1. Fuel-filler door (P. 3-23)— Fuel recommendation (P. 9-4)
2. Antenna (P. 4-82)
3. Rear combination light (bulb replacement) (P. 8-26) 4. Rear window defroster (P. 2-35)
5. Satellite antenna (P. 4-40)
6. Rear view camera (P. 4-19)
7. High-mounted stop light
(bulb replacement) (P. 8-26) 8. Lift gate (P. 3-19)
— Intelligent Key system (P. 3-6)
9. Rear window wiper and washer — Switch operation (P. 2-34)
— Window washer fluid (P. 8-14)
10. Spare tire (under the vehicle) (P. 6-2)
11. Rear Sensor — Around View Monitor (P. 4-19)
12. Recovery hook (P. 6-17)
13. Trailer hitch (P. 9-21)
SSI0737
EXTERIOR REAR
0-4Illustrated table of contents

1. Cargo light (P. 2-68)
2. Cup holders (3rd row seat) (P. 2-56)
3. Rear ventilators (P. 4-30)
4. Coat hooks (P. 2-59)
5. Rear personal lights (P. 2-66)6. Tray (P. 2-58)
— USB memory operation* (P. 4-61)
— iPod player operation* (P. 4-70)
7. Door armrest — Power window controls (P. 2-61)
— Power door lock switch (P. 3-5) 8.
Automatic drive positioner switch (P. 3-30)
9. Sun visors (P. 3-26)
10. Moon roof switch (P. 2-63)
11. Map lights (P. 2-66)
12. Sunglasses holder (P. 2-56)
13. Inside rearview mirror (P. 3-27)
— HomeLink universal transceiver
(P. 2-68)
14. Cargo area — Power outlet (P. 2-52)
— Cargo floor box (P. 2-60)
— Luggage hooks (P. 2-59)
— Jacking tools (P. 6-4)
15. Rear console box (P. 2-58) — Cup holders (2nd row seat)* (P. 2-54)
— Pocket* (P. 2-58)
16. Cup holders (2nd row seat)* (P. 2-54)
17.
Dual head restraint DVD system* (P. 4-83)
18. Console box (P. 2-57) — Power outlet (P. 2-52)
— Auxiliary input jacks* (P. 4-84)
— Rear automatic air conditioning
system* (P. 4-37)
19. Power outlet (P. 2-52)/Front cup holders (P. 2-54)
*: if so equipped
SSI0743
PASSENGER COMPARTMENT
Illustrated table of contents0-5

1. Adaptive Front lighting System (AFS)switch* (P. 2-40)
2. Instrument brightness control switch (P. 2-41) 3. TRIP/RESET switch for twin trip odometer
(P. 2-6)
4. Headlight, fog light and turn signal switch — Headlight (P. 2-37)
— Turn signal (P. 2-42)
— Fog light (P. 2-42) 5. Steering-wheel-mounted controls
(left side)
— Audio control steering switch (P. 4-81)
— Hands-Free Phone System switch
(P. 4-96)
6. Trip computer switch (P. 2-27)
7. Wiper and washer switch (P. 2-32)
8. Steering-wheel-mounted controls (right side)
— Cruise control system* (P. 5-37)
— Intelligent Cruise Control (ICC) system*
(P. 5-39)
9. Dynamic driver assistance switch* — Lane Departure Prevention (LDP)
system* (P. 5-20)
— Distance Control Assist (DCA) system*
(P. 5-62)
10. Selector lever (P. 5-15)
11. Four-Wheel Drive (4WD) shift switch* (P. 5-84)/ SNOW mode switch (P. 2-49)/
TOW MODE switch (P. 2-49)/Vehicle
Dynamic Control (VDC) OFF switch
(P. 5-98)
12. Headlight aiming control* (P. 2-39)
13. Power lift gate main switch (P. 3-19)
14. Outside rearview mirror remote control switch (P. 3-28)
SSI0748
COCKPIT
0-6Illustrated table of contents

15. Warning systems switch* (P. 2-47)— Lane Departure Warning (LDW)*
(P. 5-20)
— Blind Spot Warning (BSW)* (P. 5-29)
— Forward Collision Warning (FCW)*
(P. 5-75)
16. Power lift gate switch (P. 3-19)
17. Electric tilting/telescopic steering wheel switch (P. 3-26)
18. Intelligent Brake Assist (IBA) OFF switch* (P. 5-80)
*: if so equipped
Illustrated table of contents0-7

1. Side ventilator (P. 4-30)
2. Meters and gauges (P. 2-5)
3. Hazard warning flasher switch (P. 2-43)
4. Center ventilator (P. 4-30)5. Center multi-function control panel
(P. 4-3)
— Vehicle information and setting
buttons (P. 4-7) 6. Center display
— Around View Monitor (P. 4-19)
— Navigation system**
— DVD player operation (P. 4-58)
7. Clock (P. 2-51)
8. Defroster switch (P. 2-35)/Deicer switch* (P. 2-36)
9. Front passenger supplemental air bag (P. 1-50)
10. Fuse box (P. 8-23)
11. Parking brake (P. 5-19)
12. Hood release handle (P. 3-18)
13. Steering wheel — Horn (P. 2-44)
— Driver supplemental air bag (P. 1-50)
— Power steering system (P. 5-94)
14. Push-button ignition switch (P. 5-10)
15. Climate controlled seat switch* (P. 2-46)/Heated seat switch* (P. 2-44)
16. Remote tip-up 2nd row seat switch* (P. 1-8)
17. Heated steering wheel switch (P. 2-43)
18. Power outlet (P. 2-52)
19. Front passenger air bag status light (P. 1-57)
20. Cup holder (P. 2-54)
SSI0733
INSTRUMENT PANEL
0-8Illustrated table of contents

21. Automatic climate control system(P. 4-31)
22. Audio system (P. 4-40)
23. Glove box (P. 2-57)
*: if so equipped
**: Refer to the separate Navigation System
Owner’s Manual.
1. Tachometer (P. 2-7)
2. Warning/Indicator lights (P. 2-10)
3. Speedometer (P. 2-6)
4. Engine coolant temperature gauge (P. 2-7) 5. Voltmeter (P. 2-9)
6. Dot matrix liquid crystal display/
Odometer/twin trip odometer (P. 2-21)
7. Engine oil pressure gauge (P. 2-8)
8. Fuel gauge (P. 2-8)
SIC4450
METERS AND GAUGES
Illustrated table of contents0-9

VK56VD ENGINE
1. Window washer fluid reservoir (P. 8-14)
2. Fuse/fusible link holder (P. 8-21)
3. Engine oil dipstick (P. 8-9)4. Power steering fluid reservoir (P. 8-12)
5. Engine oil filler cap (P. 8-9)
6. Brake fluid reservoir (P. 8-12)
7. Fuse/fusible link holder (P. 8-21)
8. Battery (P. 8-15)9. Radiator filler cap (P. 8-7)
10. Engine coolant reservoir (P. 8-7)
11. Drive belts (P. 8-17)
12. Air cleaner (P. 8-18)
SDI2585
ENGINE COMPARTMENT
0-10Illustrated table of contents

Warn-ing
light Name Page
Anti-lock Braking System
(ABS) warning light
2-11
Automatic Transmission
(AT) check warning light2-11
Automatic Transmission
(AT) oil temperature warn-
ing light2-11
Automatic Transmission
(AT) park warning light
2-11
Brake warning light 2-12
Blind Spot Warning (BSW)
system warning light (or-
ange)*2-12
Warn-
ing
light Name Page
Charge warning light 2-13
Distance Control Assist
(DCA) system warning
light (orange)* 2-13
Engine oil pressure warn-
ing light
2-13
Four-Wheel Drive (4WD)
warning light (4WD mod-
els)2-13
Intelligent Cruise Control
(ICC) system warning light
(orange)*2-14
Intelligent Key system
warning light
2-14
Lane departure warning
light (orange)*2-14
Warn-
ing
light Name Page
Low tire pressure warning
light
2-14
Master warning light 2-16
Preview Function warning
light (orange)*2-16
Seat belt warning light 2-16
Supplemental air bag
warning light2-16
Vehicle Dynamic Control
(VDC) warning light 2-17
WARNING AND INDICATOR LIGHTS
Illustrated table of contents0-11

Indica-tor
light Name Page
Adaptive Front lighting
System (AFS) indicator
light* 2-17
Automatic Transmission
(AT) position indicator
light2-18
Check suspension indica-
tor light
2-18
Cruise indicator light* 2-18
Front passenger air bag
status light2-18
High beam indicator light 2-18
Intelligent Brake Assist
(IBA) off indicator light*2-18
Lane Departure Preven-
tion (LDP) ON indicator
light (green)* 2-19
Indica-
tor
light Name Page
Low beam indicator light 2-19
Malfunction Indicator
Light (MIL)
2-19
Security indicator light 2-20
SNOW mode indicator
light2-20
TOW mode indicator light 2-20
Turn signal/hazard indica-
tor lights2-20
Vehicle Dynamic Control
(VDC) off indicator light2-20
