turn signal INFINITI G37 2010 Owners Manual

SEDAN 1. Hood (P. 3-17)
2. Headlight and turn signal
— Operation (P. 2-32)
— Bulb replacement (P. 8-16) 3. Windshield wiper and washer
— Operation (P. 2-30)
— Maintenance (P. 8-18)
4. Moonroof (if so equipped) (P. 2-52)
5. Power windows (P. 2-49)
6. Recovery hook (P. 6-13) 7. Fog light (P. 2-37)
8. Tires
— Wheel and tires (P. 8-28, P. 9-9)
— Flat tire ( 6-2)
— Tire pressure monitoring system
(TPMS) (P. 2-14, P. 5-3)
9. Outside mirrors (P. 3-26)
10. Doors
— Keys (P. 3-2)
— Door locks (P. 3-4)
— Intelligent Key system (P. 3-7)
— Remote keyless entry system (P. 3-14)
SSI0643EXTERIOR FRONT
Illustrated table of contents
0-3
 —
—
10/12/09—tbrooks


COUPE 1. Hood (P. 3-17)
2. Headlight and turn signal
— Operation (P. 2-32)
— Bulb replacement (P. 8-23)
— Fog light (P. 2-37) 3. Windshield wiper and washer
— Operation (P. 2-30)
— Maintenance (P. 8-18)
4. Moonroof (if so equipped) (P. 2-52)
5. Power windows (P. 2-49)
6. Recovery hook (P. 6-13) 7. Tires
— Wheel and tires (P. 8-28, P. 9-9)
— Flat tire ( 6-2)
— Tire pressure monitoring system (TPMS)
(P. 2-14, P. 5-3)
8. Outside mirrors (P. 3-26)
9. Doors
— Keys (P. 3-2)
— Door locks (P. 3-4)
— Intelligent Key system (P. 3-7)
— Remote keyless entry system (P. 3-14)
SSI0342
0-4 Illustrated table of contents
 —
—
10/12/09—tbrooks


1. Vehicle Dynamic Control (VDC) OFF switch
(P. 5-53)
2. Trunk lid release switch (P. 3-18)
3. Sonar system off switch (if so equipped)
(P. 5-48) 4. Instrument brightness control switch
(P. 2-36)
5. TRIP/RESET switch for twin trip odometer
(P. 2-5)
6. Headlight, fog light and turn signal switch
(P. 2-32) 7. Paddle shifter (if so equipped) (P. 5-14)
8. Steering-wheel-mounted controls
(left side)
— ENTER or tuning switch (P. 4-83)
— BACK switch (P. 4-83)
— TALK switch (if so equipped)
(P. 4-109)/Phone switch (if so equipped)
(P. 4-85)
— Volume control switches (P. 4-83)
— Source select switch (P. 4-83)
9. Trip computer switch (P. 2-24)
10. Windshield wiper and washer switch
(P. 2-30)
11. Steering-wheel-mounted controls
(right side)
— Cruise control switches (P. 5-19)
— Intelligent Cruise Control (ICC)
switches (if so equipped) (P. 5-21)
12. Hood release handle (P. 3-17)
13. Intelligent Key port (P. 5-10)
14. Electric tilting/telescopic steering wheel
lever (if so equipped) (P. 3-23)
15. Manual tilting/telescopic steering wheel
lever (if so equipped) (P. 3-23)
16. Steering wheel
— Horn (P. 2-38)
— Driver supplemental air bag (P. 1-40) SSI0670COCKPIT
Illustrated table of contents
0-9
 —
—
10/12/09—tbrooks


Indica-
tor
light Name Page
Turn signal/hazard indi-
cator lights 2-18
Vehicle Dynamic Control
(VDC) off indicator light 2-18
*: if so equipped
0-14 Illustrated table of contents
 —
—
10/12/09—tbrooks


2 Instruments and controls Cockpit ........................................... 2-2
Instrument panel .................................. 2-3
Meters and gauges ................................ 2-4
Speedometer and odometer ..................... 2-5
Tachometer .................................... 2-6
Engine coolant temperature gauge ............... 2-6
Fuel gauge ..................................... 2-7
Compass (if so equipped) .......................... 2-8
Zone variation change procedure ................ 2-9
Warning/indicator lights and audible reminders ...... 2-11
Checking bulbs ................................ 2-11
Warning lights ................................ 2-12
Indicator lights ................................ 2-16
Audible reminders ............................. 2-18
Dot matrix liquid crystal display ................... 2-19
Indicators for operation ........................ 2-21
Indicators for maintenance ..................... 2-23
Trip computer ................................. 2-24
Security systems ................................. 2-27
Vehicle security system ........................ 2-27
INFINITI Vehicle Immobilizer System ............ 2-29
Windshield wiper and washer switch ............... 2-30 Rain-sensing auto wiper system
(if so equipped) ............................... 2-31
Rear window and outside mirror defroster switch . . . 2-32
Headlight and turn signal switch .................. 2-32
Xenon headlights ............................. 2-32
Headlight switch .............................. 2-33
Turn signal switch ............................. 2-37
Fog light switch ............................... 2-37
Hazard warning flasher switch ..................... 2-37
Horn ............................................ 2-38
Heated seats (if so equipped) ..................... 2-38
SNOW mode switch (if so equipped) ............... 2-40
Vehicle Dynamic Control (VDC) OFF switch .......... 2-40
Clock ............................................ 2-40
Adjusting the time ............................. 2-40
Power outlet ..................................... 2-41
Cigarette lighter and ashtrays (if so equipped) ...... 2-42
Front ......................................... 2-42
Rear ......................................... 2-42
Storage ......................................... 2-43
Cup holders .................................. 2-43
Sunglasses holder ............................. 2-45
 —
—
10/12/09—tbrooks


1. Vehicle Dynamic Control (VDC) OFF switch
(P. 5-53)
2. Trunk lid release switch (P. 3-18)
3. Sonar system off switch (if so equipped)
(P. 5-48) 4. Instrument brightness control switch
(P. 2-36)
5. TRIP/RESET switch for twin trip odometer
(P. 2-5)
6. Headlight, fog light and turn signal switch
(P. 2-32) 7. Paddle shifter (if so equipped) (P. 5-14)
8. Steering-wheel-mounted controls
(left side)
— ENTER or tuning switch (P. 4-83)
— BACK switch (P. 4-83)
— TALK switch (if so equipped)
(P. 4-109)/Phone switch (if so equipped)
(P. 4-85)
— Volume control switches (P. 4-83)
— Source select switch (P. 4-83)
9. Trip computer switch (P. 2-24)
10. Windshield wiper and washer switch
(P. 2-30)
11. Steering-wheel-mounted controls
(right side)
— Cruise control switches (P. 5-19)
— Intelligent Cruise Control (ICC)
switches (if so equipped) (P. 5-21)
12. Hood release handle (P. 3-17)
13. Intelligent Key port (P. 5-10)
14. Electric tilting/telescopic steering wheel
lever (if so equipped) (P. 3-23)
15. Manual tilting/telescopic steering wheel
lever (if so equipped) (P. 3-23)
16. Steering wheel
— Horn (P. 2-38)
— Driver supplemental air bag (P. 1-40) SSI0670COCKPIT
2-2 Instruments and controls
 —
—
10/12/09—tbrooks


All-Wheel Drive (AWD) warning light
(AWD models)* Intelligent Cruise Control (ICC) sys-
tem warning light (orange)* Front passenger air bag status light
Anti-lock Braking System (ABS) warn-
ing light Intelligent Key warning light High beam indicator light
Low tire pressure warning light Malfunction Indicator Light (MIL)
Automatic transmission check warn-
ing light Master warning light Security indicator light
Brake warning light Preview Function warning light (or-
ange)* Slip indicator light
Seat belt warning light Low Beam indicator light (green)
Charge warning light Supplemental air bag warning light Turn signal/hazard indicator lights
Engine oil pressure warning light Automatic transmission position indi-
cator light* Vehicle Dynamic Control (VDC) off
indicator light
4 Wheel Active Steer (4WAS) warning
light* Front fog light indicator light *: if so equipped
CHECKING BULBS With all doors closed, apply the parking brake
and push the ignition switch to the ON position
without starting the engine. The following lights
will come on (if so equipped):
, or , , , ,
, , The following lights come on briefly and then go
off (if so equipped):
, or , , , ,
, If any light does not come on, it may indicate a
burned-out bulb or an open circuit in the elec-
trical system. Have the system checked by an
INFINITI retailer.
Some indicators and warnings are also dis-
played on the dot matrix crystal display be-
tween the speedometer and tachometer. (See
“DOT MATRIX LIQUID CRYSTAL DISPLAY” later in
this section.)WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS
Instruments and controls
2-11
 —
—
12/08/09—debbie


Security indicator lightThe light blinks when the ignition switch is in
the ACC, OFF or LOCK position. This function
indicates the security system equipped on the
vehicle is operational.
If the security system is malfunctioning, this
light will remain on while the ignition switch is
in the ON position. For additional information,
see “SECURITY SYSTEMS” later in this section.
Slip indicator lightThis indicator will blink when the VDC system or
the traction control system is operating, thus
alerting the driver that the vehicle is nearing its
traction limits. The road surface may be slip-
pery.
Low Beam indicator light
(green)The small light indicator light illuminates when
the front clearance lights, instrument panel
lights, rear combination lights and license plate
lights are on. The indicator light turns off when
the is turned off. Turn signal/hazard indicator
lights The light flashes when the turn signal switch
lever or hazard switch is turned on.
Vehicle Dynamic Control
(VDC) off indicator light The light comes on when the vehicle dynamic
control off switch is pushed to OFF. This indi-
cates that the vehicle dynamic control system
and traction control system are not operating.
When the vehicle dynamic control off indicator
light and slip indicator light come on with the
vehicle dynamic control system turned on, this
light alerts the driver to the fact that the vehicle
dynamic control system’s fail-safe mode is op-
erating, for example the vehicle dynamic con-
trol system may not be functioning properly.
Have the system checked by an INFINITI retailer.
If an abnormality occurs in the system, the
vehicle dynamic control system function will be
canceled but the vehicle is still driveable. For
additional information, see “VEHICLE DYNAMIC
CONTROL (VDC) SYSTEM” in the “5. Starting and
driving” section of this manual. AUDIBLE REMINDERS
Key reminder chime A chime will sound if the driver side door is
opened while the ignition switch is pushed to
the ACC position or pushed to the OFF or LOCK
position with the Intelligent Key left in the
Intelligent Key port. Make sure the ignition
switch is pushed to the OFF position, and take
the Intelligent Key with you when leaving the
vehicle.
Light reminder chime A chime will sound when the driver side door is
opened with the light switch in the or
position and the ignition switch in the
ACC, OFF or LOCK position.
Turn the light switch off when you leave the
vehicle.
Parking brake reminder chime The parking brake reminder chime will sound if
the vehicle is driven at more than 4 MPH (7
km/h) with the parking brake applied. Stop the
vehicle and release the parking brake.
2-18 Instruments and controls
 —
—
12/08/09—debbie


To defog/defrost the rear window glass and
outside mirrors (if so equipped), start the en-
gine and push the switch
 1
on. The indicator
light
 2
will come on. Push the switch again to
turn the defroster off.
It will automatically turn off in approximately 15
minutes.
CAUTIONWhen cleaning the inner side of the rear win-
dow, be careful not to scratch or damage the
rear window defroster. XENON HEADLIGHTS WARNING
HIGH VOLTAGE● When xenon headlights are on, they pro-
duce a high voltage. To prevent an electric
shock, never attempt to modify or disas-
semble. Always have your xenon headlights
replaced at an INFINITI retailer.
● Xenon headlights provide considerably
more light than conventional headlights. If
they are not correctly aimed, they might
temporarily blind an oncoming driver or the
driver ahead of you and cause a serious acci-
dent. If headlights are not aimed correctly,
immediately take your vehicle to an INFINITI
retailer and have the headlights adjusted
correctly.Type A SIC3239
Type B SIC3278
REAR WINDOW AND OUTSIDE MIRROR
DEFROSTER SWITCH HEADLIGHT AND TURN SIGNAL SWITCH
2-32 Instruments and controls
 —
—
10/12/09—tbrooks


When the xenon headlight is initially turned on,
its brightness or color varies slightly. However,
the color and brightness will soon stabilize.
● The life of xenon headlights will be shortened
by frequent on-off operation. It is generally
desirable not to turn off the headlights for
short intervals (for example, when the ve-
hicle stops at a traffic signal). Even when the
daytime running lights are active (Canada
only), the xenon headlights do not turn on.
This way the life of the xenon headlights is
not reduced.
● If the xenon headlight bulb is close to burn-
ing out, the brightness will drastically de-
crease, the light will start blinking, or the
color of the light will become reddish. If one
or more of the above signs appear, contact an
INFINITI retailer.
HEADLIGHT SWITCH
Lighting
 1
Turn the switch to the position:
The front park, side marker, tail, license
plate and instrument lights will come on.
 2
Turn the switch to the position:
Headlights will come on and all the other
lights remain on. Autolight system (if so equipped) The autolight system allows the headlights to
be set so they turn on and off automatically.
To set the autolight system:
1. Make sure the headlight switch is in the
AUTO position
 1
.
2. Push the ignition switch to the ON posi-
tion.
3. The autolight system automatically turns
the headlights on and off.
To turn the autolight system off, turn the switch
to the OFF, or position.SIC3267 SIC3268
Instruments and controls
2-33
 —
—
10/12/09—tbrooks
