Page 226 of 466

CD:
.Disc title
. Track title
CD with compressed audio files:
. Folder title
. File title
. Song title
. Album title
. Artist
Next/Previous Track and Fast
Forward/Rewind:
Push the Forward or Rewind button for
more than 1.5 seconds while a CD is being
played to fast forward or rewind through
the track. When the button is released, the
CD will return to normal play speed.
When the Forward button is pushed for
less than 1.5 seconds while a CD is being
played, the next track on the CD will be
played.
When the Rewind button is pushed for less
than 1.5 seconds within 3 seconds after
the current track started playing, the
previous track will be played.
When the Rewind button is pushed for less
than 1.5 seconds after 3 seconds from when the current track started playing, the
beginning of the current track will be
played.
REPEAT (RPT), RANDOM (RDM):
When the RPT button is pushed while the
CD is played, the play pattern can be
changed as follows:
(CD)
(CD with compressed audio files)
CD EJECT:
When the CD EJECT button is pushed with
the CD loaded, the CD will be ejected.
When this button is pushed while the CD is
being played, the CD will be ejected.
If the CD comes out and is not removed, it
will be pulled back into the slot to protect
it.
DVD (Digital Versatile Disc) PLAYER
OPERATION (models with naviga-
tion system)
Precautions
Start the engine when using the DVD
entertainment system.
Movies will not be shown on the front
display while the vehicle is in any drive
position to reduce driver distraction. Audio
is available when a movie is played. To
view movies in the front display, stop the
vehicle in a safe location, move the shift
lever to the P (Park) position (Automatic
Transmission models) or in an appropriate
gear (Manual Transmission models) and
apply the parking brake.
WARNING
. The driver must not attempt to operate
the DVD system or wear the headphones
while the vehicle is in motion so that full
attention may be given to vehicle opera-
tion.
. Do not attempt to modify the system to
display a movie on the front screen while
the vehicle is being driven. Doing so may
Monitor, climate, audio, phone and voice recognition systems4-57
Page 227 of 466

4-58Monitor, climate, audio, phone and voice recognition systems
distract the driver and may cause a
collision and serious personal injury or
death.
CAUTION
.Only operate the DVD while the vehicle
engine is running. Operating the DVD for
extended periods of time with the
engine OFF can discharge the vehicle
battery.
. Do not allow the system to get wet.
Excessive moisture such as spilled
liquids may cause the system to mal-
function.
. While playing VIDEO-CD media, this DVD
player does not guarantee complete
functionality of all VIDEO-CD formats.
Display settings
To adjust the front display mode, push the
SETTING button while the DVD is being
played, select the “Others”key and then
select the “Display”key.
To adjust the display ON/OFF, brightness,
tint, color and contrast, select the “DisplayAdjustment”
key and then select each key.
Then you can adjust each item using the
INFINITI controller. After changes have
been made push the BACK button to save
the setting.
SAA2497
Playing a DVD
DISC·AUX button:
Park the vehicle in a safe location for the
front seat occupants to operate the DVD
drive while watching the images.
Push the DISC·AUX button on the instru-
ment panel and turn the display to the DVD
mode.
When a DVD is loaded, it will be replayed
automatically.
The operation screen will be turned on
when the DISC·AUX button located on the
instrument panel is pushed while a DVD is
being played, and it will turn off auto-
Page 240 of 466

SAA2974
Automatic transmission models
SAA2426
Manual transmission models
iPod®PLAYER OPERATION
Connecting iPod
®
Open the console lid and connect the
iPod®cable to the USB connector. If
compatible, the battery of the iPod®is
charged while the connection to the
vehicle.
Depending on the version of the iPod
®, the
display on the iPod®shows an INFINITI or
Accessory Attached screen when the con-
nection is completed. When the iPod
®is
connected to the vehicle, the iPod®music
library can only be operated by the vehicle
audio controls.
* iPod
®is a trademark of Apple Inc.,
registered in the U.S. and other countries.
WARNING
Do not connect, disconnect or operate the
USB device while driving. Doing so can be a
distraction. If distracted you could lose
control of your vehicle and cause an
accident or serious injury.
CAUTION
. Do not force the USB device into the USB
port. Inserting the USB device tilted or
up-side-down into the port may damage
the port. Make sure that the USB device
is connected correctly into the USB port.
. Do not grab the USB port cover (if so
equipped) when pulling the USB device
out of the port. This could damage the
port and the cover.
. Do not leave the USB cable in a place
where it can be pulled unintentionally.
Pulling the cable may damage the port.
Refer to your device manufacturer’s owner
information regarding the proper use and
care of the device.
Compatibility
The following models are available:
Models with navigation system:
.Fifth generation iPod
®(version 1.2.3 or
later)
. iPod Classic
®(version 1.1.1 or later)
. First generation iPod touch®(version
2.0.0 or later)
Monitor, climate, audio, phone and voice recognition systems4-71
Page 289 of 466

4-120Monitor, climate, audio, phone and voice recognition systems
Audio Commands:
CommandAction
CD Starts to play a CD.
FM Turns to the FM band, selecting the station last played.
AM Turns to the AM band, selecting the station last played.
XM Turns to the SiriusXM Satellite Radio band, selecting the channel last played.
USB Turns on the USB memory.
Bluetooth Audio Turns on the Bluetooth
®audio player.
Page 312 of 466

otherwise the starter could be damaged.
4.Warm-up
Allow the engine to idle for at least 30
seconds after starting. Do not race the
engine while warming it up. Drive at
moderate speed for a short distance
first, especially in cold weather. In cold
weather, keep the engine running for a
minimum of 2 - 3 minutes before
shutting it off. Starting and stopping
the engine over a short period of time
may make the vehicle more difficult to
start.
When racing the engine up to 4,000
rpm or more under no load condition,
the engine will enter the fuel cut mode.
5. To stop the engine, shift the shift lever to the P (Park) position (AT model) or
move the shift lever to the N (Neutral)
position (MT model), and push the
ignition switch to the OFF position.
NOTE:
Care should be taken to avoid situations
that can lead to potential battery dis-
charge and potential no-start conditions
such as: 1.
Installation or extended use of electro-
nic accessories that consume battery
power when the engine is not running
(Phone chargers, GPS, DVD players,
etc.)
2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the battery may need to be
charged to maintain battery health.
AUTOMATIC TRANSMISSION
7 speed automatic transmission
The automatic transmission in your vehicle
is electronically controlled by a transmis-
sion control module to produce maximum
efficiency and smooth operation.
Shown on the following pages are the
recommended operating procedures for
this transmission. Follow these procedures
for maximum vehicle performance and
driving enjoyment.
Starting the vehicle
After starting the engine, fully depress the
foot brake pedal and push the shift lever
button before shifting the shift lever to the
R (Reverse), N (Neutral), D (Drive), DS (Drive
Sport) or Manual shift mode position. Be
sure the vehicle is fully stopped before
attempting to shift the shift lever.
This automatic transmission model is
designed so that the foot brake pedal
must be depressed before shifting from P
(Park) to any drive position while the
ignition switch position is ON.
Starting and driving5-13
DRIVING THE VEHICLE
Page 393 of 466

8-4Maintenance and do-it-yourself
fraying, wear or damage.
Seats:Check seat position controls such as
seat adjusters, seatback recliners, etc. to
ensure they operate smoothly and that all
latches lock securely in every position.
Check that the head restraints move up
and down smoothly and that the locks (if
so equipped) hold securely in all latched
positions.
Steering wheel: Check for changes in the
steering conditions, such as excessive free
play, hard steering or strange noises.
Warning lights and chimes: Make sure that
all warning lights and chimes are operating
properly.
Windshield defroster: Check that the air
comes out of the defroster outlets properly
and in sufficient quantity when operating
the heater or air conditioner.
Windshield wiper and washer*: Check that
the wipers and washers operate properly
and that the wipers do not streak.
Under the hood and vehicle
The maintenance items listed here should
be checked periodically (for example, each
time you check the engine oil or refuel).
Battery*: Check the fluid level in each cell. It should be between the MAX and MIN
lines. Vehicles operated in high tempera-
tures or under severe condition require
frequent checks of the battery fluid level.
NOTE:
Care should be taken to avoid situations
that can lead to potential battery dis-
charge and potential no-start conditions
such as:
1.
Installation or extended use of electro-
nic accessories that consume battery
power when the engine is not running
(Phone chargers, GPS, DVD players,
etc.)
2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the battery may need to be
charged to maintain battery health.
Brake and clutch fluid levels*: Make sure
that the brake and clutch fluid levels are
between the MAX and MIN lines on the
reservoir.
Engine coolant level*: Check the coolant
level when the engine is cold.
Engine drive belt*: Make sure that the
drive belt is not frayed, worn, cracked or
oily. Engine oil level*:
Check the level after
parking the vehicle on a level surface and
turning off the engine. Wait more than 15
minutes for the oil to drain back into the oil
pan.
Exhaust system: Make sure there are no
loose supports, cracks or holes. If the
sound of the exhaust seems unusual or
there is a smell of exhaust fumes, im-
mediately have the exhaust system in-
spected by an INFINITI retailer. (See
“Precautions when starting and driving”
(P.5-3) for exhaust gas (Carbon monoxide).)
Fluid leaks: Check under the vehicle for
fuel, oil, water or other fluid leaks after the
vehicle has been parked for a while. Water
dripping from the air conditioner after use
is normal. If you should notice any leaks or
if gasoline fumes are evident, check for the
cause and have it corrected immediately.
Power steering fluid level* and lines:
Check the level with the engine off. Check
the lines for proper attachment, leaks,
cracks, etc.
Radiator and hoses: Check the front of the
radiator and clean off any dirt, insects,
leaves, etc., that may have accumulated.
Make sure the hoses have no cracks,
deformation, rot or loose connections.
Page 404 of 466

amount of window washer fluid.
Recommended fluid is Genuine NISSAN
Windshield Washer Concentrate Cleaner &
Antifreeze or equivalent.
CAUTION
.Do not substitute engine anti-freeze
coolant for window washer solution. This
may result in damage to the paint.
. Do not fill the window washer reservoir
tank with washer fluid concentrates at
full strength. Some methyl alcohol
based washer fluid concentrates may
permanently stain the grille if spilled
while filling the window washer reser-
voir tank.
. Pre-mix washer fluid concentrates with
water to the manufacturer’ s recom-
mended levels before pouring the fluid
into the window washer reservoir tank.
Do not use the window washer reservoir
tank to mix the washer fluid concentrate
and water.
. Keep the battery surface clean and dry.
Clean the battery with a solution of
baking soda and water.
. Make certain the terminal connections
are clean and securely tightened.
. If the vehicle is not to be used for 30
days or longer, disconnect the negative
(−) battery terminal cable to prevent
discharging it.
NOTE:
Care should be taken to avoid situations
that can lead to potential battery dis-
charge and potential no-start conditions
such as:
1. Installation or extended use of electro-
nic accessories that consume battery
power when the engine is not running
(Phone chargers, GPS, DVD players,
etc.)
2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the battery may need to be
charged to maintain battery health.
CAUTION
When the battery cable is removed from the
battery terminal, do not close either of front doors. The automatic window adjusting
function will not work, and the side roof
panel may be damaged.
To disconnect the negative (−
) battery
terminal, perform the procedure in the
following order. Otherwise, the window
and the side roof panel may contact and
be damaged.
1. Close the windows.
2. Open the hood.
3. Close and lock all the doors.
4. Disconnect the negative (− ) battery
terminal.
5. Securely close the hood.
To connect the negative (−) battery term-
inal, perform the procedure in the follow-
ing order. Otherwise, the window and the
side roof panel may contact and be
damaged.
1. Unlock and open the driver side door. Do not close the door.
2. Open the hood.
3. Connect the negative (−) battery term- inal. Then close the hood.
4. Fully open the driver side door window.
Maintenance and do-it-yourself8-15
BATTERY
Page 457 of 466

10-2
Cleaning exterior and interior ....................... 7-2, 7-4
Climate control, Automatic climate control ........ 4-30
Clock ................................................................ 2-43
Closing the retractable hard top ....................... 3-24
Clutch fluid ....................................................... 8-13
Cockpit ............................................................... 2-3
Cold weather driving ......................................... 5-58
Compact Disc (CD) player (See audio system) ... 4-56
Compact spare tire ........................................... 8-39
Console box ...................................................... 2-47
Controller, Center multi-function control panel .... 4-5
ControlsControl panel button ...................................... 4-3
INFINITI Controller .......................................... 4-5
Coolant Capacities and
recommended fuel/lubricants ........................ 9-2
Changing engine coolant ............................... 8-9
Checking engine coolant level ........................ 8-9
Corrosion protection ........................................... 7-7
Cruise control ................................................... 5-21 Fixed speed cruise control (on ICC system) ... 5-41
Intelligent cruise control (ICC) system .......... 5-23
Cup holders ...................................................... 2-45
Current fuel consumption .................................. 2-26
D
Daytime running light system ........................... 2-37
Defroster switch, Rear window and outside mirror
defroster switch ................................................ 2-34
Dimensions ....................................................... 9-10 Distance to empty ............................................. 2-26
Door/trunk open warning .................................. 2-21
Dot matrix liquid crystal display ....................... 2-17
Drive belt .......................................................... 8-18
Drive positioner ................................................ 3-38
Driving
Cold weather driving .................................... 5-58
Driving with automatic transmission ............ 5-13
Driving with manual transmission ................ 5-18
Precautions when starting and driving ........... 5-3
DS (Drive Sport) mode ...................................... 5-15
DVD player operation ........................................ 4-57
E
Economy, Fuel ................................................... 5-47
Elapsed time ..................................................... 2-26
Elapsed time and trip odometer ........................ 2-26
Emergency tire puncture repair kit ...................... 6-8
Emission control information label .................... 9-12
Emission control system warranty ..................... 9-22
Engine Before starting the engine ........................... 5-12
Break-in schedule ........................................ 5-46
Capacities and
recommended fuel/lubricants ........................ 9-2
Changing engine coolant ............................... 8-9
Changing engine oil and filter ...................... 8-10
Checking engine coolant level ........................ 8-9
Checking engine oil level ............................. 8-10
Coolant temperature gauge ............................ 2-8
Emergency engine shut off ........................... 5-11 Engine block heater ..................................... 5-59
Engine compartment check locations ............. 8-7
Engine cooling system ................................... 8-8
Engine oil .................................................... 8-10
Engine oil and oil filter recommendation ........ 9-6
Engine oil replacement indicator .................. 2-24
Engine oil viscosity ........................................ 9-7
Engine serial number ................................... 9-12
Engine specifications ..................................... 9-8
Engine start operation indicator (Automatic
Transmission models) .................................. 2-20
Engine start operation indicator (Manual
Transmission models) .................................. 2-21
If your vehicle overheats .............................. 6-16
Starting the engine ...................................... 5-12
Event Data Recorders (EDR) ............................... 9-24
Exhaust gas (carbon monoxide) .......................... 5-3
F
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-12
Filter
Air cleaner housing filter .............................. 8-19
Changing engine oil and filter ...................... 8-10
Flashers (See hazard warning flasher switch) ...... 6-2
Flat tire ............................................................... 6-3 Changing flat tire (with spare tire) ................. 6-4
Repairing flat tire (with emergency tire
puncture repair kit) ........................................ 6-8
Flat towing ........................................................ 9-20
Floor mat cleaning .............................................. 7-5
Page 458 of 466

FluidAutomatic transmission fluid (ATF) ............... 8-12
Brake and clutch fluid .................................. 8-13
Brake fluid ................................................... 8-14
Capacities and
recommended fuel/lubricants ........................ 9-2
Engine coolant ............................................... 8-8
Engine oil .................................................... 8-10
Power steering fluid ..................................... 8-13
Window washer fluid ................................... 8-14
FM-AM-SAT radio with Compact Disc
(CD) player ........................................................ 4-53
Fog light switch ................................................ 2-39
Front passenger air bag and status light ........... 1-42
Front power seat adjustment ............................... 1-3
Front seat, Front seat adjustment ........................ 1-3
Front-seat active head restraints ....................... 1-10
Fuel Capacities and
recommended fuel/lubricants ........................ 9-2
Fuel economy............................................... 5-47
Fuel economy information (display) .............. 4-11
Fuel octane rating .......................................... 9-4
Fuel recommendation ..................................... 9-4
Fuel-filler cap ............................................... 3-31
Fuel-filler door ............................................. 3-31
Gauge ............................................................ 2-9
LOOSE FUEL CAP warning ............................. 3-33
Fuel Efficient Driving Tips .................................. 5-46
Fuses ................................................................ 8-22
Fusible links ..................................................... 8-23G
Garage door opener HomeLink®Universal Transceiver ................. 2-54
Gas cap ............................................................ 3-31
Gauge ................................................................. 2-6
Engine coolant temperature gauge ................. 2-8
Fuel gauge ..................................................... 2-9
Odometer....................................................... 2-7
Speedometer ................................................. 2-7
Tachometer .................................................... 2-8
Trip computer .............................................. 2-26
General maintenance .......................................... 8-2
Glove box ......................................................... 2-47
H
Hands-free phone system, Bluetooth®
(models with navigation system) ....................... 4-77
Hands-free phone system, Bluetooth®
(models without navigation system) .................. 4-87
Hard top If the top does not open or close ................. 3-24
Indicators for retractable hard top
(dot matrix) ......................................... 2-23, 3-22
Initializing .................................................... 3-25
Operating using the Intelligent Key .............. 3-25
Retractable hard top operation .................... 3-18
Hazard warning flasher switch ............................ 6-2
Head restraints ................................................... 1-7 Headlights
Bulb replacement ......................................... 8-27
Headlight switch .......................................... 2-35
Xenon headlights ......................................... 2-34
Heated seats .................................................... 2-39
Heater Automatic climate control ............................ 4-30
Engine block heater ..................................... 5-59
HomeLink
®Universal Transceiver ...................... 2-54
Hood release .................................................... 3-17
Horn ................................................................. 2-39
I
Ignition switch (Push-button) ................................................. 5-9
Manual transmission models ....................... 5-18
Immobilizer system ........................................... 2-30
In-cabin microfilter ............................................ 4-38
Indicator Dot matrix display ....................................... 2-17
Lights .......................................................... 2-15
INFINITI Vehicle Immobilizer System .................. 2-30
INFINITI voice recognition system .................... 4-101
INFO button ........................................................ 4-9
Inside mirror ..................................................... 3-35
Inspection/maintenance (I/M) test .................... 9-23
Instrument brightness control ........................... 2-38
Instrument panel ................................................ 2-4
Intelligent cruise control (ICC) system ............... 5-23 Preview function .......................................... 5-45
10-3
Page 459 of 466

10-4
Intelligent Cruise Control (ICC) system
warning light .................................................... 2-12
Intelligent Key ..................................................... 3-3
Intelligent Key battery discharge indicator ........ 2-20
Intelligent Key insertion indicator ...................... 2-20
Intelligent Key removal indicator ....................... 2-20
Intelligent Key system ......................................... 3-7Battery replacement ..................................... 8-25
Key operating range ....................................... 3-9
Key operation .............................................. 3-10
Warning light ............................................... 2-12
Warning signals ........................................... 3-12
Intelligent Key warning light ............................. 2-12
Interior light control switch ............................... 2-52
Interior light replacement .................................. 8-28
Interior lights .................................................... 2-52
Interior trunk lid release ................................... 3-30
iPod
®player operation ..................................... 4-71
ISOFIX child restraint ........................................ 1-21
J
Jump starting .................................................... 6-14
K
Keyless entry (See remote keyless
entry system) .................................................... 3-14
Keys ................................................................... 3-3 For Intelligent Key system .............................. 3-7
L
Labels
Air bag warning labels ................................. 1-48
Air conditioner specification label ................ 9-13
Emission control information label ............... 9-12
Engine serial number ................................... 9-12
F.M.V.S.S./C.M.V.S.S. certification label ........ 9-12
Tire and Loading Information label ...... 8-32, 9-13
Vehicle identification number (VIN) .............. 9-11
License plate, Installing front license plate ....... 9-13
Light Air bag warning light ................................... 1-48
Bulb replacement ......................................... 8-27
Fog light switch ........................................... 2-39
Headlight switch .......................................... 2-35
Headlights bulb replacement ....................... 8-27
Indicator lights ............................................ 2-15
Interior light control switch .......................... 2-52
Interior lights ............................................... 2-52
Map lights ................................................... 2-52
Replacement ................................................ 8-27
Trunk light ................................................... 2-53
Vanity mirror lights ...................................... 2-53
Warning/indicator lights and
audible reminders ........................................ 2-10
Xenon headlights ......................................... 2-34
Lights, Exterior and interior light replacement ... 8-28
Loading information (See vehicle
loading information) ......................................... 9-17 Lock
Automatic door locks ..................................... 3-6
Door locks ..................................................... 3-5
Power door lock ............................................. 3-5
Trunk lid ...................................................... 3-28
Locking with mechanical key ............................... 3-5
Low fuel warning .............................................. 2-21
Low tire pressure warning light ......................... 2-12
Low tire pressure warning system (See tire
pressure monitoring system (TPMS)) ................... 5-4
Low washer fluid warning ................................. 2-21
M
Maintenance Battery ......................................................... 8-15
General maintenance ..................................... 8-2
Indicators for maintenance ........................... 2-24
Inside the vehicle .......................................... 8-3
Maintenance precautions ............................... 8-5
Maintenance requirements ............................. 8-2
Outside the vehicle ........................................ 8-2
Seat belt maintenance ................................. 1-17
Malfunction indicator light (MIL) ....................... 2-15
Map lights ........................................................ 2-52
Master warning light ......................................... 2-13
Mechanical key (Intelligent Key system) .............. 3-4
Memory storage, Automatic drive positioner ..... 3-39
Meter Trip computer .............................................. 2-26
Meters and gauges ............................................. 2-6
Instrument brightness control ...................... 2-38
