INFINITI QX30 2019 Owner's Manual

COMBINATION SWITCH
1Turn signal, right
2Turn signal, left
3High beam headlights
4Headlight flasher
Turn signal
Move the lever up or down to signal the
turning direction. When the turn is com-
pleted, the turn signal cancels automatically.
Lane change signal
Move the lever up or down until the turn
signal begins to flash, but the lever does not
latch, to signal a lane change. Hold the lever
until the lane change is completed. Move the
lever up or down until the turn signal begins
to flash, but the lever does not latch, and
release the lever. The turn signal will auto-matically flash three times. Choose the ap-
propriate method to signal a lane change
based on road and traffic conditions.
High beam headlights
To switch on the high beam headlights:
•Turn the ignition switch to the ON position
or start the engine.
•Turn the light switch toor.
•Press the combination switch beyond the
pressure point in the direction of arrow
3.
In theposition, the high beam
headlights are only switched on when it is
dark and the engine is running.
The blue
indicator light in the com-
bination meter lights up when the high
beam headlights are switched on.
To switch off the high beam headlights:
•Move the combination switch back to its
normal position. The blueindicator
light in the combination meter goes out.
NOTE
Vehicles with High beam Assist: when High
beam Assist is active, it controls activation
and deactivation of the high beam head-
lights (see " High beam assist (LED headlight
only)" later in this section)
ADAPTIVE FRONT LIGHTING
SYSTEM (LED HEADLIGHT
ONLY) (IF EQUIPPED)
The Adaptive Front Lighting System is a sys-
tem that adjusts the headlights automatically
to suit the prevailing driving and weather
conditions. It offers advanced functions for
improved illumination of the road surface,
e.g. depending on the vehicle speed or
weather conditions. The system includes the
active light function, cornering light function
and freeway mode. The system is only active
when it is dark.
You can activate or deactivate the “Adaptive
Front Lighting System” function using the
vehicle information display (see "Switching
the Adaptive Front Lighting System on/off"
earlier in this section)
NIC2618
Instruments and controls2-67

Active light function
The active light function is a system that
moves the headlights according to the steer-
ing movements of the front wheels. In this
way relevant areas remain illuminated while
you are driving. This helps you to recognize
pedestrians, cyclists and animals. It is active
when the lights are switched on.
Cornering light function
The cornering light function improves the il-
lumination of the road over a wide angle in
the direction you are turning, enabling better
visibility in tight bends, for example. It can
only be activated when the low-beam head-
lights are switched on. It is active if you are
driving at speeds below 25 MPH (40 km/h)
and switch on the turn signal or turn the
steering wheel.
The cornering light function may remain lit for
a short time, but is automatically switched off
after no longer than three minutes.
Freeway mode
Freeway mode adjusts the light beam to re-
duce the amount of light that shines on the
opposite lane of the freeway, and oncoming
traffic.
Freeway mode is active if you are driving at a
speed above 68 MPH (110 km/h) and do not
make any large steering movements for at
least 3300 ft (1000 m) or if you are driving at
a speed above 81 MPH (130 km/h).
It is not active if you are driving at speeds
below 50 MPH (80 km/h) following activa-
tion.
NSD593NSD592NSD594
2-68Instruments and controls

HIGH BEAM ASSIST (LED
HEADLIGHT ONLY)
You can use this function to set the head-
lights to change between low beam and high
beam automatically. The system recognizes
vehicles with their lights on, either approach-
ing from the opposite direction or traveling in
front of your vehicle, and consequently
switches the headlights from high beam to
low beam.
The system automatically adapts the low
beam headlight range depending on the dis-
tance to the other vehicle. Once the system
no longer detects any other vehicles, it
switches on the high beam headlights again.
The system's optical sensor is located behind
the windshield near the overhead control
panel.
WARNING
•The high beam assist system is a conve-
nience but is not a substitute for safe
driving operation. The driver should re-
main alert at all times, ensure safe driv-
ing practices and switch the high beams
and low beam manually when necessary.
•The high beam or low beam may not
switch automatically under the follow-
ing conditions. Switch the high beam
and low beam manually.
–During bad weather (rain, fog, snow,
wind, etc.).
–When a light source similar to a head-
light or tail light is in the vicinity of
the vehicle.
–When the headlights of the oncoming
vehicle or the leading vehicle are
turned off, when the color of the light
is affected due to foreign materials
on the lights, or when the light beam
is out of position.
–When there is a sudden, continuous
change in brightness.
–When driving on a road that passes
over rolling hills, or a road that has
level differences.
–When driving on a road with many
curves.–When a sign or mirror-like surface is
reflecting intense light towards the
front of the vehicle.
–When the container, etc. being towed
by a leading vehicle is reflecting in-
tense light.
–When a headlight on your vehicle is
damaged or dirty.
–When the vehicle is leaning at an
angle due to a punctured tire, being
towed, etc.
•The timing of switching the low beam
and high beam may change under the
following situations.
–The brightness of the headlights of
the oncoming vehicle or leading ve-
hicle.
–The movement and direction of the
oncoming vehicle and the leading ve-
hicle.
–When only one light on the oncoming
vehicle or the leading vehicle is illumi-
nated.
–When the oncoming vehicle or the
leading vehicle is a two-wheeled ve-
hicle.
–Road conditions (incline, curve, the
road surface, etc.).
–The number of passengers and the
amount of luggage.
NDS595
Instruments and controls2-69

•High beam Assist does not recognize
road users:
–Who have no lights, e.g. pedestrians.
–Who have low intensity lighting, e. g.
cyclists.
–Whose lighting is blocked, e.g. by a
barrier.
•In very rare cases, High beam Assist rec-
ognizes road users too late or not at all.
In this, or in similar situations, the auto-
matic high beam headlights will not be
deactivated or activated regardless.
There is a risk of an accident.
•Always carefully observe the traffic
conditions and switch off the high beam
headlights in good time.
CAUTION
High beam Assist cannot compensate for
road and weather circumstances while
driving. The system saves the driver from
having to operate the switch. The driver
always remains responsible for choosing
the correct light setting.
Specific situations in which to operate the
headlight switch manually:
•In heavy rain, snowy conditions. (gen-
eral poor visibility and bad weather con-
ditions).
•When the vehicle sensors are dirty, cov-
ered or broken.
Switching High Beam Assist on/off
To switch on:
Turn the light switch to and press
the combination switch beyond the pressure
point in the direction of arrow
3. Theindicator light in the vehicle information dis-
play lights up when it is dark and the light
sensor switches on the low-beam headlights.
If you are driving at speeds above approxi-
mately 28 MPH (45 km/h) the headlight
range is set automatically depending on the
distance between the vehicle and other road
users.
NIC2618
2-70Instruments and controls

If you are driving at speeds above approxi-
mately 34 MPH (55 km/h) and no other road
users are detected, the high beam headlights
are switched on automatically. The
indicator light in the combination meter also
lights up.
If you are driving at speeds below approxi-
mately 28 MPH (45 km/h) or other road
users are detected or the roads are ad-
equately lit The high beam headlights are
switched off automatically. The
indica-
tor light in the combination meter goes out.
The
indicator light in the vehicle infor-
mation display remains lit.
To deactivate:
Move the combination switch back to its nor-
mal position The
indicator light in the
vehicle information display goes out.
HEADLIGHTS MISTED UP ON
THE INSIDE
Certain climatic and physical conditions may
cause moisture to form in the headlight. This
moisture does not affect the functionality of
the headlight.
INSTRUMENT BRIGHTNESS
CONTROL
The light sensor in the combination meter
automatically controls the brightness of the
instrument panel
In daylight, the displays in the combination
meter are not illuminated
The lighting in the combination meter, dis-
plays and controls in the vehicle interior can
be adjusted using the brightness control
knob.
The brightness control knob
1is located
behind the steering wheel.
Turn the brightness control knob clockwise or
counterclockwise. If the light switch is set to
orthe brightness is dependent
upon the brightness of the ambient light.
FRONT FOG LIGHTS
In conditions where visibility is poor due to
fog, snow or rain, the fog lights improve vis-
ibility as well as making it easier for other
road users to see you. They can be operated
together with the side lights or together with
the side lights and low beam headlights.
To switch on the fog lights:
•Turn the ignition switch to the ON position
or start the engine.
•Turn the light switch toor.
•Press thebutton. The greenindicator light in the combination meter
lights up
NIC2615NIC2699
FOG LIGHT SWITCH (IF SO
EQUIPPED)
Instruments and controls2-71

To switch off the front fog lights:
•press thebutton The greenindi-
cator light in the combination meter turns
off.
Only vehicles with front fog lights are
equipped with the “Fog lights” function.
REAR FOG LIGHT
The rear fog light improves the visibility of
your vehicle in heavy fog for the following
traffic. Please observe the country-specific
laws on the use of rear fog lights.
NOTE
The front fog lights must be switched on be-
fore the rear fog light will operate.
To switch on the rear fog light:
•Turn the ignition switch to the ON position
or start the engine.
•Turn the light switch toor.
•Press thebutton. The yellowindicator light in the combination meter
lights upTo switch off the rear fog light:
•press thebutton The yellowindicator light in the combination meter
turns off.
The rear fog light should be used only when
visibility is seriously reduced. (Generally, to
less than 50 m (116 ft))
To sound the horn, push the center pad area
of the steering wheel.
WARNING
Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system. Tam-
pering with the supplemental front air bag
system may result in serious personal
injury.
NIC2717
HORN
2-72Instruments and controls

WARNING
Do not use or allow occupants to use the
seat heater if you or the occupants cannot
monitor elevated seat temperatures or
have an inability to feel pain in body parts
that contact the seat. Use of the seat
heater by such people could result in seri-
ous injury.
CAUTION
•The battery could run down if the seat
heater is operated while the engine is
not running.
•Do not use the seat heater for extended
periods or when no one is using the seat.
•Do not put anything on the seat which
insulates heat, such as a blanket, cush-
ion, seat cover, etc. Otherwise, the seat
may become overheated.
•Do not place anything hard or heavy on
the seat or pierce it with a pin or similar
object. This may result in damage to the
heater.
•Any liquid spilled on the heated seat
should be removed immediately with a
dry cloth.
•When cleaning the seat, never use gaso-
line, benzine, thinner, or any similar ma-
terials.
•If any malfunctions are found or the
heated seat does not operate, turn the
switch off and have the system checked.
It is recommended you visit an INFINITI
retailer for this service.
The front seats are warmed by built-in heaters.
The switches are located on the center con-
sole and can be operated independently, for
the left-hand side seat and for the right-hand
side seat.
The three red indicator lights in the button
indicate the heating level you have selected
The system automatically switches from level
3 to level 2 after approximately eight minutes
The system automatically switches from level
2 to level 1 after approximately ten minutes.
The system automatically switches off
approximately 20 minutes after it is set to
level 1
1. Turn the ignition switch to the ON posi-
tion.
NIC2634
SEAT HEATING (IF EQUIPPED)
Instruments and controls2-73

NOTE
The seat heater can only be activated
when the ignition switch is in the ON po-
sition.
2. Start the engine.
3. Select the heat range:
•To switch on: press button1repeat-
edly until the desired heating level is
set.
•To switch off: press button1repeat-
edly until all the indicator lights turn off.
NOTE
If the battery voltage is too low, the seat
heating may switch off.
POWER WINDOWS
WARNING
•Make sure that all passengers have their
hands, etc. inside the vehicle while it is in
motion and before closing the windows.
Use the window lock switch to prevent
unexpected use of the power windows.
•To help avoid risk of injury or death
through unintended operation of the
vehicle and or its systems, including en-
trapment in windows or inadvertent
door lock activation, do not leave chil-
dren, people who require the assistance
of others or pets unattended in your ve-
hicle. Additionally, the temperature in-
side a closed vehicle on a warm day can
quickly become high enough to cause a
significant risk of injury or death to
people and pets.
The switches for all side windows are located
on the driver's door. There is also a switch on
each door for the corresponding side window
The switches on the driver's door take prece-
dence.
Auto-reverse function
The auto-reverse function can be activated
when a window is closed by automatic op-
eration.
Depending on the environment or driving con-
ditions, the auto-reverse function may be ac-
tivated if an impact or load similar to some-
thing being caught in the window occurs.
WARNING
There are some small distances immedi-
ately before the closed position which can-
not be detected. Make sure that all passen-
gers have their hands, etc., inside the
vehicle before closing the window.
If the vehicle's battery is disconnected, re-
placed, or jump started, the power window
auto-reverse function may not operate prop-
erly. If this occurs, it is recommended you visit
an INFINITI retailer to re-initialize the power
window auto-reverse system.
If the control unit detects something caught
in a window equipped with automatic opera-
tion as it is closing, the window will be imme-
diately lowered.
WINDOWS
2-74Instruments and controls

Driver’s window switch
The power windows operate when the igni-
tion switch is in the ON position.
1. Front left side window
2. Front right side window
3. Rear left side window
4. Rear right side window
The driver’s switch, the main switch, can con-
trol all windows.
•To open manually: press and hold the cor-
responding button.
•To open fully: press the button beyond the
point of resistance to the second detent and
release it. Automatic operation is started.
•To close manually: pull the corresponding
button and hold it.
•To close fully: pull the button beyond the
point of resistance and release it. Auto-
matic operation is started.
•To interrupt automatic operation: press/
pull the corresponding switch again.
NOTE
•If you press/pull the switch beyond the
point of resistance, automatic operation
is started in the corresponding direction.
You can stop automatic operation by
pressing/pulling again.
•You can continue to operate the side win-
dows after switching off the engine or re-
moving the key. This function remains ac-
tive for five minutes or until the driver's or
front-passenger door is opened.
•The side windows cannot be operated
from the rear when the override feature
for the side windows is activated.
NIC2715
Instruments and controls2-75

Locking rear side windows:
To enable/disable the override feature for
the rear side windows, press button
2.If
indicator light
1is lit, operation of the rear
side windows is disabled. Operation is only
possible using the switches in the driver's
door. If indicator light
1is off, operation is
possible using the switches in the rear com-
partment.
Passenger’s window switch
The passenger’s switch can control its corre-
sponding window.
Convenience opening feature
For vehicles with Intelligent Key:you can
ventilate the vehicle before you start driving.
The key can also be used to carry out the
following functions simultaneously:
•Unlock the vehicle
•Open the side windows
NOTE
The convenience opening feature can only be
operated using the key.
The key must be in close proximity to the
vehicle.Press and hold the
button until the side
windows are in the desired position.
To interrupt convenience opening: release
the
button.
Convenience closing feature
WARNING
When the convenience closing feature is
operating, parts of the body could become
trapped in the closing area of the side win-
dow. There is a risk of injury. Observe the
complete closing procedure when the con-
venience closing feature is operating.
When closing make sure that no parts of
the body are in the closing area.
For vehicles with Intelligent Key:The key can
also be used to carry out the following func-
tions simultaneously:
•Lock the vehicle
•Close the side windows
The driver's door and the door at which the
handle is used must both be closed. The key
must be outside the vehicle. The gap between
the key and the corresponding door handle
should not be greater than 1 m.
NIC2716NIC2640
2-76Instruments and controls
