate the
position of the object and the distance to the
object with its color and rate of blinking. When an object is detected, the indicator
(green) appears and blinks (the tone sounds
intermittently). When the vehicle moves closer
to the object, the color of the indicator turns
yellow and the rate of blinking increases (the
rate of the tone increases). When the corner of
the vehicle is very close to the object, less than
11.8 in (30 cm) away, the indicator stops blink-
ing and turns red (the tone sounds continu-
ously).
When the rear view monitor is displayed, the
colors of the sonar indicator and the distance
guide lines in the rear view indicate different
distances to the object.
The sonar indicator can be turned off in the
SONAR setting display. (See “HOW TO USE
SETTING BUTTON” in the “4. Monitor, climate,
audio, phone and voice recognition systems”
section for the “Sonar” settings.) When the
sonar indicator is off, only a tone sounds when
the sonar detects obstacles. SSD0928
Starting and driving
5-47
 —
—
04/29/10—pattie


● When the Preview Function operates, the
brake pedal may move slightly and may
make a small noise. This is not a system
malfunction.
Warning light and display When the Preview Function is not operating
properly, a chime sounds and the system warn-
ing light (orange) will come on.
Action to take :
If the warning light comes on, park the vehicle
in a safe place. Turn the engine off, restart the
engine and resume driving.
If the indicator stays on, it may indicate that the
Preview Function is malfunctioning (the brake is
operative). Although the Vehicle is still drive-
able under normal conditions, have the vehicle
checked at an INFINITI retailer. How to handle the sensor The sensor for the Preview Function is common
with Intelligent Cruise Control and is located
below the front bumper.
To keep the Preview Function operating prop-
erly, be sure to observe the following:
● Always keep the sensor clean. Wipe with a
soft cloth carefully so as not to damage the
sensor.
● Do not strike or damage the areas around
the sensor. Do not touch or remove the
screw located on the sensor. Doing so could
cause failure or malfunction. If the sensor is
damaged due to an accident, contact an
INFINITI retailer.
● Do not attach a sticker (including transpar-
ent material) or install an accessory near the
sensor. This could cause failure or malfunc-
tion. SSD0471
Starting and driving
5-51
 —
—
04/29/10—pattie


10 Index 4 Wheel Active Steer (4WAS) system .... .5-54
4 Wheel Active Steer (4WAS) warning light . .2-13
A
ABS (Anti-lock Braking System) ....... .5-52
Advanced air bag system .......... .1-45
Air bag system
Advanced air bag system ........ .1-45
Front passenger air bag and status
light ..................... 1-47
Front-seat mounted side-impact
supplemental air bag system ....... 1-50
Roof-mounted curtain side-impact
supplemental air bag system ....... 1-50
Air bag warning labels ............ .1-53
Air bag warning light ......... .1-53 , 2-16
Air cleaner housing filter .......... .8-17
Air conditioner
Air conditioner service .......... .4-38
Air conditioner specification label .... 9-14
Air conditioning system refrigerant and
lubricant recommendations ....... 4-38
Automatic climate control ........ 4-28
In-cabin microfilter ............ 4-38
Operation (See automatic climate
control) ................... 4-28
Alarm, How to stop alarm
(see vehicle security system) ........ .2-28
Alcohol, drugs and driving .......... .5-6
All-wheel drive (AWD) ............ .5-43 All-wheel drive (AWD) driving safety
precautions ................... .5-7
All-wheel drive (AWD) warning light .... .2-12
Antenna .................... .4-84
Anti-lock Braking System (ABS) ....... .5-52
Anti-lock braking system (ABS) warning
light ...................... .2-12
Appearance care
Exterior appearance care ......... .7-2
Interior appearance care ..........7-4
Armrest .................... .1-12
Ashtrays (See cigarette lighter
and ashtrays) ................. .2-42
Audible reminders .............. .2-18
Audio operation precautions ........ .4-39
Audio system ................. .4-39
Audio system, Steering wheel
audio controls ................ .4-83
Autolight system ............... .2-33
Automatic
Automatic adjusting function (front
windows) ................. .2-52
Automatic
climate control ........ 4-30
Automatic transmission fluid (ATF) .... 8-11
Climate control .............. 4-28
Driving with automatic transmission . . . 5-12
Automatic door locks ............. .3-6
Automatic drive positioner ......... .3-28
Automatic seat positione r.......... .3-28
Average fuel consumption and speed . . . .2-25
Avoiding collision and rollover ........ .5-5 B
Battery ..................... .8-13
Battery
Battery saver system ........... .2-35
Intelligent Key ............... 8-22
Variable voltage control system ..... 8-15
Before starting the engine .......... .5-10
Belts (See drive belts) ............ .8-16
Bluetooth  hands-free phone system
(models with navigation system) ...... .4-85
Booster seats ................. .1-35
Brake
Anti-lock Braking System (ABS) ..... .5-52
Brake and clutch fluid ........... 8-12
Brake system ............... 5-48
Parking brake operation . . . ...... 5-18
Brake warning light ............. .2-12
Break-in schedule .............. .5-42
Brightness control and display ON/OFF
button ...................... .4-7
Brightness control, Instrument panel . . . .2-36
Bulb check/instrument panel . . . ..... .2-11
Bulb replacement .............. .8-23
C
Cabin air filter ................ .4-38
Capacities and recommended
fuel/lubricants ................. .9-2
 —
—
04/30/10—diane


Car phone or CB radio ............ .4-85
Card holder .................. .2-47
Cargo net retainers ............. .2-49
Catalytic converter, Three way catalyst . . . .5-2
Center multi-function control panel ..... .4-2
Child restraints ................ .1-20
Child restraints
Booster seats ............... .1-35
Installation using LATCH ......... 1-25
Installation using the seat belts ..... 1-29
LATCH system ............... 1-22
Precautions on child restraints ...... 1-21
Top tether strap .............. 1-24
Child safety .................. .1-15
Child safety rear door lock .......... .3-6
Chimes
Audible reminders ............ .2-18
Seat belt warning light and chime .... 2-16
Cigarette lighter and ashtrays ....... .2-42
Circuit breaker, Fusible link ......... .8-21
Cleaning exterior and interior ..... .7-2 , 7-4
Climate control, Automatic
climate control ................ .4-28
Clock ..................... .2-40
Clutch fluid .................. .8-12
Coat hooks .................. .2-48
Cockpit ..................... .2-2
Cold weather driving ............. .5-55
Command (See Bluetooth  Hands-Free
Phone System) ............ .4-87 , 4-101
Compact Disc (CD) player
(See audio system) .............. .4-57
Compact spare tire .............. .8-39
Compass .................... .2-8
Console box ................. .2-45 Controller, Center multi-function control
panel ...................... .4-4
Controls
Control panel button (display) ...... .4-2
Heater
and
air conditioner controls
(See automatic climate control) ..... 4-28
Coolant
Capacities and recommended fuel/
lubricants .................. .9-2
Changing engine coolant .........8-8
Checking engine coolant level .......8-7
Corrosion protection ............. .7-6
Cruise control ................. .5-19
Cruise control
Fixed speed cruise control (on ICC
system) .................. .5-38
Intelligent cruise control (ICC) system . . 5-21
Cruise indicator ............... .2-22
Cup holders .................. .2-43
Current fuel consumption .......... .2-25
D
Daytime running light system ........ .2-35
Defroster switch, Rear window and outside
mirror defroster switch ........... .2-32
Dimensions .................. .9-11
Display cleaning ................ .4-6
Display controls (See center multi-function
control panel) ................. .4-2
Distance to empty .............. .2-25
Door/trunk open warning .......... .2-22
Dot matrix liquid crystal display ...... .2-19
Drive belts .................. .8-16
Drive positioner ............... .3-28 Driving
All-wheel drive (AWD) .......... .5-43
Cold weather driving ........... 5-55
Driving with automatic transmission . . . 5-12
Driving with manual transmission .... 5-16
Precautions when starting and driving . . 5-2
DS (Drive Sport) mode ............ .5-14
E
Economy, Fuel ................ .5-42
Elapsed time ................. .2-25
Elapsed time and trip odometer ...... .2-25
Emission control information label . . . . . .9-13
Emission control system warranty ..... .9-23
Engine
Before starting the engine ........ .5-10
Break-in schedule ............. 5-42
Capacities and recommended fuel/
lubricants ..................
9 -2
Changing engine coolant . . . . . . . . . 8-8
Changing engine oil and filter .......8-9
Checking engine coolant level .......8-7
Checking engine oil level . . . . . . . . . 8-8
Engine block heater ............ 5-56
Engine compartment check locations . . . 8-6
Engine cooling system ...........8-7
Engine oil ..................8-8
Engine oil and oil filter recommendation . 9-6
Engine oil replacement indicator .... 2-23
Engine oil viscosity .............9-6
Engine serial number ........... 9-12
Engine specifications ............9-8
Engine start operation indicator
(Automatic Transmission models) .... 2-21
10-2
 —
—
04/30/10—diane


Engine start operation indicator (Manual
Transmission models) ........... 2-22
If your vehicle overheats ......... 6-10
Starting the engine ............. 5-11
Engine coolant temperature gauge ..... .2-6
Entry/exit function .............. .3-28
Event Data Recorders (EDR) ......... .9-25
Exhaust gas (carbon monoxide) ....... .5-2
F
F.M.V.S.S./C.M.V.S.S. certification label . . .9-13
Filter
Air cleaner housing filter ........ .8-17
Changing engine oil and filter .......8-9
Flashers (See hazard warning
flasher switch) ................ .2-37
Flat tire ..................... .6-2
Flat towing .................. .9-21
Floor mat cleaning ............... .7-5
Fluid
Automatic transmission fluid (ATF) . . . .8-11
Brake and clutch fluid ........... 8-12
Capacities and recommended fuel/
lubricants ..................9-2
Engine coolant ...............8-7
Engine oil ..................8-8
Power steering fluid ............ 8-11
Window washer fluid ........... 8-13
FM-AM-SAT radio with Compact Disc (CD)
player ..................... .4-54
Fog light switch ............... .2-37
Front passenger air bag and status light . .1-47
Front power seat adjustment ......... .1-3
Front seat, Front seat adjustment ...... .1-3 Front-seat active head restraints ...... .1-11
Fuel
Capacities and recommended fuel/
lubricants .................. .9-2
Fuel economy ............... 5-42
Fuel economy information (display) ....4-9
Fuel octane rating .............9-4
Fuel recommendation ...........9-4
Fuel-filler cap ................ 3-21
Fuel-filler door ............... 3-21
Gauge ....................2-7
Fuses ..................... .8-20
Fusible links ................. .8-21
G
Garage
door opener, HomeLink  Universal
Transceiver .................. .2-57
Gascap .................... .3-21
Gauge ...................... .2-4
Gauge
Engine coolant temperature gauge . . . .2-6
Fuel gauge ..................2-7
Odometer ..................2-5
Speedometer ................2-5
Tachometer .................2-6
Trip computer ............... 2-24
General maintenance ............. .8-2
Glove box ................... .2-45
Golf bag stowing ............... .2-48 H
Hands-free phone system, Bluetooth
(with navigation system) .......... .4-85
Hands-free phone system, Bluetooth
(without navigation system) ........ .4-96
Hazard warning flasher switch . . ..... .2-37
Head restraints ................. .1-9
Headlights
Bulb replacement ............ .8-25
Headlight switch .............. 2-33
Xenon headlights ............. 2-32
Heated seats ................. .2-38
Heater
Automatic climate control ........ .4-28
Engine block heater ............ 5-56
HomeLink  Universal Transceiver ...... .2-57
Hood release ................. .3-17
Hook, Coat hooks .............. .2-48
Horn ...................... .2-38
Ignition switch
Automatic transmission models ..... .5-12
Manual transmission models . . . . . . . 5-16
I
Ignition switch (Push-button) ......... .5-7
Immobilizer system ............. .2-29
In-cabin microfilter .............. .4-38
Indicator
lights ................ .2-16
Indicator,
Dot matrix display ........ .2-19
INFINITI Vehicle Immobilizer System .... .2-29
INFINITI voice recognition standard
mode ..................... .4-109
10-3
 —
—
04/30/10—diane
