5-32Starting and driving
JVS0308X
Driver assist system lane indicator
LDW system operation
The LDW system provides a lane departure
warning function when the vehicle is driven
at speeds of approximately 45 MPH (70
km/h) and above. When the vehicle
approaches either the left or the right side
of the traveling lane, a warning chime will
sound and the driver assist system lane
indicator (orange) in the vehicle informa-
tion display will blink to alert the driver.
The warning function will stop when the
vehicle returns inside of the lane markers.
The LDW system is not designed to warn
under the following conditions..
When you operate the lane change
signal and change traveling lanes in
the direction of the signal. (The LDW
system will become operable again
approximately 2 seconds after the lane
change signal is turned off.)
. When the vehicle speed lowers to less
than approximately 45 MPH (70 km/h).
. When the Blind Spot Intervention
TM
(BSI) system activates an audible warn-
ing or steering control.
After the above conditions have finished
and the necessary operating conditions are
satisfied, the LDW functions will resume.
Temporary disabled status at high
temperature
If the vehicle is parked in direct sunlight
under high temperature conditions (over
approximately 1048 F (408C) and then
started, the LDW system may be deacti-
vated automatically. The high cabin tem-
perature warning message will appear in
the vehicle information display.
When the interior temperature is reduced,
the LDW system will resume operating
automatically.
JVS0246X
Turning the LDW system ON/OFF
Perform the following steps to turn the
LDW system on or off.
1. Push the MENU button
*1and touch
[Driver Assistance] on the lower dis-
play.
2. Touch [Lane Assist].
3. Touch [Lane Departure Warning] to turn the system ON/OFF.

5-34Starting and driving
ered with water, dirt, snow, etc.
. On roads where discontinued lane
markers are still detectable.
. On roads where there are sharp curves.
. On roads where there are sharply
contrasting objects, such as shadows,
snow, water, wheel ruts, seams or lines
remaining after road repairs. (The LDP
system could detect these items as
lane markers.)
. On roads where the traveling lane
merges or separates.
. When the vehicle’s traveling direction
does not align with the lane marker.
. When traveling close to the vehicle in
front of you, which obstructs the lane
camera unit detection range.
. When rain, snow or dirt adheres to the
windshield in front of the lane camera
unit.
. When the headlights are not bright due
to dirt on the lens or if the aiming is not
adjusted properly.
. When strong light enters the lane
camera unit. (For example, the light
directly shines on the front of the
vehicle at sunrise or sunset.) .
When a sudden change in brightness
occurs. (For example, when the vehicle
enters or exits a tunnel or under a
bridge.)
JVS0308X
Driver assist system lane indicator
LDP system operation
The LDP system provides a lane departure
warning and steering control assistance
when the vehicle is driven at speeds of
approximately 45 MPH (70 km/h) and
above. When the vehicle approaches either
the left or the right side of the traveling
lane, a warning chime will sound and the
driver assist system lane indicator (orange)
will blink to alert the driver. Then, the LDP
system will automatically apply the steer-
ing for a short period of time to help assist
the driver to return the vehicle to the center
of the traveling lane.

5-36Starting and driving
Automatic deactivation
Condition A:
The warning and assist functions of the
LDP system are not designed to work under
the following conditions:
.When you operate the lane change
signal and change the traveling lanes
in the direction of the signal. (The LDP
system will be deactivated for approxi-
mately 2 seconds after the lane change
signal is turned off.)
. When the vehicle speed lowers to less
than approximately 45 MPH (70 km/h).
. When the BSI system activates an
audible warning or steering control.
After the above conditions have finished
and the necessary operating conditions are
satisfied, the warning and assist functions
will resume.
Condition B:
The assist function of the LDP system is not
designed to work under the following
conditions (warning is still functional):
. When the steering wheel is turned as
far as necessary for the vehicle to
change lanes. .
When the accelerator pedal is de-
pressed while the steering control
assist is provided.
. When the Intelligent Cruise Control (ICC)
approach warning occurs.
. When the hazard warning flashers are
operated.
. When driving on a curve at high speed.
After the above conditions have finished
and the necessary operating conditions are
satisfied, the LDP steering control assist
function will resume.
Condition C:
Under the following conditions, a beep will
sound and the LDP system will be canceled
automatically. The “LDP currently unavail-
able” message will appear in the vehicle
information display, and the LDP system
cannot be activated:
. When the VDC system (except TCS
function) or ABS operates.
. When the VDC system is turned off.
. When the INFINITI Drive Mode Selector
is turned to the SNOW mode.
Action to take:
When the above conditions no longer exist,
push the dynamic driver assistance switch
again to turn the LDP system back on. Temporary disabled status at high tem-
perature:
If the vehicle is parked in direct sunlight
under high temperature conditions (over
approximately 1048F (408C)) and then the
LDP system is turned on, the LDP system
may be deactivated automatically. The
“ high cabin temperature” message will
appear in the vehicle information display.
Action to take:
When the above conditions no longer exist,
push the dynamic driver assistance switch
again to turn the LDP system back on.
LANE CAMERA UNIT MAINTENANCE
The LDW/LDP system uses the same lane
camera unit that is used by Active Lane
Control, located above the inside mirror.
For maintenance of the camera, see “Lane
camera unit maintenance ”(P.5-29).

5-38Starting and driving
SSD1028
Side indicator light
The BSW system operates above approxi-
mately 20 MPH (32 km/h). If the radar
sensors detect vehicles in the detection
zone, the side indicator light illuminates. If
the driver then activates the turn signal, a
chime will sound twice and the side
indicator light will flash.
The BSI system operates above approxi-
mately 37 MPH (60 km/h). If the system
detects a vehicle in the detection zone and
your vehicle is approaching the lane
marker, the BSI system provides an audi-
ble warning (three times), flashes the side
indicator light and slightly applies the
steering for a short period of time to help return the vehicle back to the traveling
lane. The BSI system provides an audible
warning and turns on or flashes the side
indicator light even if the BSW system is
off.
WARNING
.
The BSW and BSI systems are not a
replacement for proper driving procedure
and are not designed to prevent contact
with vehicles or objects. When changing
lanes, always use the side and rear
mirrors and turn and look in the direc-
tion you will move to ensure it is safe to
change lanes. Never rely solely on the
BSW or BSI system.
. Using the BSI system under some road,
lane marker or weather conditions could
lead to improper system operation. Al-
ways rely on your own steering and
braking operation to avoid accidents.
. The BSW and BSI systems may not
provide a warning or steering control
for vehicles that pass through the
detection zone quickly.
SSD1028
Side indicator light
BSW system operation
If the radar sensors detect vehicles in the
detection zone, the side indicator light
located inside the vehicle (near the outside
mirrors) illuminates. If the turn signal is
then activated, the side indicator light
flashes and a chime sounds twice. The
side indicator light continues to flash until
the detected vehicles leave the detection
zone.
The side indicator lights illuminate for a
few seconds when the ignition switch is
placed in the ON position.

The brightness of the side indicator lights
is adjusted automatically depending on the
brightness of the ambient light.
A chime sounds if the radar sensors have
already detected vehicles when the driver
activates the turn signal. If a vehicle comes
into the detection zone after the driver
activates the turn signal, then only the side
indicator light flashes and no chime
sounds. (See“BSW/BSI driving situations”
(P.5-43).)
JVS0246X
Turning the BSW system ON/OFF:
Perform the following steps to turn the
BSW system on or off.
1. Push the MENU button
*1and touch
[Driver Assistance] on the lower dis-
play.
2. Touch [Blind Spot Assist].
3. Touch [Blind Spot Warning] to turn the system ON/OFF.
Setting the side indicator light brightness:
The brightness of the side indicator lights
can be changed in the following steps:
1. Push the MENU button
*1and touch [Driver Assistance] on the lower dis-
play.
2. Touch [Blind Spot Assist].
3. Touch [Side Indicator Brightness] and select [Bright], [Standard] or [Dark].
When the brightness setting is changed,
the side indicator lights illuminate for a
few seconds.
Starting and driving5-39

5-40Starting and driving
SSD1028
Side indicator light
BSI system operation
If the radar sensors detect vehicles in the
detection zone, the side indicator light
located inside the vehicle (near the outside
mirrors) illuminates. If your vehicle is
approaching a lane marker, the side
indicator light flashes and an audible
warning will sound three times. Then the
system applies the steering for a short
period of time to help return the vehicle
back to the center of the lane. BSI operates
regardless of turn signal usage.NOTE:
.
Warning and steering control will only
be activated if the side indicator light
is already illuminated when your vehi-
cle approaches a lane marker. If
another vehicle comes into the detec-
tion zone after your vehicle has
crossed a lane marker, no warning or
steering control will be activated. (See
“BSW/BSI driving situations” (P.5-43).)
. The BSI system is typically activated
earlier than the Lane Departure Pre-
vention (LDP) system when your vehi-
cle is approaching a lane marker.
JVS0206X
Dynamic driver assistance switch
JVS0309X
Driver assist system blind spot indicator

The BSI system turns on when the dynamic
driver assistance switch on the steering
wheel is pushed when the [Blind Spot
Intervention] is enabled in the settings
menu on the lower display. The driver
assist system blind spot indicator (green)
in the vehicle information display illumi-
nates when the BSI system is turned on.
The BSI system provides an audible warn-
ing and flashes the side indicator light
when BSI is activated even if the BSW
system is off.
JVS0246X
How to enable/disable the BSI system:
Perform the following steps to enable or
disable the BSI system.
1. Push the MENU button
*1and touch
[Driver Assistance] on the lower dis-
play.
2. Touch [Blind Spot Assist].
3. Touch [Blind Spot Intervention] to enable or disable the system.
WARNING
. Do not use the BSI system under the
following conditions because the system may not function properly.
—During bad weather (for example,
rain, fog, snow, wind, etc.)
—When driving on slippery roads,such as on ice or snow, etc.
—When driving on winding or uneven
roads.
—When there is a lane closure due toroad repairs.
—When driving in a makeshift lane.
—When driving on roads where thelane width is too narrow.
—When driving with a tire that is notwithin normal tire conditions (for
example, tire wear, low tire pressure,
installation of spare tire, tire chains,
non-standard wheels).
—When the vehicle is equipped with
non-original steering parts or sus-
pension parts.
. Excessive noise (for example, audio
system volume, open vehicle window)
will interfere with the chime sound, and
it may not be heard.
Starting and driving5-41

5-48Starting and driving
radar obstruction”warning message ap-
pears even after the BSI system is turned
on again, stop the vehicle in a safe location
and turn the engine off. Check for and
remove objects obscuring the radar sen-
sors on the rear bumper, and restart the
engine.
Condition C:
If the vehicle is parked in direct sunlight
under high temperature conditions (over
approximately 1048F (408C)) and then the
BSI system is turned on, the BSI system
may be deactivated automatically. The
“high cabin temperature” warning mes-
sage will appear in the vehicle information
display.
Action to take:
When the above conditions no longer exist,
push the dynamic driver assistance switch
again to turn the BSI system back on.
BSW/BSI malfunction
When the BSW/BSI systems malfunction,
they will be turned off automatically, a
beep will sound, the and the system
“malfunction” warning message with the
driver assist system blind spot indicator
(orange) will appear in the vehicle informa-
tion display. Action to take:
Stop the vehicle in a safe location, turn the
engine off and restart the engine.
If the system malfunction warning message
with the driver assist system blind spot
indicator (orange) continues to be dis-
played, have the BSW/BSI systems
checked by an INFINITI retailer.
BACK-UP COLLISION INTERVENTION
(BCI) SYSTEM
The Back-up Collision Intervention (BCI)
system can help alert the driver of
approaching vehicles or rear objects when
the driver is backing out of a parking
space.
When the shift lever is in the R (Reverse)
position and the vehicle speed is less than
approximately 5 MPH (8 km/h), the BCI
system operates.JVS0233X
JVS0173X

5-60Starting and driving
JVS0235X
PRECAUTIONS ON VEHICLE-TO-VE-
HICLE DISTANCE CONTROL MODE
The system is intended to enhance the
operation of the vehicle when following a
vehicle traveling in the same lane and
direction.
If the radar sensor
*Adetects a slower
moving vehicle ahead, the system will
reduce the vehicle speed so that your
vehicle follows the vehicle in front at the
selected distance.
The system automatically controls the
throttle and applies the brakes (up to
approximately 40% of vehicle braking power) if necessary.
The detection range of the sensor is
approximately 650 ft (200 m) ahead.
WARNING
.
This system is only an aid to assist the
driver and is not a collision warning or
avoidance device. It is the driver’ s
responsibility to stay alert, drive safely
and be in control of the vehicle at all
times.
. The system is primarily intended for use
on straight, dry, open roads with light
traffic. It is not advisable to use the
system in city traffic or congested areas.
. This system will not adapt automatically
to road conditions. This system should
be used in evenly flowing traffic. Do not
use the system on roads with sharp
curves, or on icy roads, in heavy rain or
in fog.
The radar sensor will not detect under
most conditions:
.Stationary and slow moving vehicles
. Pedestrians or objects in the roadway .
Oncoming vehicles in the same lane
. Motorcycles traveling offset in the travel
lane
WARNING
. As there is a performance limit to the
distance control function, never rely
solely on the Intelligent Cruise Control
(ICC) system. This system does not
correct careless, inattentive or absent-
minded driving, or overcome poor visi-
bility in rain, fog, or other bad weather.
Decelerate the vehicle speed by depres-
sing the brake pedal, depending on the
distance to the vehicle ahead and the
surrounding circumstances in order to
maintain a safe distance between vehi-
cles.
. If the vehicle ahead comes to a stop, the
vehicle decelerates to a standstill within
the limitations of the system. The
system will cancel once it judges that
the vehicle has come to a standstill and
sound a warning chime. To prevent the
vehicle from moving, the driver must
depress the brake pedal.
. The system may not detect the vehicle in

5-68Starting and driving
JVS0210X
1. System set display with vehicle ahead
2. System set display without vehicleahead
System operation
WARNING
Normally when controlling the distance to a
vehicle ahead, this system automatically
accelerates or decelerates your vehicle
according to the speed of the vehicle ahead.
Depress the accelerator to properly accel-
erate your vehicle when acceleration is
required for a lane change. Depress the brake pedal when deceleration is required to
maintain a safe distance to the vehicle
ahead due to its sudden braking or if a
vehicle cuts in. Always stay alert when
using the ICC system.
The driver sets the desired vehicle speed
based on the road conditions. The ICC
system maintains the set vehicle speed,
similar to standard cruise control, as long
as no vehicle is detected in the lane ahead.
The ICC system displays the set speed.Vehicle detected ahead:
When a vehicle is detected in the lane
ahead, the ICC system decelerates the
vehicle by controlling the throttle and
applying the brakes to match the speed
of a slower vehicle ahead. The system then
controls the vehicle speed based on the
speed of the vehicle ahead to maintain the
driver selected distance.
The stoplights of the vehicle come on
when braking is performed by the ICC
system.
When the brake operates, a noise may be
heard. This is not a malfunction.
When a vehicle ahead is detected, the
vehicle ahead detection indicator comes
on. The ICC system will also display the set
speed and selected distance.
Vehicle ahead not detected:
When a vehicle is no longer detected
ahead, the ICC system gradually acceler-
ates your vehicle to resume the previously
set vehicle speed. The ICC system then
maintains the set speed.
When a vehicle is no longer detected the
vehicle ahead detection indicator turns off.
If a vehicle ahead appears during accel-
eration to the set vehicle speed or any time
