climate settings INFINITI Q70 2014 Quick Reference Guide

7
Fuel-filler Door
The fuel-filler doors is located on the passenger’s side of
the vehicle.
w hen the doors, of the vehicle are locked or unlocked,
the fuel-filler door is automatically locked or unlocked
at the same time.
To open the door, push the upper left side of the door.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Loose Fuel Cap
A LOOSE FUEL CAP
warning message will appear in the
vehicle information display
01 when the fuel-filler
cap is not tightened correctly.
To tighten, turn the cap clockwise until a single click
is heard.
The warning message will disappear when the vehicle
detects the fuel-filler cap is properly tightened and the
reset button
02 is pressed for more than 1 second.
If the cap is not properly tightened, the Malfunction

Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and

the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
02
01
Clock Set/Adjustment
DIGITAL CLOCK ADJUSTMENT
To adjust the time and the appearance of the clock
on the display:
1.


Press the

SE tt ING button on the control panel.
2.


Touch the

Others key.
3.


Touch the

Clock key.
The following settings can be adjusted:
•


On-screen Clock:
The clock in the upper right corner of the display can be turned ON or O\
FF.
•

Clock Format (24h): The clock can be set to 12 hours or 24 hours.
•


Offset (hour):
The time can be adjusted by increasing or decreasing per hour.
•


Offset (min):
The time can be adjusted by increasing or decreasing per minute.
•


Daylight Savings
t ime: The application of daylight savings time can be turned ON or OFF.
•

t ime Zone: Adjust the time zone. Choose a time zone from the available list.
Press the BAC k button to return to the previous screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
1276460_14a_Infiniti_Q70_QRG_102813.indd 710/28/13 2:30 PM

12
first drive features
Automatic Climate Controls (if so equipped)
01 AUt O BU tt ON

The automatic mode may be used year-round. Press the AU t O button to turn the system
on, and the system will automatically control the inside temperature (a\
utomatic cooling
and/or dehumidified heating), air flow distribution and fan speed.
02 CLIMA t E BU tt ON

Press the CLIMA
t E button to adjust your automatic climate controls using the climate
settings on the control panel display screen.
03 DRIVER’S SIDE t EMPERA t URE CON t ROL BU tt ONS
Press the driver’s side temperature control buttons up for warmer air or down for
cooler air.
0406
0809120701101102
0305
Windshield Wiper and Washer Switch
Move the lever to the following positions to operate
the windshield wipers:
01 Mist (MIS t ) - One sweep operation of the wipers.
02 Auto
(A U t O ) - Operates the rain-sensing wipers
intermittently. The intermittent speed can be
adjusted by twisting the time control ring
03 to

increase or decrease the wiper sensitivity.
04 Low
(LO) - w ipers operate at a continuous
low-speed.
05
h
igh ( h I) - w ipers operate at a continuous
high-speed.
06 Pull the lever toward you to activate the washer. T
he wipers will operate several times.
RAIN-SENSING AUTO w IPER SYSTEM
The rain-sensing auto wiper system can automatically turn on the wipers \
and adjust the wiper
speed, depending on the rainfall and the vehicle speed.
To turn on the rain-sensing auto wiper system, push the lever down to th\
e AU t O position
02 .
The wiper will sweep once while the ignition switch is in the ON position.
The rain sensor sensitivity level can be adjusted by turning the time co\
ntrol ring 03 to
increase or decrease sensitivity.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
MISt
OFF
AU

t O
LO
h

I
02
04
05
0103
06
1276460_14a_Infiniti_Q70_QRG_102813.indd 1210/28/13 2:31 PM

13
04 DRIVER’S SIDE MANUAL AIR FLOW CONt ROL BU tt ON

Press the driver’s side manual air flow buttons to manually control t\
he driver’s side air
flow modes.
The following air flow indicator modes will display on the control panel\
display screen:



Air flows from the center and side vents.



Air flows from the center, side and foot vents.



Air flows mainly from the foot vents.



Air flows from the defroster and foot vents.
05 PASSENGER’S SIDE t EMPERA t URE CON t ROL BU tt ONS

To manually adjust the passenger’s side temperature, press the passen\
ger’s side
temperature control buttons up
for warmer air or down for cooler air.
06 PASSENGER’S SIDE MANUAL AIR FLOW CON t ROL BU tt ON

Press the passenger’s side manual air flow buttons to manually contro\
l the passenger’s
side air flow modes.
The following air flow indicator modes will display on the control panel\
display screen:



Air flows from the center and side vents.



Air flows from the center, side and foot vents.



Air flows mainly from the foot vents.



Air flows from the defroster and foot vents.
07 FAN SPEED CON t ROL BU tt ONS

Press the left button to decrease the fan speed or press the right
button to

increase the fan speed.
08 DEFROS t ING/DEFOGGING FRON t AND SIDE WINDOWS

Press the defroster control button
to turn the system on. The A/C automatically turns

on when the defroster mode is selected. This feature removes humidity fr\
om the air.
To defrost the front and side windows, set the temperature controls
03 and fan speed

controls 07 to their maximum settings. 09 DEFROS t ING REAR WINDOW AND OU t SIDE MIRRORS
Push the rear window defroster switch
to turn the system on or off. This function automatically turns off after approximately 15 minutes.
10 FORESt BU tt ON
Press the forest button
to activate the Forest Air® system.

This system’s settings will activate the breeze mode, the outside odo\
r and exhaust gas
detection sensor, the inside air quality sensor and the auto humidity co\
ntrol. The fan
speed and air flow is automatically set to the auto position.
11 IN t A k E AIR CON t ROL BU tt ON

Press the intake air control button to recirculate interior air inside the vehicle.
The indicator light on the button will illuminate. This system is used to a\
void certain
outside odors and helps to adjust the inside vehicle temperature more ef\
fectively.
The air recirculation mode cannot be activated when the climate control \
system is in the
front defroster mode
or front defroster and foot vent mode
.
Press the intake air control button again to change the air circulation from the
intake air to the outside air. The indicator light on the button will turn off.
12 OFF BU tt ON
Press the
OFF button to turn the climate control system off.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
1276460_14a_Infiniti_Q70_QRG_102813.indd 1310/28/13 2:31 PM

22
08 S t A t US – Press multiple times to display audio information, air conditioner\
status, fuel

economy or navigation directions.
09 – Press to switch between the day screen (bright) and the night sc\
reen (dark). Press and

hold the button to turn the display off. Press again to turn the display\
on.
10
BAC k – Press to return to the previous screen. In a settings screen, this\
button can also
be used to apply the setting. In a character input screen, this button can \
also delete the char-
acters that have been entered.
11 VOICE – Press to hear the current voice guidance for a programmed route.
For more information, please refer to your Navigation System Owner’s \
Manual.
DVD Player (if so equipped)
This system allows you to play video
files via a dvd



or C
d from the front display.
To view movies on the front display, stop the vehicle
in a safe location, move the shift lever to the P (PAR
k )
position and apply the parking brake.
To reduce driver distraction, movies will not be shown



on the front display while the vehicle is in any




drive position.
For more information, refer to the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
system guide
