low beam INFINITI Q50 2014 Quick Reference Guide

11
06
light illuminates in the instrument panel.
Pull the headlight switch back to the original
position to select the low beam. The blue
indicator light turns off.
Pull and release the headlight control switch 05 to

flash the headlight high beams on and off.
HIGH BEAM ASSIST (if so equipped)
The high beam assist system will operate when
the vehicle is driven at approximately 22 MPH (35 km/h) and above. If \
an oncoming vehicle
or leading vehicle appears in front of your vehicle when the high beam is on, the headlights
will automatically be switched to the low beam.
Following the procedure below only activates the high beam assist system\
. This does not
necessarily turn on the high beam, even if there is no other traffic. Bo\
th ambient light and
traffic conditions have to be correct for the high beam to illuminate.
To activate high beam assist, turn the headlight control switch to the AUTO position
01 and
push the headlight control switch 04 forward to turn on the high beam. The high beam

assist indicator light will illuminate.
FOG LIGHT SWITCH
The headlights must be on and the low beams selected for the fog lights to operate.
Turn the switch (inside collar) to the
position
06 to turn the fog lights on.
Turn the switch (inside collar)
to the
OFF position to turn the fog lights off.
For more information, refer to the “Instruments and controls (section 2 )” of your Owner’s Manual.
Windshield Wiper and Washer Switch
RAIN-SENSING AUTO WIPER SYSTEM (if so equipped)
Move the lever to the following positions to operate



the windshield wipers:

01 Mist (MIST) - One sweep operation of the wipers.
02 Auto (A UTO ) - Operates the rain-sensing wipers
intermittently. The intermittent speed can be
adjusted by twisting the time control ring
03 .
04 Low (LO) - Wipers operate at a continuous
low speed.
05 High (HI) - Wipers operate at a continuous
high speed.
06 Pull the lever toward you to activate the washer. The wipers will operate several times.
PULLING UP THE WIPER ARM
Quickly move the lever to the MIST 01 position twice.
This will place the wiper arms into the service position to allow remova\
l of the wiper blades.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
MIST
OFFINT
LO
HI
06
03
01
02
04
05
