8-12Maintenance and do-it-yourself
Y51D-V-E01-662E477D-FA0C-4DA9-8B55-B58B05C7E362The engine cooling system is filled at the
factory with a pre-diluted mixture of 50%
Genuine NISSAN Long Life Antifreeze/Cool-
ant (blue) and 50% water to provide year-
round anti-freeze and coolant protection.
The anti-freeze solution contains rust and
corrosion inhibitors. Additional engine
cooling system additives are not neces-
sary.
WARNING
.Never remove the radiator cap when the
engine is hot. Wait until the engine and
radiator cool down. Serious burns could
be caused by high pressure fluid escap-
ing from the radiator. See precautions in
“If your vehicle overheats” (P.6-12).
. The radiator is equipped with a pressure
type radiator cap. To prevent engine
damage, use only a genuine NISSAN
radiator cap.
CAUTION
.Never use any cooling system additives
such as radiator sealer. Additives may
clog the cooling system and cause damage to the engine, transmission
and/or cooling system.
. When adding or replacing coolant, be
sure to use only Genuine NISSAN Long
Life Antifreeze/Coolant (blue) or equiva-
lent. Genuine NISSAN Long Life Anti-
freeze/Coolant (blue) is pre-diluted to
provide antifreeze protection to −348F
(−378C). If additional freeze protection is
needed due to weather where you
operate your vehicle, add Genuine
NISSAN Long Life Antifreeze/Coolant
(blue) concentrate following the direc-
tions on the container. If an equivalent
coolant other than Genuine NISSAN Long
Life Antifreeze/Coolant (blue) is used,
follow the coolant manufacture’s instruc-
tions to maintain minimum antifreeze
protection to −348F (−378C). The use of
other types of coolant solutions other
than Genuine NISSAN Long Life Anti-
freeze/Coolant (blue) or equivalent may
damage the engine cooling system.
. The life expectancy of the factory-fill
coolant is 105,000 miles (168,000 km)
or 7 years. Mixing any other type of
coolant other than Genuine NISSAN Long
Life Antifreeze/Coolant (blue) , including
Genuine NISSAN Long Life Antifreeze/ Coolant (green), or the use of non-
distilled water will reduce the life
expectancy of the factory-fill coolant.
Refer to the INFINITI Service and Main-
tenance Guide for more details.
ENGINE COOLING SYSTEM
Condition:

Black plate (451,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
SDI2043
CHECKING ENGINE COOLANT LEVELY51D-V-E01-84AE9FA6-E55B-4D94-91B9-C765423765DC
Type AGUID-ADA6E49A-21E7-4E48-8999-4B103F566062Check the coolant levelin the reservoir
when the engine is cold. If the coolant
level is below MIN
*2, open the reservoir
tank cap and add coolant up to the MAX
*1
level. If the reservoir tank is empty, check
the coolant level in the radiator when the
engine is cold. If there is insufficient
coolant in the radiator, fill the radiator
with coolant up to the filler opening and
also add it to the reservoir tank up to the
MAX level
*1.
Tighten the cap securely after adding engine coolant.
If the cooling system requires coolant
frequently, have it checked by an INFINITI
retailer.
SDI2624
Type BGUID-341ED9AB-6462-4E58-94AF-F9670CA91ED2Check the coolant level in the reservoir
tank when the engine is running and after
it reaches normal operating temperature. If
the coolant level is below MIN level
*2,
add coolant up to the MAX level
*1. If the
reservoir tank is empty, check the coolant
level in the radiator when the engine is
cold . If there is insufficient coolant in the
radiator, fill the radiator with coolant up to
the filler cap above the radiator upper hose
opening and also add it to the reservoir
tank up to the MAX level
*1. Put on the
filler cap above the radiator upper hose
and with the reservoir cap open, start the
Maintenance and do-it-yourself8-13
Condition:

Black plate (452,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
8-14Maintenance and do-it-yourself
engine. Run the engine until it reaches
normal operating temperature. Add coolant
up to the MAX level
*1. Tighten the cap
securely after adding engine coolant.
If the cooling system requires coolant
frequently, have it checked by an INFINITI
retailer.
CHANGING ENGINE COOLANTY51D-V-E01-A426F257-7E1C-4FDD-BCE7-CC70502D59EAMajor cooling system repairs should be
performed by an INFINITI retailer. The
service procedures can be found in the
appropriate INFINITI Service Manual.
Improper servicing can result in reduced
heater performance and engine overheat-
ing.
WARNING
. To avoid the danger of being scalded,
never change the coolant when the
engine is hot.
. Never remove the radiator cap when the
engine is hot. Serious burns could be
caused by high pressure fluid escaping
from the radiator.
. Avoid direct skin contact with used
coolant. If skin contact is made, wash thoroughly with soap or hand cleaner as
soon as possible.
. Keep coolant out of reach of children and
pets.
Engine coolant must be disposed of
properly. Check your local regulations.
Y51D-V-E01-A7C453B1-918A-4063-9B01-B06D637810DF
SDI2541
VK56VD engine
SDI2045
VQ37VHR engine
ENGINE OIL
Condition:

Black plate (458,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
8-20Maintenance and do-it-yourself
opening.
Add a washer solvent to the washer for
better cleaning. In the winter season, add a
windshield washer antifreeze. Follow the
manufacturer’s instructions for the mixture
ratio.
Refill the reservoir more frequently when
driving conditions require an increased
amount of window washer fluid.
Recommended fluid is Genuine NISSAN
Windshield Washer Concentrate Cleaner &
Antifreeze or equivalent.
CAUTION
.Do not substitute engine anti-freeze
coolant for window washer solution. This
may result in damage to the paint.
. Do not fill the window washer reservoir
tank with washer fluid concentrates at
full strength. Some methyl alcohol
based washer fluid concentrates may
permanently stain the grille if spilled
while filling the window washer reser-
voir tank.
. Pre-mix washer fluid concentrates with
water to the manufacturer’s recom-
mended levels before pouring the fluid into the window washer reservoir tank.
Do not use the window washer reservoir
tank to mix the washer fluid concentrate
and water.
Y51D-V-E01-53727028-85F3-446D-8050-B21208C99FC8.
Keep the battery surface clean and dry.
Clean the battery with a solution of
baking soda and water.
. Make certain the terminal connections
are clean and securely tightened.
. If the vehicle is not to be used for 30
days or longer, disconnect the negative
(−) battery terminal cable to prevent
discharging it.
NOTE:
Care should be taken to avoid situations
that can lead to potential battery dis-
charge and potential no-start conditions
such as:
1. Installation or extended use of electro-
nic accessories that consume battery
power when the engine is not running
(Phone chargers, GPS, DVD players,
etc.)
2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the battery may need to be
charged to maintain battery health.
WARNING
. Do not expose the battery to flames or
electrical sparks. Hydrogen gas gener-
BATTERY
Condition:

Black plate (488,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
9-2Technical and consumer information
Y51D-V-E01-C061365F-EF7D-4287-BD30-362698201633The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the“8. Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
Recommended specifications
US measure Imp measure Liter
Fuel 20-1/8 gal 16-3/4 gal 76See
“Fuel information” (P.9-4).
Engine oil See“Engine oil” (P.8-14) for changing engine oil.
. Genuine NISSAN engine oil or equivalent
. INFINITI recommends Genuine NISSAN Ester Engine Oil
available at an INFINITI retailer.
. Engine oil with API Certification Mark
. Viscosity SAE 5W-30
. For additional information, see “Engine oil and oil filter
recommendation” (P.9-6).
Drain and refill
With oil filter change
VQ37VHR
5-1/8 qt 4-3/8 qt 4.9
VK56VD (2WD)
6-3/8 qt 5-1/4 qt 6.0
(AWD) 6-1/2 qt 5-3/8 qt 6.1
Without oil filter
change VQ37VHR
4-7/8 qt 4.0 qt4.6
VK56VD (2WD)
6.0 qt 5.0 qt 5.7
(AWD) 6-1/8 qt 5-1/8 qt 5.8
Cooling system
Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant
(blue) or equivalent
With reservoir
VQ37VHRNon-pressurized
radiator reservoir
tank
8-7/8 qt 7-3/8 qt 8.4
Pressurized radia-
tor reservoir tank 9-1/2 qt 7-7/8 qt 9.0
VK56VD 11-1/2 qt 9-5/8 qt 10.9
Reservoir VQ37VHR
7/8 qt 3/4 qt0.8
VK56VD 7/8 qt 3/4 qt0.8
Automatic transmission fluid —— —.
Genuine NISSAN Matic S ATF
Using automatic transmission fluid other than Genuine
NISSAN Matic S ATF will cause deterioration in driveability
and automatic transmission durability, and may damage
the automatic transmission, which is not covered by the
INFINITI new vehicle limited warranty.
Differential gear oil —— —Front:
.
Genuine NISSAN Differential Oil Hypoid Super GL-5 80W-
90 or API GL-5 Viscosity SAE 80W-90 For hot climates,
Viscosity SAE 90 is suitable for ambient temperatures
above 328F (08C).
Rear:
. API GL-5 synthetic gear oil, Viscosity SAE 75W-90 See an
INFINITI retailer for service for synthetic oil.
CAPACITIES AND RECOMMENDED FUEL/
LUBRICANTS
Condition:

Black plate (512,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
10-2
Child safety...
...................................................... 1-18
Child safety rear door lock ...
.................................. 3-6
Chimes Audible reminders ...
....................................... 2-19
Seat belt warning light and chime ...
............... 2-15
Cigarette lighter and ashtrays ...
........................... 2-46
Circuit breaker
Fusible link ...
.................................................. 8-28
Cleaning exterior and interior ...
....................... 7-2, 7-4
Climate control
Automatic climate control ...
............................ 4-34
Clock ...
................................................................ 2-45
Coat hooks ...
....................................................... 2-51
Cockpit ...
............................................................... 2-3
Cold weather driving ...
....................................... 5-105
Compact Disc (CD) player (See audio system) ...
... 4-65
Compact spare tire ...
........................................... 8-46
Console box ...
...................................................... 2-49
Controller
Center multi-function control panel ...
................ 4-6
Controls Control panel button ...
...................................... 4-4
INFINITI Controller ...
.......................................... 4-6
Coolant Capacities and
recommended fuel/lubricants ...
........................ 9-2
Changing engine coolant ...
............................. 8-14
Checking engine coolant level ...
...................... 8-13
Corrosion protection ...
........................................... 7-7
Cruise control ...
................................................... 5-47
Fixed speed cruise control (on ICC system) ...
... 5-67 Intelligent cruise control (ICC) system
...
.......... 5-49
Cruise indicator ... ................................................ 2-23
Cup holders ...
...................................................... 2-47
Current fuel consumption ...
.................................. 2-27
D
Daytime running light system ...
........................... 2-37
Defroster switch Rear window and outside mirror
defroster switch ...
........................................... 2-34
Dimensions ...
....................................................... 9-10
Display cleaning ...
................................................. 4-8
Display controls (See center multi-function
control panel) ...
..................................................... 4-4
Distance Control Assist (DCA) system ...
................ 5-71
Distance Control Assist (DCA) system
switch indicator ...
................................................ 2-24
Distance Control Assist (DCA) system
warning light ...
.................................................... 2-12
Distance to empty ...
............................................. 2-27
Dot matrix liquid crystal display ...
....................... 2-19
Drive belts ...
........................................................ 8-22
Drive positioner ...
................................................ 3-27
Driving
Cold weather driving ...
.................................. 5-105
Driving with automatic transmission ...
............ 5-14
Precautions when starting and driving ...
........... 5-3
DVD player operation ...
........................................ 4-66
E
ECO drive indicator light ...
................................... 2-17
ECO mode ...
......................................................... 5-20
ECO pedal system ...
............................................. 5-21
Economy
Fuel ...
............................................................. 5-92
Elapsed time ...
..................................................... 2-27
Elapsed time and trip odometer ...
........................ 2-27
Emission control information label ...
.................... 9-13
Emission control system warranty ...
..................... 9-20
Engine Before starting the engine ...
........................... 5-13
Break-in schedule ...
........................................ 5-91
Capacities and
recommended fuel/lubricants ...
........................ 9-2
Changing engine coolant ...
............................. 8-14
Changing engine oil and filter ...
...................... 8-15
Checking engine coolant level ...
...................... 8-13
Checking engine oil level ...
............................. 8-15
Coolant temperature gauge ...
............................ 2-8
Emergency engine shut off ...
........................... 5-11
Engine block heater ...
................................... 5-106
Engine compartment check locations ...
............. 8-7
Engine cooling system ...
................................. 8-12
Engine oil ...
.................................................... 8-14
Engine oil and oil filter recommendation ...
........ 9-6
Engine oil replacement indicator ...
.................. 2-25
Engine oil viscosity ...
........................................ 9-7
Engine serial number ...
................................... 9-12
Engine specifications ...
..................................... 9-8
Condition:

Black plate (513,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
Engine start operation indicator...
................... 2-22
If your vehicle overheats ...
.............................. 6-12
Starting the engine ...
...................................... 5-13
Engine coolant temperature gauge ...
...................... 2-8
Entry/exit function Automatic drive positioner ...
........................... 3-27
Event Data Recorders (EDR) ...
............................... 9-23
Exhaust gas (carbon monoxide) ...
.......................... 5-3
F
F.M.V.S.S./C.M.V.S.S. certification label ...
............. 9-12
Filter
Air cleaner housing filter ...
.............................. 8-24
Changing engine oil and filter ...
...................... 8-15
Flashers (See hazard warning flasher switch) ...
...... 6-2
Flat tire ...
............................................................... 6-3
Flat towing ...
........................................................ 9-19
Floor mat cleaning ...
.............................................. 7-6
Floor mat positioning aid ...
.................................... 7-6
Fluid Automatic transmission fluid (ATF) ...
............... 8-18
Brake fluid ...
................................................... 8-19
Capacities and
recommended fuel/lubricants ...
........................ 9-2
Engine coolant ...
............................................. 8-12
Engine oil ...
.................................................... 8-14
Power steering fluid ...
..................................... 8-18
Window washer fluid ...
................................... 8-19
FM-AM-SAT radio with Compact Disc
(CD) player ...
........................................................ 4-62
Fog light switch ...
................................................ 2-40 Forest Air
®...
........................................................ 4-43
Forward Collision Warning (FCW) system ...
........... 5-83
Front passenger air bag and status light ...
........... 1-45
Front power seat adjustment ...
............................... 1-3
Front seat Front seat adjustment ...
.................................... 1-3
Front-seat active head restraints ...
......................... 1-9
Fuel Capacities and
recommended fuel/lubricants ...
........................ 9-2
Fuel economy ...
............................................... 5-92
Fuel economy information (display) ...
.............. 4-12
Fuel Information ...
............................................. 9-4
Fuel octane rating ...
.......................................... 9-4
Fuel-filler cap ...
............................................... 3-21
Fuel-filler door ...
............................................. 3-21
Gauge ...
............................................................ 2-9
Fuel efficient driving tips ...
................................... 5-91
Fuses ...
................................................................ 8-28
Fusible links ...
..................................................... 8-28
G
Garage door opener
HomeLink®Universal Transceiver ...
................. 2-60
Gas cap ...
............................................................ 3-21
Gauge ...
................................................................. 2-6
Engine coolant temperature gauge ...
................. 2-8
Fuel gauge ...
..................................................... 2-9
Odometer ...
....................................................... 2-7
Speedometer ...
................................................. 2-7
Tachometer ...
.................................................... 2-8 Trip computer
...
.............................................. 2-26
General maintenance ...
.......................................... 8-2
Glove box ...
......................................................... 2-49
H
Hands-free phone system
Bluetooth®(models with
navigation system) ...
....................................... 4-85
Bluetooth
®(models without
navigation system) ...
....................................... 4-95
Hazard warning flasher switch ...
............................ 6-2
Head restraints/headrests ...
................................... 1-5
Headlights Aiming control (See adaptive front lighting
system (AFS)) ...
............................................... 2-37
Bulb replacement ...
......................................... 8-33
Headlight switch ...
.......................................... 2-35
Xenon headlights ...
......................................... 2-34
Heated seats ...
.................................................... 2-41
Heated steering wheel ...
...................................... 2-40
Heater
Automatic climate control ...
............................ 4-34
Engine block heater ...
................................... 5-106
Hill start assist system ...
................................... 5-104
HomeLink
®Universal Transceiver ...
...................... 2-60
Hood release ...
.................................................... 3-17
Hook
Coat hooks ...
.................................................. 2-51
Horn ...
................................................................. 2-41
10-3
Condition:

Black plate (517,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
Spark plugs...
...................................................... 8-23
Speedometer ...
...................................................... 2-7
SPORT mode ...
..................................................... 5-20
STANDARD mode ...
............................................... 5-20
Starting Before starting the engine ...
........................... 5-13
Jump starting ...
............................................... 8-22
Precautions when starting and driving ...
........... 5-3
Push starting ...
............................................... 6-11
Starting the engine ...
...................................... 5-13
STATUS button ...
.................................................. 4-10
Status light, Front passenger air bag ...
................ 1-45
Steering
Heated steering wheel ...
................................. 2-40
Power steering fluid ...
..................................... 8-18
Power steering system ...
................................. 5-97
Steering lock release malfunction indicator
(if so equipped) ...
........................................... 2-22
Steering-wheel-mounted controls
for audio ...
...................................................... 4-82
Tilt/telescopic steering ...
................................. 3-23
Steering lock (if so equipped) ...
........................... 5-11
Storage ...
............................................................. 2-47
Sun visors ...
........................................................ 3-24
Sunglasses holder ...
............................................ 2-48
Sunshade (rear) ...
................................................ 2-56
Supplemental air bag warning labels ...
................ 1-51
Supplemental air bag warning light ...
......... 1-51, 2-15
Supplemental restraint system ...
.......................... 1-38
Precautions on supplemental
restraint system ...
........................................... 1-38 Switch
Autolight switch ...
........................................... 2-35
Fog light switch ...
........................................... 2-40
Hazard warning flasher switch ...
....................... 6-2
Headlight switch ...
.......................................... 2-35
Ignition switch ...
............................................. 5-14
Intelligent Brake Assist (IBA) OFF switch ...
...... 2-44
Power door lock switch ...
.................................. 3-5
Rear window and outside mirror
defroster switch ...
........................................... 2-34
Turn signal switch ...
........................................ 2-39
Vehicle dynamic control (VDC) off switch ...
...... 2-45
Warning systems switch ...
............................... 2-43
T
Tachometer ...
......................................................... 2-8
Temperature gauge Engine coolant temperature gauge ...
................. 2-8
Theft (INFINITI Vehicle Immobilizer System) Engine start ...
................................................. 2-30
Three-way catalyst ...
.............................................. 5-4
Tilt/telescopic steering ...
...................................... 3-23
“TIMER” indicator ...
.............................................. 2-23
Tire
Tire replacement indicator ...
............................ 2-25
Tire rotation ...
................................................. 8-43
Tire pressure
Low tire pressure warning light ...
.................... 2-13
Tires Flat tire ...
.......................................................... 6-3
Low tire pressure warning system ...
... 5-4, 6-3, 8-36 Spare tire
...
.................................................... 8-46
Tire and Loading information label ...
...... 8-38, 9-13
Tire chains ...
................................................... 8-43
Tire dressing ...
.................................................. 7-4
Tire pressure ...
................................................ 8-36
Tire pressure information (display) ...
............... 4-12
Tire pressure monitoring
system (TPMS) ...
.............................. 5-4, 6-3, 8-36
Types of tires ...
............................................... 8-42
Uniform tire quality grading ...
......................... 9-19
Wheel/tire size ...
.............................................. 9-9
Wheels and tires ...
.......................................... 8-36
Touch screen system ...
........................................... 4-6
Towing Flat towing ...
................................................... 9-19
Tow truck towing ...
.......................................... 6-13
Towing a trailer ...
............................................ 9-19
TPMS Tire pressure monitoring system ...
... 5-4, 6-3, 8-36
Tire pressure warning system ...
....... 5-4, 6-3, 8-36
Trailer towing ...
.................................................... 9-19
Transceiver
HomeLink
®Universal Transceiver ...
................. 2-60
Transmission Automatic transmission fluid (ATF) ...
............... 8-18
Driving with automatic transmission ...
............ 5-14
Transmission shift lever lock release ...
............ 5-18
Transmitter (See remote keyless entry system) ...
... 3-13
Traveling or registering your vehicle in
another country ...
................................................ 9-11
Trip computer ...
................................................... 2-26
10-7
Condition:
