TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-41
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
14ECM CIRCUIT
[C1A14]××××

ECM malfunction.

Accelerator pedal position sensor
malfunction.

ICC sensor integrated unit mal-
function.ACS-56
15GEAR POSITION
[C1A15]×××

TCM malfunction.

A/T turbine revolution sensor mal-
function.

A/T vehicle speed sensor mal-
function.ACS-57
16RADAR STAIN
[C1A16]×× ×
ICC sensor integrated unit body
window has contamination.ACS-58
18LASER AIMING INCMP
[C1A18]×× ×
Laser beam aiming of ICC sensor
integrated unit is not adjusted.ACS-58
21UNIT HIGH TEMP
[C1A21]×× ×
Temperature around ICC sensor
integrated unit is excessively high.ACS-58
24NP RANGE
[C1A24]×××

Park/neutral position switch mal-
function.

TCM malfunction.ACS-59
25 SHIFT RANGE IND
[C1A25]×××
TCM malfunction.ACS-59
26ECD MODE MALF
[C1A26]×××

ABS actuator and electric unit
(control unit) malfunction.

ICC sensor integrated unit mal-
function.ACS-60
27ECD PWR SUPLY CIR
[C1A27]××××

ABS actuator and electric unit
(control unit) power supply voltage
is excessively low.

ABS actuator and electric unit
(control unit) malfunction.ACS-60
55NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.
No malfunction item has been
detected. —
100CAN COMM CIRCUIT
[U1000]××××

ICC sensor integrated unit detects
CAN communication malfunction.ACS-61
11 0CONTROL UNIT (CAN)
[U1010]××××

ICC sensor integrated unit detects
malfunction by CAN initial diagno-
sis.ACS-61
DTC
No.CONSULT-II
screen termsICC
system
warning
lampFail-safe
Malfunctions detected where...Refer-
ence
page Vehicle-
to-
vehicle
distance
control
modeConven-
tional
(fixed
speed)
cruise
control
modeBrake
assist
(with
preview
function)

ACS-42
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
DTC 0 CONTROL UNITNKS004D0
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if any item other than “CONTROL UNIT [C1A00]” (DTC 0) is indicated on self-diagnosis display.
Is any indicated?
YES >> 1. Repair or replace applicable item. Refer to ACS-40, "Diagnostic Trouble Code (DTC) Chart" .
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 1 POWER SUPPLY CIR, DTC 2 POWER SUPPLY CIR 2NKS004D1
1. CHECK CONNECTOR ICC SENSOR INTEGRATED UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC sensor integrated unit connector, and connect it securely again.
3. Erase DTC and perform ICC running test. Then perform self-diagnosis of ICC system again.
4. Check if “POWER SUPPLY CIR [C1A01]” (DTC 1) or “ POWER SUPPLY CIR 2 [C1A02]” (DTC 2) is indi-
cated in self-diagnosis item in the display.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter-
minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
2. CHECK POWER SUPPLY CIRCUIT FOR ICC SENSOR INTEGRATED UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC sensor integrated unit connector.
3. Turn ignition switch ON.
4. Check voltage between ICC sensor integrated unit harness con-
nector and ground.
OK or NG
OK >> GO TO 3.
NG >> 1. Repair or replace ICC sensor integrated unit power
supply harness or fuse.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
Terminals
Voltag e
(Approx.) (+)
(–)
ICC sensor integrated
unit connectorTerminal
E61 1 Ground Battery voltage
PKIB8375E

ACS-44
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
2. PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ABS” self-diagnosis. Refer to BRC-23, "
CONSULT-II Functions (ABS)" .
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 5 BRAKE SW/STOP L SWNKS004D4
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “BRAKE SW/STOP L SW [C1A05]” (DTC
5) is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK ICC BRAKE SWITCH WITH ICC DATA MONITOR
With CONSULT-II
With “ICC” “DATA MONITOR”, check if “BRAKE SW” operates normally.
OK or NG
OK >> GO TO 3.
NG >> GO TO 6.
3. CHECK STOP LAMP SWITCH WITH ABS DATA MONITOR
With CONSULT-II
With “ABS” “DATA MONITOR”, check if “STOP LAMP SW” operates normally.
OK or NG
OK >> GO TO 4.
NG >> GO TO 11.
4. PERFORM ECM SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ENGINE” self-diagnosis. Refer to EC-123, "
CONSULT-II Function (ENGINE)" (for VQ35DE) or
EC-826, "
CONSULT-II Function (ENGINE)" (for VK45DE).
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> GO TO 5.

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-45
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
5. PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ABS” self-diagnosis. Refer to BRC-23, "
CONSULT-II Functions (ABS)" .
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
6. CHECK ICC BRAKE SWITCH INSTALLATION AND ADJUSTMENT
Check ICC brake switch for proper installation, and adjust the switch if necessary. Refer to BR-6, "
BRAKE
PEDAL" .
OK or NG
OK >> GO TO 7.
NG >> 1. Adjust ICC brake switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
7. CHECK ICC BRAKE SWITCH
Check ICC brake switch. Refer to ACS-69, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> GO TO 8.
NG >> 1. Replace ICC brake switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
8. CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ICC brake switch connector.
3. Turn ignition switch ON.
4. Check voltage between ICC brake switch harness connector
and ground.
OK or NG
OK >> GO TO 9.
NG >> 1. Repair or replace harness or fuse.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
Terminals
Voltage
(Approx.) (+)
(–)
ICC brake switch
connectorTe r m i n a l
E111 1 Ground Battery voltage
PKIB9335E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-47
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
13. CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch connector.
3. Turn ignition switch ON.
4. Check voltage between stop lamp switch harness connector and
ground.
OK or NG
OK >> GO TO 14.
NG >> 1. Repair or replace harness or fuse.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
14. CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT)
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check continuity between stop lamp switch harness connector
(A) and ABS actuator and electric unit (control unit) harness
connector (B).
4. Check continuity between stop lamp switch harness connector
(A) and ground.
OK or NG
OK >> 1. Perform “ABS” self-diagnosis. Refer to BRC-23, "CONSULT-II Functions (ABS)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace harness between stop lamp switch and ABS actuator and electric unit (control
unit).
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
Terminals
Voltage
(Approx.) (+)
(–)
Stop lamp switch
connectorTe r m i n a l
E124 3 Ground Battery voltage
PKIC0833E
AB
Continuity
Connector Terminal Connector Terminal
E124 4 E30 30 Yes
A
GroundContinuity
Connector Terminal
E124 4 No
PKIC0834E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-55
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
19. PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ABS” self-diagnosis. Refer to BRC-23, "
CONSULT-II Functions (ABS)" .
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
20. CHECK STOP LAMP SWITCH INSTALLATION AND ADJUSTMENT
Check stop lamp switch for proper installation, and adjust the switch if necessary. Refer to BR-6, "
BRAKE
PEDAL" .
OK or NG
OK >> GO TO 21.
NG >> 1. Adjust stop lamp switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
21. CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to ACS-69, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> GO TO 22.
NG >> 1. Replace stop lamp switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
22. CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch connector.
3. Turn ignition switch ON.
4. Check voltage between stop lamp switch harness connector and
ground.
OK or NG
OK >> GO TO 23.
NG >> 1. Repair or replace harness or fuse.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
Terminals
Voltage
(Approx.) (+)
(–)
Stop lamp switch
connectorTe r m i n a l
E124 3 Ground Battery voltage
PKIC0833E

ACS-56
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
23. CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT)
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check continuity between stop lamp switch harness connector
(A) and ABS actuator and electric unit (control unit) harness
connector (B).
4. Check continuity between stop lamp switch harness connector
(A) and ground.
OK or NG
OK >> 1. Perform “ABS” self-diagnosis. Refer to BRC-23, "CONSULT-II Functions (ABS)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace harness between stop lamp switch and ABS actuator and electric unit (control
unit).
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 14 ECM CIRCUITNKS004D8
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “ECM CIRCUIT [C1A14]” (DTC 14) is indi-
cated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. PERFORM ECM SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ENGINE” self-diagnosis. Refer to EC-123, "
CONSULT-II Function (ENGINE)" (for VQ35DE) or
EC-826, "
CONSULT-II Function (ENGINE)" (for VK45DE).
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
AB
Continuity
Connector Terminal Connector Terminal
E124 4 E30 30 Yes
A
GroundContinuity
Connector Terminal
E124 4 No
PKIC0834E

ACS-60
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
DTC 26 ECD MODE MALFNKS004DF
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “ECD MODE MALF [C1A26]” (DTC 26) is
indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ABS” self-diagnosis. Refer to BRC-23, "
CONSULT-II Functions (ABS)" .
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 27 ECD PWR SUPLY CIRNKS004DG
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “ECD PWR SUPLY CIR [C1A27]” (DTC
27) is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY CIRCUIT
With CONSULT-II
Check ABS actuator and electric unit (control unit) power supply circuit. Refer to BRC-37, "
ABS Actuator and
Electric Unit (Control Unit) Power Supply and Ground Circuit" .
OK or NG
OK >> 1. Perform “ABS” self-diagnosis. Refer to BRC-23, "CONSULT-II Functions (ABS)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-61
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
DTC 100 CAN COMM CIRCUITNKS004DH
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis.
2. Print self-diagnostic result.
>> After printing self-diagnostic result, go to “CAN system”. Refer to LAN-42, "
Precautions When
Using CONSULT-II" .
DTC 110 CONTROL UNIT (CAN)NKS004DI
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis.
2. Print self-diagnostic result.
3. Erase DTC and perform ICC running test. Then perform self-diagnosis of ICC system again.
4. Check if “CONTROL UNIT (CAN) [U1010]” (DTC 110) is indicated in self-diagnosis item in the display.
Is malfunction indicated?
YES >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> INSPECTION END

ACS-62
[ICC]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2007 April2007 M35/M45
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Symptom ChartNKS004DJ
Symptoms Reference page
OperationMAIN switch does not switch ON.Symptom 1
ACS-63
MAIN switch does not switch OFF.Symptom 1
ACS-63
Cruise does not function for setting (powering functions).Symptom 2
ACS-64
CANCEL switch does not function.Symptom 3
ACS-65
Resume does not function.Symptom 3
ACS-65
Set speed does not increase.Symptom 3
ACS-65
Set distance to the vehicle ahead cannot be changed.Symptom 3
ACS-65
ICC is not cancelled when the A/T selector lever is in other than
“D” and “M”.Symptom 4
ACS-65
Display/ChimeDot matrix LCD does not appear.Check combination meter. Refer to DI-18, "Trouble Diagnosis" .
Chime does not function.Symptom 5
ACS-66
Control Driving force is hunting.Symptom 6
ACS-67
Function to detect
the vehicle aheadSystem frequently cannot detect the vehicle ahead.Symptom 7
ACS-67
Distance to detect the vehicle ahead is short.Symptom 7
ACS-67
System misidentifies a vehicle even though there is no vehicle
ahead.

Refer to ACS-15, "LASER BEAM AIMING
ADJUSTMENT" .

Refer to ACS-12, "ICC System Running
Te s t" .
System misidentifies a vehicle in the next lane.

Refer to ACS-15, "LASER BEAM AIMING
ADJUSTMENT" .

Refer to ACS-12, "ICC System Running
Te s t" .
System does not detect a vehicle at all.Symptom 8
ACS-68
