INFINITI M35 2007 Factory Service Manual

AT-82
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
45
Slips/Will
Not
EngageWith selector lever in
“D” position, driving is
not possible.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Line pressure testAT- 5 5
3. PNP switchAT- 11 3
4. A/T positionAT- 2 2 7
5. Control valve with TCMAT- 2 3 6
OFF vehicle6. Torque converterAT- 3 0 1
7. Oil pump assemblyAT- 3 2 2
8. 1st one-way clutchAT- 3 3 3
9. Gear systemAT- 2 8 1
10. Reverse brakeAT- 3 0 1
11. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-Sectional View (VQ35DE Models for 2WD)" ,
AT-18, "
Cross-Sectional View (VK45DE Models for 2WD)" or
AT-19, "
Cross-Sectional View (AWD Models)" .)AT- 3 0 1
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT-18,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT-19,
"Cross-Sectional View (AWD Models)" .)AT- 3 0 1
46With selector lever in
“R” position, driving is
not possible.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Line pressure testAT- 5 5
3. PNP switchAT- 11 3
4. A/T positionAT- 2 2 7
5. Control valve with TCMAT- 2 3 6
OFF vehicle6. Gear systemAT- 2 8 17. Output shaftAT- 3 0 1
8. Reverse brakeAT- 3 0 1
47Does Not
ChangeDoes not change M5
→ M4.
Refer to AT-214, "A/T
Does Not Shift: 5th
Gear → 4th Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT- 2 2 7
4. Manual mode switchAT- 1 6 7
5. ATF pressure switch 1AT- 1 7 2
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle 8. Front brake (brake band)AT- 3 0 1
No. Item Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-83
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M4548
Does Not
ChangeDoes not change M4
→ M3.
Refer to AT-215, "A/T
Does Not Shift: 4th
Gear → 3rd Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 1 and ATF pressure switch 3AT-172,
AT-174
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Front brake (brake band)AT-3019. Input clutchAT-327
49Does not change M3
→ M2.
Refer to AT-217, "A/T
Does Not Shift: 3rd
Gear → 2nd Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 6AT-178
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Front brake (brake band)AT-3019. Input clutchAT-327
10. High and low reverse clutchAT-339
50Does not change M2
→ M1.
Refer to AT-218, "A/T
Does Not Shift: 2nd
Gear → 1st Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 5AT-176
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Input clutchAT-3279. High and low reverse clutchAT-339
10. Direct clutchAT-341
51Cannot be changed to
manual mode.
Refer to AT-213,
"Cannot Be Changed
to Manual Mode" .ON vehicle1. Manual mode switchAT-167
2. Turbine revolution sensorAT- 11 7
3. CAN communication lineAT-105
52 OthersShift point is high in
“D” position.ON vehicle1. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9
,
AT-140
2. Accelerator pedal position sensorAT-132
3. CAN communication lineAT-105
4. A/T fluid temperature sensorAT-135
5. Control valve with TCMAT-236
No. Item Symptom Condition Diagnostic ItemReference
page

AT-84
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
53
OthersShift point is low in “D”
position.ON vehicle1. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9
,
AT- 1 4 0
2. Accelerator pedal position sensorAT- 1 3 2
3. CAN communication lineAT- 1 0 5
4. Control valve with TCMAT- 2 3 6
54Judder occurs during
lock-up.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. Turbine revolution sensorAT- 11 7
4. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9,
AT- 1 4 0
5. Accelerator pedal position sensorAT- 1 3 2
6. CAN communication lineAT- 1 0 5
7. Torque converter clutch solenoid valveAT- 1 2 6
8. Control valve with TCMAT- 2 3 6
OFF vehicle 9. Torque converterAT- 3 0 1
55Strange noise in “R”
position.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. CAN communication lineAT- 1 0 5
4. Control valve with TCMAT- 2 3 6
OFF vehicle5. Torque converterAT- 3 0 1
6. Oil pump assemblyAT- 3 2 2
7. Gear systemAT- 2 8 1
8. High and low reverse clutchAT- 3 3 9
9. Reverse brakeAT- 3 0 1
56Strange noise in “N”
position.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. CAN communication lineAT- 1 0 5
4. Control valve with TCMAT- 2 3 6
OFF vehicle5. Torque converterAT- 3 0 16. Oil pump assemblyAT- 3 2 2
7. Gear systemAT- 2 8 1
No. Item Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-85
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
57
OthersStrange noise in “D”
position.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT-124
3. CAN communication lineAT-105
4. Control valve with TCMAT-236
OFF vehicle5. Torque converterAT-301
6. Oil pump assemblyAT-322
7. Gear systemAT-281
8. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT- 1 8 ,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT- 1 9 ,
"Cross-Sectional View (AWD Models)" .)AT-301
58Vehicle dose not
decelerate by engine
brake.
Refer to AT-220,
"Vehicle Does Not
Decelerate by Engine
Brake" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 5AT-176
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Input clutchAT-3279. High and low reverse clutchAT-339
10. Direct clutchAT-341
59Engine brake does
not work M5 → M4.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 1AT-172
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle 8. Front brake (brake band) AT-301
60Engine brake does
not work M4 → M3.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 1 and ATF pressure switch 3AT-172,
AT-174
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Front brake (brake band)AT-3019. Input clutchAT-327
No. Item Symptom Condition Diagnostic ItemReference
page

AT-86
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
61
OthersEngine brake does
not work M3 → M2.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT- 2 2 7
4. Manual mode switchAT- 1 6 7
5. ATF pressure switch 6AT- 1 7 8
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle8. Front brake (brake band)AT- 3 0 19. Input clutchAT- 3 2 7
10. High and low reverse clutchAT- 3 3 9
62Engine brake does
not work M2 → M1.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT- 2 2 7
4. Manual mode switchAT- 1 6 7
5. ATF pressure switch 5AT- 1 7 6
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle8. Input clutchAT- 3 2 79. High and low reverse clutchAT- 3 3 9
10. Direct clutchAT- 3 4 1
63 Maximum speed low.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Line pressure testAT- 5 5
3. Accelerator pedal position sensorAT- 1 3 2
4. CAN communication lineAT- 1 0 5
5. Direct clutch solenoid valveAT- 1 5 5
6. Control valve with TCMAT- 2 3 6
OFF vehicle7. Torque converter AT- 3 0 1
8. Oil pump assemblyAT- 3 2 2
9. Input clutchAT- 3 2 7
10. Gear systemAT- 2 8 1
11. High and low reverse clutchAT- 3 3 9
12. Direct clutchAT- 3 4 1
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-Sectional View (VQ35DE Models for 2WD)" ,
AT-18, "
Cross-Sectional View (VK45DE Models for 2WD)" or
AT-19, "
Cross-Sectional View (AWD Models)" .)AT- 3 0 1
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT-18,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT-19,
"Cross-Sectional View (AWD Models)" .)AT- 3 0 1
No. Item Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-87
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M4564
OthersExtremely large
creep.ON vehicle1. Engine idle speed EC-83
(for
VQ35DE
engine),
EC-785

(for
VK45DE
engine)
2. CAN communication lineAT-105
3. ATF pressure switch 5AT-176
OFF vehicle 4. Torque converterAT-301
65With selector lever in
“P” position, vehicle
does not enter parking
condition or, with
selector lever in
another position, park-
ing condition is not
cancelled.
Refer to AT-191, "
In
“P” Position, Vehicle
Moves When Pushed"
.ON vehicle1. PNP switchAT- 11 3
2. A/T positionAT-227
OFF vehicle 3. Parking componentsAT-250

(2WD
models) or
AT-301

(AWD
models)
66Vehicle runs with A/T
in “P” position.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Control valve with TCMAT-236
OFF vehicle5. Parking componentsAT-250

(2WD
models) or
AT-301

(AWD
models)
6. Gear systemAT-281
67Vehicle runs with A/T
in “N” position.
Refer to AT-192, "In
“N” Position, Vehicle
Moves" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Control valve with TCMAT-236
OFF vehicle5. Input clutchAT-327
6. Gear systemAT-281
7. Direct clutchAT-341
8. Reverse brakeAT-301
9. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-Sectional View (VQ35DE Models for 2WD)" ,
AT- 1 8 , "
Cross-Sectional View (VK45DE Models for 2WD)" or
AT- 1 9 , "
Cross-Sectional View (AWD Models)" .)AT-301
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT- 1 8 ,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT- 1 9 ,
"Cross-Sectional View (AWD Models)" .)AT-301
No. Item Symptom Condition Diagnostic ItemReference
page

AT-88
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
68
OthersEngine does not start
in “N” or “P” position.
Refer to AT-190, "Engine Cannot Be
Started in “P” or “N”
Position" .ON vehicle1. Push-button ignition switch and starterPG-3
, SC-
8
2. A/T positionAT- 2 2 7
3. PNP switchAT- 11 3
69Engine starts in posi-
tions other than “N” or
“P”.ON vehicle1. Push-button ignition switch and starterPG-3
, SC-
8
2. A/T positionAT- 2 2 7
3. PNP switchAT- 11 3
70 Engine stall.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. Turbine revolution sensorAT- 11 7
4. Torque converter clutch solenoid valveAT- 1 2 6
5. CAN communication lineAT- 1 0 5
6. Control valve with TCMAT- 2 3 6
OFF vehicle 7. Torque converterAT- 3 0 1
71Engine stalls when
selector lever shifted
“N” → “D”or “R”.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. Turbine revolution sensorAT- 11 7
4. Torque converter clutch solenoid valveAT- 1 2 6
5. CAN communication lineAT- 1 0 5
6. Control valve with TCMAT- 2 3 6
OFF vehicle 7. Torque converterAT- 3 0 1
72Engine speed does
not return to idle.
Refer to AT-212,
"Engine Speed Does
Not Return to Idle" .ON vehicle1. A/T fluid level and stateAT- 5 3
2. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 7 6,
AT- 1 5 5

3. ATF pressure switch 1 and front brake solenoid valveAT- 1 7 2
,
AT- 1 5 1
4. Accelerator pedal position sensorAT- 1 3 2
5. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9,
AT- 1 4 0
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle8. Front brake (brake band)AT- 3 0 19. Direct clutchAT- 3 4 1
No. Item Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-89
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
TCM Input/Output Signal Reference ValuesNCS001KG
A/T ASSEMBLY HARNESS CONNECTOR TERMINAL LAYOUT
TCM INSPECTION TABLE
Data are reference value and are measured between each terminal and ground.
SCIA1658E
TerminalWire
colorItem Condition Data (Approx.)
1R/WPower supply
(Memory back-up)Always Battery voltage
2R/WPower supply
(Memory back-up)Always Battery voltage
3 L CAN-H – –
4VK-line (CONSULT-
II signal)The terminal is connected to the data link connector for CONSULT-II. –
5 B Ground Always 0 V
6 Y/R Power supply– Battery voltage
–0 V
7R/LBack-up lamp
relaySelector lever in “R” position. 0 V
Selector lever in other positions. Battery voltage
8 P CAN-L – –
9GR/RStarter relaySelector lever in “N”, “P” positions. Battery voltage
Selector lever in “R”, “D” positions. 0 V
10 B Ground Always 0 V

AT-90
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
CONSULT-II Function (A/T)NCS001KH
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
FUNCTION
CONSULT-II REFERENCE VALUE
NOTICE:
1. The CONSULT-II electrically displays shift timing and lock-up timing (that is, operation timing of each sole-
noid).
Check for time difference between actual shift timing and the CONSULT-II display. If the difference is
noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) displayed on CONSULT-II and that indicated in Service Man-
ual may differ slightly. This occurs because of the following reasons:
–Actual shift schedule has more or less tolerance or allowance,
–Shift schedule indicated in Service Manual refers to the point where shifts start, and
–Gear position displayed on CONSULT-II indicates the point where shifts are completed.
3. Display of solenoid valves on CONSULT-II changes at the start of shifting, while gear position is displayed
upon completion of shifting (which is computed by TCM).
Diagnostic test mode Function Reference page
Self-diagnostic results Self-diagnostic results can be read and erased quickly.AT- 9 2
Data monitor Input/Output data in the ECU can be read.AT- 9 6
CAN diagnostic support
monitorThe results of transmit/receive diagnosis of CAN communication can be read.AT- 1 0 0
Function testPerformed by CONSULT-II instead of a technician to determine whether each system
is “OK” or “NG”.—
DTC work support Select the operating condition to confirm Diagnostic Trouble Codes.AT- 1 0 0
ECU part number ECU part number can be read. —
Item name Condition Display value
(Approx.)
VHCL/S SE-A/T
During drivingApproximately
matches the speed
meter reading. VHCL/S SE-MTR
ACCELE POSIReleased accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
CLSD THL POSReleased accelerator pedal. ON
Fully depressed accelerator pedal. OFF
W/O THL POSFully depressed accelerator pedal. ON
Released accelerator pedal. OFF
BRAKE SWDepressed brake pedal. ON
Released brake pedal. OFF
ENGINE SPEED Engine runningClosely matches the
tachometer reading.
TURBINE REV During driving (lock-up ON)Approximately
matches the engine
speed.
ATF TEMP SE 1
0°C (32° F) - 20°C (68°F) - 80°C (176°F)3.3 - 2.7 - 0.9 V
ATF TEMP SE 23.3 - 2.5 - 0.7 V
TCC SOLENOID Lock-up is active 0.4 - 0.6 A
LINE PRES SOL During driving 0.2 - 0.6 A

TROUBLE DIAGNOSIS
AT-91
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
FR/B SOLENOIDFront brake engaged. Refer to AT- 2 1 . 0.6 - 0.8 A
Front brake disengaged. Refer to AT- 2 1
. 0 - 0.05 A
I/C SOLENOIDInput clutch disengaged. Refer to AT- 2 1
. 0.6 - 0.8 A
Input clutch engaged. Refer to AT- 2 1
. 0 - 0.05 A
D/C SOLENOIDDirect clutch disengaged. Refer to AT- 2 1
. 0.6 - 0.8 A
Direct clutch engaged. Refer to AT- 2 1
. 0 - 0.05 A
HLR/C SOLHigh and low reverse clutch disengaged. Refer to AT- 2 1
. 0.6 - 0.8 A
High and low reverse clutch engaged. Refer to AT- 2 1
. 0 - 0.05 A
STARTER RELAYSelector lever in “N”, “P” positions. ON
Selector lever in “R”, “D” positions. OFF
SLCT LVR POSISelector lever in “N”, “P” positions. N/P
Selector lever in “R” position. R
Selector lever in “D” position. D
ON OFF SOLLow coast brake engaged. Refer to AT- 2 1
.ON
Low coast brake disengaged. Refer to AT- 2 1
.OFF
ATF PRES SW 1Front brake engaged. Refer to AT- 2 1
.ON
Front brake disengaged. Refer to AT- 2 1
.OFF
ATF PRES SW 2Low coast brake engaged. Refer to AT- 2 1
.ON
Low coast brake disengaged. Refer to AT- 2 1
.OFF
ATF PRES SW 3Input clutch engaged. Refer to AT- 2 1
.ON
Input clutch disengaged. Refer to AT- 2 1
.OFF
ATF PRES SW 5Direct clutch engaged. Refer to AT- 2 1
.ON
Direct clutch disengaged. Refer to AT- 2 1
.OFF
ATF PRES SW 6High and low reverse clutch engaged. Refer to AT- 2 1
.ON
High and low reverse clutch disengaged Refer to AT- 2 1
.OFF
MANU MODE SWManual shift gate position (neutral) ON
Other than the above OFF
NON M-MODE SWManual shift gate position OFF
Other than the above ON
UP SW LEVERSelector lever: + side ON
Other than the above OFF
DOWN SW LEVERSelector lever: - side ON
Other than the above OFF
GEAR During driving 1, 2, 3, 4, 5Item name Condition Display value
(Approx.)
