COMBINATION METERS
DI-21
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2007 April2007 M35/M45
3. CHECK CONTINUITY BETWEEN COMBINATION METER AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and unified meter and
A/C amp. connector.
3. Check continuity between combination meter harness connector
(A) and unified meter and A/C amp. harness connector (B).
OK or NG
OK >> Replace combination meter.
NG >> Repair harness or connector.
Engine Speed Signal Inspection NKS003U8
Symptom: Tachometer indication is malfunction.
1. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Start engine and select “METER A/C AMP” on CONSULT-II.
2. Using “TACHO METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” to that of tachometer of combination
meter.
Is the value in tachometer almost same as the value in the monitor?
OK >> GO TO 2.
NG >> Replace combination meter. (Perform self-diagnosis of
ECM when the value in the monitor indicates 8191.875
rpm. Then repair or replace the malfunction part.)
2. CHECK ECM OUTPUT SIGNAL
1. Select “ENGINE” on CONSULT-II.
2. Using “ENG SPEED” on “DATA MONITOR”, print out the CON-
SULT-II screen when the engine is idling.
3. Select “METER A/C AMP” on CONSULT-II.
4. Using “TACHO METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” of the idling speed to that of the
“ENG SPEED”.
OK or NG
OK >> Perform self-diagnosis of ECM. Refer to EC-123, "CON-
SULT-II Function (ENGINE)" (for VQ35DE) or EC-826,
"CONSULT-II Function (ENGINE)" (for VK45DE).
NG >> Replace unified meter and A/C amp.
AB
Continuity
Connector Terminal Connector Terminal
M52 1 M64 28 Yes
PKIB7641E
PKIA2090E
SKIA4367E
Page 1441 of 4647
DI-22
COMBINATION METERS
Revision: 2007 April2007 M35/M45
Engine Coolant Temperature Signal InspectionNKS003U9
Symptom: Water temperature gauge indication is malfunction.
1. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Start engine and select “METER A/C AMP” on CONSULT-II.
2. Using “W TEMP METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” to the indication of water tempera-
ture gauge of combination meter.
Is the indication of water temperature gauge same as the value in
the monitor?
OK >> GO TO 2.
NG >> Replace combination meter. [Perform self-diagnosis of ECM when the value in the monitor indi-
cates 215°C (419°F). Then repair or replace the malfunction part.]
2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “ENGINE” on CONSULT-II.
2. Using “COOLAN TEMP/S” on “DATA MONITOR”, print out the
CONSULT-II screen.
3. Select “METER A/C AMP” on CONSULT-II.
4. Using “W TEMP METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” to that of the “COOLAN TEMP/S”.
OK or NG
OK >> Perform self-diagnosis of ECM. Refer to EC-123, "CON-
SULT-II Function (ENGINE)" (for VQ35DE) or EC-826,
"CONSULT-II Function (ENGINE)" (for VK45DE).
NG >> Replace unified meter and A/C amp.
Fuel Level Sensor Signal InspectionNKS003UA
Symptom:
Fuel gauge indication is malfunction.
Low-fuel warning lamp indication is irregular.
NOTE:
The following symptoms are not malfunction.
Fuel level sensor unit
Depending on vehicle position or driving circumstance, the fuel level in the tank varies, and the pointer
may fluctuate.
If the vehicle is fueled with the ignition switch ON, the pointer will move slowly.
Low-fuel warning lamp
Depending on vehicle position or driving circumstance, the fuel in the tank flows and the warning lamp ON
timing may change.
Water temperature gauge pointer Reference value of data monitor °C (°F)
Hot Approx. 130 (266)
Middle Approx. 70 - 105 (158 - 221)
Cold Approx. 50 (122)
PKIA2091E
SKIA4368E
Page 1451 of 4647
DI-32
UNIFIED METER AND A/C AMP
Revision: 2007 April2007 M35/M45
DATA MONITOR
Operation Procedure
1. Touch “METER A/C AMP” on “SELECT SYSTEM” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
3. Touch either “MAIN SIGNALS” or “SELECTION FROM MENU” on the “DATA MONITOR” screen.
4. When “SELECTION FROM MENU” is selected, touch individual items to be monitored. When “MAIN SIG-
NALS” is selected, main items will be monitored.
5. Touch “START”.
6. Touch “RECORD” while monitoring, then the status of the moni-
tored item can be recorded. To stop recording, touch “STOP”.
Display Item List
X: Applicable MAIN SIGNALS Monitors main signals.
SELECTION FROM MENU Selects and monitors individual signal.
SKIA4957E
Display item [Unit]MAIN
SIGNALSSELECTION
FROM MENUDescription
SPEED METER [km/h] or [mph] X XDisplays the value of vehicle speed signal, which is input from ABS
actuator and electric unit (control unit).
SPEED OUTPUT [km/h] or [mph] X XDisplays the value of vehicle speed signal, which is transmitted to
each unit with CAN communication.
TACHO METER [rpm] X X Displays the value of engine speed signal, which is input from ECM.
W TEMP METER [°C] or [°F] X XDisplays the value of engine coolant temperature signal, which is
input from ECM.
FUEL METER [lit.] X XDisplays the value, which processes a resistance signal from fuel
gauge.
DISTANCE [km] or [mile] X XDisplays the value, which is calculated by vehicle speed signal from
ABS actuator and electric unit (control unit), fuel gauge and fuel
consumption from ECM.
FUEL W/L [ON/OFF] X X Displays [ON/OFF] condition of low-fuel warning lamp.
MIL [ON/OFF] X Displays [ON/OFF] condition of malfunction indicator lamp.
AIR PRES W/L [ON/OFF] X Displays [ON/OFF] condition of low tire pressure warning lamp.
SEAT BELT W/L [ON/OFF] X Displays [ON/OFF] condition of seat belt warning lamp.
BUZZER [ON/OFF] X X Displays [ON/OFF] condition of buzzer.
DOOR W/L [ON/OFF] X Displays [ON/OFF] condition of door warning lamp.
HI-BEAM IND [ON/OFF] X Displays [ON/OFF] condition of high beam indicator.
TURN IND [ON/OFF] X Displays [ON/OFF] condition of turn indicator.
FR FOG IND [ON/OFF] X Displays [ON/OFF] condition of front fog indicator.
OIL W/L [ON/OFF] X Displays [ON/OFF] condition of oil pressure warning lamp.
VDC/TCS IND [ON/OFF] X Displays [ON/OFF] condition of VDC/TCS OFF indicator lamp.
ABS W/L [ON/OFF] X Displays [ON/OFF] condition of ABS warning lamp.
SLIP IND [ON/OFF] X Displays [ON/OFF] condition of SLIP indicator lamp.
BRAKE W/L [ON/OFF] X Displays [ON/OFF] condition of brake warning lamp. *
Page 1530 of 4647
EC-1
ENGINE CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION EC
A
EC
Revision: 2007 April2007 M35/M45
ENGINE CONTROL SYSTEM
VQ35DE
INDEX FOR DTC ...................................................... 16
DTC No. Index ....................................................... 16
Alphabetical Index .................................................. 20
PRECAUTIONS ........................................................ 24
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ................................................................ 24
Precautions for Procedures without Cowl Top Cover ... 24
On Board Diagnostic (OBD) System of Engine and
A/T .......................................................................... 24
Precaution .............................................................. 25
PREPARATION ......................................................... 28
Special Service Tools ............................................. 28
Commercial Service Tools ...................................... 29
ENGINE CONTROL SYSTEM .................................. 30
System Diagram ..................................................... 30
Multiport Fuel Injection (MFI) System .................... 31
Electronic Ignition (EI) System ............................... 33
Fuel Cut Control (At No Load and High Engine
Speed) .................................................................... 34
AIR CONDITIONING CUT CONTROL ..................... 35
Input/Output Signal Chart ....................................... 35
System Description ................................................ 35
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ... 36
System Description ................................................ 36
Component Description .......................................... 37
CAN COMMUNICATION .......................................... 38
System Description ................................................ 38
EVAPORATIVE EMISSION SYSTEM ....................... 39
Description ............................................................. 39
Component Inspection ........................................... 42
Removal and Installation ........................................ 43
How to Detect Fuel Vapor Leakage ....................... 43
ON BOARD REFUELING VAPOR RECOVERY
(ORVR) ...................................................................... 46
System Description ................................................ 46
Diagnostic Procedure ............................................. 47
Component Inspection ........................................... 49POSITIVE CRANKCASE VENTILATION ................. 51
Description .............................................................. 51
Component Inspection ............................................ 51
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ........................................................................ 53
Description .............................................................. 53
ON BOARD DIAGNOSTIC (OBD) SYSTEM ............ 54
Introduction ............................................................. 54
Two Trip Detection Logic ........................................ 54
Emission-Related Diagnostic Information ............... 55
Malfunction Indicator Lamp (MIL) ........................... 70
OBD System Operation Chart ................................ 73
BASIC SERVICE PROCEDURE ............................... 78
Basic Inspection ..................................................... 78
Idle Speed and Ignition Timing Check .................... 83
Procedure After Replacing ECM ............................ 85
VIN Registration ..................................................... 85
Accelerator Pedal Released Position Learning ...... 86
Throttle Valve Closed Position Learning ................. 86
Idle Air Volume Learning ........................................ 86
Fuel Pressure Check .............................................. 88
TROUBLE DIAGNOSIS ............................................ 90
Trouble Diagnosis Introduction ............................... 90
DTC Inspection Priority Chart ................................. 96
Fail-Safe Chart ....................................................... 98
Symptom Matrix Chart ............................................ 99
Engine Control Component Parts Location ..........103
Vacuum Hose Drawing ..........................................111
Circuit Diagram .....................................................112
ECM Harness Connector Terminal Layout ...........114
ECM Terminals and Reference Value ...................114
CONSULT-II Function (ENGINE) ..........................123
Generic Scan Tool (GST) Function .......................135
CONSULT-II Reference Value in Data Monitor .....138
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................141
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .143
Description ............................................................143
Testing Condition ..................................................143
Page 1534 of 4647
EC-5
C
D
E
F
G
H
I
J
K
L
M
ECA
Revision: 2007 April2007 M35/M45 DTC Confirmation Procedure ............................... 438
Wiring Diagram .................................................... 439
Diagnostic Procedure ........................................... 440
Component Inspection ......................................... 444
DTC P0455 EVAP CONTROL SYSTEM ................ 445
On Board Diagnosis Logic ................................... 445
DTC Confirmation Procedure ............................... 446
Diagnostic Procedure ........................................... 447
DTC P0456 EVAP CONTROL SYSTEM ................ 453
On Board Diagnosis Logic ................................... 453
DTC Confirmation Procedure ............................... 454
Overall Function Check ........................................ 455
Diagnostic Procedure ........................................... 456
DTC P0460 FUEL LEVEL SENSOR ...................... 462
Component Description ........................................ 462
On Board Diagnosis Logic ................................... 462
DTC Confirmation Procedure ............................... 462
Diagnostic Procedure ........................................... 463
Removal and Installation ...................................... 463
DTC P0461 FUEL LEVEL SENSOR ...................... 464
Component Description ........................................ 464
On Board Diagnosis Logic ................................... 464
Overall Function Check ........................................ 464
Diagnostic Procedure ........................................... 465
Removal and Installation ...................................... 465
DTC P0462, P0463 FUEL LEVEL SENSOR CIR-
CUIT ........................................................................ 466
Component Description ........................................ 466
On Board Diagnosis Logic ................................... 466
DTC Confirmation Procedure ............................... 466
Diagnostic Procedure ........................................... 467
Removal and Installation ...................................... 467
DTC P0500 VSS ..................................................... 468
Description ........................................................... 468
On Board Diagnosis Logic ................................... 468
DTC Confirmation Procedure ............................... 468
Overall Function Check ........................................ 469
Diagnostic Procedure ........................................... 469
DTC P0506 ISC SYSTEM ....................................... 470
Description ........................................................... 470
On Board Diagnosis Logic ................................... 470
DTC Confirmation Procedure ............................... 470
Diagnostic Procedure ........................................... 471
DTC P0507 ISC SYSTEM ....................................... 472
Description ........................................................... 472
On Board Diagnosis Logic ................................... 472
DTC Confirmation Procedure ............................... 472
Diagnostic Procedure ........................................... 473
DTC P0550 PSP SENSOR ..................................... 474
Component Description ........................................ 474
CONSULT-II Reference Value in Data Monitor Mode
. 474
On Board Diagnosis Logic ................................... 474
DTC Confirmation Procedure ............................... 474
Wiring Diagram .................................................... 475
Diagnostic Procedure ........................................... 476
Component Inspection ......................................... 478
Removal and Installation ...................................... 478DTC P0603 ECM POWER SUPPLY .......................479
Component Description ........................................479
On Board Diagnosis Logic ....................................479
DTC Confirmation Procedure ...............................479
Wiring Diagram .....................................................480
Diagnostic Procedure ...........................................481
DTC P0605 ECM .....................................................483
Component Description ........................................483
On Board Diagnosis Logic ....................................483
DTC Confirmation Procedure ...............................483
Diagnostic Procedure ...........................................484
DTC P0643 SENSOR POWER SUPPLY ................486
On Board Diagnosis Logic ....................................486
DTC Confirmation Procedure ...............................486
Wiring Diagram .....................................................487
Diagnostic Procedure ...........................................489
DTC P0850 PNP SWITCH ......................................491
Component Description ........................................491
CONSULT-II Reference Value in Data Monitor Mode
.491
On Board Diagnosis Logic ....................................491
DTC Confirmation Procedure ...............................491
Overall Function Check ........................................492
Wiring Diagram .....................................................493
Diagnostic Procedure ...........................................494
DTC P1148, P1168 CLOSED LOOP CONTROL ....496
On Board Diagnosis Logic ....................................496
DTC P1211 TCS CONTROL UNIT ..........................497
Description ............................................................497
On Board Diagnosis Logic ....................................497
DTC Confirmation Procedure ...............................497
Diagnostic Procedure ...........................................497
DTC P1212 TCS COMMUNICATION LINE ............498
Description ............................................................498
On Board Diagnosis Logic ....................................498
DTC Confirmation Procedure ...............................498
Diagnostic Procedure ...........................................498
DTC P1217 ENGINE OVER TEMPERATURE ........499
Description ............................................................499
CONSULT-II Reference Value in Data Monitor Mode
.500
On Board Diagnosis Logic ....................................500
Overall Function Check ........................................500
Wiring Diagram .....................................................502
Diagnostic Procedure ...........................................504
Main 12 Causes of Overheating ...........................507
Component Inspection ..........................................509
DTC P1220 FUEL PUMP CONTROL MODULE
(FPCM) ....................................................................510
Description ............................................................510
CONSULT-II Reference Value in Data Monitor Mode
.510
On Board Diagnosis Logic ....................................510
DTC Confirmation Procedure ...............................511
Wiring Diagram .....................................................512
Diagnostic Procedure ...........................................513
Component Inspection ..........................................517
DTC P1225 TP SENSOR ........................................518
Component Description ........................................518
Page 1537 of 4647
EC-8Revision: 2007 April2007 M35/M45 .683
Wiring Diagram .....................................................684
Diagnostic Procedure ...........................................685
Component Inspection ..........................................689
IGNITION SIGNAL ..................................................691
Component Description ........................................691
Wiring Diagram .....................................................692
Diagnostic Procedure ...........................................697
Component Inspection ..........................................702
Removal and Installation ......................................703
REFRIGERANT PRESSURE SENSOR ..................704
Component Description ........................................704
Wiring Diagram .....................................................705
Diagnostic Procedure ...........................................706
Removal and Installation ......................................708
SNOW MODE SWITCH ...........................................709
Description ............................................................709
CONSULT-II Reference Value in the Data Monitor
Mode .....................................................................709
Wiring Diagram .....................................................710
Diagnostic Procedure ...........................................711
Component Inspection ..........................................713
MIL AND DATA LINK CONNECTOR ......................714
Wiring Diagram .....................................................714
SERVICE DATA AND SPECIFICATIONS (SDS) ....716
Fuel Pressure .......................................................716
Idle Speed and Ignition Timing .............................716
Calculated Load Value ..........................................716
Mass Air Flow Sensor ...........................................716
Intake Air Temperature Sensor .............................716
Engine Coolant Temperature Sensor ...................716
Fuel Tank Temperature Sensor ............................716
Crankshaft Position Sensor (POS) .......................716
Camshaft Position Sensor (PHASE) ....................716
A/F Sensor 1 Heater .............................................716
Heated Oxygen Sensor 2 Heater .........................717
Throttle Control Motor ...........................................717
Fuel Injector ..........................................................717
Fuel Pump ............................................................717
VK45DE
INDEX FOR DTC .....................................................718
DTC No. Index ......................................................718
Alphabetical Index ................................................722
PRECAUTIONS .......................................................726
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ...............................................................726
Precautions for Procedures without Cowl Top Cover .726
On Board Diagnostic (OBD) System of Engine and
A/T ........................................................................726
Precaution ............................................................727
PREPARATION .......................................................730
Special Service Tools ...........................................730
Commercial Service Tools ....................................731
ENGINE CONTROL SYSTEM ................................732
System Diagram ...................................................732
Multiport Fuel Injection (MFI) System ...................733Electronic Ignition (EI) System ..............................735
Fuel Cut Control (At No Load and High Engine
Speed) ..................................................................736
AIR CONDITIONING CUT CONTROL ....................737
Input/Output Signal Chart .....................................737
System Description ...............................................737
AUTOMATIC SPEED CONTROL DEVICE (ASCD) .738
System Description ...............................................738
Component Description ........................................739
CAN COMMUNICATION .........................................740
System Description ...............................................740
EVAPORATIVE EMISSION SYSTEM .....................741
Description ............................................................741
Component Inspection ..........................................744
Removal and Installation .......................................745
How to Detect Fuel Vapor Leakage ......................745
ON BOARD REFUELING VAPOR RECOVERY
(ORVR) ....................................................................748
System Description ...............................................748
Diagnostic Procedure ............................................749
Component Inspection ..........................................751
POSITIVE CRANKCASE VENTILATION ................753
Description ............................................................753
Component Inspection ..........................................753
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ......................................................................755
Description ............................................................755
ON BOARD DIAGNOSTIC (OBD) SYSTEM ...........756
Introduction ...........................................................756
Two Trip Detection Logic .......................................756
Emission-Related Diagnostic Information .............757
Malfunction Indicator Lamp (MIL) .........................772
OBD System Operation Chart ...............................774
BASIC SERVICE PROCEDURE .............................780
Basic Inspection ....................................................780
Idle Speed and Ignition Timing Check ..................785
Procedure After Replacing ECM ...........................787
VIN Registration ....................................................787
Accelerator Pedal Released Position Learning .....788
Throttle Valve Closed Position Learning ...............788
Idle Air Volume Learning .......................................788
Fuel Pressure Check ............................................790
TROUBLE DIAGNOSIS ..........................................792
Trouble Diagnosis Introduction .............................792
DTC Inspection Priority Chart ...............................798
Fail-Safe Chart ......................................................800
Symptom Matrix Chart ..........................................801
Engine Control Component Parts Location ...........805
Vacuum Hose Drawing .........................................814
Circuit Diagram .....................................................815
ECM Harness Connector Terminal Layout ............817
ECM Terminals and Reference Value ...................817
CONSULT-II Function (ENGINE) ..........................826
Generic Scan Tool (GST) Function .......................838
CONSULT-II Reference Value in Data Monitor .....841
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................845
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .847
Description ............................................................847
Page 1541 of 4647
EC-12Revision: 2007 April2007 M35/M45 DTC Confirmation Procedure ..............................11 4 6
Wiring Diagram ....................................................11 4 7
Diagnostic Procedure ..........................................11 4 8
Component Inspection .........................................11 5 2
DTC P0455 EVAP CONTROL SYSTEM ................115 3
On Board Diagnosis Logic ...................................11 5 3
DTC Confirmation Procedure ..............................11 5 4
Diagnostic Procedure ..........................................11 5 5
DTC P0456 EVAP CONTROL SYSTEM ................116 0
On Board Diagnosis Logic ...................................11 6 0
DTC Confirmation Procedure ..............................11 6 1
Overall Function Check .......................................11 6 2
Diagnostic Procedure ..........................................11 6 3
DTC P0460 FUEL LEVEL SENSOR ......................116 9
Component Description .......................................11 6 9
On Board Diagnosis Logic ...................................11 6 9
DTC Confirmation Procedure ..............................11 6 9
Diagnostic Procedure ..........................................11 7 0
Removal and Installation .....................................11 7 0
DTC P0461 FUEL LEVEL SENSOR ......................117 1
Component Description .......................................11 7 1
On Board Diagnosis Logic ...................................11 7 1
Overall Function Check .......................................11 7 1
Diagnostic Procedure ..........................................11 7 2
Removal and Installation .....................................11 7 2
DTC P0462, P0463 FUEL LEVEL SENSOR CIR-
CUIT .......................................................................117 3
Component Description .......................................11 7 3
On Board Diagnosis Logic ...................................11 7 3
DTC Confirmation Procedure ..............................11 7 3
Diagnostic Procedure ..........................................11 7 4
Removal and Installation .....................................11 7 4
DTC P0500 VSS .....................................................117 5
Description ...........................................................11 7 5
On Board Diagnosis Logic ...................................11 7 5
DTC Confirmation Procedure ..............................11 7 5
Overall Function Check .......................................11 7 6
Diagnostic Procedure ..........................................11 7 6
DTC P0506 ISC SYSTEM ......................................117 7
Description ...........................................................11 7 7
On Board Diagnosis Logic ...................................11 7 7
DTC Confirmation Procedure ..............................11 7 7
Diagnostic Procedure ..........................................11 7 8
DTC P0507 ISC SYSTEM ......................................117 9
Description ...........................................................11 7 9
On Board Diagnosis Logic ...................................11 7 9
DTC Confirmation Procedure ..............................11 7 9
Diagnostic Procedure ..........................................11 8 0
DTC P0550 PSP SENSOR .....................................118 1
Component Description .......................................11 8 1
CONSULT-II Reference Value in Data Monitor Mode
11 8 1
On Board Diagnosis Logic ...................................11 8 1
DTC Confirmation Procedure ..............................11 8 1
Wiring Diagram ....................................................11 8 2
Diagnostic Procedure ..........................................11 8 3
Component Inspection .........................................11 8 5
Removal and Installation .....................................11 8 5DTC P0603 ECM POWER SUPPLY .......................11 86
Component Description .......................................11 8 6
On Board Diagnosis Logic ...................................11 8 6
DTC Confirmation Procedure ...............................11 8 6
Wiring Diagram ....................................................11 8 7
Diagnostic Procedure ...........................................11 8 8
DTC P0605 ECM ....................................................11 90
Component Description .......................................11 9 0
On Board Diagnosis Logic ...................................11 9 0
DTC Confirmation Procedure ...............................11 9 0
Diagnostic Procedure ...........................................11 9 1
DTC P0643 SENSOR POWER SUPPLY ...............11 93
On Board Diagnosis Logic ...................................11 9 3
DTC Confirmation Procedure ...............................11 9 3
Wiring Diagram ....................................................11 9 4
Diagnostic Procedure ...........................................11 9 6
DTC P0850 PNP SWITCH ......................................11 98
Component Description .......................................11 9 8
CONSULT-II Reference Value in Data Monitor Mode
11 9 8
On Board Diagnosis Logic ...................................11 9 8
DTC Confirmation Procedure ...............................11 9 8
Overall Function Check ........................................11 9 9
Wiring Diagram ....................................................1200
Diagnostic Procedure ...........................................1201
DTC P1140, P1145 IVT CONTROL POSITION SEN-
SOR ........................................................................1203
Component Description .......................................1203
CONSULT-II Reference Value in Data Monitor Mode
1203
On Board Diagnosis Logic ...................................1203
DTC Confirmation Procedure ...............................1203
Wiring Diagram ....................................................1204
Diagnostic Procedure ...........................................1207
Component Inspection .........................................1210
Removal and Installation ......................................1210
DTC P1148, P1168 CLOSED LOOP CONTROL ...1211
On Board Diagnosis Logic ...................................1211
DTC P1211 TCS CONTROL UNIT .........................1212
Description ...........................................................1212
On Board Diagnosis Logic ...................................1212
DTC Confirmation Procedure ...............................1212
Diagnostic Procedure ...........................................1212
DTC P1212 TCS COMMUNICATION LINE ............1213
Description ...........................................................1213
On Board Diagnosis Logic ...................................1213
DTC Confirmation Procedure ...............................1213
Diagnostic Procedure ...........................................1213
DTC P1217 ENGINE OVER TEMPERATURE .......1214
Description ...........................................................1214
CONSULT-II Reference Value in Data Monitor Mode
1215
On Board Diagnosis Logic ...................................1215
Overall Function Check ........................................1215
Wiring Diagram ....................................................1217
Diagnostic Procedure ...........................................1219
Main 13 Causes of Overheating ..........................1223
Component Inspection .........................................1224
DTC P1220 FUEL PUMP CONTROL MODULE
Page 1545 of 4647
![INFINITI M35 2007 Factory Manual PDF EC-16
[VQ35DE]
INDEX FOR DTC
Revision: 2007 April2007 M35/M45
[VQ35DE]INDEX FOR DTCPFP:00024
DTC No. IndexNBS004RU
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble d](/img/42/57024/w960_57024-1544.png "INFINITI M35 2007 Factory Manual PDF EC-16
[VQ35DE]
INDEX FOR DTC
Revision: 2007 April2007 M35/M45
[VQ35DE]INDEX FOR DTCPFP:00024
DTC No. IndexNBS004RU
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble d")
EC-16
[VQ35DE]
INDEX FOR DTC
Revision: 2007 April2007 M35/M45
[VQ35DE]INDEX FOR DTCPFP:00024
DTC No. IndexNBS004RU
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-161, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .
If DTC U1010 is displayed with other DTC, first perform the trouble diagnosis for DTC U1010. Refer
to EC-164, "
DTC U1010 CAN COMMUNICATION" .
DTC*1
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*
2ECM*3
U1000
1000*4CAN COMM CIRCUITEC-161
U1001
1001*4CAN COMM CIRCUITEC-161
U1010 1010 CONTROL UNIT(CAN)EC-164
P0000 0000NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.—
P0011 0011 INT/V TIM CONT-B1EC-166
P0021 0021 INT/V TIM CONT-B2EC-166
P0031 0031 A/F SEN1 HTR (B1)EC-170
P0032 0032 A/F SEN1 HTR (B1)EC-170
P0037 0037 HO2S2 HTR (B1)EC-177
P0038 0038 HO2S2 HTR (B1)EC-177
P0051 0051 A/F SEN1 HTR (B2)EC-170
P0052 0052 A/F SEN1 HTR (B2)EC-170
P0057 0057 HO2S2 HTR (B2)EC-177
P0058 0058 HO2S2 HTR (B2)EC-177
P0075 0075 INT/V TIM V/CIR-B1EC-185
P0081 0081 INT/V TIM V/CIR-B2EC-185
P0101 0101 MAF SEN/CIRCUITEC-193
P0102 0102 MAF SEN/CIRCUITEC-202
P0103 0103 MAF SEN/CIRCUITEC-202
P0112 0112 IAT SEN/CIRCUITEC-209
P0113 0113 IAT SEN/CIRCUITEC-209
P0117 0117 ECT SEN/CIRCEC-214
P0118 0118 ECT SEN/CIRCEC-214
P0122 0122 TP SEN 2/CIRCEC-219
P0123 0123 TP SEN 2/CIRCEC-219
P0125 0125 ECT SENSOREC-226
P0127 0127 IAT SENSOREC-229
P0128 0128 THERMSTAT FNCTNEC-232
P0130 0130 A/F SENSOR1 (B1)EC-234
P0131 0131 A/F SENSOR1 (B1)EC-244
P0132 0132 A/F SENSOR1 (B1)EC-253
P0133 0133 A/F SENSOR1 (B1)EC-262
P0137 0137 HO2S2 (B1)EC-274
P0138 0138 HO2S2 (B1)EC-285
Page 1546 of 4647
![INFINITI M35 2007 Factory Manual PDF INDEX FOR DTC
EC-17
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45P0139 0139 HO2S2 (B1)EC-298
P0150 0150 A/F SENSOR1 (B2)EC-234
P0151 0151 A/F SENSOR1 (B2)EC-244
P0152 0152 A/F SE](/img/42/57024/w960_57024-1545.png "INFINITI M35 2007 Factory Manual PDF INDEX FOR DTC
EC-17
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45P0139 0139 HO2S2 (B1)EC-298
P0150 0150 A/F SENSOR1 (B2)EC-234
P0151 0151 A/F SENSOR1 (B2)EC-244
P0152 0152 A/F SE")
INDEX FOR DTC
EC-17
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45P0139 0139 HO2S2 (B1)EC-298
P0150 0150 A/F SENSOR1 (B2)EC-234
P0151 0151 A/F SENSOR1 (B2)EC-244
P0152 0152 A/F SENSOR1 (B2)EC-253
P0153 0153 A/F SENSOR1 (B2)EC-262
P0157 0157 HO2S2 (B2)EC-274
P0158 0158 HO2S2 (B2)EC-285
P0159 0159 HO2S2 (B2)EC-298
P0171 0171 FUEL SYS-LEAN-B1EC-309
P0172 0172 FUEL SYS-RICH-B1EC-320
P0174 0174 FUEL SYS-LEAN-B2EC-309
P0175 0175 FUEL SYS-RICH-B2EC-320
P0181 0181 FTT SENSOREC-331
P0182 0182 FTT SEN/CIRCUITEC-337
P0183 0183 FTT SEN/CIRCUITEC-337
P0222 0222 TP SEN 1/CIRCEC-342
P0223 0223 TP SEN 1/CIRCEC-342
P0300 0300 MULTI CYL MISFIREEC-349
P0301 0301 CYL 1 MISFIREEC-349
P0302 0302 CYL 2 MISFIREEC-349
P0303 0303 CYL 3 MISFIREEC-349
P0304 0304 CYL 4 MISFIREEC-349
P0305 0305 CYL 5 MISFIREEC-349
P0306 0306 CYL 6 MISFIREEC-349
P0327 0327 KNOCK SEN/CIRC-B1EC-359
P0328 0328 KNOCK SEN/CIRC-B1EC-359
P0335 0335 CKP SEN/CIRCUITEC-364
P0340 0340 CMP SEN/CIRC-B1EC-371
P0345 0345 CMP SEN/CIRC-B2EC-371
P0420 0420 TW CATALYST SYS-B1EC-380
P0430 0430 TW CATALYST SYS-B2EC-380
P0441 0441 EVAP PURG FLOW/MONEC-386
P0442 0442 EVAP SMALL LEAKEC-391
P0443 0443 PURG VOLUME CONT/VEC-400
P0444 0444 PURG VOLUME CONT/VEC-408
P0445 0445 PURG VOLUME CONT/VEC-408
P0447 0447 VENT CONTROL VALVEEC-415
P0448 0448 VENT CONTROL VALVEEC-422
P0451 0451 EVAP SYS PRES SENEC-428
P0452 0452 EVAP SYS PRES SENEC-431
P0453 0453 EVAP SYS PRES SENEC-437
P0455 0455 EVAP GROSS LEAKEC-445
DTC*1
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*
2ECM*3
Page 1547 of 4647
![INFINITI M35 2007 Factory Manual PDF EC-18
[VQ35DE]
INDEX FOR DTC
Revision: 2007 April2007 M35/M45
P0456 0456 EVAP VERY SML LEAKEC-453
P0460 0460 FUEL LEV SEN SLOSHEC-462
P0461 0461 FUEL LEVEL SENSOREC-464
P0462 0462 FUEL LEVL SEN/CIRCEC](/img/42/57024/w960_57024-1546.png "INFINITI M35 2007 Factory Manual PDF EC-18
[VQ35DE]
INDEX FOR DTC
Revision: 2007 April2007 M35/M45
P0456 0456 EVAP VERY SML LEAKEC-453
P0460 0460 FUEL LEV SEN SLOSHEC-462
P0461 0461 FUEL LEVEL SENSOREC-464
P0462 0462 FUEL LEVL SEN/CIRCEC")
EC-18
[VQ35DE]
INDEX FOR DTC
Revision: 2007 April2007 M35/M45
P0456 0456 EVAP VERY SML LEAKEC-453
P0460 0460 FUEL LEV SEN SLOSHEC-462
P0461 0461 FUEL LEVEL SENSOREC-464
P0462 0462 FUEL LEVL SEN/CIRCEC-466
P0463 0463 FUEL LEVL SEN/CIRCEC-466
P0500 0500
VEH SPEED SEN/CIRC*5EC-468
P0506 0506 ISC SYSTEMEC-470
P0507 0507 ISC SYSTEMEC-472
P0550 0550 PW ST P SEN/CIRCEC-474
P0603 0603 ECM BACK UP/CIRCUITEC-479
P0605 0605 ECMEC-483
P0643 0643 SENSOR POWER/CIRCEC-486
P0700 0700 TCMAT- 11 2
P0705 0705 PNP SW/CIRCAT- 11 3
P0710 0710 ATF TEMP SEN/CIRCAT-135
P0717 0717 TURBINE SENSORAT- 11 7
P0720 0720
VEH SPD SEN/CIR AT*5AT- 11 9
P0725 0725 ENGINE SPEED SIGAT-124
P0740 0740 TCC SOLENOID/CIRCAT-126
P0744 0744 A/T TCC S/V FNCTNAT-128
P0745 0745 L/PRESS SOL/CIRCAT-130
P0850 0850 P-N POS SW/CIRCUITEC-491
P1148 1148 CLOSED LOOP-B1EC-496
P1168 1168 CLOSED LOOP-B2EC-496
P1211 1211 TCS C/U FUNCTNEC-497
P1212 1212 TCS/CIRCEC-498
P1217 1217 ENG OVER TEMPEC-499
P1220 1220 FPCM/CIRCUITEC-510
P1225 1225 CTP LEARNINGEC-518
P1226 1226 CTP LEARNINGEC-520
P1421 1421 COLD START CONTROLEC-522
P1550 1550 BAT CURRENT SENSOREC-524
P1551 1551 BAT CURRENT SENSOREC-531
P1552 1552 BAT CURRENT SENSOREC-531
P1553 1553 BAT CURRENT SENSOREC-538
P1554 1554 BAT CURRENT SENSOREC-545
P1564 1564 ASCD SWEC-552 (Models with ICC)
EC-559
(Models with ASCD)
P1568 1568
ICC COMMAND VALUE*
6EC-566
P1572 1572 ASCD BRAKE SWEC-567 (Models with ICC)
EC-576
(Models with ASCD)
P1574 1574 ASCD VHL SPD SENEC-584
(Models with ICC)
EC-586
(Models with ASCD) DTC*
1
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*
2ECM*3
