[ Edit: 2012/ 1/ 17 Model: V36-D ]4-92 Monitor, climate, audio, phone and voice recognition systems SAA1772
CONTROL BUTTONS GUID-0B868A4F-9B5D-45FD-8767-9633BA3ABBBF
1) PHONE button
2) TALK /PHONE SEND button SAA2519
CONNECTING PROCEDURE GUID-5001AC50-4CF3-478F-AA37-19C8B982C9BF
1. Push the PHONE button or the
button, and select the “ Connect Phone ”
key. SAA2520
2. When a PIN code appears on the
screen, operate the compatible Blue-
tooth ®
cellular phone to enter the PIN
code.
The connecting procedure of the cellu-
lar phone varies according to each
cellular phone. See the cellular phone
Owner ’ s Manual for the details. You can
also visit
www.InfinitiUSA.com/bluetooth or call
INFINITI Consumer Affairs Department
for instructions on pairing INFINITI
recommended cellular phones.
When the connection process is com-
pleted, the screen will return to the

Black plate (271,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Phone menu display.
PHONE SELECTION GUID-55FEE7E0-1713-47B1-B3A9-605D3DAAC920
Up to 5 cellular phones can be registered
to the system. To switch to connect another
cellular phone, push PHONE button and
select the “ Connected Phones ” key. The
registered cellular phones are shown on
the list. If you select a cellular phone that
is different from the one currently con-
nected, the newly selected phone will be
connected to the system.
VEHICLE PHONEBOOK GUID-9C55C4DB-C8AB-40D9-9A84-A06D2C3EF82D
This vehicle has two phonebooks available
for hands-free use. Depending on the
phone, the system may automatically
download the entire cell phone ’ s phone-
book into the “ Handset Phonebook ” . For
the details about downloading a phone-
book, see “ Phone setting ” (P.4-98). If a
phonebook does not automatically down-
load, the vehicle phonebook may be set for
up to 1,000 entries. This phonebook allows
the recording of a name to speak while
using voice recognition. SAA2521
1. Push the PHONE button and select the
“ Vehicle Phonebook ” key.
2. Select the “ Add New ” key at the top of
the screen. SAA2522
3. Choose the method for entering the
phonebook entry. For this example,
select “ Enter Number by Keypad ” .
4. Enter the digits and select the “ OK ”
key. (See “ How to use touch screen
(models with navigation system) ” (P.4-
5).)
Monitor, climate, audio, phone and voice recognition systems
4-93

Black plate (272,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-94 Monitor, climate, audio, phone and voice recognition systems SAA2523
5. Select the “ Voicetag ” key to record a
name to speak when using the INFINITI
Voice Recognition system.
6. Select the “ Store ” key and prepare to
speak the name after the tone.
7. When the voicetag is successfully
saved, select the “ OK ” key to save the
phonebook entry.
8. After the phonebook entry is saved, it
will show a screen that is ready to call
the number. Press the BACK button to
return to the Vehicle Phonebook.
There are different methods to input a
phone number. Select one of the following options instead of “ Enter Number by Key-
pad ” in step 3.
. Copy from Call History
The system will show a list of incoming,
outgoing or missed calls that were
downloaded from the connected cellu-
lar phone (depending on the phone ’ s
compatibility). Select one of these
entries to save in the vehicle phone-
book.
. Copy from the Handset
The system will show the connected
cellular phone ’ s phonebook that was
downloaded (depending on the
phone ’ s compatibility). Select one of
these entries to save in the vehicle
phonebook. SAA2620
Editing the Vehicle Phonebook GUID-595130B1-D7D0-45B8-8BB0-FEE71007B86A
1. Push the PHONE button and select the
“ Vehicle Phonebook ” key.
2. Select the desired entry from the
displayed list.
3. Select the “ Edit ” key.
4. Select the desired item to change.

Black plate (273,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2523
The following editing items are available:
. Entry #
Changes the displayed number of the
selected entry.
. Name
Edit the name of the entry using the
keypad displayed on the screen.
. Number
Edit the phone number using the key-
pad displayed on the screen.
. Type
Select an icon from the icon list.
. Voicetag
Confirm and store the voicetag. Voice- tags allow easy dialing using the
INFINITI Voice Recognition system.
(See “ INFINITI Voice Recognition system
(models with navigation system) ” (P.4-
114).)
To delete an entry, select the “ Delete ” key
at step 3.
SAA2524
MAKING A CALL GUID-0C40BF3A-B58B-4CB6-9E2E-8530EF09E8AF
To make a call, follow this procedure.
1. Push the PHONE button on the instru-
ment panel or the
button on the
steering wheel. The “ PHONE ” screen
will appear on the display.
2. Select the “ Handset Phonebook ” key
on the “ PHONE ” menu.
3. Select the desired entry from the list.
4. Confirm the correct entry by selecting
for the correct number from the list.
Monitor, climate, audio, phone and voice recognition systems
4-95

Black plate (274,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-96 Monitor, climate, audio, phone and voice recognition systems SAA2621
5. Select the “ Call ” key to start dialing the
number.
There are different methods to make a call.
Select one of the following options instead
of “ Handset Phonebook ” in step 2 above.
. Vehicle Phonebook
Select an entry stored in the Vehicle ’ s
Phonebook.
. Call History
Select an outgoing, incoming or missed
call downloaded from your cell phone
(depending on your phone ’ s compat-
ibility). . Dial Number
Input the phone number manually
using the keypad displayed on the
screen. (See “ How to use touch screen
(models with navigation system) ” (P.4-
5).)
SAA2525
RECEIVING A CALL GUID-FE730D1E-3F70-48A5-8B81-14DE254EC5A9
When you hear a phone ring, the display
will change to the incoming call mode. To
receive a call, perform one of the following
procedures listed below.
1. Select the “ Answer ” key.
2. Push the PHONE button on the instru-
ment panel.
3. Push the
button on the steering
wheel.
There are some options available when
receiving a call. Select one of the following
displayed on the screen.

Black plate (275,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. Answer
Accept an incoming call to talk.
. Hold Call
Put an incoming call on hold.
. Reject Call
Reject an incoming call.
To finish the call, perform one of the
following procedures listed below.
1. Select the “ Hang up ” key.
2. Push the PHONE button on the instru-
ment panel.
3. Push the
button on the steering
wheel. SAA3587
DURING A CALL GUID-E7292060-1082-4B42-B84D-1CC0C3989595
There are some options available during a
call. Select one of the following displayed
on the screen if necessary.
. Hang up
Finish the call.
. Use Handset
Transfer the call to the cellular phone.
. Mute
Mute your voice to the person.
. Keypad
Using the touch tone, send digits to the
connected party for using services such
as voicemail. . Cancel Mute
This will appear after “ Mute ” is se-
lected. Mute will be canceled.
. Switch Call*
Select “ Switch Call ” to answer another
incoming call. By selecting “ Hang up ” ,
you can end a call and can speak to a
caller who is on hold again.
* This function may not be usable,
depending on the model of phone.
To adjust the person ’ s voice to be louder or
quieter, push the volume control switch (+
or − ) on the steering wheel or turn the
volume control knob on the instrument
panel while talking on the phone. This
adjustment is also available in the SETTING
mode.
Monitor, climate, audio, phone and voice recognition systems
4-97

Black plate (276,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-98 Monitor, climate, audio, phone and voice recognition systems JVH0136M
PHONE SETTING GUID-8FECEF20-9C18-4585-B43E-38A99A0162B3
To set up the Bluetooth ®
Hands-Free
Phone System to your preferred settings,
push the SETTING button on the instrument
panel and select the “ PHONE ” key.
Edit Vehicle Phonebook GUID-41CB2CF1-B64F-4448-BF68-2C5657AE091D
To edit the vehicle phonebook, use the
same procedure as described in “ Vehicle
phonebook ” (P.4-93).
Delete Phonebook GUID-C896369C-416F-48E8-9F8C-AC7E77D25AE8
The vehicle phonebook entries can be
deleted all at the same time or one by one. Download Handset Phonebook GUID-A49F6D86-FE66-49A6-BB04-A2F864868A2E
Download the contacts registered in a
Bluetooth ®
cellular phone. Availability of
this function depends on each cellular
phone. The memory downloading proce-
dure from the cellular phone also varies
according to each cellular phone. See
cellular phone Owner ’ s Manual for details.
When “ Auto Download ” is active, the
system will automatically re-download the
entries registered in the phone everytime it
is paired with the vehicle, even after you
delete the entries from your vehicle ’ s
Handset Memory.
Volume & Ringtone GUID-9D884A00-6072-4E32-B06D-6CC767038D21
The following kinds of phone volume can
be set. Pushing the PHONE button and
selecting the “ Volume & Ringtone ” key can
also operate the same settings.
. Ringtone/Incoming Call/Outgoing Call
To increase or decrease the volume,
select the “ Ringtone ” , “ Incoming Call ”
or “ Outgoing Call ” key and adjust it
with the INFINITI controller.
. Automatic Hold
When this function is activated, an
incoming phone call is automatically
held. . Vehicle Ringtone
When this function is activated, a
specific ringtone that is different from
the cellular phone will sound when
receiving a call.
Auto Download GUID-585B86FE-316C-4FA3-82D9-0DD44AA36120
When this item is activated, the phonebook
of a hands-free phone is automatically
downloaded at the same time that the
hands-free phone is connected.
When this item is active, the system will
automatically re-download the entries re-
gistered in the connected phone even if
you attempt to delete the entries.

Black plate (277,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]TROUBLESHOOTING GUIDE GUID-255F4733-9310-4BC9-8430-43A290EAEE69
The system should respond correctly to all voice commands without difficulty. If problems are encountered, try the following solutions.
Where the solutions are listed by number, try each solution in turn, starting with number 1, until the problem is resolved. Symptom Solution
System fails to interpret the command
correctly. 1. Ensure that the command is valid. (See “ INFINITI Voice Recognition system (models with navigation system) ” (P.4-114).)
2. Ensure that the command is spoken after the tone.
3. Speak clearly without pausing between words and at a level appropriate to the ambient noise level in the vehicle.
4. Ensure that the ambient noise level is not excessive (for example, windows open or defroster on). NOTE: If it is too noisy to
use the phone, it is likely that the voice commands will not be recognized.
5. If more than one command was said at a time, try saying the commands separately.
The system consistently selects the
wrong voicetag. 1. Ensure that the voicetag requested matches what was originally stored. (See “ Vehicle phonebook ” (P.4-93).)
2. Replace one of the names being confused with a new name.
Monitor, climate, audio, phone and voice recognition systems
4-99

Black plate (278,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-100 Monitor, climate, audio, phone and voice recognition systems GUID-7B37E21C-D986-47A8-9978-11E1AEF26433
WARNING. Use a phone after stopping your vehicle
in a safe location. If you have to use a
phone while driving, exercise extreme
caution at all times so full attention may
be given to vehicle operation.
. If you find yourself unable to devote full
attention to vehicle operation while
talking on the phone, pull off the road
to a safe location and stop your vehicle
before doing so.
CAUTIONTo avoid draining the vehicle battery, use a
phone after starting the engine.
Your vehicle is equipped with Bluetooth ®
Hands-Free Phone System. If you are an
owner of a Bluetooth ®
enabled cellular
phone, you can set up the wireless
connection between your cellular phone
and the in-vehicle phone module. With
Bluetooth ®
wireless technology, you can
make or receive a telephone call with your
cellular phone in your pocket. Once your cellular phone is paired to the
in-vehicle phone module, no phone con-
necting procedure is required. Your phone
is automatically connected with the in-
vehicle phone module when the ignition
switch is pushed to the “ ON ” position with
the registered cellular phone turned on
and carried in the vehicle.
You can register up to 5 different Blue-
tooth ®
cellular phones in the in-vehicle
phone module. However, you can talk on
only one cellular phone at a time.
When a call is active, the audio system and
microphone (located in the ceiling in front
of the rearview mirror) are used for the
handsfree communications.
If the audio system is being used at the
time, the audio mode will mute and will
stay muted until the active call is ended.
The INFINITI Voice Recognition system
supports the phone commands, so dialing
a phone number using your voice is
possible.
Before using the Bluetooth ®
Hands-Free
Phone System, refer to the following notes.
. Wireless LAN (Wi-Fi) and the Bluetooth ®
functions share the same frequency
band (2.4 GHz). Using the Bluetooth ®and the wireless LAN functions at the
same time may slow down or discon-
nect the communication and cause
undesired noise. It is recommended
that you turn off the wireless LAN (Wi-
Fi) when using the Bluetooth ®
func-
tions.
. Set up the wireless connection between
a cellular phone and the in-vehicle
phone module before using the Blue-
tooth ®
Hands-Free Phone System.
. Some Bluetooth ®
enabled cellular
phones may not be recognized by the
in-vehicle phone module.
. You will not be able to use a hands-free
phone under the following conditions:
— Your vehicle is outside of the tele-
phone service area.
— Your vehicle is in an area where it is
difficult to receive radio waves; such
as in a tunnel, in an underground
parking garage, behind a tall build-
ing or in a mountainous area.
— Your cellular phone is locked in
order not to be dialed.
. When the radio wave condition is not
ideal or ambient sound is too loud, it
may be difficult to hear the other
person ’ s voice during a call.Bluetooth ®
HANDS-FREE PHONE SYSTEM
(models without navigation system) (if so
equipped)

Black plate (279,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. Immediately after the ignition switch is
pushed to the “ ON ” position, it may be
impossible to receive a call for a short
period of time.
. Do not place the cellular phone in an
area surrounded by metal or far away
from the in-vehicle phone module to
prevent tone quality degradation and
wireless connection disruption.
. While a cellular phone is connected
through the Bluetooth ®
wireless con-
nection, the battery power of the
cellular phone may discharge quicker
than usual.
. If the Bluetooth ®
Hands-Free Phone
System seems to be malfunctioning,
please contact an INFINITI retailer.
. Some cellular phones or other devices
may cause interference or a buzzing
noise to come from the audio system
speakers. Storing the device in a
different location may reduce or elim-
inate the noise.
. Refer to the cellular phone Owner ’ s
Manual regarding the telephone pairing
procedure specific to your phone,
battery charging, cellular phone anten-
na, etc. . The antenna display on the monitor will
not coincide with the antenna display
of some cellular phones.
. Keep the interior of the vehicle as quiet
as possible to hear the caller ’ s voice
clearly as well as to minimize its
echoes.
. If reception between callers is unclear,
adjusting the incoming or outgoing call
volume may improve the clarity.
. This wireless hands free car kit is based
on Bluetooth ®
technology,
— Frequency: 2402 MHz - 2480 MHz
— Output Power: 4.14 dBm E.I.R.P
— Modulation: FHSS GFSK 8DPSK, p /
4DQPSK
— Number of Channel: 79
— This wireless equipment can ’ t be
used for any services related to
safety because there is the possibi-
lity of radio interference. REGULATORY INFORMATION GUID-C749FDCB-737E-4519-B4F3-DFCB7CB3B425
FCC Regulatory information GUID-65EE5CA7-E4CB-455D-AF2F-D3892B1FD807
. CAUTION: To maintain compliance with
FCC ’ s RF exposure guidelines, use only
the supplied antenna. Unauthorized
antenna, modification, or attachments
could damage the transmitter and may
violate FCC regulations.
. Operation is subject to the following
two conditions:
1) this device may not cause interfer-
ence and
2) this device must accept any inter-
ference, including interference that
may cause undesired operation of
the device
IC Regulatory information GUID-D2159791-E888-41E9-AB71-827684C5E939
. Operation is subject to the following
two conditions: (1) this device may not
cause interference, and (2) this device
must accept any interference, including
interference that may cause undesired
operation of the device.
. This Class B digital apparatus meets all
requirements of the Canadian Interfer-
ence-Causing Equipment Regulations.
Monitor, climate, audio, phone and voice recognition systems
4-101
