maintenance INFINITI Q50 2015 Quick Reference Guide

table of contents
new system features INFINITI Connection™ (if so equipped) ............................. 2
Main Interface Switches Overview ................................. 3
User Registration ............................................... 4
Upper Display .................................................. 4
Around View
® Monitor (AVM) with Moving Object Detection (MOD)
(if so equipped) ................................................ 5
SiriusXM Travel Link and SiriusXM Traffic (if so equipped) .............. 6
essential information Tire Pressure Monitoring System (TPMS) with Tire Inflation Indicator .....7
Loose Fuel Cap ................................................. 8
Fuel-filler Door ................................................. 8
Lower Display Maintenance ....................................... 8
Driving Aids (if so equipped) ...................................... 8
Active Lane Control (if so equipped) ................................ 9
Heated Steering Wheel (if so equipped) .............................9
Clock Set/Adjustment .......................................... 10
first drive features INFINITI Intelligent Key System .................................. 11
Trunk Lid Release .............................................. 12
Seat Adjustments .............................................. 12
Heated Seats (if so equipped) .................................... 13
Automatic Drive Positioner (if so equipped) .........................13
Outside Mirror Control Switch .................................... 14
Starting/Stopping the Engine .................................... 14
Headlight Control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . 15
Windshield Wiper and Washer Switch ............................. 16
Climate Controls ............................................... 17
FM/AM/HD Radio
®/SiriusXM® Satellite Radio (if so equipped) ......... 19
USB (Universal Serial Bus) Connection Port /iPod® Interface ........... 20
Conventional (Fixed Speed) Cruise Control .........................20
Intelligent Cruise Control (ICC) (if so equipped) .....................21
system guide Vehicle Information Display ..................................... 22
Bluetooth® Hands-free Phone System ............................. 22
System Operating Tips ....................................... 22
Navigation System (if so equipped) ............................... 25
HomeLink
® Universal Transceiver (if so equipped) ................... 26
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2015/q50 or snap this barcode with an
appropriate barcode reader.
Additional information about your vehicle is also available
in your Owner’s Manual, Navigation System Owner’s Manual
and at www.InfinitiUSA.com.
Please see your Owner’s Manual for important safety information
and system operation limitations.
• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to your InTouch
™ Owner’s Manual,
the “Safety –– Seats, seat belts and supplemental restraint
system (section 1)” and the “Starting and driving (section 5)”
of your Owner’s Manual.
2045927_15c_Infiniti_Q50_QRG_071415.indd 47/14/15 3:38 PM

3
Scheduled Maintenance Notification – Receive scheduled maintenance notifications based
on mileage data provided by your vehicle.

Maintenance Alert – Receive notification of a vehicle system malfunction that triggers
instrument panel warning lights.

Destination Assistance – Receive point-of-interest assistance via a guided IVR (Interactive
Voice Response) or a Response Specialist by pressing the
key on the map screen or the
INFINITI Connection™ web portal.

Destination Send-to-Vehicle – Find and download point-of-interest information from
Google Maps™. To access, go to the INFINITI Connection menu and select “Sync All
Information Feeds”. Then go to the feeds menu page and download the desired
destination information.

Connected Search – Select “Connected Search” from the Destination menu on the vehicle’s
Navigation System to conduct a point-of-interest search within a certain distance of the
vehicle’s location.

Drive Zone – Monitor the movement of your vehicle within a specified region. Set up
boundaries in the Monitoring section of the INFINITI Connection web portal.

Max Speed Alert – Set up a maximum speed on the INFINITI Connection web portal. You will
receive notifications if your vehicle exceeds the maximum speed setting.


Mobile Information Service – Receive the latest news headlines, stock quotes and sports

scores by setting up preferences on the Mobile Information Service page in the INFINITI
Connection web portal.

Valet Alert – Use Valet Alert to set up a 0.2-mile radius around your vehicle.
• Activate alerts by pressing the “Connect to Voice Menu” button on the INFINITI
Connection screen or by pressing the
key on the map screen.
• At the prompt, say “Valet Alert” and then “Activate” or “Deactivate”.
For more information, refer to the “Viewing technical information (section 7)” of your Navigation System Owner’s Manual.
Main Interface Switches Overview
1 AUDIO – Press to navigate to the main audio
screen. From here, all of the audio functions can
be accessed.
2 MENU – Press to navigate to the main menu screen.
From here, there is access to the navigation functions
and all the applications, including the settings application.
3 CLIMATE – Press to navigate to the CLIMATE controls screen. From here, you have access to
climate control, heated steering wheel and heated seat functions.
For more information, refer to the “Getting Started (section 2)” of your InTouch Owner’s Manual.
123
2045927_15c_Infiniti_Q50_QRG_071415.indd 37/14/15 3:38 PM

7
Tire Pressure Monitoring System (TPMS) with Tire Inflation Indicator
A Flat Tire Visit Dealer or Tire Pressure Low —
Add Air warning message will appear in the vehicle
information display
1 and the low tire pressure
warning light 2 will illuminate when one or more
tires are low in pressure and air is needed.
• The tire pressures should be checked when
the tires are cold. The tires are considered cold
after the vehicle has been parked for 3 hours
or more or driven less than 1 mi (1.6 km) at
moderate speeds.

When adding air to an under-inflated tire, the TPMS
with Tire Inflation Indicator provides visual and
audible signals to help you inflate the tire to the recommended COLD tire pressure.
To use the tire inflation indicator:
1. Move the shift lever to the P (PARK) position and apply the parking brake.
2. Place the ignition switch in the ON position. Do not start the engine.
3. Add air to the under-inflated tire, and within a few seconds, the hazard warning lights will
start flashing.
4. When the designated tire pressure is reached, the horn will beep once and the hazard
warning flashers will stop flashing.
5. Repeat this procedure for any additional under-inflated tires.

After tire pressures are adjusted, drive the vehicle at speeds above 16 mph (25 km/h). The
Flat Tire Visit Dealer or Tire Pressure Low — Add Air warning message and low tire pressure
warning light will extinguish.

When the low tire pressure warning light flashes for 1 minute and then remains on, the
TPMS is not functioning properly. Have the system checked by an INFINITI retailer.

Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and
the outside temperature. Low outside temperature can lower the temperature of the air
inside the tire, which can cause a lower tire inflation pressure. This may cause the low tire
pressure warning light to illuminate. If the warning light illuminates, check the tire pressure
in your tires.
• Check the tire pressure (including the spare tire) often and always prior to long
distance trips.

The Tire and Loading Information label contains valuable information. Please refer to the
“Technical and consumer information (section 9)” in your Owner’s Manual for the location
of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
essential information
1
2
2045927_15c_Infiniti_Q50_QRG_071415.indd 77/14/15 3:38 PM

8
essential information
Lower Display Maintenance
Only use a microfiber cloth to clean the lower display.
For more information, refer to the “Appearance and care (section 7)” of your Owner’s Manual.
Driving Aids (if so equipped)
The trip computer displays different driving aids, including Forward Emergency Braking,
Lane Departure Prevention and Blind Spot Intervention if they are currently activated.

To disable driving aids or warnings:
1. Press the MENU button just below the lower display.
2. Touch the right arrow key
until you see Driver
Assistance . Touch the Driver Assistance key.
3. Touch the key that corresponds with the driving
aid or warning you would like to turn off (Forward
Assist , Lane Assist or Blind Spot Assist).
4. Select the driving aid line key to disable.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
Fuel-filler Door
The fuel-filler door is located on the passenger’s, rear
side of the vehicle.

Make sure that at least the driver’s door is unlocked.

Push and release the left side of the fuel-filler door
to open.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
2
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear in
the vehicle information display
1 when the fuel-
filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click
is heard.

The warning message will extinguish when the
vehicle detects the fuel-filler cap is properly
tightened and the
or button
2
is pressed.

If the cap is not properly tightened, the Malfunction
Indicator Light

may illuminate.
For more information, refer to the “Instruments and controls (section 2)”
and the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1
2045927_15c_Infiniti_Q50_QRG_071415.indd 87/14/15 3:39 PM

11
first drive features
INFINITI Intelligent Key System
The INFINITI Intelligent Key system allows you to lock or
unlock the vehicle, open the trunk and start the engine.
It is important to make sure the Intelligent Key is with
you (that is, in your pocket or purse).

The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.
LOCKING AND UNLOCKING DOORS
Using the Intelligent Key:
• Touch the inside of the door handle

1 to unlock
the corresponding front door.
• Pressing the request switch

2 while touching the
inside of the door handle will unlock the rest of the
doors.
• To lock the vehicle, press either door handle
request switch

3 once.
• Change vehicle settings to unlock all doors by touching the inside of
the door handle
1. For more information, refer to the “Information
and settings (section 8)” of your Owner’s Manual.
Using the key fob:
• Press the

button
5 on the key fob to unlock the driver’s door.
• Press the

button 5 again; all other doors will unlock.
• Press the

button
4 on the key fob.
To release the trunk lid, press the button
6 for more than 1
second. Lift the trunk lid to access the trunk.

The Intelligent Key can also be used to activate the panic alarm by
pressing and holding the

button
7 for more than 1 second. Once
activated, the panic alarm and headlights will stay on for a period
of time.
INFINITI INTELLIGENT KEY BATTERY DISCHARGE

If the battery of the Intelligent Key is discharged
or environmental conditions interfere with the
Intelligent Key operation, start the engine according
to the following procedure:
1. Move the shift lever to the P (PARK) position.
2. Firmly apply the foot brake.
3. Touch the ignition switch with the Intelligent Key,
and a chime will sound.
4. Within 10 seconds after the chime sounds, press
the ignition switch while depressing the brake
pedal and the engine will start.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and
the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
2
1
3
4
5
6
7
2045927_15c_Infiniti_Q50_QRG_071415.indd 117/14/15 3:39 PM
