NOTE:
It may take some time until the Idling Stop
System activates under the following con-
ditions:
.when the battery is discharged.
. when the outside temperature is low or
high.
. when the battery is replaced or the
battery terminal is disconnected for
extended periods and then reconnected.
NOTE:
When the Idling Stop System indicator light
illuminates, the engine starts running auto-
matically under at least one of the following
conditions:
. The brake pedal is released with the shift
lever in the D (Drive) or N (Neutral)
position.
. The shift lever is placed in the D (Drive)
or R (Reverse) position from the N
(Neutral) or P (Park) position.
. The driver’s seat belt is unfastened, or
the driver’s door is open.
. The battery voltage becomes low (due to
electrical load from other vehicle sys-
tems like headlights, heaters, etc., or
auxiliary devices connected to the 12
volt socket inside the vehicle).
. The vehicle speed is above about 1 MPH
(2 km/h). .
The front defroster is operated.
. The rear window defroster is operated.
. When the temperature inside the vehicle
is lower than approximately 68°F
(20°C).
. When the temperature inside the vehicle
is higher than approximately 86°F
(30°C). (When the air conditioner is
off, the Idling Stop System will operate.)
. When the front defroster is turned on.
(The engine may not starts depending
on the outside temperature.)
. When more than 3 minutes have elapsed
since the Idling Stop System was active.
. When the accelerator pedal is depressed.
. When the steering wheel is operated.
(The steering wheel operation may be-
come heavy, but this is not a malfunc-
tion.)
. When the battery capacity is low.
. When the power consumption is high.
. When the shift lever is placed in the R
(Reverse) position.
NOTE:
The following condition will prevent the
Idling Stop System from automatically re-
starting the engine. Starting the engine
with the ignition switch operation is then
necessary: .
The hood is open.
Use this system while waiting at stoplight,
etc. When the vehicle is stopped for long
periods of time, turn off the engine.
When the engine is stopped by the Idling
Stop System, heating, cooling and dehumi-
difying functions will be deactivated. To
avoid the air conditioning functions from
being deactivated, turn off the Idling Stop
mode by pushing the Idling Stop OFF switch.
RETROGRADE MOVEMENT
CONTROL FUNCTION
This system is designed to reduce the retro-
grade movement that occurs while the
driver’s foot changes from depressing the
brake pedal to the accelerator pedal when
moving the vehicle while the Idling Stop
System is active on a hilly road.
IDLING STOP SYSTEM DISPLAY
The status of the Idling Stop System can be
checked in the vehicle information display.
Starting and driving5-139

6-14In case of emergency
JVE0142X
2.0L turbo gasoline engine
AUXILIARY BATTERY (for 2.0L
turbo gasoline engine models)
1. If the booster battery is in anothervehicle, position the two vehiclesandto bring the batteries into close
proximity to each other.
CAUTION
. Do not allow the two vehicles to
touch.
2. Apply the parking brake. 3. Move the shift lever to the “P” (Park)
position.
4. Switch off all unnecessary electrical systems (headlights, heater, air condi-
tioner, etc.).
5. Push the ignition switch to the “OFF” position.

8-24Do-it-yourself
JVM0305X
2.0L turbo gasoline engine model
JVM0331X
2.0L turbo gasoline engine model
JVM0306X
2.0L turbo gasoline engine model (trunk)
ENGINE COMPARTMENT
WARNING
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or electronic con-
trol units or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch is placed in the OFF or LOCK position and the headlight switch is turned to OFF.
2. Open the engine hood.
3. Remove the fuse/fusible link holder cover.
4. Remove the fuse with the fuse puller.

SDI1754
5. If the fuse is open, replace it with a
new fuse. Spare fuses are stored in the
passenger compartment fuse box.
6. If a new fuse also opens, have the electrical system checked and repaired.
It is recommended you visit an INFINITI
retailer for this service.
Fusible links
If any electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace only with genuine INFINITI
parts.
JVM0256X
PASSENGER COMPARTMENT
WARNING
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or electronic con-
trol units or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch is placed in the OFF or LOCK position and the
headlight switch is turned to OFF. 2. Open the fuse box lid.
3. Remove the fuse with the fuse puller
.
4. If the fuse is open, replace it with a new fuse.
5. If a new fuse also opens, have the electrical system checked and repaired.
It is recommended you visit an INFINITI
retailer for this service. Spare fuses are
stored in the fuse box.
Do-it-yourself8-25

8-26Do-it-yourself
JVM0257X
Extended storage fuse switch (if so
equipped)
To reduce battery drain, the extended
storage fuse switch comes from the factory
switched off. Prior to delivery of your
vehicle, the switch is pushed in (switched
on) and should always remain on.
If the extended storage fuse switch is not
pushed in (switched on), the “Shipping Mode
On, Push Storage Fuse” warning may appear
in the vehicle information display. See “20.
Extended storage fuse warning” (P.2-23).
If any electrical equipment does not operate,
remove the extended storage fuse switch
and check for an open fuse.NOTE:
If the extended storage fuse switch mal-
functions or if the fuse is open, it is not
necessary to replace the switch. In this case,
remove the extended storage fuse switch
and replace it with a new fuse of the same
rating.
How to remove the extended storage fuse
switch:
1. To remove the extended storage fuse
switch, be sure the ignition switch is in
the OFF or LOCK position.
2. Be sure the headlight switch is in the OFF position.
3. Remove the fuse box cover.
4. Pinch the locking tabs
found on each
side of the storage fuse switch.
5. Pull the storage fuse switch straight out from the fuse box
.
CAUTION
Be careful not to allow children to
swallow the battery and removed parts.
INTELLIGENT KEY BATTERY
REPLACEMENT

8-44Do-it-yourself
.The original tires have built-in
tread wear indicators. When
wear indicators are visible, the
tire(s) should be replaced.
. Tires degrade with age and use.
Have tires, including the spare,
over 6 years old checked by a
qualified technician, because
some tire damage may not be
obvious. Replace the tires as
necessary to prevent tire failure
and possible personal injury.
. Improper service of the spare
tire may result in serious perso-
nal injury. If it is necessary to
repair the spare tire, it is re-
commended you visit an
INFINITI retailer for this ser-
vice.
. For additional information re-
garding tires, refer to “Impor-
tant Tire Safety Information”
(US) or “Tire Safety Informa-
tion” (Canada) in the Warranty
Information Booklet.Replacing wheels and tires
When replacing a tire, use the same size,
tread design, speed rating and load carrying
capacity as originally equipped. (See “Speci-
fications” (P.10-11) for recommended types
and sizes of tires and wheels.)
After the ignition switch is placed in the ON
position, it may take a period of time for the
tire pressure to be displayed in the vehicle
information display while the vehicle is
driven. Depending on the radio wave circum-
stance, tire pressure may not correctly be
displayed.
WARNING
. The use of tires other than those
recommended or the mixed use of
tires of different brands, construc-
tion (bias, bias-belted, radial or run-
flat), or tread patterns can adversely
affect the ride, braking, handling,
ground clearance, body-to-tire clear-
ance, tire chain clearance, speed-
ometer calibration, headlight aim
and bumper height. Some of these
effects may lead to accidents and
could result in serious personal injury.
. For Two-Wheel Drive (2WD) models,
if your vehicle was originally equipped with 4 tires that were the
same size and you are only replacing
2 of the 4 tires, install the new tires
on the rear axle. Placing new tires on
the front axle may cause loss of
vehicle control in some driving condi-
tions and cause an accident and
personal injury.
. If the wheels are changed for any
reason, always replace with wheels
which have the same off-set dimen-
sion. Wheels of a different off-set
could cause premature tire wear,
degrade vehicle handling character-
istics and/or interference with the
brake discs/drums. Such interference
can lead to decreased braking effi-
ciency and/or early brake pad/shoe
wear. See “Wheels and tires” (P.10-
12) of this manual for wheel off-set
dimensions.
. Since the spare tire is not equipped
with the TPMS, when a spare tire is
mounted or a wheel is replaced, the
TPMS will not function and the low
tire pressure warning light will flash
for approximately 1 minute. The light
will remain on after 1 minute. Have
your tires replaced and/or TPMS
system reset as soon as possible. It
is recommended you visit an INFINITI
retailer for these services.

Floor mat installation ............................................ 7-6
FluidAutomatic Transmission Fluid (ATF) ....... 8-14
Brake fluid ....................................................... 8-15
Capacities and
recommended fluids/lubricants ................. 10-2
Engine coolant .................................................. 8-6
Engine oil ........................................................ 8-10
Power steering fluid ..................................... 8-14
Window washer fluid ................................... 8-15
Fog light switch ................................................... 2-42
Forward Emergency Braking (FEB) ............ 5-106
Forward Emergency Braking (FEB) system
warning light .......................................................... 2-11
Front passenger air bag and status light ..... 1-50
Front power seat adjustment ............................. 1-3
Front seat Front seat adjustment .................................... 1-3
Fuel
Capacities and
recommended fluids/lubricants ................. 10-2
Fuel economy .............................................. 5-124
Fuel information ............................... 10-4, 10-6
Fuel octane rating ............................ 10-4, 10-6
Fuel-filler cap .................................................. 3-26
Fuel-filler door ............................................... 3-26
Gauge .................................................................. 2-9
Fuel Efficient Driving Tips .............................. 5-123
Fuses ....................................................................... 8-23
Fusible links ........................................................... 8-25G
Garage door opener
HomeLink®Universal Transceiver ............ 2-58
Gas cap ................................................................... 3-26
Gauge ........................................................................\
. 2-6
Engine coolant temperature gauge ............ 2-8
Fuel gauge ......................................................... 2-9
Odometer ............................................................ 2-7
Speedometer ...................................................... 2-7
Tachometer ....................................................... 2-8
Trip computer ................................................. 2-27
General maintenance ............................................. 9-2
Glove box ............................................................... 2-48
H
Hazard warning flasher switch ........................... 6-2
Head restraints/headrests .................................. 1-8
Headlights Aiming control (See Adaptive Front
lighting System (AFS)) ................................ 2-40
Headlight switch ............................................ 2-36
Heated seats ......................................................... 2-43
Heated steering wheel ....................................... 2-45
Heater Engine block heater ................................... 5-143
High beam assist ................................................. 2-37
Hill start assist system ..................................... 5-137
HomeLink
®Universal Transceiver .................. 2-58
Hood release ......................................................... 3-23 Hook
Coat hooks ..................................................... 2-50
Trunk hooks ................................................... 2-50
Horn ........................................................................\
. 2-42
Hydraulic pump electric power steering ..... 5-128
I
Idling Stop System ............................................ 5-138
Idling Stop System indicator light .................. 2-16
Idling Stop System reminder buzzer .............. 2-18
Ignition switch
(Push-button) ................................................. 5-11
Automatic transmission models ................ 5-16
Immobilizer system .............................................. 2-31
Indicator
Lights ................................................................ 2-16
Vehicle information display ........................ 2-19
Indicator lights ...................................................... 2-16
Indicators for operation (vehicle
information display) ............................................ 2-21
INFINITI Drive Mode Selector ......................... 5-22
INFINITI InTouch Owner’s Manual .................. 4-2
INFINITI Vehicle Immobilizer System ............ 2-31 Engine start ..................................................... 2-31
Inside mirror .......................................................... 3-30
Inspection/maintenance (I/M) test ............. 10-25
Instrument brightness control ......................... 2-41
Instrument panel ..................................................... 2-5
Intelligent All-Wheel Drive (AWD) ............... 5-125
Intelligent Cruise Control (ICC) ....................... 5-74
11-3

11-4
Intelligent Cruise Control (ICC) system
ON indicator ......................................................... 2-24
Intelligent Key .......................................................... 3-2
Intelligent Key system ........................................... 3-7Battery replacement ..................................... 8-26
Key operating range ....................................... 3-8
Key operation ................................................. 3-10
Warning signals .............................................. 3-14
Intercooler cooling system .................................. 8-9
Interior light control switch .............................. 2-56
Interior light replacement .................................. 8-30
Interior lights ......................................................... 2-55
Interior trunk lid release .................................... 3-25
ISOFIX child restraint ......................................... 1-26
J
Jump starting ........................................................... 6-9
K
Keyless entry (See remote keyless
entry system) ........................................................ 3-16
Keys ........................................................................\
.... 3-2 For Intelligent Key system ............................. 3-7
L
LabelsAir bag warning labels ................................. 1-60
Air conditioner specification label ......... 10-16
Emission control information label ........ 10-16 Engine serial number ................................. 10-15
F.M.V.S.S./C.M.V.S.S.
certification label ........................................ 10-15
Tire and Loading
information label ............................. 8-35, 10-16
Vehicle identification number (VIN) ...... 10-14
Lane Departure Warning (LDW)/Lane
Departure Prevention (LDP) ............................ 5-34
LATCH system ..................................................... 1-26
License plate
Installing front license plate ..................... 10-17
Light Air bag warning light .................................... 1-60
Bulb replacement ........................................... 8-29
Fog light switch ............................................. 2-42
Headlight switch ............................................ 2-36
Indicator lights ................................................ 2-16
Interior light control switch ........................ 2-56
Interior lights ................................................... 2-55
Map lights ........................................................ 2-55
Personal lights ................................................ 2-56
Replacement ................................................... 8-29
Trunk light ....................................................... 2-57
Vanity mirror lights ....................................... 2-57
Warning/indicator lights and
audible reminders .......................................... 2-10
Lights Exterior and interior light replacement ... 8-30
Loading information (See vehicle
loading information) ......................................... 10-19 Lock
Automatic door locks ..................................... 3-6
Door locks .......................................................... 3-4
Power door lock ............................................... 3-4
Trunk lid ........................................................... 3-23
Locking with mechanical key ............................. 3-4
Log-in function .................................................... 3-16
Loose Fuel Cap warning ....................... 2-22, 3-28
Low fuel warning light ....................................... 2-12
Low outside temperature warning ................. 2-23
Low tire pressure warning light ...................... 2-12
Low tire pressure warning system (See Tire
Pressure Monitoring
System (TPMS)) ................................ 5-5, 6-3, 8-33
M
Maintenance Battery .............................................................. 8-16
General maintenance ...................................... 9-2
Indicators for maintenance (vehicle
information display) ...................................... 2-25
Inside the vehicle ............................................. 9-3
Maintenance log ............................................ 9-17
Maintenance precautions .............................. 8-3
Maintenance requirements ........................... 9-2
Maintenance schedules ................................. 9-6
Maintenance under severe
driving conditions .......................................... 9-16
Outside the vehicle ......................................... 9-2
Seat belt maintenance ................................. 1-20
Standard maintenance .................................... 9-7

11-6
Reporting safety defects ................................ 10-24
Request switch (See Intelligent
Key system) ........................................................... 3-10
Roadside assistance program ............................. 6-2
Rollover ..................................................................... 5-9
RoofMoonroof ......................................................... 2-54
Run-flat tires .......................................................... 6-4
S
Safety Child seat belts ............................................... 1-21
Reporting safety defects .......................... 10-24
Seat adjustment
Front power seat adjustment ....................... 1-3
Front seats ......................................................... 1-3
Seat belt(s)
Child safety ..................................................... 1-21
Infants ............................................................... 1-22
Injured persons ............................................... 1-14
Larger children ............................................... 1-22
Precautions on seat belt usage ................. 1-12
Pre-crash seat belts with
comfort function ............................................ 1-14
Pregnant women ........................................... 1-14
Seat belt cleaning ............................................. 7-7
Seat belt extenders ....................................... 1-20
Seat belt maintenance ................................. 1-20
Seat belt warning light and chime ............ 2-15
Seat belts ......................................................... 1-12
Seat belts with pretensioners .................... 1-59 Shoulder belt height adjustment ............... 1-20
Small children .................................................. 1-22
Three-point type ............................................ 1-15
Seat(s)
Driver-side memory ...................................... 3-33
Heated seats ................................................... 2-43
Seats .................................................................... 1-2
Security system Vehicle security system ............................... 2-30
Security system (INFINITI Vehicle
Immobilizer System) Engine start ..................................................... 2-31
Shift lever
Shift lock release ........................................... 5-19
Shift lock release, Transmission ...................... 5-19
Shifting
Automatic transmission ............................... 5-16
Shoulder belt height adjustment ..................... 1-20
SNOW mode ......................................................... 5-23
Spare tire ............................................................. 10-12
Spark plugs ............................................................ 8-20
Speedometer ............................................................ 2-7
SPORT mode ........................................................ 5-23
SPORT+ mode ...................................................... 5-23
Standard maintenance .......................................... 9-7
STANDARD mode ............................................... 5-22
Starting
Before starting the engine .......................... 5-14
Jump starting .................................................. 8-19
Precautions when starting and driving ..... 5-4
Push starting ................................................... 6-16 Starting the engine ....................................... 5-15
Status light, Front passenger air bag ............ 1-50
Steering Direct Adaptive Steering ........................... 5-129
Heated steering wheel ................................. 2-45
Power steering fluid ..................................... 8-14
Power steering system ............................. 5-128
Tilt/telescopic steering ................................ 3-28
Storage ................................................................... 2-46
Storage box ........................................................... 2-49
Sun visors ............................................................... 3-30
Sunglasses holder ................................................ 2-48
Supplemental air bag warning labels ............. 1-60
Supplemental air bag warning light ... 1-60, 2-15
Supplemental restraint system ........................ 1-42 Precautions on supplemental
restraint system ............................................. 1-42
Switch Autolight switch ............................................. 2-36
Fog light switch ............................................. 2-42
Hazard warning flasher switch .................... 6-2
Headlight switch ............................................ 2-36
Ignition switch ................................................ 5-16
Power door lock switch ................................. 3-5
Rear window and outside mirror
defroster switch ............................................. 2-35
Turn signal switch ......................................... 2-41
Vehicle Dynamic Control (VDC)
off switch ......................................................... 2-43
