fuel INFINITI M 2013 Quick Reference Guide

table of contents
new system features Rear Sonar System (if so equipped) ................................ 2
InFInItI c onnection™ System (if so equipped) ....................... 2
Automatic Anti-glare Mirrors ...................................... 3
Forest Air
® System (if so equipped) ................................ 4
Blind Spot warning (BS w) and Blind Spot Intervention™ (BSI)
(if so equipped) ................................................ 4
ec O pedal System (if so equipped) ................................ 4

essential information
Loose Fuel c ap ................................................. 5
tire pressure Monitoring System (tpMS) ............................ 5
w arning Systems Switch (if so equipped) ........................... 6
Infiniti drive Mode Selector ...................................... 6
Accessing the Front c up holders................................... 6

first drive features
InFInItI Intelligent k ey™ System.................................. 7
t runk Lid Release ............................................... 8
Seat Adjustments ............................................... 8
Automatic drive p ositioner ....................................... 9
Outside Mirror c ontrol Switch ..................................... 9
Starting/Stopping the engine .................................... 10
headlight control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . 10
w indshield wiper/w asher Switch ................................. 11
Automatic c limate controls (if so equipped) ........................ 12
FM/AM/SiriusxM
™ Satellite Radio with cd/dvd player (if so equipped) .... 14
uSB/ip od® Interface ........................................... 15
c onventional (Fixed Speed) c ruise control ......................... 15
Intelligent c ruise control (Icc) System (if so equipped) ...............16
Fuel-Filler door ................................................ 17

system guide
t rip c omputer ................................................. 18
Bluetooth
® hands-free phone System ............................. 18
System Operating tips ....................................... 18
Bluetooth
® System with navigation (if so equipped) ...............19
Bluetooth® System without navigation (if so equipped) . . . . . . . . . . . .21
navigation System (if so equipped) ............................... 22
dvd player (if so equipped) ...................................... 23
homeLink
® universal t ransceiver ................................. 24
Additional information about your vehicle is also available in your Owner’s Manual,
Navigation System Owner’s Manual and at www.InfinitiUSA.com.
• A cellular telephone should not be used for any purpose while driving so full attention
may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured in child
restraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental
restraint system (section 1)”, “Monitor, climate, audio, phone and voice recognition
systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.

4
Forest Air® System (if so equipped)
this system helps keep the air inside your vehicle
clean using an automatic air intake and ventilation
system that monitors air quality with outside and
inside sensors.

Automatic humidity control prevents over-drying of
the passenger compartment and fogging of the
windshield. when the system is On, the defroster
may automatically turn on.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.
ECO Pedal System (if so equipped)

with the Infiniti drive Mode Selector switch
01 in
the ECO Mode, the ec O pedal system assists the
driver in improving fuel economy.

the ec O pedal system applies force to make the
accelerator pedal heavier depending on the
accelerator pedal operation.
For more information, refer to the “Starting and driving (section 5)” of your
Owner’s Manual.
Blind Spot Warning (BSW) and Blind Spot Intervention™ (BSI) (if so equipped)

the Blind Spot warning (BSw) system alerts the
driver when another vehicle moves into the vehicle’s
blind spot area.

An indicator light
01 near the driver’s outside mirror

will illuminate if the radar sensors detect a vehicle in
the detection zone.

the Blind Spot Intervention™ (BSI) system can assist
the driver in returning the vehicle to the center of the
traveling lane by applying individual brake pressure
to the left or right wheels for a short period of time.

the indicator light
02 will first illuminate in orange and
then turn green before turning off. this indicates that
the Blind Spot warning (BSw) and Blind Spot Intervention (BSI) systems are operational.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
01
02
01
new system features

5
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear in the
dot matrix liquid crystal display

01 when the fuel-
filler cap is not tightened correctly.

to tighten, turn the cap clockwise until a single click
is heard.

the warning message will disappear when the vehicle
detects the fuel-filler cap is properly tightened and the
reset button

02 is pressed for more than 1 second.

If the cap is not properly tightened, the Malfunction
Indicator Light

may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and
the
“Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Tire Pressure Monitoring System (TPMS)

A ChECk tIRE PRESSURE warning message will
appear in the dot matrix liquid crystal display

01
and the low tire pressure warning light
02 will

illuminate when one or more tires are low on
pressure and air is needed.
• The tire pressures should be checked when the
tires are cold. the tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mile (1.6km) at moderate speeds.

After tire pressures are adjusted, drive the vehicle
at speeds above 16 Mph (25km/h). the ChECk tIRE
PRESSURE warning message and low tire pressure warning light will disappear.

when the low tire pressure warning light flashes for 1 minute and then remains on, the tpMS
is not functioning properly. have the system checked by an InFInItI retailer.

tire pressure rises and falls depending on the heat caused by the vehicle’s operation and the
outside temperature. Low outside temperature can lower the temperature of the air inside the
tire, which can cause a lower tire inflation pressure. this may cause the low tire pressure
warning light to illuminate. If the warning light illuminates in low ambient temperature, check
the tire pressure in your tires.
• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

the tire and Loading Information label contains valuable information. please refer to section 9,
“technical and consumer information”, in your Owner’s Manual for the location of the tire
and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, “Starting and driving (section 5)” and the “Maintenance
and do-it-yourself (section 8)” of your Owner’s Manual.
01
02
01
02
essential information

essential information
6
Warning Systems Switch (if so equipped)
the warning systems switch
01 will turn the Lane
d eparture warning (Ldw), Blind Spot warning (BS w)
and Forward c ollision warning (Fcw) systems on or off.

when the warning systems switch is turned off, the
indicator

02 on the switch is off. If the warning
systems switch is illuminated, the system is on. the
indicator will also be off if all of the warning systems
are deactivated using the settings menu.

to enable or disable these systems, perform the
following operation:
1. press the SEttING button

03 on the control panel.
2. using the InFInItI c ontroller

04 , highlight the
“driver Assistance” key
05 on the display.
then
press the ENtER button
06 .

3. highlight the corresponding warning system key


07 , select On (enabled) or OFF (disabled) and
press the ENtER button.
For more information, refer to the “Starting and driving (section 5)” of your
Owner’s Manual.
01
02
03
04
06
05
07
Accessing the Front Cup Holders
to open the cup holders, push the
lid

01 down and release.

For more information, refer to the “Instruments and
controls (section 2)” of your Owner’s Manual. 01
Infiniti Drive Mode Selector
turn the switch to the following position to select the
corresponding drive mode:
01 Standard (•) - for standard or normal
driving.
02 SPOR
t - the engine and transmission will adjust, resulting
in higher engine rpm and a more aggressive shift pattern. In this mode, fuel economy may be reduced.
03 SNOW – u
sed on snowy roads or slippery areas. In this mode, engine output is controlled to
avoid wheel spin.
04 ECO
– Adjusts engine and transmission points to enhance fuel economy.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
0102
03
04

Fuel-Filler Door
the fuel-filler door is located on the passenger’s side of
the vehicle.

when the doors of the vehicle are locked or unlocked,
the fuel-filler door is automatically locked or unlocked
at the same time.

to open the door, once unlocked, push the upper left
side of the door.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
17

system guide
18
Trip Computer
when the
button
01 is pressed, the following
modes will appear on the dot matrix liquid crystal
display

02 :
• MPG – displays the current fuel consumption.
• MPG/MPh – displays the average fuel consumption
and speed since the last reset.
• tIME/MILES – displays the elapsed time and total
distance the vehicle has been driven since the
last reset.
• RANGE – displays the estimated distance to empty
(dte) the vehicle can be driven before refueling.
• OUtSIDE tEMP – displays the exterior air
temperature including a low temperature
warning feature.
• SEttING – Allows you to set reminders for alerts and maintenance intervals or change the
language and units used in the system.
— press the

button
03 to cycle through the various setting modes.

— press the

button
01 to choose the selected menu.

• WARNING – If there are any.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
Bluetooth® Hands-free Phone System

with an overhead microphone and sound
transmitted through the audio system speakers,
the Bluetooth
® hands-free phone System utilizes
Bluetooth wireless technology and voice recognition
to provide hands-free cellular phone communication.

A cellular telephone should not be used while driving
so full attention may be given to vehicle operation.*
S yS teM OpeRA tInG tIpS

close all windows. Surrounding noises may interfere
with system operation and performance.

press the
or
button on the steering wheel to
activate voice recognition.

wait for the tone before speaking.

Begin speaking a command within 5 seconds of the tone.
03
01
02
Bluetooth® Controls
Microphone
*Some jurisdictions prohibit the use of cellular telephones while driving.

23
07 MAP – press to display the map.
while following a programmed route, press multiple times to
change the type of route information.
08 S
tAt US – press multiple times to display audio information, the air conditioner status, fuel
economy or navigation directions.
09 – press to switch between the day screen (bright) and the night screen (dark). press and
hold the button to turn the display off. press again to turn the display on.
10 BAC k – press to return to the previous screen. In a settings screen, this button can also be
used to apply the setting. In a character input screen, this button can also delete the characters
that have been entered.
11 VOICE – press to hear the current voice guidance for a programmed route.

For more information, please refer to your navigation System Owner’s Manual.
DVD Player (if so equipped)

this system allows you to play video files via a dvd
or cd from the front display.

to view movies on the front display, stop the vehicle
in a safe location, move the shift lever to the P (PARk)
position and apply the parking brake.

to reduce driver distraction, movies will not be shown
on the front display while the vehicle is in any drive
position.
For more information, refer to the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
