INFINITI G37 2010 Owners Manual

Replace the battery as follows:
1. Release the lock knob at the back of the
Intelligent Key and remove the mechanical
key.
2. Insert a flat-blade screwdriver
 A
wrapped with a cloth into the slit
 B
of
the corner and twist it to separate the
upper part from the lower part. 3. Replace the battery with a new one.
Recommended battery: CR2032 or equivalent.
● Do not touch the internal circuit and
electric terminals as it could cause a
malfunction.
● Hold the battery by the edges. Holding
the battery across the contact points will
seriously deplete the storage capacity.
● Make sure that the + side faces the
bottom of the case.
4. Align the tips of the upper and lower
parts, and then push them together until
it is securely closed.
5. Push the buttons two or three times to
check its operation. See an INFINITI retailer if you need any assis-
tance for replacement.
FCC Notice:
This equipment has been tested and found to
comply with the limits for a Class B digital device
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential in-
stallation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the in-
structions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
– Reorient or relocate the receiving antenna
– Increase the separation between the equip-
ment and the receiver
– Connect the equipment into an outlet on a
circuit different from that to which the re-
ceiver is connected.
– Consult the retailer or an experienced
radio/TV technician for help.SDI1834 SDI2042
INTELLIGENT KEY BATTERY REPLACEMENT
8-22 Maintenance and do-it-yourself
 —
—
04/21/10—debbie


SEDAN 1. Front turn signal light and clearance light
2. Headlight (high- and low-beam)
3. Front side marker light
4. Map light
5. Rear personal light
6. Fog light
7. Step light
8. High-mounted stop light (on the rear par-
cel shelf or in the rear spoiler)*
9. Trunk light
10. License plate light
11. Back-up light
12. Rear combination light (rear turn
signal/tail/stop/side marker light)
*: Note that when the factory spoiler is
installed, the rear parcel shelf high-
mounted stop light is still present, but it
is disabled and replaced by the rear
spoiler high-mounted stop light.
SDI2501LIGHTS
Maintenance and do-it-yourself
8-23
 —
—
04/21/10—debbie


COUPE 1. Fog light
2. Headlight (high- and low-beam)
3. Front turn signal light
4. Map light
5. Clearance light
6. Front side marker light
7. Step light
8. High-mounted stop light (on the rear par-
cel shelf or in the rear spoiler)*
9. Trunk light
10. License plate light
11. Back-up light
12. Rear combination light (rear turn
signal/tail/stop/side marker light)
*: Note that when the factory spoiler is
installed, the rear parcel shelf high-
mounted stop light is still present, but it
is disabled and replaced by the rear
spoiler high-mounted stop light.
SDI2126
8-24 Maintenance and do-it-yourself
 —
—
04/21/10—debbie


HEADLIGHTS
Replacing Xenon headlight bulb :
WARNING
HIGH VOLTAGEWhen xenon headlights are on, they produce a
high voltage. To prevent an electric shock,
never attempt to modify or disassemble. Al-
ways have your xenon headlights replaced at
an INFINITI retailer. For additional information,
see “HEADLIGHT AND TURN SIGNAL SWITCH” in
the “2. Instruments and controls” section.
Use the same number and wattage shown in the
following chart as originally installed.
If replacement is required, see an INFINITI re-
tailer.
Fog may temporarily form inside the lens of the
exterior lights in the rain or in a car wash. A
temperature difference between the inside and
the outside of the lens causes the fog. This is
not a malfunction. If large drops of water collect
inside the lens, contact an INFINITI retailer. EXTERIOR AND INTERIOR LIGHTS
Sedan Item Wattage (W) Bulb No.
Headlight*
High/Low beams (xenon) 35 D2S
Front turn signal light* 28 7444NA
Front fog light* 35 H8
Clearance light* 8 7444NA
Front side marker light* 5 WY5W
Rear combination light*
back-up 16 W16W
turn signal 21 W21W
stop/tail/side marker LED —
License plate light* 5 W5W
Map light 8 —
Rear personal light 8 —
Vanity mirror light 2 —
Step light* 8 —
Trunk light* 3.4 —
High-mounted stop light* LED —
*: See an INFINITI retailer for replacement.
NOTE: Always check with the Parts Department at an INFINITI retailer for the latest information about
parts.
Maintenance and do-it-yourself
8-25
 —
—
04/21/10—debbie


Coupe Item Wattage (W) Bulb No.
Headlight*
High/Low beams (xenon) 35 D2S
Front turn signal light* 21 WY21W
Front fog light* 55 H1
Clearance light* 5 W5W
Front side marker light* 5 W5W
Rear combination light*
back-up 16 W16W
turn signal 21 W21W
stop/tail/side marker LED —
License plate light* 5 W5W
Map light 8 —
Vanity mirror light 2 —
Step light* 8 —
Trunk light* 3.4 —
High-mounted stop light* LED —
*: See an INFINITI retailer for replacement.
NOTE: Always check with the Parts Department at an INFINITI retailer for the latest information about
parts.
8-26 Maintenance and do-it-yourself
 —
—
04/21/10—debbie


Replacement procedures All other lights are either type A, B, C, D, E or F.
When replacing a bulb, first remove the lens
and/or cover.
SDI1679 Map light SDI2508
Rear personal light (Sedan only) SDI2031
Maintenance and do-it-yourself
8-27
 —
—
04/21/10—debbie


If you have a flat tire, see “FLAT TIRE” in the “6. In
case of emergency” section.
TIRE PRESSURE
Tire Pressure Monitoring System
(TPMS) This vehicle is equipped with the Tire Pressure
Monitoring System (TPMS). It monitors tire
pressure of all tires except the spare. When the
low tire pressure warning light is lit, one or
more of your tires is significantly under-
inflated.
The TPMS will activate only when the vehicle is
driven at speeds above 16 MPH (25 km/h). Also,
this system may not detect a sudden drop in tire
pressure (for example a flat tire while driving).
For more details, see “Low tire pressure warn-
ing light” in the “2. Instruments and controls”
section, “TIRE PRESSURE MONITORING SYSTEM
(TPMS)” in the “5. Starting and driving” section
and “TIRE PRESSURE MONITORING SYSTEM
(TPMS)” in the “6. In case of emergency” sec-
tion.
Tire inflation pressure
Check the pressure of the tires (includ-
ing the spare) often and always prior to
long distance trips. The recommended tire pressure specifications are shown
on the Tire and Loading Information
label under the “Cold Tire Pressure”
heading. The Tire and Loading Informa-
tion label is affixed to the driver side
center pillar. Tire pressures should be
checked regularly because: ●
Most tires naturally lose air over time. ●
Tires can lose air suddenly when
driven over potholes or other objects
or if the vehicle strikes a curb while
parking.
The tire pressures should be checked
when the tires are cold. The tires are
considered COLD after the vehicle has
been parked for 3 or more hours, or
driven less than 1 mile (1.6 km) at mod-
erate speeds.
Incorrect tire pressure, including under
inflation, may adversely affect tire life
and vehicle handling.Vanity mirror light (Type A) SDI2032
Vanity mirror light (Type B) SDI1839WHEELS AND TIRES
8-28 Maintenance and do-it-yourself
 —
—
04/21/10—debbie


WARNING●
Improperly inflated tires can fail sud-
denly and cause an accident.●
The Gross Vehicle Weight rating
(GVWR) is located on the F.M.V.S.S./
C.M.V.S.S. label. The vehicle weight
capacity is indicated on the Tire and
Loading Information label. Do not
load your vehicle beyond this capac-
ity. Overloading your vehicle may re-
sult in reduced tire life, unsafe operat-
ing conditions due to premature tire
failure, or unfavorable handling char-
acteristics and could also lead to a
serious accident. Loading beyond the
specified capacity may also result in
failure of other vehicle components.●
Before taking a long trip, or whenever
you heavily load your vehicle, use a
tire pressure gauge to ensure that the
tire pressures are at the specified
level. ●
For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety In-
formation” (Canada) in the Warranty
Information Booklet.
Maintenance and do-it-yourself
8-29
 —
—
04/29/10—pattie


Tire and Loading Information label
 1
Seating capacity: The maximum
number of occupants that can be
seated in the vehicle.
 2
Vehicle load limit: See “VEHICLE
LOADING INFORMATION” in the “9.
Technical and consumer informa-
tion” section.  3
Original size: The size of the tires
originally installed on the vehicle
at the factory.
 4
Cold tire pressure: Inflate the tires
to this pressure when the tires are
cold. Tires are considered COLD
after the vehicle has been parked
for 3 or more hours, or driven less
than 1 mile (1.6 km) at moderate
speeds. The recommended cold
tire inflation is set by the manufac-
turer to provide the best balance of
tire wear, vehicle handling, drive-
ability, tire noise, etc., up to the
vehicle’s GVWR.
 5
Tire size — see “TIRE LABELING”
later in this section.
 6
Spare tire size or compact spare
tire size (if so equipped) SDI2153
8-30 Maintenance and do-it-yourself
 —
—
04/21/10—debbie


Checking the tire pressure 1.
Remove the valve stem cap from the
tire.2.
Press the pressure gauge squarely
onto the valve stem. Do not press too
hard or force the valve stem side-
ways, or air will escape. If the hissing
sound of air escaping from the tire is
heard while checking the pressure,
reposition the gauge to eliminate this
leakage.3.
Remove the gauge. 4.
Read the tire pressure on the gauge
stem and compare it to the specifica-
tion shown on the Tire and Loading
Information label. 5.
Add air to the tire as needed. If too
much air is added, press the core of
the valve stem briefly with the tip of
the gauge stem to release pressure.
Recheck the pressure and add or re-
lease air as needed. 6.
Install the valve stem cap. 7.
Check the pressure of all other tires,
including the spare. Sedan:
SIZE COLD TIRE
INFLATION
PRESSURE
FRONT
ORIGINAL
TIRE P225/55R17
95V 230 kPa,
33 PSI
P225/
50R18 94V 230 kPa,
33 PSI
225/50R18
95W 230 kPa,
33 PSI
REAR
ORIGINAL
TIRE P225/55R17
95V 230 kPa,
33 PSI
P225/
50R18 94V 230 kPa,
33 PSI
245/45R18
96W 230 kPa,
33 PSISDI1949
Maintenance and do-it-yourself
8-31
 —
—
04/21/10—debbie
