INFINITI Q50 2021 Quick Reference Guide
Manufacturer: INFINITI, Model Year: 2021, Model line: Q50, Model: INFINITI Q50 2021Pages: 32, PDF Size: 3.54 MB
Page 21 of 32
18
FM/AM/HD/SiriusXM® Radio (if so equipped)
Apple CarPlay® lets you use your compatible iPhone® to make calls, listen to music, send and receive
messages, get directions and use iPhone apps directly from your vehicle display. The display may be
different based on iOS software version.
C
onnect your compatible iPhone to the USB connection port located under the control panel.
• Depending on the setting, the startup information screen will appear on the upper display.
• Touch “Yes” then “OK” to use Apple CarPlay.
• After the iPhone is connected, the Apple CarPlay home screen will appear, and the iPhone functions
displayed on the screen can be operated by the in-vehicle system.
While connected to Apple CarPlay, Siri
® operation can be accessed.
There are two ways to start a Siri session:
1. Press and hold the button on the steering wheel.
2. Touch and hold the key or key on the lower left corner of the Apple CarPlay screen.
Press the
button on the steering wheel or touch the key or key on the lower left corner
of the Apple CarPlay screen to end the Siri session.
Keep the interior of the vehicle as quiet as possible. Close the windows to eliminate the surrounding noises
(traffic noises, vibration sounds, etc.) and point the heater and air conditioner vents away from the ceiling,
which may prevent the system from recognizing the voice commands correctly.
When Siri finishes responding the session will automatically end and return to the home screen.
Some Siri functions may not be available during driving. For functions that can be used with Siri, please
refer to the Apple
® website.
Please see your INFINITI InTouch™ Owner’s Manual for important safety information, system limitations, and additional operating and feature information.
Apple CarPlay®
Page 22 of 32
19
Android Auto™ connects with your compatible Android® phone to control your phone, apps and navigation directly from your vehicle display.
INITIAL SETUP
• Download the Android Auto app from the Google Play™ store to your compatible Android phone.
• Launch the app fr om your Android phone and follow the directions for setting up the application. Several permissions will need to be given to the app for
Android Auto to fully function on your in-vehicle system.
USING ANDROID AUTO
To connect your Android phone to the in-vehicle system, you must connect a USB cable to the USB
connection port located under the control panel.
• Depending on the setting, the startup information screen will appear on the upper display.
• Touch “Yes” then “OK” to use Android Auto.
• After the cellular phone is connected, the Android Auto home screen will appear and can be operated by
the in-vehicle system. When connected to Android Auto, Google AssistantTM can be accessed. There are
three ways to start Google AssistantTM:
1. Press and hold the button on the steering wheel until a beep is heard.
2. Touch the key on the Launch Bar.
3.
Say “OK Google” (requires appropriate permissions enabled via cellular phone).
To return to the Android Auto home screen after operation, touch the
key on the Launch Bar.
To exit the Android Auto screen, touch the
key on the Launch Bar and then touch the exit key.
To return to the Android Auto home screen from the main menu:
1. Press the MENU button and touch the key , or
2. Touch the “Information” key , touch the “Apps” key, and then select the “Android Auto” key.
If you have difficulties with connection or performance, try a different USB cable.
Please see your INFINITI InTouch™ Owner’s Manual for important safety information, system limitations, and additional operating and
feature information.
Android Auto™
Page 23 of 32
20
Navigation System (if so equipped)
Use the Infiniti controller and OK button to navigate through
the upper display screens.
•
Press the
button to return to the previous screen.
•
Press the MAP/VOICE button
to display the map.
SETTING A ROUTE
To set a route, first ensure that the correct region is selected on
the upper display.
1.
Pr
ess the MENU button
below the lower display.
2.
Select the
“Destination” key
on the lower display.
3
.
Select the pr
eferred destination setting method.
4.
E
nter the address number, street name, and city as
prompted by the screen.
CANCELING A ROUTE
1.
Pr
ess the MENU button
below the lower display.
2.
Select the
“Cancel Route” key
on the lower display.
GUIDANCE VOLUME
•
While guidanc
e is being announced, the guidance volume can be
adjusted by turning the audio system volume knob.
•
The guidanc
e volume can also be adjusted in the “Settings” menu.
1. Pr
ess the MENU button
below the lower display.
2.
Select the
“Settings” key and then the
“Volume & Beeps” key
on the display.
3
.
N
ext, select the “Guidance Volume” key. Use
the “–” and “+” keys
to adjust the volume.Please see your INFINITI InTouch™ Owner’s Manual for important safety information,
system limitations, and additional operating and feature information.
Page 24 of 32
21
INFINITI InTouch™ Services
If equipped, your vehicle may include INFINITI
InTouch™ connected features and services
such as Emergency SOS calling, Automatic
Collision Notification, Wi-Fi, Remote Services,
Navigation, Bluetooth
® and more.
For complete information about your INFINITI
InTouch™ features and services, please visit
usa.infinitiintouch.com or
call 1-855-444-7244. For frequently
asked questions, please visit
www.infinitiusa.com/intouch/faq.
To access INFINITI InTouch™ Services:
1.
Pr
ess the MENU button
under
the lower display.
2.
Select the
“InTouch Services” key
on
the lower display.
·
Pr
ess the in-vehicle telematics SOS button
in case of an emergency, located above
and in front of the rearview mirror. INFINITI INTOUCH™
SERVICES ENROLLMENT
1.
Cr
eate an INFINITI Owner Portal account.
( https://owners.infinitiusa.com/iowners/)
2.
F
rom your INFINITI Owner
Portal account, enroll in INFINITI
InTouch™ Services.
3
.
Do
wnload the INFINITI InTouch™ Services
companion app from the App store and
log in using your INFINITI Owner Portal
ID and password.
Available services may include:
•
A
utomatic Collision Notification
•
Emergency Call
•
Wi-Fi
Please see your INFINITI InTouch™ Owner’s Manual and Owner’s Manual for important safety information, system limitations, and additional operating and feature information.
Page 25 of 32
22
Upper Display (Shortcut Menu)
The upper touch-screen display (upper display) provides the information, the view monitor system or
the navigation map (if so equipped).
To control the upper display, use the touch-screen, the Infiniti controller
or the steering
wheel switches .
WITHOUT NAVIGATION (if so equipped)
With no item selected, press the OK button
on the Infiniti controller
or steering wheel switch to display the shortcut menu on the upper display. The
shortcut menu will provide options such as:
• Audio Source
•
Audio List
•
Call Hist
ory
•
Phonebook
• Display ed Feature
•
Cust
omize This Menu
•
T
urn ALC ON/Turn ALC OFF
WITH NAVIGATION (if so equipped)
With the current vehicle location displayed on the map screen, press the OK button
on the Infiniti
controller or steering wheel switch to display the shortcut menu on the upper display.
Selecting the shortcut menu key
on the map screen will also display the shortcut menu . The
shortcut menu will provide options such as:
•
Audio Source
•
Audio List
•
Call Hist
ory
•
Phonebook
•
Canc
el Route
•
P
oints of Interest
•
Save Location
•
Split
Map Views
•
Cust
omize This Menu
•
T
urn ALC ON/Turn ALC OFF
Please see your INFINITI InTouch™ Owner’s Manual for important safety information, system limitations, and additional operating and
feature information.
Page 26 of 32
23
The ICC system is designed to maintain a
selected distance from the vehicle in front
of you and reduce the speed to match a
slower vehicle ahead.
VEHICLE-TO-VEHICLE
DISTANCE CONTROL MODE
•
T
o turn on the vehicle-to-vehicle (ICC)
cruise control mode, quickly push and
release the MAIN switch
.
•
T
o increase the distance to the
vehicle ahead to be maintained by
the ICC system, push the distance
switch
until the display shows the
desired set distance, which is shown
by the number of lines on the set
distance indicator
.
•
When a
vehicle is detected
ahead, a vehicle ahead detection
indicator
will illuminate and your
vehicle will reduce the speed to match the slower vehicle.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
•
T
o turn on the conventional (fixed speed) cruise control mode, push and hold
the MAIN switch
for longer than about 1.5 seconds.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
SETTING A CRUISING SPEED
•
Push the cruise c
ontrol ON-OFF switch
to turn
on the system.
•
With the
vehicle at the desired speed, push down the
control switch
to SET to enable cruise control.
•
The cruising speed c
an be adjusted to a higher or lower
speed by toggling the control switch
up or down.
CANCELING THE PRESET SPEED
•
Push the CANCEL switch
or tap the brake pedal.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
Cruise Control (if so equipped)Intelligent Cruise Control (ICC)
(if so equipped)
Page 27 of 32
24
Blind Spot Warning (BSW)
(if so equipped)
• The Blind Spo t Warning (BSW) can help alert
the driver of other vehicles in the blind spot area
when changing lanes.
TURNING BLIND SPOT WARNING ON OR OFF
• BSW can be turned on or off through the “Driver
Assistance” section of the lower display.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
Lane Departure Warning (LDW)
(if so equipped)
Lane Departure Warning (LDW) warns you if the vehicle is beginning
to leave the traveling lane.
• LDW is activated at speeds of 45 mph (70 km/h) and above and the
lane markings are clear.
•
I
f a front wheel passes over a lane marking, LDW will warn
you through a visual alert
and an
intermittent vibration in the steering wheel
for up to 1.5 seconds.
•
The Dynamic driv
er assistance switch
is
located on the steering wheel.
TURNING LANE DEPARTURE
WARNING ON OR OFF
• LDW can be turned on or off through the “Driver
Assistance” section of the lower display.
Please see your Owner’s Manual for important safety information, system limitations, and additional operating
and feature information.
