NOTE
The “Windshield demisting” function auto-
matically sets the blower output to the opti-
mum demisting effect. As a result, the air-
flow may increase or decrease automatically
after the
button is pressed
NOTE
You can adjust the blower output manually
while the “Windshield demisting” function is
in operation: by adjusting the airflow control
for the air-conditioning or climate control
system (see "Heater and air conditioner").
To deactivate the de-icer:
•Press thebutton. The indicator light
in thebutton turns off. The previous
settings are reactivated. Air-recirculation
mode remains deactivated.
or
•Automatic climate control: press the
button. The indicator light in the
button turns off. Airflow and air dis-
tribution are set to automatic mode.
or
•Air-conditioning system or automatic cli-
mate control: adjust the temperature con-
trol (see "Heater and air conditioner").
HEADLIGHT SWITCH
1Left-hand parking lights
2Right-hand parking lights
3Side lights and license plate lighting
4Automatic headlight mode,
controlled by the light sensor
5Low beam/high beam headlights
6Rear fog light
7Front fog lights (if equipped)
8Headlight aiming control (halogen head-
lights only)
INFINITI recommends that you consult the
local regulations concerning the use of lights.
If
you hear a warning tone when you leave the
vehicle, the side lights may still be switched on.
Turn the light switch to.
The exterior lighting (except the side lights/
parking lights) switches off automatically if you:
•Remove the key from the ignition switch
(if equipped).
•Open the driver's door with the ignition
switch in the OFF position.
CAUTION
Use the headlights with the engine running
to avoid discharging the vehicle battery.
NIC2619
LED headlights
NIC2697
Halogen headlights
HEADLIGHT AND TURN SIGNAL
SWITCHES
Instruments and controls2-65

Automatic headlight mode
is the preferred light switch setting.
The light setting is automatically selected ac-
cording to the brightness of the ambient light
(exception: poor visibility due to weather con-
ditions such as fog, snow or spray):
•Ignition switch in ACC or ON position: the
side lights are switched on or off auto-
matically depending on the brightness of
the ambient light.
•With the engine running: if you have
switched on the daytime driving lights
function in the vehicle information display,
the side lights and low beam headlights
are switched on or off automatically de-
pending on the brightness of the ambient
light.
To switch on automatic headlight mode:turn
the light switch to.
WARNING
When the light switch is set to , the
low-beam headlights may not be switched
on automatically if there is fog, snow or
other causes of poor visibility due to the
weather conditions such as spray. There is
a risk of an accident
In such situations, turn the light switch to
.The automatic headlight feature is only an
aid. The driver is responsible for the vehicle
lighting at all times.
The daytime driving lights improve the de-
tectability of your vehicle during the day.
WARNING
When the daytime running light system is
active, tail lights on your vehicle are not on.
It is necessary at dusk to turn on your
headlights. Failure to do so could cause an
accident injuring yourself and others.
When the side lights and low-beam head-
lights are switched on, the green
(side
lights) and(low-beam headlights) indi-
cator lights in the combination meter light up.
Low-beam headlights
When the ignition is switched on and the light
switch is in theposition, the side lights
and low-beam headlights are switched on
even if the light sensor does not sense dark
ambient light conditions. This is advanta-
geous when there is fog or rain.
To switch on the low-beam headlights:
•Switch the ignition switch to the ON posi-
tion, or start the engine.
•Turn the light switch to. The greenindicator light in the combination
meter lights up.
Side lights
NOTE
Always park your vehicle safely and suffi-
ciently lit according to legal standards. To
reduce the chance of a discharged vehicle
battery, avoid the continuous use of the
sidelights or parking lights for several
hours.
To switch on:turn the light switch to
.
The greenindicator light in the combi-
nation meter lights up.
Parking lights
Switching on the parking lights ensures that
the corresponding side of the vehicle is illumi-
nated.
To switch on the parking lights:
•The key is not in the ignition switch or the
switch is in the OFF position.
•Turn the light switch to(left-hand
side of the vehicle) or(right-hand
side of the vehicle).
2-66Instruments and controls

Driver’s window switch
The power windows operate when the igni-
tion switch is in the ON position.
1. Front left side window
2. Front right side window
3. Rear left side window
4. Rear right side window
The driver’s switch, the main switch, can con-
trol all windows.
•To open manually: press and hold the cor-
responding button.
•To open fully: press the button beyond the
point of resistance to the second detent and
release it. Automatic operation is started.
•To close manually: pull the corresponding
button and hold it.
•To close fully: pull the button beyond the
point of resistance and release it. Auto-
matic operation is started.
•To interrupt automatic operation: press/
pull the corresponding switch again.
NOTE
•If you press/pull the switch beyond the
point of resistance, automatic operation
is started in the corresponding direction.
You can stop automatic operation by
pressing/pulling again.
•You can continue to operate the side win-
dows after switching off the engine or re-
moving the key. This function remains ac-
tive for five minutes or until the driver's or
front-passenger door is opened.
•The side windows cannot be operated
from the rear when the override feature
for the side windows is activated.
NIC2715
Instruments and controls2-75

Locking rear side windows:
To enable/disable the override feature for
the rear side windows, press button
2.If
indicator light
1is lit, operation of the rear
side windows is disabled. Operation is only
possible using the switches in the driver's
door. If indicator light
1is off, operation is
possible using the switches in the rear com-
partment.
Passenger’s window switch
The passenger’s switch can control its corre-
sponding window.
Convenience opening feature
For vehicles with Intelligent Key:you can
ventilate the vehicle before you start driving.
The key can also be used to carry out the
following functions simultaneously:
•Unlock the vehicle
•Open the side windows
NOTE
The convenience opening feature can only be
operated using the key.
The key must be in close proximity to the
vehicle.Press and hold the
button until the side
windows are in the desired position.
To interrupt convenience opening: release
the
button.
Convenience closing feature
WARNING
When the convenience closing feature is
operating, parts of the body could become
trapped in the closing area of the side win-
dow. There is a risk of injury. Observe the
complete closing procedure when the con-
venience closing feature is operating.
When closing make sure that no parts of
the body are in the closing area.
For vehicles with Intelligent Key:The key can
also be used to carry out the following func-
tions simultaneously:
•Lock the vehicle
•Close the side windows
The driver's door and the door at which the
handle is used must both be closed. The key
must be outside the vehicle. The gap between
the key and the corresponding door handle
should not be greater than 1 m.
NIC2716NIC2640
2-76Instruments and controls

Press and hold thebutton until the side
windows are fully closed.
To interrupt convenience closing: release the
button.
You can also use the keyless locking feature
to activate convenience closing:
Touch recessed sensor surface
1on the
door handle until the side windows are fully
closed.
NOTE
Make sure you only touch recessed sensor
surface
1.
To interrupt convenience opening: release
the recessed sensor surface
1on the door
handle.
Resetting the side windows
If a side window can no longer be closed fully,
you must reset it.
1. Switch the ignition switch to the ON po-
sition.
2. Close the door.3. Pull the corresponding switch on the door
control panel until the side window is
completely closed
4. Hold the switch for an additional second.
If the side window opens again slightly:
1. Immediately pull the corresponding switch
on the door control panel until the side
window is completely closed.
2. Hold the switch for an additional second.
3. If the corresponding side window remains
closed after the button has been released,
the side window has been reset correctly.
If this is not the case, repeat the steps
above again.
If the power window automatic function
does not operate properly after performing
the procedure above, have your vehicle
checked. It is recommended you visit an
INFINITI retailer for this service.
NPA1478
Instruments and controls2-77

•Push the plug in as far as it will go. If
good contact is not made, the plug may
overheat or the internal temperature
fuse may blow.
•Before inserting or disconnecting a plug,
be sure that the electrical accessory be-
ing used is turned OFF.
•When not in use, be sure to close the cap.
Do not allow water to contact the
outlet.
WARNING
Keep the storage lids closed while driving
to help prevent injury in an accident or a
sudden stop.
GLOVE BOX
To open the glove box, pull the handle1.
To close, push the lid
2until the lock latches.
NOTE
To lock/unlock the glove box, use the me-
chanical key. For the mechanical key usage,
see "Mechanical key".
NIC2823
STORAGE
2-80Instruments and controls

FRONT OVERHEAD CONTROL
PANEL
1Switches the left-hand front reading
light on/off
2Switches the front interior lighting on
3Switches the rear interior lighting on/off
4Switches the right-hand front reading
light on/off
5Switches the front interior lighting/
automatic interior lighting control off
6Switches the automatic interior lighting
control on
Automatic interior lighting control
•To switch on: set the switch to center po-
sition
6.
•To switch off: press switch5.
The interior lighting automatically switches
on if you:
•Unlock the vehicle
•Open a door
•Remove the key from the ignition lock.
The interior lighting is activated for a short
time when the key is removed from the igni-
tion lock. You can activate this delayed
switch-off using the vehicle information dis-
play (see "Activating/deactivating the interior
lighting delay" earlier in this section).REAR READING LIGHTS
(IF EQUIPPED)
1Switches the left hand reading light on/
off
2Switches the right hand reading light on/
off
REAR ROOM LIGHT
(IF EQUIPPED)
The rear room light (without switches) can be
switched on and off using the front overhead
control panel.
NIC2630NIC2632
2-88Instruments and controls

WARNING
•Do not use the HomeLink® Universal
Transceiver with any garage door
opener that lacks safety stop and re-
verse features as required by federal
safety standards. (These standards be-
came effective for opener models manu-
factured after April 1, 1982). A garage
door opener which cannot detect an ob-
ject in the path of a closing garage door
and then automatically stop and re-
verse, does not meet current federal
safety standards. Using a garage door
opener without these features increases
the risk of serious injury or death.
•During the programming procedure
your garage door or security gate will
open and close (if the transmitter is
within range). Make sure that people or
objects are clear of the garage door,
gate, etc. that you are programming.
•Your vehicle’s engine should be turned
off while programming the HomeLink®
Universal Transceiver.NOTE
Certain garage door drives are incompatible
with the integrated garage door opener.
If you have difficulty programing the inte-
grated garage door opener, it is recom-
mended you contact your INFINITI retailer.
PROGRAMMING HOMELINK®
If you have any questions or are having diffi-
culty programming your HomeLink® but-
tons, refer to the HomeLink® web site at:
www.homelink.com or call 1-800-355-3515.1. Turn the ignition key to the ON position.
2. Press and hold one of buttons
2to4on
the HomeLink®.
HomeLink® is now in programing mode.
After a short time, indicator light
1lights
up yellow.
Indicator light
1lights up yellow as soon
as button
2,3or4is programed for
the first time. If the selected button has
already been programed, indicator light
1will only light up yellow after ten sec-
onds have elapsed.
3. Release button
2,3or4. Indicator
light
1flashes yellow.
4. Position the end of your hand-held trans-
mitter
52–8 inches (5–20 cm) away
from the HomeLink® surface, keeping the
HomeLink® indicator light
1in view.
NDI1631
2-90Instruments and controls

5. Press and hold button6on the hand held
transmitter until indicator light
1lights
up green. When indicator light
1: lights
up green: programing is finished.
When indicator light
1flashes green:
programing was successful. The next step
is to synchronize the rolling code.
6. Release button
6on the hand held trans-
mitter
5for the garage door drive sys-
tem.
If indicator light
1lights up red: repeat
the programing procedure for the corre-
sponding button on the rear-view mirror.
When doing so, vary the distance be-
tween the hand held transmitter
5and
the rear-view mirror.
The required distance between the hand
held transmitter
5and the integrated ga-
rage door opener depends on the garage
door drive system. Several attempts might
be necessary. You should test every posi-
tion for at least 25 seconds before trying
another position.
Synchronizing the rolling code
If the garage door system uses a rolling code,
you will also have to synchronize the garage
door system with the integrated garage door
opener in the rear-view mirror. To do this you
will need to use the programing button on thedoor drive control panel. The programing
button may be positioned at different loca-
tions depending on the manufacturer. It is
usually located on the door drive unit on the
garage ceiling.
Familiarize yourself with the garage door
drive operating instructions before carrying
out the following steps.
Your vehicle must be within reach of the ga-
rage door or gate opener drive. Make sure
that neither your vehicle nor any persons/
objects are present within the sweep of the
door or gate.
1. Turn the ignition key to the ON position.
2. Get out of the vehicle.
3. Press the programing button on the door
drive unit.
Usually, you now have 30 seconds to ini-
tiate the next step.
4. Get into the vehicle.
5. Press previously programed button
2,3or4on the HomeLink® until the door
closes.
The rolling code synchronization is then
complete.
If you live in Canada
Canadian radio frequency laws require a
"break" (or interruption) of the transmission
signals after broadcasting for a few seconds.
Therefore, these signals may not last long
enough for the integrated garage door
opener. The signal is not recognized during
programing. Comparable with Canadian law,
some U.S. garage door openers also feature a
"break".
Proceed as follows:
•If you live in Canada
•If you have difficulties programing the ga-
rage door opener (regardless of where you
live) when using the programing steps.
1. Press and hold one of buttons
2to4on
the HomeLink®. After a short time, indi-
cator light
1lights up yellow.
2. Release the button.
Indicator light
1flashes yellow.
3. Press button
6of the hand held trans-
mitter
5for two seconds, then release it
for two seconds.
4. Press button
6again for two seconds.
5. Repeat this sequence on button
6of the
hand held transmitter
5until indicator
light
1lights up green.
Instruments and controls2-91

When indicator light1lights up green:
programing is finished.
When indicator light
1flashes green:
programing was successful. The next step
is to synchronize the rolling code.
6. Release button
6of the hand held trans-
mitter
5for the garage door drive.
If indicator light
1lights up red: repeat
the programing process for the corre-
sponding button on the rear-view mirror.
When doing so, vary the distance be-
tween the hand held transmitter
5and
the rear-view mirror.
The required distance between the hand
held transmitter
5and the HomeLink®
depends on the garage door drive system.
Several attempts might be necessary. You
should test every position for at least
25 seconds before trying another posi-
tion.
PROGRAMMING TROUBLE
DIAGNOSIS
If the HomeLink® does not quickly learn the
hand-held transmitter information:
•Check the transmitter frequency used by
garage door drive hand-held transmitter
5and whether it is supported. The trans-
mitter frequency can usually be found onthe back of the garage door drive hand-
held transmitter. HomeLink® is compat-
ible with devices that have units which
operate in the frequency range of 280 to
433 MHz.
•Replace the hand-held transmitter5bat-
teries with new batteries.
This increases the likelihood that the hand-
held transmitter
5will transmit a strong
and precise signal to the HomeLink®.
•When programing, hold the hand-held
transmitter
5at varying distances and
angles from the button which you are pro-
graming. Try various angles at a distance
between 2 and 12 inches (5 to 30 cm) or at
the same angle but at varying distances.
•If another hand-held transmitter is avail-
able for the same garage door drive, re-
peat the same programing steps with this
hand-held transmitter
5. Before per-
forming these steps, make sure that new
batteries have been installed in the hand-
held transmitter
5.
•Note that some hand-held transmitters
only transmit for a limited amount of time
(the indicator light on the hand-held trans-
mitter goes out). Press button
6on re-
mote hand-held transmitter
5again be-
fore transmission ends.
•Align the antenna cable of the garage door
opener unit. This can improve signal
reception/ transmission.
If you have any questions or are having diffi-
culty programming your HomeLink® but-
tons, refer to the HomeLink® web site at:
www.homelink.com or 1-800-355-3515.
OPERATING THE HOMELINK®
UNIVERSAL TRANSCEIVER
The HomeLink® Universal Transceiver, after
it is programmed, can be used to activate the
programmed device.
1. Turn the ignition key to the ON position.
2. Press button
2,3or4which you have
programed to operate the garage door.
Garage door system with a fixed code:
indicator light
1lights up green
Garage door system with a rolling code:
indicator light
1flashes green.
The transmitter will transmit a signal as long
as the button is pressed. The transmission is
halted after a maximum of ten seconds and
indicator light
1lights up yellow. Press but-
ton
2,3or4again if necessary.
For convenience, the hand-held transmitter
of the device may also be used at any time.
2-92Instruments and controls
