fuse box INFINITI QX30 2019 Owner's Manual

2.0L GASOLINE ENGINE
1. Engine coolant reservoir (P. 8-3)
2. Engine oil dipstick (P. 8-5)
3. Engine oil filler cap (P. 8-5)
4. Brake fluid reservoir (P. 8-7)5. Engine air cleaner filter (P. 8-13)
6. Battery (P. 8-9)
7. Fuse box (P. 8-17)
8. Window washer fluid reservoir (P. 8-8)
NIC2833
ENGINE COMPARTMENT
Illustrated table of contents0-9

•Push the plug in as far as it will go. If
good contact is not made, the plug may
overheat or the internal temperature
fuse may blow.
•Before inserting or disconnecting a plug,
be sure that the electrical accessory be-
ing used is turned OFF.
•When not in use, be sure to close the cap.
Do not allow water to contact the
outlet.
WARNING
Keep the storage lids closed while driving
to help prevent injury in an accident or a
sudden stop.
GLOVE BOX
To open the glove box, pull the handle1.
To close, push the lid
2until the lock latches.
NOTE
To lock/unlock the glove box, use the me-
chanical key. For the mechanical key usage,
see "Mechanical key".
NIC2823
STORAGE
2-80Instruments and controls

2.0L GASOLINE ENGINE
1. Engine coolant reservoir (P. 8-3)
2. Engine oil dipstick (P. 8-5)
3. Engine oil filler cap (P. 8-5)
4. Brake fluid reservoir (P. 8-7)5. Engine air cleaner filter (P. 8-13)
6. Battery (P. 8-9)
7. Fuse box (P. 8-17)
8. Window washer fluid reservoir (P. 8-8)
WARNING
The engine cooling system is filled at the
factory with a high-quality, year-round,
antifreeze coolant solution. The antifreeze
solution contains rust and corrosion inhibi-
tors, therefore additional cooling system
additives are not necessary.
•Never remove the radiator or coolant
reservoir cap when the engine is hot.
Wait until the engine and radiator cool
down. Serious burns could be caused by
high-pressure fluid escaping from the
radiator. For additional information on
precautions, refer to "If your vehicle
overheats"
•The engine coolant reservoir tank is
equipped with a pressure type cap. To
prevent engine damage, use only a
genuine INFINITI pressure cap.
CAUTION
•Never use any cooling system additives
such as radiator sealer. Additives may
clog the cooling system and cause dam-
age to the engine, transmission and/or
cooling system.NIC2833
ENGINE COMPARTMENT CHECK
LOCATIONSENGINE COOLING SYSTEM
Do-it-yourself8-3

7. Make sure that wiper blade1is seated
correctly.
8. Move the wiper arm back onto the rear
window.If the brakes do not operate properly, it is
recommended that you have the brakes
checked. It is recommended that you visit an
INFINITI retailer for this service.
SELF-ADJUSTING BRAKES
Your vehicle is equipped with self-adjusting
brakes. The disc-type brakes self-adjust ev-
ery time the brake pedal is applied.Blown fuses must be replaced with fuses of
the same rating, which you can recognize by
the color and fuse rating. The fuse ratings are
listed in the fuse allocation chart.
If the newly inserted fuse also blows, have
the cause traced and rectified. It is recom-
mended you visit an INFINITI retailer for this
service.
The fuses in your vehicle disconnect faulty
circuits. if a fuse blows, all the components on
the circuit and their functions will fail.
BEFORE REPLACING A FUSE
•Secure the vehicle against rolling away.
•Switch off all electrical consumers.
•Remove the key from the ignition lock.
The fuses are located in various fuse boxes:
•Fuse box in the engine compartment on
the left-hand side of the vehicle, when
viewed in the direction of travel.
•Fuse box in the front-passenger footwell.
The fuse allocation chart is on the fuse box in
the front-passenger footwell.
BRAKES FUSES
Do-it-yourself8-17

ENGINE COMPARTMENT
WARNING
Never use a fuse of higher or lower amper-
age rating than that specified on the fuse
box cover. This could damage the electrical
system or electronic control units or cause
a fire.
1. Open the hood
2. Remove any existing moisture from the
fuse box using a dry cloth
3. To open: open clamps
2.
4. Fold cover
1up in the direction of the
arrow and remove it.To close:
1. Check whether the seal is lying correctly in
cover
1.
2. Insert cover
1at the back into openings
3on the fuse box.
NDI1591NDI1592
8-18Do-it-yourself

3. Fold down cover1.
4. Hook clamps into the fuse box and close
5. Close the hood.
PASSENGER COMPARTMENT
WARNING
Never use a fuse of higher or lower amper-
age rating than that specified on the fuse
box cover. This could damage the electrical
system or electronic control units or cause
a fire.To open:
1. Open the front-passenger door.
2. Remove the floor mats.
3. Fold out perforated floor covering
1in
the direction of the arrow.
NDI1593
Do-it-yourself8-19

4. To release cover3press retaining clamp
2.
5. Fold out cover
3in the direction of the
arrow to the catch.
6. Remove cover
3forwards.
NOTE
Fuse allocation chart
4is located on the
lower right-hand side of cover
3.To close:
1. Insert cover
3on the left-hand side of
the fuse box into the retainer. Cover
3engages in the retainers.
2. Fold down cover
3until clamps2lock
audibly.
3. Fold back perforated floor covering
1.
4. Fit the floor mats.
CAUTION
Be careful not to allow children to swallow
the battery or removed parts.
NDI1594
INTELLIGENT KEY BATTERY
REPLACEMENT
8-20Do-it-yourself

F
Filter.......................8-13
Air cleaner..................8-13
Engine Oil...................8-6
Flat tire......................6-2
Floormats....................7-5
Fluids ......................10-2
Air conditioner...............10-2
Automatic transmission fluid (ATF)....8-7
Brake......................8-7
Coolant....................8-3
Engine Oil...................8-5
Recommendations and capacities....10-2
Window washer...............8-8
Foglights....................2-71
Bulbinformation..............8-23
Location...................2-71
Forward emergency braking system....5-62
Limitations..................5-67
Four-wheel drive...............5-86
Freeing trapped vehicle............6-15
Fuel .......................10-2
Capacities..................10-2
Filler cap...................3-16
Filler lid....................3-16
Gauge.....................2-7
Fuel economy.................5-86
Fuel efficient driving tips...........5-85Fuses ......................8-17
Engine compartment...........8-18
Passenger compartment.........8-19
G
Gasoline......................2-7
Gauge.....................2-7
Gauges......................2-6
Engine coolant temperature........2-6
Fuel.......................2-7
Meters and gauges.............2-4
Speedometer.................2-5
Tachometer..................2-6
Glass........................7-3
Cleaning....................7-3
Glassroof....................2-78
Sunshade operation............2-78
Glovebox....................2-80
H
Hazard ......................6-2
Warningflasherswitch...........6-2
Headlights...................8-25
Bulb replacement..............8-25
Replacement (bulb).............8-25
Switch....................2-65Head restraints/Headrests..........1-7
Adjustment..................1-8
Installation..................1-9
Removal....................1-8
Heatedseats..................2-73
Operation..................2-73
Precautions.................2-73
Heater and air conditioner..........4-29
Hill Start Assist (HSA).............5-95
HomeLink® Universal Transceiver.....2-89
Ifyourvehicleisstolen ..........2-93
Operating..................2-92
Programming................2-90
Troubleshooting..............2-92
Hood.......................3-15
Closing....................3-15
Engine compartment.........0-9,8-3
Opening...................3-15
Hooks......................2-83
Horn.......................2-72
I
Idle Stop/Start System............5-29
Ignition.....................5-13
Switch................5-13,5-14
Switch positions..............5-13
Indicatorlights.................0-10
Overview...............0-10,2-8
Index11-3
