Page 331 of 468
6 In case of emergency
Hazard warning flasher switch ..................................... 6-2
Roadside assistance program ....................................... 6-2
Emergency engine shut off ............................................ 6-3
Flat tire ........................................................................\
........ 6-3Tire Pressure Monitoring System (TPMS) ........... 6-3
Run-flat tires (if so equipped) .................................. 6-4
Changing a flat tire ..................................................... 6-4 Jump starting .................................................................... 6-9
Main battery (for all models) ............................... 6-12
Auxiliary battery (for 2.0L turbo gasoline
engine models) ......................................................... 6-14
Push starting ................................................................... 6-16
If your vehicle overheats .............................................. 6-16
Towing your vehicle ...................................................... 6-17 Towing recommended by INFINITI ................... 6-18
Vehicle recovery (freeing a stuck vehicle) ........ 6-19
Page 339 of 468
JVE0106X
5. Securely store the flat tire and jackingequipment in the vehicle.
6. Place the spare tire cover (if so equipped) and the trunk floor carpeting over the
damaged tire.
7. Close the trunk.
WARNING
. Always make sure that the spare tire
(if so equipped) and jacking equip-
ment are properly secured after use.
Such items can become dangerous
projectiles in an accident or sudden
stop. .
The T-type spare tire and small size
spare tire (if so equipped) are de-
signed for emergency use. See spe-
cific instructions under the heading
“Wheels and tires” (P.8-33). To start your engine with a booster battery,
the instructions and precautions below must
be followed.
WARNING
.
If done incorrectly, jump starting can
lead to a battery explosion, resulting
in severe injury or death. It could also
damage your vehicle.
. Explosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.
. Do not allow battery fluid to come
into contact with eyes, skin, clothing
or painted surfaces. Battery fluid is a
corrosive sulphuric acid solution
which can cause severe burns. If the
fluid should come into contact with
anything, immediately flush the con-
tacted area with water.
. Keep the battery out of the reach of
children.
. The booster battery must be rated at
12 volts. Use of an improperly rated
battery can damage your vehicle.
. Whenever working on or near a
battery, always wear suitable eye
protectors (for example, goggles or
In case of emergency6-9
JUMP STARTING
Page 340 of 468
6-10In case of emergency
industrial safety spectacles) and re-
move rings, metal bands, or any other
jewelry. Do not lean over the battery
when jump starting.
. Do not attempt to jump start a
frozen battery. It could explode and
cause serious injury.
. Your vehicle has an automatic engine
cooling fan. It could come on at any
time. Keep hands and other objects
away from it.
For 2.0L turbo gasoline engine models:
The vehicle has 2 batteries, a main
battery and an auxiliary battery. The
engine cannot be started if either bat-
tery is discharged. First, apply the
following procedure to the main battery
to jump-start the engine.
If the engine does not start, apply the
procedure to the auxiliary battery. For
the position of the batteries, see “Engine
compartment check locations” (P.8-4)
or “Battery” (P.8-16).
. Use the special battery that is dedi-
cated for the Idling Stop System,
with enhanced charge-discharge ca-
pacity and life performance. Using
the non-special battery could cause
early deterioration of the battery
and/or malfunction of the Idling Stop System. For the special battery, it is
recommended to use Genuine
NISSAN parts. For more information,
it is recommended you contact an
INFINITI retailer.
. It may take some time until the Idling
Stop System activates when the
battery is replaced or the battery
terminal is disconnected for extended
periods and then reconnected.
Page 343 of 468
JVE0194X
2.0L turbo gasoline engine
4. For 2.0L turbo gasoline engine model: Pull up the engine cover and remove it.
5. Connect jumper cables in the sequence as illustrated (
???).
CAUTION
.Always connect positive (+) to posi-
tive (+) and negative (−) to body
ground (as illustrated) − not to the
battery.
. Make sure the jumper cables do not
touch moving parts in the engine
compartment and that clamps do not contact any other metal.
6. Start the engine of the booster vehicle
and let it run for a few minutes.
7. Keep the engine speed of the booster vehicle
at about 2,000 rpm, and start
the engine of the vehicle being jump
started
.
CAUTION
Do not keep the starter motor engaged
for more than 10 seconds. If the engine
does not start right away, push the
ignition switch to the OFF position and
wait 10 seconds before trying again.
8. After starting your engine, carefully disconnect the negative cable and then
the positive cable (
???).
9. Replace the vent caps (if so equipped). Be sure to dispose of the cloth used to
cover the vent holes as it may be
contaminated with corrosive acid.
10. Put the battery cover and the engine cover back to the original location.
NOTE:
For 2.0L turbo gasoline engine models, if
the engine cannot be started after the procedure above, the auxiliary battery
may be discharged. Connect the jumper
cables to the auxiliary battery and apply
the procedure shown in “Auxiliary battery
(for 2.0L turbo gasoline engine models)”
(P.6-14).
In case of emergency6-13
Page 345 of 468
JVE0143X
6. Open the trunk.
7. Remove the clip
, then remove the
trunk trim.
8. Remove the vent caps, if so equipped, on the battery.
9. Connect the jumper cables in the se- quence as illustrated (
,,,).
CAUTION
.Be sure that the jumper cables do not
touch moving parts in the engine
compartment.
. Be sure that the jumper cable’s clamps do not contact any other
metal.
10. Start the engine of the booster vehicle
and let it run for a few minutes.
11. Depress the accelerator pedal of the booster vehicle
at about 2,000 rpm.
12. Start the engine of the jumped vehicle
in the normal manner.
CAUTION
Never keep the starter motor engaged
for more than 10 seconds. If the engine does not start right away, push the
ignition switch to the “LOCK” position
and wait at least 10 seconds before
trying again.
13. After the engine is started, carefully disconnect the jumper cables in the
opposite sequence from that illustrated
(
,,,).
14. Replace the vent caps, if removed.
15. Replace the trunk trim.
NOTE:
. If the engine cannot be started after the
procedure above, both the main and the
auxiliary batteries may be discharged.
Jump-start the vehicle by connecting
one set of the jumper cables to the main
battery and another set of the jumper
cables to the auxiliary battery at the
same time, using the procedure for
jump-starting each battery.
. If the engine cannot be started, even
when the main and the auxiliary bat-
teries are jump-started at the same
time, it is recommended you contact an
INFINITI retailer.
In case of emergency6-15
Page 359 of 468
8 Do-it-yourself
Maintenance precautions ............................................... 8-3
Engine compartment check locations ......................... 8-4VR30DDTT engine ..................................................... 8-4
2.0L turbo gasoline engine ...................................... 8-5
Engine cooling system (for VR30DDTT
engine models) ................................................................... 8-6
Checking engine coolant level ................................ 8-7
Changing engine coolant .......................................... 8-7
Engine cooling system (for 2.0L turbo gasoline
engine models) ................................................................... 8-8
Checking engine coolant level ................................. 8-8
Changing engine coolant .......................................... 8-9
Intercooler cooling system (for VR30DDTT
engine models) ................................................................... 8-9 Checking intercooler coolant level ...................... 8-10
Changing intercooler coolant ............................... 8-10
Engine oil ........................................................................\
.. 8-10 Checking engine oil level ......................................... 8-11
Changing engine oil and filter ................................ 8-11
Automatic Transmission Fluid (ATF) ........................ 8-14
Power steering fluid (models with hydraulic pump
electric power steering) ................................................ 8-14
Brake fluid ........................................................................\
. 8-15
Window washer fluid .................................................... 8-15 Battery ........................................................................\
...... 8-16
Main battery location ............................................ 8-17
Auxiliary battery location (for 2.0L turbo
gasoline engine models) ........................................ 8-17
Checking battery fluid level .................................. 8-18
Jump starting ........................................................... 8-19
Variable voltage control system ................................ 8-19
Drive belts ........................................................................\
8-19
Spark plugs ..................................................................... 8-20 Replacing spark plugs ............................................ 8-21
Air cleaner ........................................................................\
8-21
Windshield wiper blades .............................................. 8-22 Cleaning ..................................................................... 8-22
Replacing ................................................................... 8-22
Brakes ........................................................................\
........ 8-23 Self-adjusting brakes ............................................. 8-23
Brake pad wear warning ....................................... 8-23
Fuses ........................................................................\
.......... 8-23 Engine compartment ............................................. 8-24
Passenger compartment ....................................... 8-25
Intelligent Key battery replacement ......................... 8-26
Lights ........................................................................\
......... 8-29 Headlights ................................................................. 8-29
Exterior and interior lights ................................... 8-30
Page 377 of 468
JUMP STARTING
If jump starting is necessary, see “Jump
starting” (P.6-9). If the engine does not start
by jump starting, the battery may have to be
replaced. It is recommended you visit an
INFINITI retailer for this service.CAUTION
.Do not ground accessories directly to
the battery terminal. Doing so will
bypass the variable voltage control
system and the vehicle battery may
not charge completely.
. Use electrical accessories with the
engine running to avoid discharging
the vehicle battery.
The variable voltage control system mea-
sures the amount of electrical discharge
from the battery and controls voltage gen-
erated by the generator.
JVM0655X
VR30DDTT engine
1. Water pump
2. Alternator
3. Drive belt auto-tensioner
4. Crankshaft pulley
5. Air conditioner compressor
Do-it-yourself8-19
VARIABLE VOLTAGE CONTROL SYSTEMDRIVE BELTS
Page 456 of 468
11-4
Intelligent Cruise Control (ICC) system
ON indicator ......................................................... 2-24
Intelligent Key .......................................................... 3-2
Intelligent Key system ........................................... 3-7Battery replacement ..................................... 8-26
Key operating range ....................................... 3-8
Key operation ................................................. 3-10
Warning signals .............................................. 3-14
Intercooler cooling system .................................. 8-9
Interior light control switch .............................. 2-56
Interior light replacement .................................. 8-30
Interior lights ......................................................... 2-55
Interior trunk lid release .................................... 3-25
ISOFIX child restraint ......................................... 1-26
J
Jump starting ........................................................... 6-9
K
Keyless entry (See remote keyless
entry system) ........................................................ 3-16
Keys ........................................................................\
.... 3-2 For Intelligent Key system ............................. 3-7
L
LabelsAir bag warning labels ................................. 1-60
Air conditioner specification label ......... 10-16
Emission control information label ........ 10-16 Engine serial number ................................. 10-15
F.M.V.S.S./C.M.V.S.S.
certification label ........................................ 10-15
Tire and Loading
information label ............................. 8-35, 10-16
Vehicle identification number (VIN) ...... 10-14
Lane Departure Warning (LDW)/Lane
Departure Prevention (LDP) ............................ 5-34
LATCH system ..................................................... 1-26
License plate
Installing front license plate ..................... 10-17
Light Air bag warning light .................................... 1-60
Bulb replacement ........................................... 8-29
Fog light switch ............................................. 2-42
Headlight switch ............................................ 2-36
Indicator lights ................................................ 2-16
Interior light control switch ........................ 2-56
Interior lights ................................................... 2-55
Map lights ........................................................ 2-55
Personal lights ................................................ 2-56
Replacement ................................................... 8-29
Trunk light ....................................................... 2-57
Vanity mirror lights ....................................... 2-57
Warning/indicator lights and
audible reminders .......................................... 2-10
Lights Exterior and interior light replacement ... 8-30
Loading information (See vehicle
loading information) ......................................... 10-19 Lock
Automatic door locks ..................................... 3-6
Door locks .......................................................... 3-4
Power door lock ............................................... 3-4
Trunk lid ........................................................... 3-23
Locking with mechanical key ............................. 3-4
Log-in function .................................................... 3-16
Loose Fuel Cap warning ....................... 2-22, 3-28
Low fuel warning light ....................................... 2-12
Low outside temperature warning ................. 2-23
Low tire pressure warning light ...................... 2-12
Low tire pressure warning system (See Tire
Pressure Monitoring
System (TPMS)) ................................ 5-5, 6-3, 8-33
M
Maintenance Battery .............................................................. 8-16
General maintenance ...................................... 9-2
Indicators for maintenance (vehicle
information display) ...................................... 2-25
Inside the vehicle ............................................. 9-3
Maintenance log ............................................ 9-17
Maintenance precautions .............................. 8-3
Maintenance requirements ........................... 9-2
Maintenance schedules ................................. 9-6
Maintenance under severe
driving conditions .......................................... 9-16
Outside the vehicle ......................................... 9-2
Seat belt maintenance ................................. 1-20
Standard maintenance .................................... 9-7
Page 458 of 468
11-6
Reporting safety defects ................................ 10-24
Request switch (See Intelligent
Key system) ........................................................... 3-10
Roadside assistance program ............................. 6-2
Rollover ..................................................................... 5-9
RoofMoonroof ......................................................... 2-54
Run-flat tires .......................................................... 6-4
S
Safety Child seat belts ............................................... 1-21
Reporting safety defects .......................... 10-24
Seat adjustment
Front power seat adjustment ....................... 1-3
Front seats ......................................................... 1-3
Seat belt(s)
Child safety ..................................................... 1-21
Infants ............................................................... 1-22
Injured persons ............................................... 1-14
Larger children ............................................... 1-22
Precautions on seat belt usage ................. 1-12
Pre-crash seat belts with
comfort function ............................................ 1-14
Pregnant women ........................................... 1-14
Seat belt cleaning ............................................. 7-7
Seat belt extenders ....................................... 1-20
Seat belt maintenance ................................. 1-20
Seat belt warning light and chime ............ 2-15
Seat belts ......................................................... 1-12
Seat belts with pretensioners .................... 1-59 Shoulder belt height adjustment ............... 1-20
Small children .................................................. 1-22
Three-point type ............................................ 1-15
Seat(s)
Driver-side memory ...................................... 3-33
Heated seats ................................................... 2-43
Seats .................................................................... 1-2
Security system Vehicle security system ............................... 2-30
Security system (INFINITI Vehicle
Immobilizer System) Engine start ..................................................... 2-31
Shift lever
Shift lock release ........................................... 5-19
Shift lock release, Transmission ...................... 5-19
Shifting
Automatic transmission ............................... 5-16
Shoulder belt height adjustment ..................... 1-20
SNOW mode ......................................................... 5-23
Spare tire ............................................................. 10-12
Spark plugs ............................................................ 8-20
Speedometer ............................................................ 2-7
SPORT mode ........................................................ 5-23
SPORT+ mode ...................................................... 5-23
Standard maintenance .......................................... 9-7
STANDARD mode ............................................... 5-22
Starting
Before starting the engine .......................... 5-14
Jump starting .................................................. 8-19
Precautions when starting and driving ..... 5-4
Push starting ................................................... 6-16 Starting the engine ....................................... 5-15
Status light, Front passenger air bag ............ 1-50
Steering Direct Adaptive Steering ........................... 5-129
Heated steering wheel ................................. 2-45
Power steering fluid ..................................... 8-14
Power steering system ............................. 5-128
Tilt/telescopic steering ................................ 3-28
Storage ................................................................... 2-46
Storage box ........................................................... 2-49
Sun visors ............................................................... 3-30
Sunglasses holder ................................................ 2-48
Supplemental air bag warning labels ............. 1-60
Supplemental air bag warning light ... 1-60, 2-15
Supplemental restraint system ........................ 1-42 Precautions on supplemental
restraint system ............................................. 1-42
Switch Autolight switch ............................................. 2-36
Fog light switch ............................................. 2-42
Hazard warning flasher switch .................... 6-2
Headlight switch ............................................ 2-36
Ignition switch ................................................ 5-16
Power door lock switch ................................. 3-5
Rear window and outside mirror
defroster switch ............................................. 2-35
Turn signal switch ......................................... 2-41
Vehicle Dynamic Control (VDC)
off switch ......................................................... 2-43
